regOct 1.1.3

A module implementing octrees for python

regOct

an implementation of an ordered octree system

Design principles

1. Provide an effective, comprehensive storage medium for cubic, three-dimensional data.
2. State checks within the octree are relatively processor unintensive.
3. The Octree is a self-contained system. All information regarding the octree is stored in the file.

Use

1. General use

Every octree has an integer "level", which defines its size. For a given level, the octree takes the form of a cube with ranges of 0 - 2**level.

regoct.Octree(level) -> Octree

# setting a value:
octree[(x, y, z, level)] = new_value
# level may be omitted if it is 0:
octree[(x, y, z)] = new_value

# getting a value:
value = octree[(x, y, z)]

2. Basic octree IO

In case it is necessary to preserve an octree for later use, it may be saved and loaded to the filesystem via as shown below:

import regoct

original_octree = Octree(2)
# load information into octree

file_path = "file_path.onc"
regoct.save(octree, file_path)
loaded_octree = regoct.load(file_path)

assert original_octree == loaded_octree

This however has a major caveat: the octrees serialized this way may only have internal values of python's base data types:

None(wip), Ellipsis(wip), bool(wip), int, float, complex, str, list, dict, set

This is addressed followingly.

3. Advanced octree IO

regoct provides a API to modify the serialization process. This is useful for implementing routines for class instances.

The ABC regoct.Interface supplies the tools for implementing the API. It requires the methods to_file(obj, saver: "regoct.SavingStream") and from_file(cls, loader: "regoct.LoadingStream"), where the params saver and loader provide access to the data using a set of methods. These methods in loader and saver mirror each other and are as follows:

regoct.SavingStream	regoct.LoadingStream	description
saver.convert(value)	loader.convert() -> any	dynamic conversion
saver.i8(value)	loader.i8() -> int	8-bit signed integer
saver.i16(value)	loader.i16() -> int	16-bit signed integer
saver.i32(value)	loader.i32() -> int	32-bit signed integer
saver.i64(value)	loader.i64() -> int	64-bit signed integer
saver.u8(value)	loader.u8() -> int	8-bit unsigned integer
saver.u16(value)	loader.u16() -> int	16-bit unsigned integer
saver.u32(value)	loader.u32() -> int	32-bit unsigned integer
saver.u64(value)	loader.u64() -> int	64-bit unsigned integer
saver.f32(value)	loader.f32() -> float	32-bit float
saver.f64(value)	loader.f64() -> float	64-bit float
saver.c64(value)	loader.c64() -> complex	2x 32-bit float complex number
saver.c128(value)	loader.c128() -> complex	2x 64-bit float complex number
saver.Str(value)	loader.Str() -> str	variable-length utf-8 string
saver.List(value)	loader.List() -> list	variable-length dynamic-type list
saver.Dict(value)	loader.Dict() -> dict	variable-length dynamic-type dict
saver.Set(value)	loader.Set() -> set	variable-length dynamic-type set

Be aware that the order in which these methods are called in the to_file and from_file methods should be equal to eachother.

import regoct
from regoct import Interface, SavingStream, LoadingStream

class DataPacket(Interface):
    def __init__(self, *args, **kwds):...

    def to_file(obj, saver: SavingStream):...

    def from_file(cls, loader: LoadingStream):...


original_octree = regoct.Octree(2)
# load information into octree

file_path = "file_path.onc"
DataPacket.save(octree, file_path)
loaded_octree = DataPacket.load(file_path)

assert original_octree == loaded_octree

Visualisation:

The module has an interactable viewer to render octrees in 3d. Currently, this is done with the statement regoct.Display(octree).main(), but since this is very verbose, expect it to change.
