sangfor-scp 0.2.0

Sangfor Cloud Platform (SCP) Open-API Python Client Library

sangfor-scp

📖 Live Examples & API Docs →

Sangfor Cloud Platform (SCP) Open-API Python Client Library

A clean, Pythonic wrapper for the Sangfor Cloud Platform REST API. Supports EC2 (AWS4-HMAC-SHA256) and Token-based authentication with a single login on initialization — no repeated auth delays between calls.

---

Features

• Single login — authenticate once in __init__, session reused for all requests
• Auto token refresh — 24-hour tokens renewed transparently
• Automatic pagination — list_all() iterates every page lazily; no manual page tracking needed
• Async task support — tasks.wait() polls until completion, raises on failure or timeout
• Idempotency — automatic X-Client-Token headers on POST/PUT requests
• Both auth methods — EC2 signature (recommended) and Token-based (RSA encrypted)
• SSL flexibility — optional SSL verification disable (for self-signed certs)

Covered APIs (Top 20 Critical Features)

Resource	Operations
Virtual Machines	list, get, create, update/rename, delete, power on/off/reboot/suspend, clone, migrate, console URL, password reset, batch ops, soft delete & restore
Tasks	get, wait (with timeout & progress callback)
Resource Pools (AZ)	list, get, overview, storage tags
Tenants	list, get, find by name
VPC Networks	list, create, get, update, delete
Subnets	list, create, get, delete
Images	list (ISO/aCloud), get
Volumes (Disks)	list, create, get, delete, resize, attach, detach
Elastic IPs	allocate, bind, unbind, release, update bandwidth
Physical Hosts	list, get, interfaces
System	version, maintenance mode, platform info, license

---

Installation

pip install sangfor-scp

With Token-based authentication support (RSA encryption):

pip install sangfor-scp[token-auth]

---

Quick Start

EC2 Authentication (Recommended)

from sangfor_scp import SCPClient

client = SCPClient(
    host="10.134.37.79",
    access_key="your_access_key",
    secret_key="your_secret_key",
    region="cn-south-1",
    verify_ssl=False,   # SCP uses self-signed certs by default
)

Token-Based Authentication

from sangfor_scp import SCPClient

client = SCPClient(
    host="10.134.37.79",
    username="admin",
    password="your_password",
    verify_ssl=False,
)

---

Usage Examples

List All Virtual Machines

# Iterates all pages automatically — no pagination code needed
for vm in client.servers.list_all():
    print(vm["id"], vm["name"], vm["status"])

# Filter by resource pool
for vm in client.servers.list_all(az_id="az-uuid", status="running"):
    print(vm["name"])

Create a VM and Wait for Completion

result = client.servers.create(
    az_id="az-uuid",
    image_id="image-uuid",
    storage_tag_id="storage-tag-uuid",
    cores=2,
    memory_mb=2048,
    name="my-vm",
    networks=[{
        "vif_id": "net0",
        "vpc_id": "vpc-uuid",
        "subnet_id": "subnet-uuid",
        "connect": 1,
        "model": "virtio",
    }],
    power_on=True,
)

# Wait up to 5 minutes for the VM to be ready
task = client.tasks.wait(result["task_id"], timeout=300)
vm_id = result["uuids"][0]
print(f"VM created: {vm_id}")

Rename / Update a VM

# Rename
task_id = client.servers.rename("vm-uuid", "new-name")
client.tasks.wait(task_id)

# Update multiple properties at once (only passed fields are changed)
task_id = client.servers.update(
    "vm-uuid",
    name="renamed-vm",
    cores=4,
    memory_mb=8192,
    description="Updated description",
)
client.tasks.wait(task_id)

Power Operations

client.servers.stop("vm-uuid")
client.servers.stop("vm-uuid", force=True)     # force power off
client.servers.start("vm-uuid")
client.servers.reboot("vm-uuid")
client.servers.reboot("vm-uuid", force=True)   # force reboot
client.servers.suspend("vm-uuid")

Clone a VM

result = client.servers.clone(
    "vm-uuid",
    name="cloned-vm",
    az_id="az-uuid",           # optional: target resource pool
    storage_tag_id="tag-uuid", # optional: target storage
)
client.tasks.wait(result["task_id"])
new_vm_id = result["uuid"]

Migrate a VM

# Migrate to a specific host (None = auto-select)
task_id = client.servers.migrate("vm-uuid", host_id="host-uuid")
client.tasks.wait(task_id)

Get Console URL (VNC/SPICE/RDP)

info = client.servers.get_console("vm-uuid")
print(info["url"])   # Open in browser for noVNC console

# SPICE console
info = client.servers.get_console("vm-uuid", protocol="spice")

Batch Operations

vm_ids = ["vm-uuid-1", "vm-uuid-2", "vm-uuid-3"]

# Soft delete (move to recycle bin)
client.servers.soft_delete(vm_ids)

# Restore from recycle bin
task_id = client.servers.restore("vm-uuid-1")
client.tasks.wait(task_id)

# Other batch actions
client.servers.batch_action(vm_ids, "start_servers_action")
client.servers.batch_action(vm_ids, "stop_servers_action")
client.servers.batch_action(vm_ids, "reboot_servers_action")

Disk Management

# Create a standalone disk
result = client.volumes.create(
    az_id="az-uuid",
    storage_tag_id="tag-uuid",
    size_mb=102400,   # 100 GB
    name="data-disk",
)
client.tasks.wait(result["task_id"])
volume_id = result["volume_id"]

# Attach to a VM
task_id = client.servers.attach_volume("vm-uuid", volume_id)
client.tasks.wait(task_id)

# Detach
task_id = client.servers.detach_volume("vm-uuid", volume_id)
client.tasks.wait(task_id)

Network Management

# List VPCs
for vpc in client.networks.list_vpcs(az_id="az-uuid"):
    print(vpc["id"], vpc["name"])

# Create Subnet
result = client.networks.create_subnet(
    vpc_id="vpc-uuid",
    az_id="az-uuid",
    cidr="192.168.10.0/24",
    name="subnet-app",
    gateway_ip="192.168.10.1",
)

# List subnets in a VPC
for subnet in client.networks.list_subnets(vpc_id="vpc-uuid"):
    print(subnet["id"], subnet["cidr"])

Elastic IP

# Allocate
eip = client.eips.allocate(az_id="az-uuid", bandwidth_mb=100)
eip_id = eip["id"]

# Bind to a VM
task_id = client.eips.bind(eip_id, server_id="vm-uuid")
client.tasks.wait(task_id)

# Unbind and release
client.eips.unbind(eip_id)
client.eips.release(eip_id)

Platform Overview

# Resource utilization summary
overview = client.resource_pools.overview()
print(f"Total VMs: {overview['server']['total']}")
print(f"Running VMs: {overview['server']['running_count']}")

# SCP version
info = client.system.version()
print(info["build_version"])

Async Task with Progress Callback

def on_progress(task_data):
    print(f"Progress: {task_data['progress']}% — {task_data.get('description', '')}")

task = client.tasks.wait(
    task_id="task-uuid",
    timeout=600,
    poll_interval=5,
    progress_callback=on_progress,
)

Manual Pagination

# Get a single page with full metadata
page = client.servers.list_page(page_num=0, page_size=10)
print(f"Total VMs: {page['total_size']}")
print(f"Next page: {page['next_page_num']}")

# Count without fetching all records
total = client.servers.count(az_id="az-uuid")
print(f"VM count in pool: {total}")

---

Error Handling

from sangfor_scp import (
    SCPError,
    SCPNotFoundError,
    SCPAuthError,
    SCPRateLimitError,
    SCPTaskError,
    SCPTimeoutError,
)

try:
    vm = client.servers.get("nonexistent-id")
except SCPNotFoundError:
    print("VM not found")

try:
    task = client.tasks.wait("task-uuid", timeout=60)
except SCPTaskError as e:
    print(f"Task failed: {e.message}")
    print(f"Task data: {e.task_data}")
except SCPTimeoutError as e:
    print(f"Timed out after {e.timeout}s")

---

Requirements

• Python >= 3.8
• requests >= 2.28.0
• urllib3 >= 1.26.0
• pycryptodome >= 3.17 (only for Token-based auth)

---

SCP Version Compatibility

SCP Version	Supported
5.8.8R6+	Basic APIs
6.3.0+	Full VM, Tenant, Network APIs
6.3.70+	AK/SK self-service, Tenant resource pool query
6.8.0+	Banner alerts, Email, G2H proxy, EIP APIs
6.10.0+	Extended host query APIs
6.11.1+	Latest API version (20240725)

---

License

MIT License — see LICENSE for details.

---

Special Thanks

🏆 A Tribute to the Man Who Started It All

Thank you, Onur Çılbır.

Not every hero wears a cape. Some wear a smile while casually introducing their colleagues to a 200-page Chinese cloud platform API specification and saying "it shouldn't be that hard."

Onur Çılbır is that hero. Or villain. The line is blurry at this point.

It was Onur who, with the enthusiasm of someone who clearly would not be doing the actual implementation, introduced us to Sangfor Cloud Platform — a technology so full of surprises that we are still finding new ones. AWS4-HMAC-SHA256 signatures, RSA-encrypted passwords, version-specific endpoints, pagination quirks, and the eternal mystery of next_page_num: "" — none of this would have been possible without his generous recommendation.

"It has an Open API, it'll be straightforward," — Onur Çılbır, allegedly.

Thanks to Onur, we now intimately understand what it means to spend an afternoon reading about idempotency tokens, only to discover that the endpoint you need was added in "SCP 6.3.70 and later." We have read more XML-era authentication documentation than any living person should. We have emerged changed. Possibly for the worse.

We did not ask for this. But here we are, and we shipped it anyway.

— The grateful (and slightly traumatized) survivors of this project
