S2CONV: differentiable and accelerated spherical convolutions

S2CONV is a JAX package implementing the generalised lifted spherical convolution and the spherical convolutions it unifies, for scalar fields, spin fields and functions on the rotation group. All operators are differentiable, can be JIT compiled and run on GPUs, and are exact for band-limited signals. The harmonic transforms are those of S2FFT.

The generalised lifted convolution 🌐

A spin-$s$ field on the sphere is lifted to the rotation group $\mathrm{SO}(3)$ through the irreducible representation of spin $s$ of the stabiliser, convolved on $\mathrm{SO}(3)$ with a kernel $\Psi$, and projected back to the sphere through the adjoint of the lift for a possibly different spin $s'$:

\mathcal{C}_{s\to s'}[\Psi] = \Lambda_{s'}^{\dagger}\,(\Psi\star\Lambda_s\,\cdot\,),\qquad
\mathcal{C}_{s\to G}[\Psi] = \Psi\star\Lambda_s\,\cdot\,,\qquad
\mathcal{C}_{G\to s'}[\Psi] = \Lambda_{s'}^{\dagger}\,(\Psi\star\cdot\,),\qquad
\mathcal{C}_{G\to G}[\Psi] = \Psi\star\cdot\,.

In harmonic space each operator reads a single entry, column, row or the whole block of the Wigner coefficients of the kernel. For example, a spin $s \to s'$ convolution multiplies each harmonic coefficient by a single Wigner coefficient of the kernel,

\left(\mathcal{C}_{s\to s'}[\Psi]\,{}_sf\right)_{\ell m} = (-1)^{s+s'}\,{}_sf_{\ell m}\,\Psi^{\ell *}_{-s',-s},

and every bounded rotation-equivariant map between spin fields is of this form. The convolutions of the literature differ only in their kernels.

The non-equivariant constructions that keep the output of a directional kernel on the sphere are also provided, as evaluations of a lifted convolution on a section of the bundle (standard correlation, commutative anisotropic convolution; section) or as harmonic-diagonal operators (harmonic multiplication, sifting; diagonal).

Transform backends ⚡

S2CONV delegates the spin spherical harmonic and Wigner transforms to S2FFT, through s2conv.transforms, with a choice of backend:

All backends except "numpy" are differentiable in reverse mode (jax.grad, jax.vjp); "jax" and "precompute" can be JIT compiled and run on GPUs. Forward mode (jax.jvp, jax.jacfwd) works through "precompute", and through "jax" with S2FFT 1.5.0 or later, but not through "jax_ssht". The harmonic operators themselves support both modes.

Installation 💻

S2CONV requires Python 3.11 or later, and is tested on Python 3.11, 3.12 and 3.13 (on 3.13 it needs S2FFT 1.5.0 or later). Install it from PyPI with

pip install s2conv

which also installs its dependencies, JAX and S2FFT. To install the development version instead, run pip install . from a clone of this repository. The optional extras are tests (the test suite), notebooks (the Marimo notebooks), docs (the documentation) and ssht (the "jax_ssht" backend). For GPU support install a CUDA build of JAX, following the JAX installation guide.

Usage 🚀

Enable double precision before using S2CONV, as for S2FFT:

import jax

jax.config.update("jax_enable_x64", True)

import jax.numpy as jnp
import numpy as np
import s2conv
from s2fft.utils.signal_generator import generate_flm

L = 32
rng = np.random.default_rng(0)
f = s2conv.inverse(generate_flm(rng, L, spin=2), L, spin=2)  # a spin-2 field on the MW grid

A spin $2 \to 1$ convolution with a Gaussian multiplier, directly or through its canonical kernel and the generalised lifted convolution:

el = np.arange(L)
c = np.exp(-0.5 * el * (el + 1) * 0.05**2)
g = s2conv.convolve_multiplier(f, c, L, s_in=2, s_out=1)

kernel = s2conv.kernels.multiplier(c, s_in=2, s_out=1)
g = s2conv.convolve(f, kernel, L, s_in=2, s_out=1)

A directional convolution with a steerable spin-2 kernel, whose output on the rotation group is a tuple of spin fields:

flm = s2conv.forward(f, L, spin=2)
psi = generate_flm(rng, L, spin=2) * (np.abs(np.arange(-(L - 1), L)) < 4)  # orders |n| < 4
F = s2conv.classical.directional_convolution(flm, psi, spin=2, N=4)  # Wigner coefficients
F_samples = s2conv.wigner_inverse(F, L, N=4)  # samples on SO(3)
spins = s2conv.lifting.spin_components(F)  # spin fields s' = -3, ..., 3

The operators are JAX functions, so they can be compiled and differentiated:

@jax.jit
def loss(c):
    return jnp.sum(jnp.abs(s2conv.convolve_multiplier(f, c, L, s_in=2, s_out=1)) ** 2)

grad = jax.grad(loss)(jnp.asarray(c))

Harmonic-space operators (s2conv.lifted, s2conv.classical, s2conv.physics, s2conv.diagonal) act on coefficients in the S2FFT layout and broadcast over leading axes, so that batches, channels or spins can be carried as leading dimensions or mapped with jax.vmap.

Notebooks 📓

Two Marimo notebooks run in the browser on molab, which installs their dependencies from the list at the top of each file:

• notebooks/lifted_convolutions.py demonstrates each convolution with S2CONV and checks it numerically against the closed forms of the article, a literal evaluation on a sampling of the rotation group and the real-space definitions.
• notebooks/real_fields.py applies the lifted convolutions to real spin fields of the Earth and the sky.

To run them locally, install the package with the notebook extras,

pip install ".[notebooks]"
marimo edit notebooks/lifted_convolutions.py

or let Marimo install the dependencies in an isolated environment with uv, marimo edit --sandbox notebooks/lifted_convolutions.py.

Equivariance tests 📐

s2conv.utils.equivariance measures the rotational equivariance of any operator with the protocol of Cobb et al. (2021) and Ocampo et al. (2023). It takes the mean, over random band-limited signals and Haar-random rotations, of the relative error ‖T(𝓡f) − 𝓡(Tf)‖ / ‖𝓡(Tf)‖, and reports alongside it the normalisation ‖T(𝓡f)‖ of those papers. The script benchmarks/equivariance.py applies this to every operator of the package at the scale of the papers, 100 signals × 100 rotations. It tabulates the equivariance errors, reduction errors and timings as markdown, JSON and LaTeX, each stamped with the git commit of the code that produced it:

python benchmarks/equivariance.py -L 16 32 64 -o equivariance.json --latex equivariance.tex

In double precision the equivariant operators give errors of about 10⁻¹⁵ (about 2 × 10⁻⁷ in single precision), while the section-evaluated and harmonic-diagonal operators give errors of order one. The user guide has the details.

The script benchmarks/scaling.py times the four lifted convolutions against band-limit L, with the azimuthal band-limit N fixed, on one CPU core, and plots the times against an L³ reference, the scaling of their transforms (user guide):

python benchmarks/scaling.py -o scaling.json --plot scaling.pdf > scaling.md

Tests 🚦

pip install .[tests]
pytest

The tests marked slow run every operator of the equivariance benchmark at 20 signals × 20 rotations; pytest -m "not slow" skips them.

Contributors ✨

Thanks goes to these wonderful people (emoji key):

Jason McEwen 💻 🤔 🔬 📖 🚧 👀

This project follows the all-contributors specification, and we welcome contributions of any kind; see CONTRIBUTING.md.

Attribution 📚

S2CONV implements the construction of the article Unifying spherical convolutions through lifting (J. D. McEwen, 2026, forthcoming); please cite it, and S2FFT, if you use this code:

@unpublished{mcewen2026unifying,
   author      = "Jason D. McEwen",
   title       = "Unifying spherical convolutions through lifting",
   year        = "2026",
   note        = "Forthcoming"
}

@article{price:s2fft,
   author      = "Matthew A. Price and Jason D. McEwen",
   title       = "Differentiable and accelerated spherical harmonic and Wigner transforms",
   journal     = "Journal of Computational Physics",
   year        = "2024",
   volume      = "510",
   pages       = "113109",
   eprint      = "arXiv:2311.14670",
   doi         = "10.1016/j.jcp.2024.113109"
}

License 📝

S2CONV is released under the MIT licence (see LICENCE.txt).
