qrcodefyi 0.1.1

QR code encyclopedia API client — look up QR types, versions 1-40, encoding modes, error correction levels, standards, and specifications from QRCodeFYI.

qrcodefyi

QR code encyclopedia API client for Python. Look up QR code types including Model 1, Model 2, Micro QR, rMQR, iQR, SQRC, and Frame QR, all 40 versions with module grids from 21x21 to 177x177, 4 encoding modes, 4 Reed-Solomon error correction levels, structural components, and governing standards from QRCodeFYI -- the comprehensive QR code reference with 425 records covering every major QR variant in use today.

Extracted from QRCodeFYI, a QR code knowledge platform with 425 records spanning 7 QR types, 40 versions, encoding modes, error correction mathematics, scan scenarios, and use cases used by mobile developers, payment system architects, and marketing technologists worldwide.

Explore QR codes at qrcodefyi.com -- Type Explorer | Version Reference | Standards | Encoding Modes

Table of Contents

• Install
• Quick Start
• What You'll Find on QRCodeFYI
  • QR Code Types
  • QR Code Versions (1-40)
  • Error Correction Levels
  • Encoding Modes
  • QR Code Structure
  • Mask Patterns
  • Key QR Code Standards
• API Endpoints
• Command-Line Interface
• MCP Server (Claude, Cursor, Windsurf)
• REST API Client
• Learn More About QR Codes
• Also Available
• Tag FYI Family
• FYIPedia Developer Tools
• License

Install

pip install qrcodefyi[api]     # API client (httpx)
pip install qrcodefyi[cli]     # + CLI (typer, rich)
pip install qrcodefyi[mcp]     # + MCP server
pip install qrcodefyi[all]     # Everything

Quick Start

from qrcodefyi.api import QRCodeFYI

with QRCodeFYI() as api:
    # Search types, standards, components, glossary
    results = api.search("micro qr")
    print(results)

    # Look up a specific QR type
    model2 = api.qr_type("model-2")
    print(model2["name"], model2["year_introduced"])  # QR Code Model 2 1997

    # Get version details (1-40) with data capacities
    v10 = api.version(10)
    print(v10["modules"], v10["data_capacity"])  # 57x57 modules

    # Compare two QR types side-by-side
    diff = api.compare("model-1", "model-2")
    print(diff)

What You'll Find on QRCodeFYI

QRCodeFYI is a comprehensive QR code encyclopedia covering every QR variant, all 40 versions, 4 encoding modes, 4 error correction levels, structural components, and governing standards. QR codes (Quick Response codes) are two-dimensional matrix barcodes invented by Denso Wave in 1994 for Toyota's automotive parts tracking. Now the most widely deployed 2D symbology in the world, QR codes power mobile payments, product authentication, WiFi sharing, digital menus, vaccine certificates, and billions of consumer interactions daily.

QR Code Types

The QR code family includes several distinct variants, each designed for specific size, capacity, and application constraints:

Type	Year	Versions	Max Capacity	Key Feature
QR Code Model 1	1992	1-14	1,167 numerics	Original version, no alignment patterns
QR Code Model 2	1997	1-40	7,089 numerics	Current standard, alignment patterns, ISO 18004
Micro QR Code	2004	M1-M4	35 numerics	Single finder pattern, 11x11 to 17x17 modules
rMQR (Rectangular Micro QR)	2022	R7x43-R17x139	361 numerics	Rectangular form factor for narrow spaces
iQR Code	2008	1-61	40,637 numerics	Square or rectangular, direct part marking
SQRC	2007	--	Encrypted data	Public and private data layers
Frame QR	2014	--	Canvas area	Embeddable graphics in center canvas

Model 2 dominance: Over 99% of QR codes in production use Model 2. It introduced alignment patterns (absent in Model 1) that enable reliable reading of larger symbols printed on curved surfaces. The ISO 18004:2024 standard defines Model 2 exclusively.

Micro QR for constrained spaces: Micro QR uses only one finder pattern (versus three in standard QR), reducing the minimum symbol size to 11x11 modules. The trade-off is lower data capacity (35 numeric characters maximum at M4) and only three error correction levels (L, M, Q -- no H).

Learn more: Type Explorer | Glossary

QR Code Versions (1-40)

Every QR Code Model 2 has a version number from 1 to 40 that determines its physical size and data capacity. Version 1 is a 21x21 module grid; each subsequent version adds 4 modules per side, so Version 40 is a 177x177 module grid with 31,329 total modules.

Version	Modules	Numeric (L)	Alphanumeric (L)	Byte (L)	Alignment Patterns
1	21x21	41	25	17	0
5	37x37	154	93	64	1
10	57x57	652	395	271	6
20	97x97	2,061	1,249	858	21
30	137x137	4,158	2,520	1,732	45
40	177x177	7,089	4,296	2,953	81

Version selection: Choose the smallest version that fits your data at the desired error correction level. Over-sizing wastes print area and increases scanning time. Under-sizing forces higher-density encoding that requires higher print resolution. Most applications use versions 1-10.

Learn more: Version Explorer | Encoding Modes

Error Correction Levels

QR codes use Reed-Solomon error correction, dividing the data area into blocks and appending error correction codewords. Higher correction levels allow recovery from more damage but reduce usable data capacity.

Level	Recovery	Overhead	Best For
L (Low)	~7%	Minimal	Clean environments, maximum data capacity
M (Medium)	~15%	Moderate	General purpose, default for most applications
Q (Quartile)	~25%	Significant	Industrial environments, moderate damage expected
H (High)	~30%	Maximum	Harsh conditions, logo embedding in QR center

Logo embedding: Level H is specifically designed for QR codes with embedded logos or graphics. The 30% error recovery allows the finder and timing patterns to reconstruct data even when the center modules are obscured by a brand logo. The logo should not exceed 20-25% of the total QR area for reliable scanning.

Encoding Modes

QR codes support four data encoding modes, each optimized for different character sets. A single QR code can switch between modes within the data stream using mode indicators, optimizing overall capacity.

Mode	Character Set	Bits/Char	Mode Indicator	Example Use
Numeric	0-9	3.33	0001	Phone numbers, product IDs, postal codes
Alphanumeric	0-9, A-Z, space, $%*+-./:	5.5	0010	URLs (uppercase), serial numbers
Byte (ISO 8859-1)	Full 8-bit	8	0100	UTF-8 text, binary data, vCards
Kanji (Shift JIS)	JIS X 0208	13	1000	Japanese text (double-byte Kanji)

Mixed-mode optimization: A URL like HTTPS://EXAMPLE.COM/path123 can be encoded as Alphanumeric for the uppercase portion and Byte mode for lowercase characters. Smart encoders automatically segment the data stream to minimize total bit count, reducing the required QR version by 1-3 levels in many real-world payloads.

ECI (Extended Channel Interpretation): For character sets beyond ISO 8859-1, QR codes support ECI mode indicators that declare the encoding (e.g., ECI 000026 for UTF-8). This enables reliable encoding of Chinese, Arabic, Korean, and other scripts without the Kanji mode's Shift JIS limitation.

Learn more: Encoding Modes | Standards

QR Code Structure

Every QR code contains mandatory structural components that enable reliable machine reading:

Component	Function	Present In
Finder Patterns	Three large squares at corners for orientation detection	All QR types
Timing Patterns	Alternating black/white modules for coordinate mapping	All QR types
Alignment Patterns	Smaller squares for distortion correction	Version 2+ (Model 2)
Format Information	Error correction level + mask pattern (15 bits, BCH coded)	All QR types
Version Information	Version number (18 bits, Golay coded)	Version 7+
Data + EC Codewords	Interleaved data and error correction modules	All QR types
Quiet Zone	4-module white border	All QR types

Mask Patterns

QR codes apply one of 8 mask patterns (numbered 0-7) to the data area to optimize readability. The encoder evaluates all 8 masks against four penalty rules -- large same-color regions, 1:1:3:1:1 finder-like patterns, row/column uniformity, and proportion of dark modules -- and selects the mask with the lowest total penalty score.

Key QR Code Standards

Standard	Organization	Scope
ISO/IEC 18004:2024	ISO	QR Code Model 2 (current edition)
ISO/IEC 23941:2022	ISO	Rectangular Micro QR (rMQR)
JIS X 0510	JISC	Original Japanese QR standard
AIM ITS/04-001	AIM	International symbology specification

Learn more: Standards Reference | Type Explorer

API Endpoints

Free, no authentication required. JSON responses with CORS enabled.

Method	Endpoint	Description
GET	/api/type/{slug}/	QR code type detail with specs
GET	/api/version/{version}/	QR version detail (1-40)
GET	/api/component/{slug}/	Structural component detail
GET	/api/encoding/{slug}/	Encoding mode detail
GET	/api/standard/{slug}/	Standard detail with linked types
GET	/api/use-case/{slug}/	Use case detail with examples
GET	/api/term/{slug}/	Glossary term definition
GET	/api/search/?q={query}	Search across all content types
GET	/api/compare/?a={slug}&b={slug}	Compare two QR types
GET	/api/random/	Random QR type discovery
GET	/api/openapi.json	OpenAPI 3.1.0 specification

Example

# Search for Micro QR formats
curl -s "https://qrcodefyi.com/api/search/?q=micro+qr" | python -m json.tool

Full API documentation at qrcodefyi.com/api/. OpenAPI 3.1.0 spec: qrcodefyi.com/api/openapi.json.

Command-Line Interface

qrcodefyi search "micro qr"          # Search all content
qrcodefyi qr-type model-2            # QR type detail
qrcodefyi compare model-1 model-2    # Side-by-side comparison
qrcodefyi random                     # Discover a random QR type

MCP Server (Claude, Cursor, Windsurf)

{
    "mcpServers": {
        "qrcodefyi": {
            "command": "uvx",
            "args": ["--from", "qrcodefyi[mcp]", "python", "-m", "qrcodefyi.mcp_server"]
        }
    }
}

Tools: qrcode_search, qrcode_lookup, qrcode_compare

REST API Client

from qrcodefyi.api import QRCodeFYI

with QRCodeFYI() as api:
    api.search("micro qr")                # Full-text search
    api.qr_type("model-2")                # QR type detail
    api.version(10)                        # Version detail (1-40)
    api.component("finder-pattern")        # Structural component
    api.encoding("numeric")                # Encoding mode
    api.standard("iso-iec-18004")          # Standard detail
    api.use_case("mobile-payment")         # Use case
    api.glossary_term("error-correction")  # Glossary term
    api.compare("model-1", "model-2")      # Compare two types
    api.random()                           # Random discovery
    api.openapi()                          # OpenAPI 3.1.0 spec

Learn More About QR Codes

• Browse: Type Explorer · Version Reference · Encoding Modes
• Reference: Standards · Use Cases · Glossary
• API: REST API Docs · OpenAPI Spec

Also Available

Platform	Install	Link
npm	npm install qrcodefyi	npm
Go	go get github.com/fyipedia/qrcodefyi-go	pkg.go.dev
Rust	cargo add qrcodefyi	crates.io
Ruby	gem install qrcodefyi	rubygems.org
MCP	uvx --from "qrcodefyi[mcp]" python -m qrcodefyi.mcp_server	Config
