RefIdxDB

Python interface for various refractive index databases

I was tired to download files from here and there, parse them each manually and locally. Hence, I copied most of my parsing code into this project, so it can be developed further.

Installation

refidxdb can be downloaded from PiPy.org:

pip install refidxdb

After the pip command, the refidxdb command should be available.

CLI

The main purpose of the CLI is to download and cache the databases locally and interact with it. The data will be downloaded to $HOME/.cache/refidxdb under a folder corresponding to the class name. Please use refidxdb --help to explore the functionality.

Example:

$ # Download all databases
$ # equivalent to refidxdb db --download aria,refidx
$ refidxdb db --download all
Downloading the database for RefIdx from https://github.com/polyanskiy/refractiveindex.info-database/releases/download/v2024-08-14/rii-database-2024-08-14.zip to /home/mar/.cache/refidxdb/RefIdx
Downloading the database for Aria from https://eodg.atm.ox.ac.uk/ARIA/data_files/ARIA.zip to /home/mar/.cache/refidxdb/Aria
All databases downloaded!
Bye :)

$ # Replace table with plot to display a graph of the data in the terminal
$ refidxdb show --db aria --data "data_files/Minerals/Olivine/z_orientation_(Fabian_et_al._2001)/olivine_Z_Fabian_2001.ri" --display table --bounds 2.5,15.5
shape: (2_748, 3)
┌───────────┬──────────┬──────────┐
│ w         ┆ n        ┆ k        │
│ ---       ┆ ---      ┆ ---      │
│ f64       ┆ f64      ┆ f64      │
╞═══════════╪══════════╪══════════╡
│ 2.500617  ┆ 1.619696 ┆ 0.000053 │
│ 2.501381  ┆ 1.619685 ┆ 0.000053 │
│ 2.502144  ┆ 1.619674 ┆ 0.000053 │
│ 2.502909  ┆ 1.619663 ┆ 0.000053 │
│ 2.503674  ┆ 1.619652 ┆ 0.000053 │
│ …         ┆ …        ┆ …        │
│ 15.369648 ┆ 1.42662  ┆ 0.036282 │
│ 15.398545 ┆ 1.419686 ┆ 0.036761 │
│ 15.427528 ┆ 1.412672 ┆ 0.037256 │
│ 15.456643 ┆ 1.405576 ┆ 0.037768 │
│ 15.485869 ┆ 1.398394 ┆ 0.038299 │
└───────────┴──────────┴──────────┘

$ # Explore the databases using streamlit
$ refidxdb explore
/home/user/Projects/refidxdb/refidxdb

  You can now view your Streamlit app in your browser.

  Local URL: http://localhost:8501
  Network URL: http://10.42.42.212:8501

API

RefIdxDB: is the main blueprint class from which all the specific parser classes need to inherit. This yields a unified API, i.e., all the instances have the same methods available.

path: is the path leading to the wanted file relative to the database. This value can be usually copied from the URL.

data: represents the raw data obtained from the file found under path.

nk: are the parsed real and imaginary parts of the refractive index. The main column is always the wavelength, i.e., wave numbers will always be transformed into wavelengths.

interpolate: you rarely want to use the tables as is, therefore an interpolation method is implemented to calculate n and k for a target wavelength.

Supported DBs

refractiveindex.info

refractiveindex.info mainly differentiates between raw data with wavelengths in micrometers, or polynomial functions which hold for a certain range. The raw data is contained in YAML files, with each data type being referenced.

Currently, supported data types are:

• tabulated_nk
• tabulated_n
• tabulated_k
• formula 1
• formula 2
• formula 3

ARIA - Aerosol Refractive Index Archive

Aria consists of ri files, which are whitespace separated values. The header is prefixed by a hashtag #. The FORMAT value gives information about the column labels. Both wavelengths WAVL and wave numbers WAVN will be read correctly and transformed into wavelengths with no SI prefix (meters [m]). The default scales for wavelengths and wave numbers are 1e-6 (micrometers) and 1e2 (centimeters^-1).

Similar projects

RefIdxDB is, to the best of my knowledge, the only project that tries to unify multiple databases under one API. Nevertheless, there are projects that have tried to achieve the same for a single database:

• refractiveindex
• PyTMM - the API is implemented in refractiveindex.py
• PyOptik

TODO

• Aria has sometimes spaces or URL encoded characters. Those need to be decoded using urllib.parse.unquote.
• Fix for refidx: data-nk/other/commercial polymers/CR-39/mono.yml
