RuleTreeRank

RuleTreeRank (RTR) is an interpretable Learning-to-Rank framework that models ranking as a two-stage process: it first groups items with a shallow rule tree, then refines the score locally through instance-based comparisons.

RTR is designed for query-supported ranking problems. In candidate screening, for example, a query is a job offer and each item is a candidate. The same candidate can be relevant for one job and irrelevant for another, so the final ranking is induced within each query by sorting the RTR scores in descending order.

What RTR Does

• Stage I: rule-based grouping. A shallow RuleTreeRegressor partitions the feature space into interpretable leaves and assigns each item a coarse score.
• Stage II: local refinement. Inside each leaf, RTR learns an interpretable pairwise distance model and uses a local k-NN correction over the Stage-I residuals.
• Explanations. The first stage gives a decision path, while the second stage exposes the local neighbours and pairwise rules used for the correction.

The package also exposes MixedRTR, a query-aware variant that trains the local refinement by both tree leaf and query when query-specific historical context is required.

Installation

pip install ruletreerank

Latest development version:

pip install git+https://github.com/jacons/RuleTreeRank.git

From a clone, for development:

git clone https://github.com/jacons/RuleTreeRank.git
cd RuleTreeRank
python3 -m venv .venv && source .venv/bin/activate
pip install -e ".[dev]"
pytest

Requires Python 3.10 or newer.

Minimal Usage

import numpy as np
from RuleTree import RuleTreeRegressor

from ltr_utility import ModelParam
from ruletreerank import KNNRegFast, PairwiseDistanceTree, RuleTreeRank

X_train = np.random.default_rng(0).normal(size=(100, 5))
y_train = X_train @ np.array([1.4, -0.7, 0.5, 0.0, 0.2])
q_train = np.repeat(np.arange(10), 10)

model = RuleTreeRank(
    distance_f=ModelParam(PairwiseDistanceTree, {
        "base_regressor": ModelParam(RuleTreeRegressor, {"max_depth": 2, "random_state": 0}),
        "feature_concat": False,
        "feature_diff": True,
        "feature_sq_diff": True,
        "subsample": 0.5,
    }),
    aggregation_f=ModelParam(KNNRegFast, {"n_neighbors": 5, "n_jobs": 1}),
    base_regressor=RuleTreeRegressor(max_depth=2, random_state=0),
    dist_objective="residuals",
)

model.fit(X_train, y_train, q_train)

scores = model.predict(X_train, q=q_train, output="full")
ranking_for_query_0 = np.argsort(-scores[q_train == 0])

Mathematical View

Ranking data is represented as a collection of queries and their items:

$$ \mathcal{D} = {(q, X_q, y_q)}_{q \in \mathcal{Q}}, \quad X_q = {\mathbf{x}1,\ldots,\mathbf{x}{n_q}}. $$

RTR learns a two-stage pointwise scoring function:

$$ f(\mathbf{x}) = r(\mathbf{x}) + s(\mathbf{x}). $$

The first term, $r(\mathbf{x})$, is the score assigned by a shallow decision tree. If $\ell(\mathbf{x})$ is the leaf reached by item $\mathbf{x}$, the baseline score is the leaf mean:

$$ r(\mathbf{x}) = \frac{1}{|\ell(\mathbf{x})|} \sum_{\mathbf{x}_j \in \ell(\mathbf{x})} y_j. $$

Training residuals are then computed as $\varepsilon_j = y_j - r(\mathbf{x}_j)$. The second term, $s(\mathbf{x})$, is a local correction: for a test item $\mathbf{x}^\star$, RTR retrieves the $k$ nearest training items in the same leaf using a learned pairwise distance model, then averages their residuals:

$$ s(\mathbf{x}^\star) = \frac{1}{k} \sum_{\mathbf{x}_j \in N_k(\mathbf{x}^\star)} \varepsilon_j. $$

The final ranking for a query is obtained by sorting items by $f(\mathbf{x})$ in decreasing order.

Examples

• examples/min_example.ipynb: minimal RTR example on a scikit-learn dataset, with tables and plots showing the double-stage behaviour.
• examples/synthetic_ranking_task.ipynb: synthetic ranking task with a hidden linear scoring function and relevance labels induced by ranking.

Repository Layout

• src/ruletreerank/: core RTR, MixedRTR, pairwise distance tree, and fast k-NN components.
• src/ltr_utility/: shared interfaces, dataset utilities, query splitting, clustering, and explanation helpers.
• examples/: executable notebooks for minimal and synthetic ranking workflows.
• tests/: smoke test covering the two-stage fit/predict path.
