rag-agent-mcp 0.1.5

RAG Agent - MCP Server for LightRAG

RAG Agent

RAG Agent is a CLI-enabled MCP server for integrating LightRAG Dataset functionality with AI tools. Provides a unified interface for managing datasets, querying data, and accessing knowledge graphs through the MCP protocol. Can be run directly via uvx rag-agent.

Description

RAG Agent is a specialized bridge between LightRAG's Dataset API and MCP-compatible clients. It enables dataset-isolated RAG operations, allowing you to create, manage, and query multiple independent datasets with their own knowledge graphs and document collections.

Key Features

• Health Check: Verify LightRAG API server status and configuration before operations
• Guided Workflow: Built-in prompt to guide users through RAG operations step-by-step
• Dataset Management: Create, update, delete, and list datasets with full configuration control
• Dataset Queries: Execute queries on single or multiple datasets with cross-dataset reranking
• Document Management: Upload, list, and delete documents within specific datasets
• Knowledge Graph Access: Retrieve graph data and labels for dataset-specific knowledge graphs
• Dataset Isolation: Each dataset maintains its own PostgreSQL schema for complete data separation

Installation

Quick Start with uvx (Recommended)

# Run directly without installation
uvx rag-agent --host localhost --port 9621

Development Installation

# Create a virtual environment
uv venv --python 3.11

# Install the package in development mode
uv pip install -e .

Requirements

• Python 3.11+
• Running LightRAG API server

Usage

Important: RAG Agent should be run as an MCP server through an MCP client configuration file (mcp-config.json), or directly via uvx rag-agent.

Command Line Options

The following arguments are available when configuring the server in mcp-config.json:

• --host: Supabase URL or LightRAG API host (default: localhost). Supports full URLs like https://xxx.supabase.co
• --port: API port (default: 9621). Ignored for standard ports (80/443) when using full URLs
• --api-key: Supabase anon key or LightRAG API key (required for authentication)
• --user: Authentication user (email for Supabase Auth, username for Kong Basic Auth)
• --user-password: User password for authentication

Authentication Modes

RAG Agent supports three authentication modes, automatically determined by the --user parameter format:

Mode	Trigger Condition	Description
API Key	Only --api-key provided	Legacy mode, uses API key header
Kong Basic Auth	--user is NOT an email	HTTP Basic Authentication for Kong gateway
Supabase Auth	--user IS an email (contains @)	JWT token authentication with auto-refresh

Integration with LightRAG API

The MCP server requires a running LightRAG API server. Start it as follows:

# Create virtual environment
uv venv --python 3.11

# Install dependencies
uv pip install -r LightRAG/lightrag/api/requirements.txt

# Start LightRAG API
uv run LightRAG/lightrag/api/lightrag_server.py --host localhost --port 9621 --working-dir ./rag_storage --input-dir ./input --llm-binding openai --embedding-binding openai --log-level DEBUG

Setting up as MCP server

To set up RAG Agent as an MCP server, add the following configuration to your MCP client configuration file (e.g., mcp-config.json):

Using uvx (Recommended):

API Key Mode (Legacy):

{
  "mcpServers": {
    "rag-agent": {
      "command": "uvx",
      "args": [
        "rag-agent",
        "--host", "localhost",
        "--port", "9621",
        "--api-key", "your_api_key"
      ]
    }
  }
}

Supabase Auth Mode (JWT):

{
  "mcpServers": {
    "rag-agent": {
      "command": "uvx",
      "args": [
        "rag-agent",
        "--host", "https://your-project.supabase.co",
        "--api-key", "your_supabase_anon_key",
        "--user", "[e-mail]",
        "--user-password", "your_password"
      ]
    }
  }
}

Kong Basic Auth Mode:

{
  "mcpServers": {
    "rag-agent": {
      "command": "uvx",
      "args": [
        "rag-agent",
        "--host", "https://api-gateway.example.com",
        "--api-key", "your_api_key",
        "--user", "service_account",
        "--user-password", "your_password"
      ]
    }
  }
}

Development

{
  "mcpServers": {
    "rag-agent": {
      "command": "uv",
      "args": [
        "--directory", "/path/to/rag-agent",
        "run", "src/rag_agent/main.py",
        "--host", "localhost",
        "--port", "9621",
        "--api-key", "your_api_key",
        "--user", "[e-mail]",
        "--user-password", "your_password"
      ]
    }
  }
}

Replace /path/to/rag-agent with the actual path to your rag-agent directory.

Container Image (LightRAG API + RAG Agent)

Build a single image that starts LightRAG API and RAG Agent together.

Build

Option A — clone LightRAG during build:

docker build \
  --build-arg LIGHTRAG_REPO_URL="<git url to LightRAG repo>" \
  --build-arg LIGHTRAG_REF=main \
  -t rag-agent:local .

Option B — mount LightRAG at runtime: build without args, and mount the repo to /opt/LightRAG when running.

Run (local test)

docker run --rm -it \
  -e LLM_BINDING=openai \
  -e EMBEDDING_BINDING=openai \
  -e OPENAI_API_KEY=sk-... \
  -p 9621:9621 \
  -v "$(pwd)/data:/data" \
  rag-agent:local bash

Inside the container the entrypoint starts LightRAG API (0.0.0.0:9621) and then execs RAG Agent when invoked with mcp (see below for MCP client integration). Logs are written to stderr to avoid interfering with MCP stdio.

Use with MCP client (docker-run)

Most MCP clients spawn servers via stdio. Configure your MCP client to run this container with -i (interactive, no TTY) so stdio is attached to the MCP server process:

{
  "mcpServers": {
    "rag-agent": {
      "command": "docker",
      "args": [
        "run", "--rm", "-i",
        "-e", "LLM_BINDING=openai",
        "-e", "EMBEDDING_BINDING=openai",
        "-e", "OPENAI_API_KEY=sk-...",
        "-e", "MCP_API_KEY=", // optional, only if LightRAG API requires it
        "-v", "/absolute/path/to/data:/data",
        "rag-agent:local",
        "mcp"
      ],
      "alwaysAllow": [
        "create_dataset", "get_dataset", "list_datasets", "update_dataset", "delete_dataset",
        "get_dataset_statistics", "query_dataset", "query_multiple_datasets",
        "upload_document_to_dataset", "get_dataset_documents", "delete_dataset_document",
        "scan_dataset_documents", "get_dataset_graph", "get_dataset_graph_labels"
      ]
    }
  }
}

Notes:

• The container runs LightRAG API inside and binds it to localhost:9621 for the MCP server; you do not need to expose it unless you want external access.
• If your LightRAG build needs different bindings, set LLM_BINDING, EMBEDDING_BINDING and their provider keys (e.g., OPENAI_API_KEY).
• To customize LightRAG paths, use LIGHTRAG_WORKDIR, LIGHTRAG_INPUTDIR, and LIGHTRAG_EXTRA_ARGS.

Available MCP Tools

Health Check

• check_health: Check LightRAG API server health status, configuration, and version information

Prompts

• start_rag_workflow: Initial workflow prompt that guides users through the recommended steps:
  1. Check API server health
  2. List available datasets
  3. Choose appropriate operations based on available datasets

Dataset Management

• create_dataset: Create a new dataset with full configuration (name, description, RAG type, storage type, etc.)
• get_dataset: Get detailed information about a specific dataset by ID
• list_datasets: List all datasets with pagination and filtering by status/visibility
• update_dataset: Update dataset configuration and metadata
• delete_dataset: Delete a dataset and all its associated data
• get_dataset_statistics: Get comprehensive statistics for a dataset (document count, graph metrics, etc.)

Dataset Queries

• query_dataset: Execute a query on a specific dataset with full RAG capabilities
  • Supports multiple search modes (global, hybrid, local, mix, naive)
  • Configurable token limits and response types
  • High-level and low-level keyword prioritization
• query_multiple_datasets: Execute cross-dataset queries with automatic result merging
  • Query multiple datasets simultaneously
  • Optional cross-dataset reranking
  • Per-dataset document filtering

Dataset Document Management

• upload_document_to_dataset: Upload a document file to a specific dataset
• get_dataset_documents: List documents in a dataset with pagination and status filtering
• delete_dataset_document: Delete a specific document from a dataset
• scan_dataset_documents: Scan dataset's input directory for new documents

Dataset Knowledge Graph

• get_dataset_graph: Retrieve knowledge graph data for a dataset
  • Optional node label filtering
  • Configurable depth and node limits
• get_dataset_graph_labels: Get all graph labels (node and relationship types) for a dataset

Usage Examples

Recommended Workflow

# Step 1: Check API server health
check_health()
# Returns: Server status, configuration, version info

# Step 2: List available datasets
list_datasets()
# Returns: All datasets with pagination

# Step 3: Choose your operation based on available datasets

Creating and Querying a Dataset

# Create a new dataset
create_dataset(
    name="research_papers",
    description="Academic research papers collection",
    rag_type="rag",
    visibility="private"
)

# Upload documents to the dataset
upload_document_to_dataset(
    dataset_id="<dataset-uuid>",
    file_path="/path/to/paper.pdf"
)

# Query the dataset
query_dataset(
    dataset_id="<dataset-uuid>",
    query_text="What are the main findings?",
    mode="mix",
    top_k=10
)

Cross-Dataset Query

# Query multiple datasets simultaneously
query_multiple_datasets(
    dataset_ids=["<dataset-1-uuid>", "<dataset-2-uuid>"],
    query_text="Compare approaches to machine learning",
    enable_rerank=True,
    top_k=5
)

Managing Dataset Knowledge Graph

# Get graph labels
get_dataset_graph_labels(dataset_id="<dataset-uuid>")

# Retrieve graph data
get_dataset_graph(
    dataset_id="<dataset-uuid>",
    node_label="CONCEPT",
    max_depth=3,
    max_nodes=100
)

Development

Installing development dependencies

uv pip install -e ".[dev]"

Running linters

ruff check src/
mypy src/

License

MIT
