routir 0.0.2

A simple and fast search service for hosting state-of-the-art retrieval models.

RoutIR: Fast Server for Hosting Retrieval Models for Retrieval-Augmented Generation

RoutIR is a Python package that provides a simple and efficient wrapper around arbitrary retrieval models, including first stage retrieval, reranking, query expansion, and result fusion, and provides efficient asynchronous query batching and serving.

Get Started

You can install routir in your environment through pip or uv.

pip install routir

RoutIR comes with a number of extras to install only the dependencies for the models you would like to serve. These extras include dense, gpu, plaidx, and sparse. You can instal any combinations, such as

pip install "routir[dense,gpu]"

To start the service, simply provide the config file to the cli command routir to start. You can also optionally specify the port through --port flag (default 8000).

routir config.json --port 5000

You can also use uvx to let uv creates a virtual environment on the fly for you:

uvx --with transformers --with torch routir config.json

Use --with to specify additional packages that you may need for serving the model. Please refer to uv documentation for more information.

Authentication

To protect the endpoint, set a Bearer token with --api_key (or the ROUTIR_API_KEY environment variable — preferred, since CLI args are visible in ps):

ROUTIR_API_KEY=sekret routir config.json --port 5000

When set, every request must carry an Authorization: Bearer <token> header. /ping stays open so liveness probes don't need credentials. When unset, the server accepts unauthenticated requests as before.

gRPC (optional)

In addition to the REST HTTP API, RoutIR can serve the same operations over gRPC for lower per-request overhead — especially useful for server-to-server traffic (e.g. relayed services in a distributed cluster). Install the extra and start the server with --grpc:

pip install "routir[grpc]"
routir config.json --port 5000 --grpc --grpc-port 50051

REST and gRPC run as two separate listeners in the same process and share the same in-process service registry, cache, and --api_key. The flags:

• --grpc — opt-in switch (off by default; REST-only behavior is identical to before this flag existed).
• --grpc-port — gRPC TCP port (default 50051).
• --grpc-max-message-mb — cap on inbound/outbound gRPC message size in MB (default 64).

The proto contract lives at src/routir/proto/routir.proto (package routir.v1). RPCs mirror the REST endpoints 1:1 (Ping, Avail, Search, Score, Content, Pipeline); generated stubs are checked into src/routir/proto/_generated/ so installers don't need protoc. Regenerate after editing the proto with bash scripts/build_proto.sh (requires routir[dev]).

Sharing one external port via nginx

REST and gRPC always bind to different in-process ports. If you need a single external port (e.g. HTTPS on :443), terminate TLS in nginx and route by path — gRPC requests target /routir.v1.Routir/*:

server {
    listen 443 ssl http2;

    location /routir.v1.Routir/ {
        grpc_pass grpc://localhost:50051;
    }

    location / {
        proxy_pass http://localhost:5000;
    }
}

This is the recommended production setup. RoutIR itself stays plaintext; nginx terminates TLS for both transports.

Configuration

The configuration file four major blocks: services, collections, server_imports, and file_imports.

• services and collections are list of object configuring each engine and each collection being served
• server_imports is list of external RoutIR endpoints that you would like to mirror in this endpoint. This will allow the end users to construct retrieval pipelines using services hosted on other machines. This is particularly helpful in a distributed compute cluster.
• file_imports is a list of custom Python scripts implemeting custom engines that RoutIR should load at initialization. More in the Extension section.

For example, if there are two other RoutIR instances running on compute01:5000 and compute02:5000 where each host plaidx-neuclir and RankLllama, you can import them as following. Users using this endpoint will be able to use both plaidx-neuclir and RankLlama. The following is an example config.

{
    "server_imports": [
        "http://compute01:5000",
        "http://compute02:5000",
    ],
    "file_imports": [
        "./examples/rank1_extension.py"
    ],
    "services": [
        {
            "name": "qwen3-neuclir",
            "engine": "Qwen3",
            "cache": 1024,
            "cache_ttl": 1024000,
            "batch_size": 32,
            "max_wait_time": 0.05,
            "config": {
                "index_path": "hfds:routir/neuclir-qwen3-8b-faiss-PQ2048x4fs",
                "api_key": "YOUR_API_KEY_HERE OR AT OPENAI_API_KEY ENVIRONMENT VARIABLE",
                "embedding_base_url": "https://api.fireworks.ai/inference/v1/",
                "embedding_model_name": "accounts/fireworks/models/qwen3-embedding-8b",
                "k_scale": 5
            }
        },
        {
            "name": "rank1",
            "engine": "Rank1Engine",
            "config": {}
        }
    ],
    "collections": [
        {
            "name": "neuclir",
            "doc_path": "./neuclir-doc.jsonl"
        }
    ]
}

If you want to use Redis for caching, add cache_redis_url and cache_redis_kwargs to the service object. If your Redis instance is password-protected (which you should), add password field to cache_redis_kwargs.

HTTP API

1. Available services: GET /avail. An example output of the service initiated with the previous example config would be:

{
    "content": ["neuclir"],
    "score": ["Rank1", "RankLlama"],
    "search": ["qwen3-neuclir", "plaidx-neuclir"],
    "fuse": ["RRF", "ScoreFusion"],
    "decompose_query": []
}

2. Search an index: POST /search. The following is an example request using cURL.

curl -X POST http://localhost:5000/search \
-H "Content-Type: application/json" \
-d '{"service": "qwen3-neuclir", "query": "my test queries", "limit": 15}'

Output:

{
  "cached": true,
  "processed": true,
  "query": "my test queries",
  "scores": {
    "05a83946-dca2-4518-9bc3-3d394394d5e3": 0.3807981014251709,
    "36faf9fc-3751-4047-bb1c-2bd90fa6f4d4": 0.3675723671913147,
    "3a9ba832-f689-4204-8627-96abd73be65f": 0.42572247982025146,
    "6a5b81f3-9154-4959-9e88-79edfcecb43f": 0.3666379451751709,
    "6b086402-a00c-4fd8-8772-fade1f4b3198": 0.3996303975582123,
    "76ec4dd1-fb6e-4a1e-b3e2-4b6214886e52": 0.3723523020744324,
    "8c6e9e63-ea22-406e-a841-2dc645a3d2e2": 0.4014992415904999,
    "90f2e4af-8a92-4869-9c73-013fead4876d": 0.3644096851348877,
    "9dc749e8-f7a7-4c76-9883-03c7bc620d92": 0.37544310092926025,
    "aa3542e0-0c62-4518-9a0a-07eaa5b1eb00": 0.3768806755542755,
    "aeba1a4c-e02e-4d37-898c-68732c05b7d9": 0.3764134645462036,
    "b564d3aa-983d-42a4-b5ba-e6d43e79c094": 0.3760540783405304,
    "e46324a8-e9fb-442f-806d-1ed8f0efb2b0": 0.37497588992118835,
    "f91c5cf9-020b-4019-a483-41aee141808c": 0.3672129511833191,
    "fd6f8822-ddf4-4264-a449-5ecc7884c8ec": 0.36940526962280273
  },
  "service": "qwen3-neuclir",
  "timestamp": 1761023408.7890506
}

3. Score/Rerank a list of text given a query: POST /score. This allows you to score/rerank arbitrary pieces of text, such as document content, pasages in a document for context compression, or generated reponses for ranking answer relevancy. The following is an example request:

curl -X POST http://localhost:5000/score \
-H "Content-Type: application/json" \
-d '{
    "service": "rank1",
    "query": "what is routir",
    "passages": [
        "routir is a python package",
        "sushi is the best food in the world"
    ]
}'

Output:

{
  "cached": false,
  "processed": true,
  "query": "what is routir",
  "scores": [
    0.9999997617631468,
    7.889264466868659e-06
  ],
  "service": "rank1",
  "timestamp": 1761026442.1780925
}

4. Search with dynamic pipeline: POST /pipeline. This allows the end users to construct an arbirary search pipeline with available engines on the fly. For example

curl -X POST http://localhost:5000/pipeline \
-H "Content-Type: application/json" \
-d '{
    "pipeline": "{qwen3-neuclir, plaidx-neuclir}RRF%50 >> rank1",
    "query": "which team is the world series champion in 2020?",
    "collection": "neuclir"
}'

Output:

{
  "cached": false,
  "collection": "neuclir",
  "pipeline": "{qwen3-neuclir, plaidx-neuclir}RRF%50 >> rank1",
  "processed": true,
  "query": "which team is the world series champion in 2020?",
  "scores": {
    "027b3f6f-3dc6-4e69-86ae-2a98f8c4a881": 0.999999712631481,
    "066e645a-a495-4622-bcc8-7a804f598bcf": 5.4222202626709005e-06,
    "0ced1751-181a-4abb-8d64-37c362ede67c": 0.9999986290429566,
    "1c0d1e33-ea2c-48f3-9422-6f81259095eb": 0.9999996940976272,
    "27b429cc-b2a0-43cf-8b2b-883796486780": 4.539786865487149e-05,
    "2d11d0a3-78de-4201-ad26-64a6ac4b148f": 1.8925157266468097e-05,
    "302d1c1a-d620-4971-a44c-c1faead39494": 1.6701429809483402e-05,
    "39d2608d-e0a5-4b52-bb0e-b04968e21a15": 0.033085980653064666,
    "3c3c49f3-24b1-4dad-ac57-35b0565ab9b8": 2.1444943303118133e-05,
    "6e65cae3-443d-4cdd-9efc-8dfb3e1fe0b1": 6.962258739847376e-06,
    "7e4a4d57-9e73-4fb6-8ea7-584d0549c508": 0.0052201256185966365,
    "7ecdc77d-ea8c-4d48-9235-c21df9086831": 0.9999999397642365,
    "8660ca1b-ef5a-4c3a-a3e9-692e1e686f07": 1.9947301971022554e-06,
    "88b3eff5-738a-4bcd-b31a-15d9f1b9e198": 3.288748281343353e-06,
    "940bb6ff-f88a-40cd-88c1-2ae719d1dc74": 0.99999980249468,
    "a3edc861-7cf5-4152-a32b-90961bd12b80": 1.8925155010490798e-05,
    "c26f5a26-e732-4deb-80d6-b3ad6b249927": 0.9999986290426297,
    "da57d712-c6a8-4fa3-8e68-7f21ea7d3167": 0.9999996072138465,
    "ed231d01-05d9-4ed6-98d6-97b4e3e64aae": 0.00317268301626477,
    "f3954f32-62e6-4cb3-9ef2-78fe3dcb8f7a": 1.9947304348917116e-06
  },
  "service": "rank1",
  "timestamp": 1761026586.5823486
}

Python Client

For Python callers, the routir.client subpackage provides a typed client that hides the wire details. It defaults to gRPC when available and transparently falls back to REST otherwise — so the same client code works against any RoutIR endpoint regardless of how it's configured.

from routir.client import AsyncClient

async with AsyncClient(
    endpoint="http://host:5000",      # REST base URL
    grpc_endpoint="host:50051",       # optional; omit to skip gRPC
    api_key="...",                    # optional Bearer token
) as c:
    print(c.transport)                # "grpc" or "rest"
    r = await c.search(service="qwen3-neuclir", query="hello", limit=10)
    s = await c.score(service="rank1", query="q", passages=["a", "b"])
    p = await c.pipeline(
        pipeline="{qwen3-neuclir, plaidx-neuclir}RRF%50 >> rank1",
        query="who won the 2020 world series?",
        collection="neuclir",
    )

A synchronous wrapper is available for non-async callers:

from routir.client import Client

with Client(endpoint="http://host:5000", grpc_endpoint="host:50051") as c:
    print(c.ping())

The first positional argument routes by URL scheme: http:///https:// go to the REST slot, grpc:///grpcs:// to the gRPC slot. Either is enough on its own:

AsyncClient("grpc://host:50051")          # gRPC only
AsyncClient("http://host:5000")           # REST only (or auto-discovers gRPC — see below)
AsyncClient("https://routir.example.com") # REST over TLS via reverse proxy

On the first call, an AsyncClient with transport="auto" (the default) probes the gRPC endpoint once. If reachable, it commits to gRPC for the lifetime of the client; on UNIMPLEMENTED, channel errors, or a missing grpcio install it falls back to REST and logs a warning. UNAUTHENTICATED does not trigger fallback — credential problems are surfaced rather than silently masked.

Auto-discovery. When only a plain http:// REST URL is supplied, the client queries /avail once on first use; if the server is running with --grpc, it advertises its grpc_port there, and the client switches itself to gRPC (logging a warning). Pass transport="rest" to opt out. This is skipped for https:// URLs because the advertised port isn't externally reachable in a reverse-proxy deployment.

Retries are differentiated per transport: REST retries on connection errors and HTTP 5xx (not 4xx); gRPC retries on UNAVAILABLE, DEADLINE_EXCEEDED, RESOURCE_EXHAUSTED, and ABORTED. Both transports share the same timeout, retries, and api_key settings.

See examples/client_tutorial.ipynb for a walkthrough.

The same client powers RoutIR's own server-to-server Relay engine, so server_imports entries can declare a grpc_endpoint to use gRPC for inter-server traffic:

{
    "server_imports": [
        {"endpoint": "http://compute01:5000", "grpc_endpoint": "compute01:50051"},
        "http://compute02:5000"
    ]
}

Plain strings (REST-only) are still accepted and behave as before.

Extension Examples

We provide several examples for integrating other IR toolkits with RoutIR. Please refer to each example for details.

[!WARNING] The Python script implementing the custom Engine needs to be imported through file_imports in the config. When using uvx, remember to put the essential packages at --with.

1. PyTerrier

python ./examples/pyterrier_extension.py # to build the index
uvx --with python-terrier routir ./examples/pyterrier_example_config.json --port 8000 # serve it at port 8000

2. Pyserini

uvx --with pyserini routir ./examples/pyserini_example_config.json --port 8000 # serve it at port 8000

3. Rank1

uvx --with mteb==1.39.0 --with vllm routir ./examples/rank1_example_config.json

The specific mteb version is crucial for this example.

Other Helper Scripts

Here is an example command to generate .npy files containing Qwen3 document embeddings from a .jsonl file with id, title, and text fields:

python -m routir.utils.qwen3_encode /path/to/docs.jsonl /output/path \
--id-field id --fields title text --docs-per-file 10000
--batch-size 8 --model-name Qwen/Qwen3-Embedding-8B

To provide reference for the FAISS index structure that RoutIR uses, you can refer to the routir.utils.faiss_indexing for details. Here is an example command to generate a FAISS index from a directory containing .npy files, each with features and ids fields (as generated by the above script):

python -m routir.utils.faiss_indexing \
./encoded_vectors/ ./faiss_index.PQ2048x4fs.IP/ \
--index_string "PQ2048x4fs" --use_gpu --sampling_rate 0.25

Contribution

We welcome any feedback, feature requests and pull requests. Please raise issues on GitHub. Feel free to reach out to us through emails, ACM SIGIR Slack, or GitHub issues.

Attribution

Please cite our paper if you use our RoutIR package.

@article{routir,
  title={RoutIR: Fast Serving of Retrieval Pipelines for Retrieval-Augmented Generation},
  author={Yang, Eugene and Yates, Andrew and Lawrie, Dawn and Mayfield, James and Adriaanse, Trevor},
  journal={arXiv preprint arXiv:2601.10644},
  year={2026}
}
