Reticulum MeshChatX

Русский | Deutsch | Italiano | 中文 | 日本語

Fork of Reticulum MeshChat by Liam Cottle. MeshChatX adds LXST voice calls, RRC relay chat, Nomad map overlays, plugins, raw SQLite (no Peewee), and Electron 41 desktop builds.

This project is independent from the original Reticulum MeshChat project and is not affiliated with it.

• Website: meshchatx.com
• Forum: forum.meshchatx.com
• RRC Hub: coming soon
• Source: github.com/Quad4-Software/MeshChatX
• Mirror: lavaforge.org/Reticulum-Things/MeshChatX
• Releases: github.com/Quad4-Software/MeshChatX
• Changelog: CHANGELOG.md
• Donate: donate.md
• LXMF: f489752fbef161c64d65e385a4e9fc74
• Umbrel App Store: apps.umbrel.com/app/meshchatx

rngit NomadNet Node: 132f67e79d9b24aad014e93015fb858f:/page/index.mu

git clone rns://06a54b505bb67b25ef3f8097e8001edc/public/MeshChatX

Changes from Reticulum MeshChat

• LXST for calls
• RRC relay chat
• More tools, panes, and tabs
• Map with MBTiles, plus remote KMZ/KML/GeoJSON overlays (NomadNet /file/ and RNGit sparse fetch)
• Raw SQL instead of Peewee
• Native fetch instead of Axios
• Electron 41.x (bundled Node 24)
• Wheels ship with the web server and built frontend assets
• i18n
• pnpm and UV for dependencies

Requirements

• Python 3.11 or newer
• Node.js 24 or newer
• pnpm 11.1.2
• UV

The bundled web UI needs Safari 16.4, Chrome 111, or Firefox 128 or later.

Install methods

Tagged releases build Linux wheel/AppImage/deb/rpm, Windows, macOS, Flatpak, and Android APKs (when the tag is on dev or master) in build-release.yml. The container image is docker.yml. Branch and PR Android CI is android-build.yml. Linux x64 and arm64 AppImage + DEB are built on GitHub. RPM is uploaded when the job produces one.

Docker

• Docker Hub: quad4io/meshchatx
• GHCR: ghcr.io/quad4-software/meshchatx
• Default tags (for example :latest) are Alpine. Use -hardened for Chainguard/Wolfi, or -extra for Alpine plus i2pd and yggdrasil (:latest-extra, same Dockerfile with VARIANT=extra).

docker compose up -d

docker run -d --name reticulum-meshchatx \
  --restart unless-stopped \
  --init \
  --user 1000:1000 \
  --security-opt no-new-privileges:true \
  --cap-drop ALL \
  --read-only \
  --tmpfs /tmp:noexec,nosuid,size=256m \
  --tmpfs /home/meshchat:nosuid,size=64m \
  --cpus=2.0 \
  --memory=1g \
  --memory-reservation=256m \
  --pids-limit=512 \
  -p 127.0.0.1:8000:8000 \
  -v meshchatx-config:/config \
  ghcr.io/quad4-software/meshchatx:latest

Swap in quad4io/meshchatx:latest if you prefer Docker Hub.

Default compose mapping: host 127.0.0.1:8000 to container port 8000, named volume meshchatx-config to /config. That volume works with the image meshchat user (UID 1000) without bind-mount permission fixes.

To bind a host directory instead, use -v "$(pwd)/meshchat-config:/config" (or the same path in Compose volumes). The container runs as UID 1000, so that directory must be writable by uid 1000:

sudo chown -R 1000:1000 ./meshchat-config

Create the directory first if it is empty. Otherwise Docker may create it as root-only.

Inspect or wipe the named volume:

docker volume inspect meshchatx-config
docker rm -f reticulum-meshchatx
docker volume rm meshchatx-config

The last two commands destroy persisted data.

Install from release artifacts

Linux AppImage (x64/arm64)

Download ReticulumMeshChatX-v<version>-linux-<arch>.AppImage from releases, then:

chmod +x ./ReticulumMeshChatX-v*-linux-*.AppImage
./ReticulumMeshChatX-v*-linux-*.AppImage

Debian/Ubuntu

Download the matching .deb, then:

sudo apt install ./ReticulumMeshChatX-v*-linux-*.deb

RPM

Download the .rpm if the release has one, then:

sudo rpm -Uvh ./ReticulumMeshChatX-v*-linux-*.rpm

Python wheel

Release wheels include the built web assets.

pip install ./reticulum_meshchatx-*-py3-none-any.whl
meshchatx --headless

pipx works too:

pipx install ./reticulum_meshchatx-*-py3-none-any.whl

Run from source (web server)

git clone https://github.com/Quad4-Software/MeshChatX.git
cd MeshChatX
corepack enable
pnpm config set verify-store-integrity true
pnpm install --frozen-lockfile
pip install "uv==0.11.15"
uv lock --check
uv sync --group dev
pnpm run build-frontend
uv run python -m meshchatx.meshchat --headless --host 127.0.0.1

pnpm install --frozen-lockfile fails if pnpm-lock.yaml does not match package.json, so an unexpected upstream version cannot land silently. Store integrity is also on in pnpm-workspace.yaml. The extra pnpm config set line hardens the user-level config too.

pnpm v11+ blocks lifecycle scripts by default. Only packages listed under allowBuilds in pnpm-workspace.yaml may run install scripts (electron, electron-winstaller, esbuild). uv lock --check fails if uv.lock is out of date with pyproject.toml. uv sync then installs from the lockfile only. Pin UV with pip install "uv==0.11.15" to match CI.

To update dependencies on purpose, run pnpm update or uv lock in its own commit and read the lockfile diff before you push.

Linux sandbox

Firejail or Bubblewrap (bwrap) can isolate the native meshchatx binary (alias: meshchat) while leaving network access for Reticulum and the web UI. Examples, pip/pipx, Poetry, and USB serial notes: linux-sandbox.md.

That page also shows up in the in-app Documentation list when meshchatx-docs is bundled or synced.

Linux desktop emoji fonts

The emoji picker uses system fonts through Electron/Chromium. Empty squares mean a color emoji package is missing. Install one and restart the app.

If glyphs still fail, run fc-cache -fv or wait until the next login. noto-fonts helps on minimal installs that lack other symbol coverage.

Windows microphone (Electron, Windows 10 / 11)

Calls and voice attachments use the mic through Chromium. If the UI has no access or getUserMedia fails, check Windows privacy first. That is a common miss for Win32 apps, Electron included.

1. Win+R, paste ms-settings:privacy-microphone, Enter.
2. Turn Microphone access on.
3. Enable Let desktop apps access your microphone (wording varies by Windows version).
4. If a per-app list appears, make sure MeshChatX is not denied.

Also check Settings, System, Sound so the app is not muted and a working input device is selected.

Offline builds

Two levels:

1. Cached: you already ran make install once, so node_modules, .venv, and local caches exist.
2. Air-gapped: the build machine has never had internet. Build a bundle on a networked machine and copy it over.

Cached offline builds

Set MESHCHATX_OFFLINE_BUILD=1 before any build command. That skips micron-parser-go WASM, the Reticulum manual, and repository wheel fetches, and runs package managers offline. Missing cache files fail the build instead of hanging.

MESHCHATX_OFFLINE_BUILD=1 make install
MESHCHATX_OFFLINE_BUILD=1 pnpm run build:offline
MESHCHATX_OFFLINE_BUILD=1 pnpm run dist:linux:offline
MESHCHATX_OFFLINE_BUILD=1 ./gradlew :app:assembleRelease

Cached mode only skips build-time network. The first make install still needs the network, or pre-populated pnpm and uv caches.

Air-gapped builds

On the online machine:

pnpm run bundle:offline
bash scripts/create-offline-bundle.sh --warm-packaging
tar czf meshchatx-offline-linux-x64.tar.gz -C vendor/offline meshchatx-offline-bundle-*/

--warm-packaging is optional. It pre-downloads tools such as appimagetool.

On the air-gapped machine:

tar xzf meshchatx-offline-linux-x64.tar.gz
bash scripts/install-offline.sh
MESHCHATX_OFFLINE_BUILD=1 make build
MESHCHATX_OFFLINE_BUILD=1 pnpm run dist:linux

The bundle is platform-specific (Electron, esbuild, and other native binaries). Create it on the same OS and architecture as the air-gapped host. That host still needs node, pnpm, uv, and python3. The bundle is dependencies and caches, not the toolchain.

Android is separate. The offline bundle does not include Chaquopy wheels. Build those on an online machine with bash scripts/build-android-wheels-local.sh, copy android/vendor/ next to the project, then run Gradle with MESHCHATX_OFFLINE_BUILD=1.

Desktop packages from source

pnpm run dist:linux-x64
pnpm run dist:linux-arm64
pnpm run dist:rpm
task dist:fe:rpm

Windows (x64 and arm64) and macOS (arm64 and universal) scripts are in package.json for local builds.

Container build (wheel, AppImage, deb, rpm)

Dockerfile.build runs the same shell steps CI uses (Poetry, pnpm, task, packaging APT deps). It is aimed at linux/amd64 (NodeSource amd64 tarball, Task amd64 binary).

MESHCHATX_BUILD_TARGETS defaults to all. Other values: wheel, or electron (AppImage + deb for x64 and arm64, best-effort RPM, no wheel).

docker build -f Dockerfile.build -t meshchatx-build:local .
docker build -f Dockerfile.build --build-arg MESHCHATX_BUILD_TARGETS=wheel -t meshchatx-build:wheel .

Copy artifacts off the image:

cid=$(docker create meshchatx-build:local)
docker cp "${cid}:/artifacts" ./meshchatx-artifacts
docker rm "${cid}"

Android

Native APK builds, not only Termux. From the repo root:

bash scripts/build-android-wheels-local.sh
cd android
./gradlew --no-daemon :app:assembleDebug :app:assembleRelease

Offline:

MESHCHATX_OFFLINE_BUILD=1 ./gradlew --no-daemon :app:assembleRelease

That skips the repository wheels fetch. android/vendor/ wheels and meshchatx/public/repository-server-bundled/bundled/ must already be present.

There is one Android variant. Gradle syncs the full meshchatx/ tree into app/src/main/python/meshchatx/, including the offline repository wheel bundle. Published builds are universal: one debug APK and one release APK per run, with the native ABIs from android/app/build.gradle.

• Debug: android/app/build/outputs/apk/debug/app-debug.apk
• Release: android/app/build/outputs/apk/release/ReticulumMeshChatX-v*-android-universal-unsigned.apk
• GitHub release: ReticulumMeshChatX-v-android-universal.apk

Release APKs are unsigned unless you configure signing (scripts/sign-android-apks.sh). Native ABIs follow android/app/build.gradle, including armeabi-v7a when that ABI is enabled. Building those wheels needs an Android SDK on ANDROID_HOME.

If dist/reticulum_meshchatx-*.whl exists (for example from python -m build --wheel -o dist .), bundled repository refresh prefers that wheel over PyPI. CI builds that wheel before the Android Gradle step.

More: android-termux.md, android/README.md.

Configuration

CLI args and matching env vars:

Branches

Development

task install
task format
task lint
task test
task build

Makefile targets call the same Taskfile commands:

Versioning

Current version is 4.8.5.

Edit the version field in package.json, then run pnpm run version:sync (also the first step of pnpm run build). That copies the number into pyproject.toml, the Python version modules, Android Gradle, electron/app-version.json, this README and the translated READMEs, the Raspberry Pi pipx example, Arch PKGBUILD helpers, third-party notices, and GitHub issue-template placeholders.

Changelog entries are still written by hand when you cut a release. meshchatx.version is read from meshchatx/src/version.py without importing meshchatx.src, so import meshchatx stays lightweight.

Database corruption and data reset

If MeshChatX fails to start with errors such as database disk image is malformed, DatabaseError, or corrupted ratchet data, the desktop crash screen offers:

• Restore latest backup from database-backups/ or snapshots/ inside the MeshChatX storage folder
• Choose backup file for a zip you saved elsewhere
• Try auto-repair (--auto-recover: SQLite checkpoint / integrity pass)
• Emergency mode, which opens the app without the database so you can export from About when possible
• Copy reset instructions with the folders to delete for a clean reinstall

Storage locations

Legacy Reticulum MeshChat data may still exist at ~/.reticulum-meshchat/ (or the Windows equivalent). Automatic database backups go to database-backups/ inside the MeshChatX storage folder after a successful run.

Complete removal

Quit MeshChatX. On Windows, also end ReticulumMeshChatX.exe in Task Manager if it is still running. Then delete the MeshChatX storage folder and the Reticulum config folder for your install type. That removes the local identity, messages, contacts, path cache, and ratchet state. The next launch creates a new identity unless you restore a backup first.

Linux / macOS:

rm -rf ~/.reticulum-meshchatx ~/.reticulum ~/.reticulum-meshchat

Windows PowerShell:

Remove-Item -Recurse -Force "$env:USERPROFILE\.reticulum-meshchatx", "$env:USERPROFILE\.reticulum", "$env:USERPROFILE\.reticulum-meshchat" -ErrorAction SilentlyContinue

If you pass --storage-dir or --reticulum-config-dir, delete those directories instead.

Command-line restore

When the backend can start briefly, or you run from source:

meshchatx --storage-dir /path/to/storage --restore-db /path/to/backup.zip

Security

• SECURITY.md
• LEGAL.md
• Built-in integrity checks and HTTPS/WSS defaults at runtime
• CI and release builds on GitHub Actions

Adding a language

My workflow: ArgosTranslate, then a local LLM (Qwen 3 + Gemma 4).

People are welcome to send fixes via LXMF (f489752fbef161c64d65e385a4e9fc74) or however you can reach me.

Locale discovery is automatic. Add a file under meshchatx/src/frontend/locales/ (for example xx.json) with the same keys as en.json and a top-level _languageName string for the selector label. Copy en.json and translate the values. Machine-assisted generation is optional.

For a machine-generated first draft from en.json, use scripts/argos_translate.py. It keeps interpolation variables such as {count} intact.

pipx install argostranslate
python scripts/argos_translate.py --from en --to xx --input meshchatx/src/frontend/locales/en.json --output meshchatx/src/frontend/locales/xx.json --name "Your Language Name"

After a machine pass, have an LLM or a human check grammar, context, and tone.

pnpm test -- tests/frontend/i18n.test.js --run

That checks key parity with en.json. No other code changes. The app, language selector, and tests pick up locales from meshchatx/src/frontend/locales/ at build time.

Donation

Donations are voluntary. They help fund time spent on this app.

Ways to give: donate.md (Monero, Ko-Fi, Buy Me a Coffee).

Credits

• Liam Cottle - original Reticulum MeshChat
• RFnexus - micron parser JavaScript work
• markqvist - Reticulum, LXMF, LXST

License

Project-owned portions are 0BSD. Original upstream portions from Reticulum MeshChat remain MIT. Full text: LICENSE.
