rionid 8.0.0

Ring-stored ion IDentification: A pure Python tool for Schottky spectrum analysis.

RionID (Ring-stored ion IDentification)

RionID is a Python software for the identification of ions stored in storage rings. It simulates revolution frequencies based on magnetic rigidity or frequency settings and matches them against experimental Schottky spectra.

Features

• Pure Python: No ROOT dependencies required.
• Automated Matching: Includes Quick PID logic to scan $\alpha_p$ and Reference Frequency to find the best match ($\chi^2$ minimization).
• Signal Processing: Built-in baseline subtraction (BrPLS) and peak detection.
• Standalone: Bundles barion and lisereader (GPL-3.0) for easy installation without complex dependency management.

Installation

Option 1: From PyPI (Recommended)

RionID is available on the Python Package Index. This is the easiest way to install it along with all dependencies.

pip install rionid

Option 2: From Source

If you want the development version:

git clone https://github.com/GSI-Nuclear-Astrophysics/rionid.git
cd rionid
pip install .

Usage

Graphical User Interface (GUI)

Once installed, you can launch the GUI simply by typing:

rionid

Command Line Interface (CLI)

You can also run simulations directly from the terminal:

rionid datafile.npz -f 11.2452 -r 209Bi+83 -psim fragments.lpp -b 5.5

Arguments

• datafile: Input spectrum file (.npz, .csv, .txt).
• -r, --refion: Reference ion (e.g., 72Ge+35).
• -ap, --alphap: Momentum compaction factor.
• -psim: LISE++ output file for fragment yields.
• -hrm: Harmonics to simulate.
• -b, --brho: Magnetic rigidity (Brho) [Tm].
• -f, --fref: Revolution frequency [Hz].
• --remove_baseline: Apply baseline subtraction.
• --peak_threshold_pct: Peak detection threshold (0.0 - 1.0).

Acknowledgements

• Dr. RuiJiu Chen for providing the C++ Time-of-Flight simulation code that inspired the backbone of this software.
• Dr. Shahab Sanjari for guidance on software architecture and Schottky analysis.

License

This project is licensed under the GNU General Public License v3.0. See the LICENSE file for details.
