🤖 RobotMCP - AI-Powered Test Automation Bridge

Python Robot Framework FastMCP License

Plain English in, real Robot Framework tests out — with an AI agent doing the typing.

RobotMCP (rf-mcp) is a Model Context Protocol (MCP) server that hands your coding agent the keys to Robot Framework. The agent discovers keywords, runs steps live against Browser, Selenium, Appium, Requests, a database, or the desktop, sees what actually happens, and — once the steps pass — writes you a clean .robot suite. No guessed locators, no hallucinated keywords, no "works on my machine". Built on Robot Framework: open source, and always evolving.

New to rf-mcp? Jump to Getting Started. Want the full picture? See the MCP tool reference, configuration, and worked examples.

📺 Video Tutorial

RobotMCP Tutorial

Intro

https://github.com/user-attachments/assets/ad89064f-cab3-4ae6-a4c4-5e8c241301a1


✨ Quick Start

Three commands and a sentence. That's the whole setup.

1️⃣ Install it as a tool

# Everything (Browser, Selenium, Appium, Requests, Database)
uv tool install "rf-mcp[all]"

# ...or just what you need — API testing is pure Python, nothing else to do:
uv tool install "rf-mcp[api]"

This puts a robotmcp command on your PATH. Extras decide which test libraries come along — see the extras table under Installation.

2️⃣ Wire it into your coding agent

robotmcp init            # detects libraries, prints the MCP config to paste
robotmcp install         # registers rf-mcp into the agents it finds

robotmcp install writes the right MCP config for Claude Code, Codex, GitHub Copilot, opencode, Gemini CLI, Kilo Code, goose, and Cursor — each in its own format, without touching your other servers. Prefer to do it by hand? Every agent accepts:

{ "mcpServers": { "robotmcp": { "command": "robotmcp" } } }

If you have an existing Robot Framework project, run robotmcp install from that project's directory instead of pasting the snippet. The snippet launches rf-mcp in its own environment; robotmcp install inspects your project and writes a launch that can also see your libraries. See Which environment runs your tests.

Which environment runs your tests

rf-mcp imports Robot Framework libraries into its own Python process, and runs your suites in that same interpreter. So whichever environment rf-mcp launches in is the environment your tests execute in.

  • No existing RF project (you're exploring a site or API and authoring tests from scratch): a plain uv tool install is exactly right. rf-mcp's own environment has the bundled libraries, and there is nothing to configure.

  • An existing RF project (your own keyword libraries, a pinned Robot Framework, pip libraries rf-mcp doesn't bundle): rf-mcp's own environment cannot see any of it. Run robotmcp install from the project directory — it detects the project's environment and writes a launch that layers rf-mcp onto it, so your libraries are importable. Check what it resolved with:

    robotmcp doctor -C .


    That reports the resolved launch, which of your project's libraries rf-mcp would see, and whether your project's Robot Framework version differs from the one that would execute the tests. If your project pins Robot Framework 6.x, rf-mcp routes to the attach bridge instead of silently testing on a different RF.

    Note that desktop automation (PlatynUI) is never layered onto a project environment — it is a pre-release that uv will not resolve as a transitive dependency. Desktop sessions use rf-mcp's own environment.

Legacy / manual config (running from a checkout, HTTP transport)
{
  "servers": {
    "robotmcp": {
      "type": "stdio",
      "command": "uv",
      "args": ["run", "-m", "robotmcp.server"],
      "env": { "UV_COMPILE_BYTECODE": "1" }
    }
  }
}

UV_COMPILE_BYTECODE=1 precompiles the dependency tree at install time. Without it, the first server launch after an install/upgrade pays several seconds of .pyc compilation before the MCP handshake completes (some clients time out and show the server as unavailable). It is a one-time, install-time cost.

HTTP

Start the MCP server with HTTP transport:

uv run -m robotmcp.server --transport http --host 127.0.0.1 --port 8000

Then configure your AI agent:

{
  "servers": {
    "robotmcp": {
      "type": "http",
      "url": "http://localhost:8000/mcp"
    }
  }
}

Claude Code

claude mcp add rf-mcp -- uvx rf-mcp

3️⃣ Start testing — just ask

Use #robotmcp to create a TestSuite and execute it step wise.
Create a test for https://www.saucedemo.com/ that:
- Logs in to https://www.saucedemo.com/ with valid credentials
- Adds two items to cart
- Completes checkout process
- Verifies success message

Use Selenium Library.
Execute the test suite stepwise and build the final version afterwards.

That's it. rf-mcp walks the agent through discovery, live execution, and suite generation — you just describe the test.


📚 Documentation

Guide What's inside
Getting Started Install, wire into your agent, run your first test
MCP Tool Reference Every tool rf-mcp exposes to the agent — parameters, returns, when to reach for it
Configuration Every ROBOTMCP_* environment variable and CLI flag
Examples Copy-pasteable web / API / mobile / desktop / BDD / data-driven walkthroughs
Library Plugins Teach rf-mcp about your own Robot Framework libraries
Instruction Templates Steer the agent's behavior per project

🛠️ Installation

The Quick Start covers the recommended path (uv tool install). This section has the extras table, alternative install methods, and the full agent-registration details.

Extras

Extras decide which Robot Framework libraries come along:

Extra Adds Post-install
api RequestsLibrary none
web SeleniumLibrary + Browser Selenium: none (Selenium Manager fetches the driver); Browser: robotmcp init --browsers
mobile AppiumLibrary Appium server (external)
database DatabaseLibrary a DB driver
desktop PlatynUI native desktop (Windows/Linux) Python 3.12+; not in [all] — see below
frontend Django dashboard —
memory Persistent semantic memory (sqlite-vec + model2vec) ROBOTMCP_MEMORY_ENABLED=true
all every extra above except desktop (and semantic) as above

Browser Library also needs Playwright browsers — run robotmcp init --browsers (or rfbrowser init) once, inside rf-mcp's own environment. Node.js is only needed for Browser.

Desktop (desktop) — an explicit opt-in

PlatynUI's native core is still published as a pre-release, so desktop is not part of [all]: including it would make uv tool install "rf-mcp[all]" fail for everyone. Install it on its own:

uv tool install --prerelease=allow "rf-mcp[desktop]"   # uv, uvx and pipx need the flag
pip install "rf-mcp[desktop]"                          # pip, poetry and pdm do not

uv, uvx and pipx (which is uv-backed) refuse a transitive pre-release pin unless you pass --prerelease=allow (or set UV_PRERELEASE=allow).

Supported desktop platforms — PlatynUI publishes wheels only for:

Supported Not supported
Linux x86_64 / aarch64 with glibc ≥ 2.34 (Ubuntu 22.04+, Debian 12+, RHEL 9+) Linux with glibc < 2.34 (Ubuntu 20.04, Debian 11, RHEL/Rocky 8, Amazon Linux 2)
macOS Apple Silicon (arm64) macOS Intel (x86_64)
Windows x86_64 / arm64 musl / Alpine

There is no source distribution, so unsupported platforms cannot build it either. [all] installs fine on all of them — you just don't get desktop automation.

Other install methods

pip install "rf-mcp[all]"                 # pip instead of uv
pipx install "rf-mcp[all]"                # pipx
uv add "rf-mcp[all]" && uv sync           # into an existing uv project

# Desktop automation is a separate opt-in (pre-release; uv/uvx/pipx need the flag):
uv tool install --prerelease=allow "rf-mcp[desktop]"
uv add --prerelease=allow "rf-mcp[desktop]" && uv sync

# From source (development)
git clone https://github.com/manykarim/rf-mcp.git && cd rf-mcp
uv sync --all-extras --dev

Docker

Pre-built images (headless for CI, plus a VNC image for visual debugging):

docker pull ghcr.io/manykarim/rf-mcp:latest          # headless
docker run -p 8000:8000 -p 8001:8001 ghcr.io/manykarim/rf-mcp:latest    # HTTP + frontend
docker run -it --rm ghcr.io/manykarim/rf-mcp:latest uv run robotmcp     # STDIO

docker pull ghcr.io/manykarim/rf-mcp-vnc:latest      # X11 desktop over VNC/noVNC
docker run -p 8000:8000 -p 8001:8001 -p 5900:5900 -p 6080:6080 ghcr.io/manykarim/rf-mcp-vnc:latest

Headless bundles Chromium, Firefox ESR and the Playwright browsers. VNC ports: 8000 (MCP HTTP), 8001 (frontend), 5900 (VNC), 6080 (noVNC — http://localhost:6080/vnc.html).

Register into coding agents

robotmcp list                              # supported agents + what's detected/registered
robotmcp install                           # interactive: registers into detected agents
robotmcp install --agents claude-code,codex,gemini
robotmcp install --agents all --scope user
robotmcp install --dry-run                 # show the plan, write nothing
robotmcp uninstall                         # safe, reversible removal

Supported agents (each written in its own file/format, other MCP servers preserved): Claude Code, OpenAI Codex, GitHub Copilot, opencode, Gemini CLI, Kilo Code, goose, Cursor (plus pi, listed as planned until its config convention is confirmed).

Uses your project's environment. Install into a project that has its own set-up environment (uv, poetry, pdm, pipenv, rye, hatch, or a plain .venv) and rf-mcp is wired to run against that environment — so it sees your project's libraries, keywords and resources, not just its bundled ones. It launches the resolved command and verifies your libraries are reachable before writing the config; a blind or broken command is refused. A global uvx / uv tool install still serves every project with no per-project setup. Point it with -C <dir>, opt into installing rf-mcp into the project env with --into-project, and run robotmcp doctor --project-dir <dir> to see which of your libraries the launch reaches.

Scope. Installs default to --scope project (writes into the current project, e.g. ./.mcp.json) where the agent supports it; use --scope user for a global (home-directory) install. goose only supports user scope; GitHub Copilot only supports project scope.

Safe & reversible. Every change is recorded in a hash-tracked manifest (~/.local/state/robotmcp/install-manifest.json). robotmcp uninstall removes only entries unchanged since install — a hand-edited entry is left in place and reported, and unrelated servers are never touched. Prefer to edit config yourself? Add { "mcpServers": { "robotmcp": { "command": "robotmcp" } } }.

🔌 Library Plugins

Extend RobotMCP with custom libraries via the plugin system. Two discovery modes are available:

  • Entry points (robotmcp.library_plugins) for packaged plugins.
  • Manifest files (JSON) under .robotmcp/plugins/ for workspace overrides.

See the Library Plugin Authoring Guide for detailed instructions and explore the sample plugin in examples/plugins/sample_plugin to get started quickly.


🖥️ Frontend Dashboard

RobotMCP ships with an optional Django-based dashboard that mirrors active sessions, keywords, and tool activity.

RobotMCP Frontend Dashboard

  1. Install frontend extras
    pip install rf-mcp[frontend]

  2. Start the MCP server with the frontend enabled
    uv run -m robotmcp.server --with-frontend

    • Default URL: http://127.0.0.1:8001/
    • Quick toggles: --frontend-host, --frontend-port, --frontend-base-path
    • Environment equivalents: ROBOTMCP_ENABLE_FRONTEND=1, ROBOTMCP_FRONTEND_HOST, ROBOTMCP_FRONTEND_PORT, ROBOTMCP_FRONTEND_BASE_PATH, ROBOTMCP_FRONTEND_DEBUG
  3. Connect your MCP client (Cline, Claude Desktop, etc.) to the same server process—the dashboard automatically streams events once the session is active.

To disable the dashboard for a given run, either omit the flag or pass --without-frontend.


📋 Instruction Templates

RobotMCP sends server-level instructions to LLMs via the MCP initialize response, guiding them to discover keywords before executing them. This significantly reduces failed tool calls and wasted tokens, especially for smaller LLMs.

Configuration

Three environment variables control instruction behavior:

Variable Values Default
ROBOTMCP_INSTRUCTIONS off / default / custom default
ROBOTMCP_INSTRUCTIONS_TEMPLATE minimal / standard / detailed / browser-focused / api-focused standard
ROBOTMCP_INSTRUCTIONS_FILE Path to .txt or .md file (none, required when mode=custom)
ROBOTMCP_LOG_LEVEL DEBUG / INFO / WARNING / ERROR — stderr log verbosity WARNING
ROBOTMCP_MCP_LOG_NOTIFICATIONS set to 1 to also forward logs to the client as MCP notifications/message (structured, level-tagged) (off)

Output & logging. The MCP stdio channel (stdout) carries only JSON-RPC; all logs and a one-line readiness banner go to stderr. Logging defaults to WARNING so the client is not flooded — set ROBOTMCP_LOG_LEVEL=INFO/DEBUG to troubleshoot. Logging never blocks execution (it is drained on a background thread with drop-on-overflow), and fd 1 is never redirected out from under the transport.

Built-in Templates

Template ~Tokens Best For
minimal ~40 Capable LLMs (Claude Opus, GPT-4) — brief reminder only
standard ~400 Mid-range LLMs (Claude Sonnet, GPT-4o) — balanced workflow guide
detailed ~600 Smaller LLMs (Claude Haiku, GPT-4o-mini) — step-by-step with examples
browser-focused ~350 Web-only testing scenarios
api-focused ~300 API-only testing scenarios

Example

{
  "servers": {
    "robotmcp": {
      "type": "stdio",
      "command": "uv",
      "args": ["run", "-m", "robotmcp.server"],
      "env": {
        "ROBOTMCP_INSTRUCTIONS": "default",
        "ROBOTMCP_INSTRUCTIONS_TEMPLATE": "detailed"
      }
    }
  }
}

Custom Instructions

Set ROBOTMCP_INSTRUCTIONS=custom and provide a file via ROBOTMCP_INSTRUCTIONS_FILE. Custom files support {available_tools} placeholder substitution. Allowed extensions: .txt, .md, .instruction, .instructions. If the file is missing or fails validation, the server falls back to the standard template automatically.

See docs/INSTRUCTION_TEMPLATES_GUIDE.md for the full guide.


🪝 Debug Attach Bridge

https://github.com/user-attachments/assets/8d87cd6e-c32e-4481-9f37-48b83f69f72f

RobotMCP ships with robotmcp.attach.McpAttach, a lightweight Robot Framework library that exposes the live ExecutionContext over a localhost HTTP bridge. When you debug a suite from VS Code (RobotCode) or another IDE, the bridge lets RobotMCP reuse the in-process variables, imports, and keyword search order instead of creating a separate context.

MCP Server Setup

Example configuration with passed environment variables for Debug Bridge

Using UV

{
  "servers": {
    "RobotMCP": {
      "type": "stdio",
      "command": "uv",
      "args": ["run", "src/robotmcp/server.py"],
      "env": {
        "ROBOTMCP_ATTACH_HOST": "127.0.0.1",
        "ROBOTMCP_ATTACH_PORT": "7317",
        "ROBOTMCP_ATTACH_TOKEN": "change-me",
        "ROBOTMCP_ATTACH_DEFAULT": "auto"
      }
    }
  }
}

Using Docker

{
  "servers": {
    "RobotMCP": {
      "command": "docker",
      "args": ["run", "-i", "--rm", "ghcr.io/manykarim/rf-mcp:latest", "uv", "run", "robotmcp"],
      "env": {
        "ROBOTMCP_ATTACH_HOST": "127.0.0.1",
        "ROBOTMCP_ATTACH_PORT": "7317",
        "ROBOTMCP_ATTACH_TOKEN": "change-me",
        "ROBOTMCP_ATTACH_DEFAULT": "auto"
      }
    }
  }
}

Robot Framework setup

Import the library and start the serve loop inside the suite that you are debugging:

*** Settings ***
Library    robotmcp.attach.McpAttach    token=${DEBUG_TOKEN}

*** Variables ***
${DEBUG_TOKEN}    change-me

*** Test Cases ***
Serve From Debugger
    MCP Serve    port=7317    token=${DEBUG_TOKEN}    mode=blocking    poll_ms=100
    [Teardown]    MCP Stop
  • MCP Serve port=7317 token=${TOKEN} mode=blocking|step poll_ms=100 — starts the HTTP server (if not running) and processes bridge commands. Use mode=step during keyword body execution to process exactly one queued request.
  • MCP Stop — signals the serve loop to exit (used from the suite or remotely via RobotMCP attach_stop_bridge).
  • MCP Process Once — processes a single pending request and returns immediately; useful when the suite polls between test actions.
  • MCP Start — alias for MCP Serve for backwards compatibility.

The bridge binds to 127.0.0.1 by default and expects clients to send the shared token in the X-MCP-Token header.

Configure RobotMCP to attach

Start robotmcp.server with attach routing by providing the bridge connection details via environment variables (token must match the suite):

export ROBOTMCP_ATTACH_HOST=127.0.0.1
export ROBOTMCP_ATTACH_PORT=7317          # optional, defaults to 7317
export ROBOTMCP_ATTACH_TOKEN=change-me    # optional, defaults to 'change-me'
export ROBOTMCP_ATTACH_DEFAULT=auto       # auto|force|off (auto routes when reachable)
export ROBOTMCP_ATTACH_STRICT=0           # set to 1/true to fail when bridge is unreachable
uv run python -m robotmcp.server

When ROBOTMCP_ATTACH_HOST is set, execute_step(..., use_context=true) and other context-aware tools first try to run inside the live debug session. Use the new MCP tools to manage the bridge from any agent:

  • attach_status — reports configuration, reachability, and diagnostics from the bridge (/diagnostics).
  • attach_stop_bridge — sends a /stop command, which in turn triggers MCP Stop in the debugged suite.

🎪 Example Workflows

🌐 Web Application Testing (BDD)

Prompt:

Use RobotMCP to create a test suite and execute it step wise.
It shall:

- Open https://demoshop.makrocode.de/
- Add item to cart
- Assert item was added to cart
- Add another item to cart
- Assert another item was added to cart
- Checkout
- Assert checkout was successful

Execute step by step and build final test suite afterwards
Create in BDD style and use Keywords with embedded arguments when applicable

Result: BDD-style Robot Framework test suite with Given/When/Then keywords, embedded arguments, and extracted variables.

🌐 Web Application Testing (Data-Driven)

Prompt:

Use RobotMCP to create a test suite and execute it step wise.
It shall:

- Open https://saucedemo.com
- Login with different user/password combinations
- Assert message or login

Execute step by step and build final test suite afterwards
Create in datadriven style and add multiple test rows with different scenarios
Use Test Template setting in suite

Result: Data-driven Robot Framework test suite with Test Template and parameterized rows for each login scenario.

📱 Mobile App Testing

Prompt:

Use RobotMCP to create a TestSuite and execute it step wise.
It shall:
- Launch app from tests/appium/SauceLabs.apk
- Perform login flow
- Add products to cart
- Complete purchase

Appium server is running at http://localhost:4723
Execute the test suite stepwise and build the final version afterwards.

Result: Mobile test suite with AppiumLibrary keywords and device capabilities.

🔌 API Testing

Prompt:

Read the Restful Booker API documentation at https://restful-booker.herokuapp.com.
Use RobotMCP to create a TestSuite and execute it step wise.
It shall:

- Create a new booking
- Authenticate as admin
- Update the booking
- Delete the booking
- Verify each response

Execute the test suite stepwise and build the final version afterwards.

Result: API test suite using RequestsLibrary with proper error handling.

🧪 XML/Database Testing

Prompt:

Create a xml file with books and authors.
Use RobotMCP to create a TestSuite and execute it step wise.
It shall:
- Parse XML structure
- Validate specific nodes and attributes
- Assert content values
- Check XML schema compliance

Execute the test suite stepwise and build the final version afterwards.

Result: XML processing test using Robot Framework's XML library.


🔍 MCP Tools

rf-mcp exposes its capabilities to the agent as MCP tools, grouped by purpose: planning & orchestration, session & execution, discovery & documentation, observability & diagnostics, suite lifecycle, locator guidance, visual validation, and optional persistent memory.

Full reference: docs/MCP_TOOLS.md — every tool with its parameters, returns, and when to reach for it. Your agent reads these descriptions directly; you rarely need to call them by hand.

🧪 BDD & Data-Driven Test Generation

BDD Style (Given/When/Then)

Prompt:

Use RobotMCP to create a test suite and execute it step wise.
It shall:

- Open https://demoshop.makrocode.de/
- Add item to cart
- Assert item was added to cart
- Add another item to cart
- Assert another item was added to cart
- Checkout
- Assert checkout was successful

Execute step by step and build final test suite afterwards
Create in BDD style and use Keywords with embedded arguments when applicable

Result: RobotMCP executes each step, inspects the DOM between actions, and generates a BDD-style suite with Given/When/Then keywords:

*** Test Cases ***
Demoshop BDD Purchase Workflow
    Given the demoshop is open
    When the user adds the first product to cart
    Then the cart should contain 1 item
    When the user adds the second product to cart
    Then the cart should contain 2 items
    When the user proceeds to checkout
    And the user fills in the checkout form
    And the user places the order
    Then the order confirmation should be displayed

*** Keywords ***
the demoshop is open
    New Browser    chromium
    New Context
    New Page    ${DEMOSHOP_URL}

the user adds the first product to cart
    Click    ${FIRST_PRODUCT_BUTTON}

During stepwise execution, use bdd_group and bdd_intent on execute_step to control how steps are grouped into behavioral keywords. Call build_test_suite(bdd_style=True) at the end.

Data-Driven Templates

Prompt:

Use RobotMCP to create a test suite and execute it step wise.
It shall:

- Open https://saucedemo.com
- Login with different user/password combinations
- Assert message or login

Execute step by step and build final test suite afterwards
Create in datadriven style and add multiple test rows with different scenarios
Use Test Template setting in suite

Result: RobotMCP builds a parameterized suite using Test Template with named data rows:

*** Settings ***
Library         Browser
Test Template   Verify Login

*** Test Cases ***          USERNAME            PASSWORD        EXPECTED
Valid User                  standard_user       secret_sauce    Products
Locked Out User             locked_out_user     secret_sauce    locked out
Invalid Password            standard_user       wrong_pass      Username and password do not match

Use manage_session(action="start_test", template="Verify Login") to set the template keyword, then manage_session(action="add_data_row", test_name="Valid User", args=["standard_user", "secret_sauce", "Products"]) to add each row.


🧠 Small LLM Optimization

RobotMCP includes optimizations for small and medium-sized LLMs (8K-32K context windows) that reduce token overhead and improve tool call accuracy.

Dynamic Tool Profiles

Control which tools are visible to the LLM based on the workflow phase. Smaller models see fewer, more compact tools:

manage_session(action="set_tool_profile", tool_profile="browser_exec")

Profiles: browser_exec, api_exec, discovery, minimal_exec, full. Reduces tool description overhead from ~7,000 to ~1,000 tokens. Can also be set via the ROBOTMCP_TOOL_PROFILE environment variable.

Response Verbosity

Control response detail level to reduce token consumption. Available on most tools via the detail_level parameter:

  • minimal – Essential output only (60-80% token reduction)
  • standard – Balanced output (default)
  • full – Complete detailed output

Set a default via ROBOTMCP_OUTPUT_VERBOSITY=compact|standard|verbose.

Delta State Responses

get_session_state supports incremental responses that only return sections that changed since the last call:

# First call returns full state (version 1):
get_session_state(session_id="...", sections=["variables", "page_source"])

# Subsequent calls return only what changed:
get_session_state(session_id="...", mode="delta", since_version=1)

In mode="auto" (the default), the server automatically returns delta responses when a previous version exists. This reduces token usage by 50-80% for multi-step workflows where only variables or page content change between steps.

Artifact Externalization

Large outputs (HTML page source, execution logs, stack traces) are automatically externalized into fetchable artifacts instead of being inlined in the response:

# Response includes artifact_id instead of full content:
{"result": "...", "artifact_id": "abc123", "artifact_hint": "Full page source available via fetch_artifact"}

# Fetch when needed:
fetch_artifact(artifact_id="abc123")

This keeps tool responses compact while preserving access to full output on demand.

Intent Action

The intent_action tool provides a library-agnostic entry point for common test actions. Instead of requiring the LLM to know library-specific keyword names and locator syntax, it expresses intent:

intent_action(intent="click", target="text=Login", session_id="...")
intent_action(intent="fill", target="#username", value="testuser", session_id="...")

The server resolves intent + target to the correct keyword and locator format for the session's active library (Browser, SeleniumLibrary, or AppiumLibrary).

Navigate Fallback

When intent_action(intent="navigate") fails because no browser or page is open, the server automatically opens the browser/page and retries:

  • Browser Library: executes New Browser + New Page (or just New Page if browser exists)
  • SeleniumLibrary: executes Open Browser about:blank chrome

The response includes fallback_applied: true and fallback_steps count. Saves 2-4 tool calls per session.

Batch Execution

The execute_batch tool executes multiple keywords in a single MCP call, reducing N round-trips to 1. Steps can reference results from earlier steps via ${STEP_N} variables:

execute_batch(session_id="...", steps=[
    {"keyword": "Go To", "args": ["https://example.com"]},
    {"keyword": "Get Title", "assign_to": "title"},
    {"keyword": "Should Be Equal", "args": ["${STEP_2}", "Example Domain"]}
], on_failure="recover")

If a step fails, resume_batch lets you insert fix steps and retry from the failure point.

Strict Mode Hints

When a Browser Library keyword fails because the selector matches multiple elements (Playwright strict mode), the error response includes a hint suggesting >> nth=0 (zero-based index) or >> visible=true selector chains, with concrete examples using the actual keyword name and element count.

Type-Constrained Parameters

All action/mode/strategy parameters use Literal types, producing enum constraints in the JSON Schema. This eliminates hallucinated values (e.g., action="setup" instead of action="init"). All values accept case-insensitive input.

Automatic Parameter Coercion

Common small LLM mistakes are corrected server-side:

  • JSON-stringified arrays ("[\"Browser\"]") are parsed to native arrays
  • Comma-separated strings ("Browser,BuiltIn") are split into lists
  • Deprecated keywords (GET) are mapped to current equivalents (GET On Session)

Instruction Templates

Configurable server-level instructions guide LLMs to follow the "discover-then-act" pattern. Choose a template sized for your LLM's capability — from minimal (~40 tokens) for Claude Opus to detailed (~600 tokens) for Claude Haiku. See Instruction Templates above.


🧠 Persistent Semantic Memory

RobotMCP can learn from past sessions and recall successful patterns, locators, and error fixes — reducing trial-and-error for repeated testing scenarios.

How It Works

Memory is powered by sqlite-vec (vector search) and model2vec (256-dimensional embeddings). When enabled, the server:

  1. Stores successful step sequences, working locators, and error→fix mappings after each tool call
  2. Recalls relevant memories and injects them as hints into tool responses (e.g., execute_step failures include previous fixes, get_session_state includes previously successful step patterns)
  3. Learns across sessions — the warm database persists between server restarts

Installation

pip install rf-mcp[memory]
# or
uv pip install rf-mcp[memory]

Configuration

Enable via environment variables:

{
  "servers": {
    "robotmcp": {
      "type": "stdio",
      "command": "uv",
      "args": ["run", "-m", "robotmcp.server"],
      "env": {
        "ROBOTMCP_MEMORY_ENABLED": "true",
        "ROBOTMCP_MEMORY_DB_PATH": "./memory.db"
      }
    }
  }
}

Memory MCP Tools

When memory is enabled, five additional tools become available:

Tool Description
recall_step Recall previously successful step sequences. Call before building new test steps to reuse proven patterns.
recall_fix Recall known fixes for an error. Call immediately when execute_step fails before retrying.
recall_locator Recall working locators for a UI element. Call before DOM inspection for familiar elements.
store_knowledge Store domain knowledge (e.g., site structure, auth flows) for future recall.
get_memory_status Check memory availability and statistics at session start.

Response Augmentation

Memory hints are automatically injected into existing tool responses — no LLM cooperation required:

  • execute_step failures: Previous fixes and working locators are included in the error response
  • get_session_state: Previously successful step patterns for the scenario are included
  • analyze_scenario: Recalled step sequences from past sessions are suggested

All memory lookups have a 50ms timeout to avoid impacting response latency.

Benchmark Results

Tested across 8 scenarios (72 opencode invocations, 3 iterations each) with qwen/qwen3-coder:

Scenario Type Best Result Memory Recall Rate
Complex web flows (checkout) -23% calls, -22% tokens 3/3 iterations
Exploration-heavy browsing -44% calls on best iteration 3/3 iterations
API error recovery -3% calls ±3% (tightest CI) 3/3 iterations

Memory benefits are strongest for complex, multi-step scenarios where past locators and step sequences reduce exploratory tool calls.


⚙️ Configuration

rf-mcp runs with sensible defaults; when you need to tune it, everything is an environment variable away — instruction templates, the attach bridge, output/token economy, memory, the frontend dashboard, PlatynUI desktop safety, and more.

Full reference: docs/CONFIGURATION.md — every ROBOTMCP_* variable with its accepted values and default, plus the robotmcp CLI flags and subcommands.

🤝 Contributing

We welcome contributions! Here's how to get started:

  1. Fork the repository
  2. Clone your fork locally
  3. Install development dependencies: uv sync
  4. Create a feature branch
  5. Add comprehensive tests for new functionality
  6. Run tests: uv run pytest tests/
  7. Submit a pull request

Code quality and security analysis

Every push runs a Quality job covering four areas:

area tool where findings appear
code quality ruff Security tab (code scanning) + quality-reports artifact
code security ruff --select S (flake8-bandit) as above
dependency advisories osv-scanner against uv.lock as above
maintainability radon run summary + artifact

The Quality check never fails on findings. It reports them and stays green, so a finding never blocks a merge. It fails only when an analyzer could not run — an analyzer that fails to install would otherwise report zero findings, which is indistinguishable from a clean result.

Every run prints a short digest to the job log and the run summary. For the full detail, download the quality-reports artifact or open the repository's Security tab.

Run the same checks locally:

uv run ruff check src/          # quality + security, same rules as CI
uv run radon mi src/ -s         # maintainability per file

On the rule set: [tool.ruff.lint].select in pyproject.toml is pinned deliberately, and ruff is pinned to an exact version. Measured on this codebase the selection swings the finding count 26× — 439 for the current selection versus 5,763 for ruff's bare default. If you widen it, widen it on purpose and re-measure; don't delete the selection to "use the defaults". A signal nobody can act on gets ignored, which is what happened to the SonarCloud check this replaced.

There is deliberately no "new code" quality gate (fail only on newly-introduced issues). No open-source artifact-based stack provides one for free. If the finding count is driven down and starts creeping back up, that's the point to reconsider.

📝 Changelog

  • v0.34.0 – Native desktop automation (rf-mcp[desktop], PlatynUI, Windows-ready); project-aware installer that uses your project's own libraries; leaner agent instructions; cold-start hang, Windows dry-run deadlock and generated-suite path fixes; tool profiles restored on FastMCP 3
  • v0.31.1 – Packaging cleanup (exclude tests/examples from sdist)
  • v0.31.0 – BDD/data-driven generation, namespace architecture fixes, persistent memory, 71-88% token reduction
  • v0.30.1 – FastMCP 3.x compatibility layer
  • v0.30.0 – Small LLM optimization (tool profiles, intent action, response optimization, type constraints)
  • v0.29.0 – Instruction templates, multi-test sessions, batch execution, smart timeouts

📄 License

Apache 2.0 License - see LICENSE file for details.


⭐ Star us on GitHub if RobotMCP helps your test automation journey!

Made with ❤️ for the Robot Framework and AI automation community.

Release files for rf-mcp 0.36.0

For a detailed explanation of source distributions (sdists) and built distributions (wheels), please see the package formats documentation.

Source distribution (sdist)

Source distribution for rf-mcp 0.36.0
File Size Uploaded
rf_mcp-0.36.0.tar.gz 920.7 kB Details

Built distribution (wheel)

Table of built distributions (wheels) for rf-mcp 0.36.0
File Interpreter ABI Platform
rf_mcp-0.36.0-py3-none-any.whl Python 3 none any Details

Total release size: 1.9 MB

Release files / rf_mcp-0.36.0.tar.gz

Download URL rf_mcp-0.36.0.tar.gz
Size 920.7 kB
Tags Source
SHA-256 checksum
How to use checksums
d3d8c19a24836edd480915b3a3311b4bd9bdf821be683eaf5b792f5a27fa96ab
BLAKE2b-256 checksum
How to use checksums
bb20c0aa6ac66a556782e6410e80738b2833ed365e121e0b41b6d76854a833b8
Upload date
Uploaded using Trusted Publishing?
What is trusted publishing?
No
Uploaded via uv/0.9.26 {"installer":{"name":"uv","version":"0.9.26","subcommand":["publish"]},"python":null,"implementation":{"name":null,"version":null},"distro":{"name":"Ubuntu","version":"24.04","id":"noble","libc":null},"system":{"name":null,"release":null},"cpu":null,"openssl_version":null,"setuptools_version":null,"rustc_version":null,"ci":null}

Release files / rf_mcp-0.36.0-py3-none-any.whl

Download URL rf_mcp-0.36.0-py3-none-any.whl
Size 984.0 kB
Tags Python 3
SHA-256 checksum
How to use checksums
bf11451cb94ba51192551cd6bb89f49d5fdf0f60cf764857c8bdd5cf6bd6f203
BLAKE2b-256 checksum
How to use checksums
53f955525ca19399b45083af4b0ddbc34a107c5c5ff156e16c6d53920e97d414
Upload date
Uploaded using Trusted Publishing?
What is trusted publishing?
No
Uploaded via uv/0.9.26 {"installer":{"name":"uv","version":"0.9.26","subcommand":["publish"]},"python":null,"implementation":{"name":null,"version":null},"distro":{"name":"Ubuntu","version":"24.04","id":"noble","libc":null},"system":{"name":null,"release":null},"cpu":null,"openssl_version":null,"setuptools_version":null,"rustc_version":null,"ci":null}

Release history Release notifications | RSS feed

This release

0.36.0 This release

2 release files

0.35.0

2 release files

0.34.0

2 release files

0.31.2

2 release files

0.31.1

2 release files

0.31.0

2 release files

0.30.1

2 release files

0.30.0

2 release files

0.27.0

2 release files

0.26.0

2 release files

0.24.1

2 release files

0.23.0

2 release files

0.22.0

2 release files

0.21.0

2 release files

0.20.0

2 release files

0.19.0

2 release files

0.11.0

2 release files

0.10.0

2 release files

0.9.0

2 release files

0.8.1

2 release files

0.8.0

2 release files

0.7.2

2 release files

0.7.1

2 release files

0.7.0

2 release files

0.5.1

2 release files

0.5.0

2 release files

0.4.0

2 release files

0.3.5

2 release files

0.3.4

2 release files

0.3.3

2 release files

0.3.2

2 release files

0.3.1

2 release files

0.3.0

2 release files

0.2.2

2 release files

0.2.1

2 release files

0.2.0

2 release files

Anthropic, PBC Visionary sponsor Bloomberg Visionary sponsor Hudson River Trading Visionary sponsor Meta Visionary sponsor NVIDIA Visionary sponsor Microsoft Sustainability sponsor Depot Continuous Integration AWS Cloud computing and Security Sponsor Datadog Monitoring Fastly CDN Google Download Analytics Sentry Error logging StatusPage Status page
