Robot Data Audit (RDA)

PyPI Python License: MIT

Audit robot dataset quality. Local only.

RDA checks LeRobot-format datasets for data integrity, temporal consistency, and motion anomalies. It flags problematic episodes and reports what's wrong. RDA is a diagnostic tool only — it does not guarantee training success rate improvements.


Quick Start

pip install robot-data-audit           # install
rda audit /path/to/dataset             # audit → text + JSON report in <dataset>/rda_report.json

Sample Output

$ rda audit ~/datasets/my_robot_data

  ── Verdict ──
  PASS:    180 (90.0%)
  REVIEW:   15 ( 7.5%)
  EXCLUDE:   5 ( 2.5%)

  ── Top Issues ──
  1. [HIGH ★] Action discontinuity: 3421 spikes across 195 episodes
  2. [MEDIUM] High idle ratio: median 72% idle, 28% effective motion
  3. [LOW] Extreme acceleration spikes: 2847 across 180 episodes

Output options: --format json for scripting, -o FILE to save elsewhere.


Real Audit Results

Audited on ArmnetBench (SO-101 arm, 2,499 episodes) and DROID (100 episodes):

Metric ArmnetBench (2,499 ep) DROID (100 ep)
Action spikes detected 5,229 (200-ep subset run) 1,428
Median idle ratio 0.2% 8.6%
Median episode duration 22.4s (200-ep subset run) 15.0s
Verdict All PASS All PASS

Idle ratios re-measured at v0.12.3. The earlier values (68.6% / 70.7%) came from a 3 × MAD fallback that overshoots the median on continuously moving data; see docs/benchmark.md.

Both are curated benchmark datasets — all episodes pass. RDA also runs on noisier, real-world collections where REVIEW/EXCLUDE verdicts appear more frequently.

Full calibration analysis (ArmnetBench, comparing successful vs failure episodes by label): docs/ARMNETBENCH_CALIBRATION_REPORT.md


Design

  • Local only — No data leaves your machine. Runs entirely offline.
  • Diagnostic, not predictive — RDA identifies data issues. Whether fixing them improves training is a separate question and depends on your task, model, and setup.
  • Statistical anomaly detection — Uses MAD on reference distributions instead of fixed thresholds (no hardcoded 3σ rules). Adapts to each dataset's characteristics.
  • Universal core metrics — Primary ranking uses 3 platform-independent metrics (duration, spike_count, effective_motion_ratio). Platform-specific signals (velocity, path_length) are optional diagnostics.

See docs/MVP_PRODUCT_SPEC.md for full metric definitions.


Metrics

Tier Metric Detects Cross-platform?
L1 Timestamp monotonicity Clock resets, duplicates ✅
L1 Frame interval consistency Irregular sampling ✅
L1 Schema compliance Missing/extra fields ✅
L1 Numeric sanity Values exceeding loose physical bounds (angle/force/torque/velocity) ✅
L2 Temporal gap detection Time discontinuities ✅
L2 Sensor synchronization Multi-sensor drift ⚠️
L2 Temporal sufficiency Idle vs active structure ✅
L3 Velocity spikes Implausible jumps ️
L3 Motion discontinuities Jerky trajectories ⚠️
L3 Idle frame detection Paused segments ✅
L4 Duration outliers Too short / too long ✅
L4 Spike count outliers Unusual jerk profiles ✅
L4 Effective motion ratio Low-activity episodes ✅
SP Privacy/PII exposure scan (pii_scan) Identifiers in text surfaces, precise geolocation features, faces in sampled frames (--pii-video) ✅

pii_scan (v0.9.22+) covers YD/T 6771-2026's 安全性 dimension — the only P0 admission gate among the eight quality dimensions. It reports evidence a human must review, not compliance: WARNING-level by default (never changes the verdict), promoted to a gate only with --pii-strict. No OCR (licence plates, badges), no voice biometrics, no consent review. Findings carry a masked snippet plus a SHA-256 fingerprint — raw identifiers never reach the report.


CLI Reference

rda audit

rda audit /path/to/dataset [OPTIONS]
Option Description
-o, --output FILE Save JSON report (default: <path>/rda_report.json)
--format [json|text] Output format (default: text)
--platform TEXT Robot platform name for Tier 3 normalization
--blind Redact identifying paths and operator-authored free text for externally shareable reports
--pii-video Extend the privacy scan to sampled video frames (needs [pii] extra)
--pii-strict Treat privacy findings as an acceptance gate instead of a warning
--continue-on-unverifiable Keep exit 0 when episodes are UNVERIFIABLE instead of failing; records verifiability_override: true in the report
-v, --verbose Verbose output

Exit codes: 0 = no EXCLUDE, 1 = error, 2 = at least one EXCLUDE, 3 = audit completed but nothing was effectively audited (zero episodes, or every episode lacked auditable content) — never report this as a pass, 4 = at least one episode was UNVERIFIABLE: a critical check applies to it but its input is absent from this copy (typically videos never downloaded). Absence is not a pass — re-run on a complete copy, or pass --continue-on-unverifiable to record the override and keep exit 0.


Python API

from rda.audit.dataset_audit import DatasetAuditor
from rda.io.lerobot_loader import iter_episodes, load_lerobot_dataset

dataset_info = load_lerobot_dataset("/path/to/dataset")
auditor = DatasetAuditor()
result = auditor.audit_dataset(dataset_info, iter_episodes("/path/to/dataset"))
print(f"PASS: {result.verdict_counts['PASS']}")

Development

git clone https://github.com/liesliy/rda.git
cd rda
pip install -e ".[dev]"
pytest

Citation

@software{robot_data_audit,
  title     = {Robot Data Audit: Quality Auditing for Robot Manipulation Datasets},
  author    = {Niu Su Tech},
  year      = {2026},
  url       = {https://github.com/liesliy/rda}
}

License

MIT
