routerlurb 1.1.0

RouteRL is a multi-agent reinforcement learning framework for urban route choice in different city networks. This subpackage is developed to support its compatibility with URB until the full integration.

RouteRL

Multi-Agent Reinforcement Learning framework for modeling and simulating the collective route choices of humans and autonomous vehicles.

RouteRL is a novel framework that integrates Multi-Agent Reinforcement Learning (MARL) with a microscopic traffic simulation, SUMO, facilitating the testing and development of efficient route choice strategies. The proposed framework simulates the daily route choices of driver agents in a city, including two types:

• human drivers, emulated using discrete choice models,
• and AVs, modeled as MARL agents optimizing their policies for a predefined objective.

RouteRL aims to advance research in MARL, traffic assignment problems, social reinforcement learning (RL), and human-AI interaction for transportation applications.

For overview see the paper and for more details, check the documentation online.

RouteRL usage and functionalities at a glance

The following is a simplified code of a possible standard MARL algorithm implementation via TorchRL.

env = TrafficEnvironment(seed=42, **env_params) # initialize the traffic environment

env.start() # start the connection with SUMO

for episode in range(human_learning_episodes): # human learning
    env.step()

env.mutation() # some human agents transition to AV agents

collector = SyncDataCollector(env, policy, ...)  # collects experience by running the policy in the environment (TorchRL)

# training of the autonomous vehicles; human agents follow fixed decisions learned in their learning phase
for tensordict_data in collector:

    # update the policies of the learning agents
    for _ in range(num_epochs):
      subdata = replay_buffer.sample()
      loss_vals = loss_module(subdata)

      optimizer.step()
    collector.update_policy_weights_()

policy.eval() # set the policy into evaluation mode

# testing phase using the already trained policy
num_episodes = 100
for episode in range(num_episodes):
    env.rollout(len(env.machine_agents), policy=policy)

env.plot_results() # plot the results
env.stop_simulation() # stop the connection with SUMO

Documentation

• Tutorials:
  • Quickstart.
  • Medium network and AVs behaviors.
  • Big network and independent AV agents.
  • Large-scale network.

Installation

• Prerequisite: Make sure you have SUMO installed in your system. This procedure should be carried out separately, by following the instructions provided here.
• Option 1: Install the latest stable version from PyPI:

    pip install routerlurb


• Option 2: Clone this repository for latest version, and manually install its dependencies:

    git clone https://github.com/COeXISTENCE-PROJECT/RouteRL.git
    cd RouteRL
    pip install -r requirements.txt


Reproducibility capsule

We have an experiment script encapsulated in a CodeOcean capsule. This capsule allows demonstrating RouteRL's capabilities without the need for SUMO installation or dependency management.

1. Visit the capsule link.
2. Create a free CodeOcean account (if you don’t have one).
3. Click Reproducible Run to execute the code in a controlled and reproducible environment.

---

Credits

RouteRL is part of COeXISTENCE (ERC Starting Grant, grant agreement No 101075838) and is a team work at Jagiellonian University in Kraków, Poland by: Ahmet Onur Akman and Anastasia Psarou (main contributors) supported by Grzegorz Jamroz, Zoltán Varga, Łukasz Gorczyca, Michał Hoffmann and others, within the research group of Rafał Kucharski.
