samapy 1.0.4

SAMAPy - Solar Alone Multi-objective Advisor for Hybrid Renewable Energy Systems Python Package

SAMAPy: Solar Alone Multi-Objective Advisor Python

Solar Alone Multi-Objective Advisor - Python Package

Free and open-source hybrid renewable energy system optimization
FAST Research Group, Western University, London, Ontario, Canada

---

SAMAPy is an open-source Python package for the optimal sizing and techno-economic analysis of hybrid renewable energy systems (HRES). Developed at the FAST Research Group, Western University, it combines physics-based energy simulation with state-of-the-art metaheuristic optimization to find the lowest-cost system configuration that satisfies reliability and renewable energy constraints.

SAMAPy handles the full modelling stack (solar PV, wind turbines, battery storage, diesel generators, grid interconnection, heat pumps, and electric vehicles) under real-world utility pricing structures including Time-of-Use, tiered rates, and Ontario's Ultra-Low Overnight tariff.

---

Table of Contents

• Key Features
• Supported Components
• Optimization Algorithms
• Installation
• Quick Start
• CLI Workflow
• Python API
• Input Data
• Outputs
• Examples
• Contributing
• License
• Citation

---

Key Features

• Multi-component modelling: PV, wind, battery (Li-ion & lead-acid), diesel generator, grid, heat pump (Bosch & Goodman), and EV with V2G
• 8 electricity rate structures: flat, seasonal, monthly, tiered, seasonal-tiered, monthly-tiered, TOU, and ultra-low overnight (ULO)
• 8 natural gas rate structures: supporting $/m³, $/kWh, and $/therm pricing with automatic unit conversion
• 4 metaheuristic optimizers: PSO, ADE, GWO, and ABC, each tunable from a YAML config
• Comprehensive economic analysis: NPC, LCOE, IRR, payback period, cash flow charts, avoided-cost breakdown
• Net Energy Metering (NEM): annual credit reconciliation with configurable caps
• Rich result outputs: 15+ publication-quality figures, hourly CSV data, and printed performance tables
• Interactive configuration wizard: samapy-config guides you through every parameter and writes a ready-to-run YAML file
• One-command optimization: samapy-run reads your YAML and launches the chosen algorithm

---

Supported Components

Component	Models / Options
Solar PV	Monofacial, configurable tilt & azimuth, SAM-based POA irradiance
Wind Turbine	Generic power curve, hub-height wind-shear correction
Battery	Li-ion (default), Lead-Acid
Diesel Generator	Generic linear fuel curve
Grid	Buy/sell with NEM, configurable import/export limits
Heat Pump	Bosch (BOVA series), Goodman — full COP lookup tables
Electric Vehicle	V2G capable, travel-pattern modelling, degradation tracking

---

Optimization Algorithms

Algorithm	Flag	Strengths
Particle Swarm Optimization	pso	Fast convergence, well-tuned defaults
Advanced Differential Evolution	ade	Self-adaptive, good for multimodal problems
Grey Wolf Optimizer	gwo	Strong global search
Artificial Bee Colony	abc	Balanced exploration / exploitation

---

Installation

Requires Python 3.9 or later.

## Installation

### Stable release (V 1.0.1)
pip install samapy

### Testing release (for testers and early adopters), to install the latest test version from TestPyPI:

pip install -i https://test.pypi.org/simple/ --extra-index-url https://pypi.org/simple/ samapy

To install the latest development version directly from source:

git clone https://github.com/Sas1997/SAMA.git
cd SAMA
pip install -e .

Verify the installation:

python -c "import samapy; print('SAMAPy installed successfully')"

---

Quick Start

The fastest way to run SAMAPy is through its two CLI commands.

Step 1: Generate a configuration file

samapy-config

This launches an interactive wizard that walks you through every system parameter — components, pricing, economics, optimizer settings — and writes a samapy_config_COMPLETE.yaml file in your working directory.

Step 2: Run the optimization

samapy-run

SAMAPy reads your YAML, runs the chosen algorithm, and saves all results to samapy_outputs/.

Step 3: Inspect results

samapy_outputs/
├── figs/
│   ├── Cash_Flow.svg
│   ├── Energy Distribution.png
│   ├── Battery State of Charge.png
│   ├── Grid Hourly Cost.png
│   ├── hp_heating_performance.png
│   ├── hp_cop_vs_temp.png
│   └── ...
└── data/
    └── Outputforplotting.csv

---

CLI Workflow

samapy-config

samapy-config

Launches the step-by-step configuration wizard. No arguments required. Produces samapy_config_COMPLETE.yaml.

samapy-run

samapy-run [OPTIONS]

Options:
  -c, --config PATH      Path to YAML config  [default: samapy_config_COMPLETE.yaml]
  -a, --algorithm ALGO   Override algorithm: pso | ade | gwo | abc
  --output DIR           Override output directory  [default: samapy_outputs]
  --dry-run              Validate config without running
  --no-gui               Disable matplotlib GUI (for headless servers)
  --verbose              Show full parameter load log and config summary

Examples:

# Use defaults
samapy-run

# Explicit config path and algorithm
samapy-run -c my_project/config.yaml -a ade

# Validate config without running optimization
samapy-run --dry-run --verbose

# Run on a headless server
samapy-run --no-gui --output /results/run_01

---

Python API

For programmatic use, scripting, and integration into research workflows.

Minimal example

from samapy.cli.config_loader import load_config, apply_config
from samapy.optimizers.swarm import Swarm

# Load a wizard-generated YAML
config = load_config("samapy_config_COMPLETE.yaml")
indata = apply_config(config)

# Run PSO optimization
optimizer = Swarm()
optimizer.optimize()

Accessing content data files

SAMAPy bundles default weather and load data. Use get_content_path to locate them reliably regardless of where the package is installed:

from samapy import get_content_path

meteo_path  = get_content_path("METEO.csv")
eload_path  = get_content_path("Eload.csv")
house_path  = get_content_path("house_load.xlsx")

Accessing input data

After apply_config (or directly after import), all simulation parameters live on the InData singleton:

from samapy.core.Input_Data import InData

print(f"Annual load:     {InData.Eload.sum():.0f} kWh")
print(f"Peak irradiance: {InData.G.max():.0f} W/m²")
print(f"Min temperature: {InData.T.min():.1f} °C")
print(f"Discount rate:   {InData.ir*100:.2f}%")

Generating results manually

from samapy.results.Results import Gen_Results
import numpy as np

# X = [N_PV, N_WT, N_bat, N_DG, Cn_inverter]
X = np.array([12.0, 0.0, 8.0, 0.0, 10.5])
Gen_Results(X, output_dir="my_outputs")

---

Input Data

Required files

File	Description	Format
Eload.csv	Hourly electrical load	8760 rows, 1 column, kWh
METEO.csv	Hourly weather data	NSRDB/SAM format with header
house_load.xlsx	Hourly heating & cooling loads	Column 1: heating kWh, Column 2: cooling kWh

Place your files in the working directory and point to them via the wizard or YAML config. SAMAPy copies them into the package content folder automatically.

Built-in defaults

SAMAPy ships with London, Ontario TMY data so you can run a test optimization immediately after installation without providing any files.

Weather data

Weather data must follow the NSRDB CSV format (as exported from https://nsrdb.nrel.gov). SAMAPy uses NREL's SAM libraries internally to compute plane-of-array (POA) irradiance from the global horizontal values in the file.

---

Outputs

Console output

SAMAPy prints a full techno-economic summary after every optimization run:

------------- System Size --------------
Cpv  (kW) = 12.0
Cbat (kWh) = 8.004
Cdg  (kW) = 0.0
Cinverter (kW) = 10.5

************* Economic Results *************
NPC  = $ 48,321.44
LCOE = 0.14 $/kWh
IRR  = 8.73%
Payback Period: 9 years

============ Technical Results =============
PV Power  = 18,432 kWh
RE  = 94.32 %
LPSP Total = 0.00 %

Figures saved to samapy_outputs/figs/

File	Description
Cash_Flow.svg	Annual cash flow waterfall with cumulative total
Cash Flow_ADV.png	Cash flow vs. grid-only baseline
Energy Distribution.png	Hourly power dispatch over the year
Battery State of Charge.png	Battery SOC profile
Grid Interconnection.png	Hourly grid import and export
Grid Hourly Cost.png	Colour map of hourly electricity price
Specific day results.png	Detailed 24-hour dispatch for a sample day
electricity_comparison.png	Bill comparison: with vs. without system
hp_heating_performance.png	HP heating load vs. electrical power consumed
hp_cooling_performance.png	HP cooling load vs. electrical power consumed
hp_cop_vs_temp.png	COP as a function of ambient temperature
hp_monthly_summary.png	Monthly energy, power, and COP bar charts
EV Energy.png	EV SOC and charge/discharge profile

Data saved to samapy_outputs/data/

File	Description
Outputforplotting.csv	Full 8760-row hourly dataset of all power flows, prices, SOC, and environmental variables

---

Examples

See the Examples and Sample Optimization Output sections of the documentation for five complete worked examples covering:

1. Basic solar + battery + grid: the simplest grid-tied PV system
2. Full hybrid system: PV + wind + battery + diesel generator
3. Heat pump integration: adding a Goodman or Bosch heat pump
4. Electric vehicle (V2X): EV with vehicle-to-grid discharge
5. YAML-driven workflow: using the wizard output programmatically

---

Contributing

Contributions are welcome. Please open an issue to discuss your idea before submitting a pull request.

1. Fork the repository
2. Create a feature branch (git checkout -b feature/your-feature)
3. Commit your changes with clear messages
4. Push and open a pull request against main

Please follow PEP 8 style and include docstrings for any new public functions.

---

License

SAMAPy is distributed under the GNU General Public License v3.0. See License for the full text.

---

Citation

If you use SAMAPy in your research, please cite:

@software{sadat2024samapy,
  author    = {Sadat, Seyyed Ali},
  title     = {{SAMAPy}: Solar Alone Multi-Objective Advisor — Python Package},
  year      = {2024},
  url       = {https://github.com/Sas1997/SAMA},
  note      = {FAST Research Group, Western University, London, Ontario, Canada}
}

---

Contact

Seyyed Ali Sadat, FAST Research Group, Western University 📧 [e-mail] 🔗 github.com/Sas1997/SAMA
