qpax 0.0.10

Differentiable QP solver in JAX.

qpax

Differentiable QP solver in JAX.

This package can be used for solving convex quadratic programs of the following form:

$$ \begin{align*} \underset{x}{\text{minimize}} & \quad \frac{1}{2}x^TQx + q^Tx \ \text{subject to} & \quad Ax = b, \ & \quad Gx \leq h \end{align*} $$

where $Q \succeq 0$. This solver can be combined with JAX's jit and vmap functionality, as well as differentiated with reverse-mode grad.

The QP is solved with a primal-dual interior point algorithm detailed in cvxgen, with the solution to the linear systems computed with reduction techniques from cvxopt. At an approximate primal-dual solution, the the primal variable $x$ is differentiated with respect to the problem parameters using the implicit function theorem as shown in optnet, and their pytorch-based qp solver qpth.

Installation

To install directly from github using pip:

$ pip install qpax

Alternatively, to install from source in editable mode:

$ pip install -e .

Usage

🚨 Float32 Warning 🚨

The solver tolerance (solver_tol) should be something reasonable given the available precision. With 32bit precision (the default in JAX), solver_tol should be greater than 1e-5.

Precision	Tolerance
jnp.float32	solver_tol$\in$ [1e-5, 1e-2]
jnp.float64	solver_tol$\in$ [1e-12, 1e-2]

In order to enable 64bit precision, you can do the following at startup:

# again, this only works on startup!
import jax
jax.config.update("jax_enable_x64", True)

This is taken from the JAX - The Sharp Bits.

Solving a QP

We can solve QPs with qpax in a way that plays nice with JAX's jit and vmap:

import qpax

# solve QP (this can be combined with jit or vmap)
x, s, z, y, converged, iters = qpax.solve_qp(Q, q, A, b, G, h, solver_tol=1e-6)

Solving a batch of QP's

Here let's solve a batch of nonnegative least squares problems as QPs. This outlines two bits of functionality from qpax, first is the ability to solve QPs without any equality constraints, and second is the ability to vmap over a batch of QPs.

import numpy as np
import jax
import jax.numpy as jnp
from jax import jit, grad, vmap
import qpax
import timeit

"""
solve batched non-negative least squares (nnls) problems

min_x    |Fx - g|^2
st        x >= 0
"""

n = 5   # size of x
m = 10  # rows in F

# create data for N_qps random nnls problems
N_qps = 10000
Fs = jnp.array(np.random.randn(N_qps, m, n))
gs = jnp.array(np.random.randn(N_qps, m))

@jit
def form_qp(F, g):
  # convert the least squares to qp form
  n = F.shape[1]
  Q = F.T @ F
  q = -F.T @ g
  G = -jnp.eye(n)
  h = jnp.zeros(n)
  A = jnp.zeros((0, n))
  b = jnp.zeros(0)
  return Q, q, A, b, G, h

# create the QPs in a batched fashion
Qs, qs, As, bs, Gs, hs = vmap(form_qp, in_axes = (0, 0))(Fs, gs)

# create function for solving a batch of QPs
batch_qp = jit(vmap(qpax.solve_qp_primal, in_axes = (0, 0, 0, 0, 0, 0)))

xs = batch_qp(Qs, qs, As, bs, Gs, hs)

Differentiating a QP

Alternatively, if we are only looking to use the primal variable x, we can use solve_qp_primal which enables automatic differentiation:

import jax
import jax.numpy as jnp
import qpax

def loss(Q, q, A, b, G, h):
    x = qpax.solve_qp_primal(Q, q, A, b, G, h, solver_tol=1e-4, target_kappa=1e-3)
    x_bar = jnp.ones(len(q))
    return jnp.dot(x - x_bar, x - x_bar)

# gradient of loss function
loss_grad = jax.grad(loss, argnums = (0, 1, 2, 3, 4, 5))

# compatible with jit
loss_grad_jit = jax.jit(loss_grad)

# calculate derivatives
derivs = loss_grad_jit(Q, q, A, b, G, h)
dl_dQ, dl_dq, dl_dA, dl_db, dl_dG, dl_dh = derivs

where target_kappa is used to determine how much smoothing should be applied to the gradients through solve_qp_primal. For more detail on target_kappa, please refer to the paper.

Citation

@misc{tracy2024differentiability,
    title={On the Differentiability of the Primal-Dual Interior-Point Method},
    author={Kevin Tracy and Zachary Manchester},
    year={2024},
    eprint={2406.11749},
    archivePrefix={arXiv},
    primaryClass={math.OC}
}
