sb3-extra-buffers

Unofficial implementation of extra Stable-Baselines3 buffer classes. Aims to reduce memory usage drastically with minimal overhead. Featured in SB3 docs :-)

Links:

• My Master's Thesis (which started this as a side project)
• Stable Baselines3
• SB3 Contrib (experimental features for SB3)
• SBX (SB3 + JAX, uses SB3 buffers so can also benefit from compressed buffers here)
• RL Baselines3 Zoo (training framework for SB3)

Description: Tired of reading a cool RL paper and realizing that the author is storing a MILLION observations in their replay buffers? Yeah me too. This project has implemented several compressed buffer classes that replace Stable Baselines3's standard buffers like ReplayBuffer and RolloutBuffer. With as simple as 2-5 lines of extra code and negligible overhead, memory usage can be reduced by more than 95%! Please consider citing this project if this is helpful to your research :-)

Main Goal: Reduce the memory consumption of memory buffers in Reinforcement Learning while adding minimal overhead.

Installation

Install via PyPI:

pip install "sb3-extra-buffers[fast,extra]"

Other install options:

pip install "sb3-extra-buffers"          # only installs minimum requirements
pip install "sb3-extra-buffers[extra]"   # installs extra dependencies for SB3
pip install "sb3-extra-buffers[fast]"    # installs python-isal, numba, zstd, lz4
pip install "sb3-extra-buffers[isal]"    # only installs python-isal
pip install "sb3-extra-buffers[numba]"   # only installs numba
pip install "sb3-extra-buffers[zstd]"    # only installs python-zstd
pip install "sb3-extra-buffers[lz4]"     # only installs python-lz4
pip install "sb3-extra-buffers[vizdoom]" # installs vizdoom

Current Progress & Available Features:

• Memory Saving: reported here
• Progress Tracker Issue: https://github.com/Trenza1ore/sb3-extra-buffers/issues/1

Motivation: Reinforcement Learning is quite memory-hungry due to massive buffer sizes, so let's try to tackle it by not storing raw frame buffers in full np.float32 or np.uint8 directly and find something smaller instead. For any input data that are sparse and containing large contiguous region of repeating values, lossless compression techniques can be applied to reduce memory footprint.

Applicable Input Types:

• Semantic Segmentation masks (1 color channel)
• Color Palette game frames from retro video games
• Grayscale observations
• RGB (Color) observations
• For noisy input with a lot of variation (mostly RGB), using zstd is recommended, run-length encoding won't work as great and can potentially even increase memory usage. See benchmark.

Implemented Compression Methods:

• none No compression other than casting to elem_type and storing as bytes.
• rle Vectorized Run-Length Encoding for compression.
• rle-jit JIT-compiled version of rle, uses numba library.
• gzip Built-in gzip compression via gzip.
• igzip Intel accelerated variant via isal.igzip, uses python-isal library.
• zstd Zstandard compression via python-zstd. (Recommended)
• lz4-frame LZ4 (frame format) compression via python-lz4.
• lz4-block LZ4 (block format) compression via python-lz4.

• gzip supports 0~9 compression levels, 0 is no compression, 1 is least compression
• igzip supports 0~3 compression levels, 0 is least compression
• zstd supports 1~22 standard compression levels and -100~-1 ultra-fast compression levels, -100 is fastest and 22 is slowest.
• lz4-frame supports 0~16 standard compression levels and negative levels translates into acceleration factor.
• lz4-block supports three modes, split into positive/zero/negative compression levels. 1~12 are in high_compression mode and negative levels translates into acceleration factor in fast mode, setting 0 enables default mode.
• Shorthands are supported (for lz4 methods including / is required):
  • pattern = ^((?:[A-Za-z]+)|(?:[\w\-]+/))(\-?[0-9]+)$
  • igzip3 = igzip/3 = igzip level 3
  • zstd-5 = zstd/-5 = zstd level -5
  • lz4-frame/5 = lz4-frame level 5

Benchmark for Compressed Buffers (on MsPacmanNoFrameskip-v4)

• Frame Stack & Vec Envs: both 4
• Buffer Size: 40,000 (split across 4 vectorized environments)
• Notes: Performed on an M4 Macbook Air, so igzip doesn't benefit from Intel's SIMD acceleration, also data transfer between CPU & GPU may have lower latency.
• Saving Test: The example DQN / PPO model loaded and evaluated using the code in examples, DQN for saving test, PPO for loading test. The exact same observations are stored into each buffer for fairness. Latency refers to the total number of seconds spent on adding observation to / sampling from the specific buffer and baseline refers to using ReplayBuffer / RolloutBuffer directly.
• Loading Test: Sample all trajectories from rollout buffers with batch size of 64, target device: mps. SB3's RolloutBuffer stores np.float32 observations so it's 4x the size of np.uint8.
• TLDR:
  • zstd in general is very decent at save latency & memory saving, personally I recommend zstd-3.
  • zstd-1 ~ zstd-5 seems to be the sweet spot.
  • gzip0 should be avoided, saving / loading has similar latency as zstd-5, but 13x bigger.
  • MsPacman at 84x84 resolution is too visually noisy for rle , although decompression isn't half-bad

Example Usage

from stable_baselines3 import PPO
from stable_baselines3.common.utils import get_linear_fn
from stable_baselines3.common.callbacks import EvalCallback
from sb3_extra_buffers.compressed import CompressedRolloutBuffer, find_buffer_dtypes
from sb3_extra_buffers.training_utils.atari import make_env

ATARI_GAME = "MsPacmanNoFrameskip-v4"

if __name__ == "__main__":
    # Get the most suitable dtypes for CompressedRolloutBuffer to use
    obs = make_env(env_id=ATARI_GAME, n_envs=1, framestack=4).observation_space
    compression = "rle-jit"  # or use "igzip1" since it's relatively noisy
    buffer_dtypes = find_buffer_dtypes(obs_shape=obs.shape, elem_dtype=obs.dtype, compression_method=compression)

    # Create vectorized environments after the find_buffer_dtypes call, which initializes jit
    env = make_env(env_id=ATARI_GAME, n_envs=8, framestack=4)
    eval_env = make_env(env_id=ATARI_GAME, n_envs=10, framestack=4)

    # Create PPO model with CompressedRolloutBuffer as rollout buffer class
    model = PPO("CnnPolicy", env, verbose=1, learning_rate=get_linear_fn(2.5e-4, 0, 1), n_steps=128,
                batch_size=256, clip_range=get_linear_fn(0.1, 0, 1), n_epochs=4, ent_coef=0.01, vf_coef=0.5,
                seed=1970626835, rollout_buffer_class=CompressedRolloutBuffer,
                rollout_buffer_kwargs=dict(dtypes=buffer_dtypes, compression_method=compression))

    # Evaluation callback (optional)
    eval_callback = EvalCallback(eval_env, n_eval_episodes=20, eval_freq=8192, log_path=f"./logs/{ATARI_GAME}/ppo/eval",
                                 best_model_save_path=f"./logs/{ATARI_GAME}/ppo/best_model")

    # Training
    model.learn(total_timesteps=10_000_000, callback=eval_callback, progress_bar=True)

    # Save the final model
    model.save("ppo_MsPacman_4.zip")

    # Cleanup
    env.close()
    eval_env.close()

Current Project Structure

sb3_extra_buffers
    |- compressed
    |    |- CompressedRolloutBuffer: RolloutBuffer with compression
    |    |- CompressedReplayBuffer: ReplayBuffer with compression
    |    |- CompressedArray: Compressed numpy.ndarray subclass
    |    |- find_buffer_dtypes: Find suitable buffer dtypes and initialize jit
    |
    |- recording
    |    |- RecordBuffer: A buffer for recording game states
    |    |- FramelessRecordBuffer: RecordBuffer but not recording game frames
    |    |- DummyRecordBuffer: Dummy RecordBuffer, records nothing
    |
    |- training_utils
         |- eval_model: Evaluate models in vectorized environment
         |- warmup: Perform buffer warmup for off-policy algorithms

Example Scripts

Example scripts have been included and tested to ensure working properly.

Evaluation results for example training scripts:

PPO on PongNoFrameskip-v4, trained for 10M steps using rle-jit, framestack: None

(Best ) Evaluated 10000 episodes, mean reward: 21.0 +/- 0.00
Q1:   21 | Q2:   21 | Q3:   21 | Relative IQR: 0.00 | Min: 21 | Max: 21
(Final) Evaluated 10000 episodes, mean reward: 21.0 +/- 0.02
Q1:   21 | Q2:   21 | Q3:   21 | Relative IQR: 0.00 | Min: 20 | Max: 21

PPO on MsPacmanNoFrameskip-v4, trained for 10M steps using rle-jit, framestack: 4

(Best ) Evaluated 10000 episodes, mean reward: 2667.0 +/- 290.00
Q1: 2300 | Q2: 2490 | Q3: 3000 | Relative IQR: 0.28 | Min: 2300 | Max: 3000
(Final) Evaluated 10000 episodes, mean reward: 2500.9 +/- 221.03
Q1: 2300 | Q2: 2390 | Q3: 2490 | Relative IQR: 0.08 | Min: 1420 | Max: 3000

DQN on MsPacmanNoFrameskip-v4, trained for 10M steps using rle-jit, framestack: 4

(Best ) Evaluated 10000 episodes, mean reward: 3300.0 +/- 770.79
Q1: 2490 | Q2: 4020 | Q3: 4020 | Relative IQR: 0.38 | Min: 2460 | Max: 4020
(Final) Evaluated 10000 episodes, mean reward: 3379.2 +/- 453.78
Q1: 2690 | Q2: 3400 | Q3: 3880 | Relative IQR: 0.35 | Min: 1230 | Max: 4090

Pytest

Make sure pytest and optionally pytest-xdist are already installed. Tests are compatible with pytest-xdist since DummyVecEnv is used for all tests.

# pytest
pytest tests -v --durations=0 --tb=short
# pytest-xdist
pytest tests -n auto -v --durations=0 --tb=short

Saving Test Observations: By default, test observations are saved to debug_obs/ for manual inspection during testing. To disable saving observations (e.g., in CI/CD to avoid unnecessary disk I/O), set the DISABLE_TEST_OBSERVATIONS_SAVE environment variable:

# Disable saving test observations (e.g., for CI/CD)
DISABLE_TEST_OBSERVATIONS_SAVE=true pytest tests -v

Compressed Buffers

Defined in sb3_extra_buffers.compressed

JIT Before Multi-Processing: When using rle-jit, remember to trigger JIT compilation before any multi-processing code is executed via find_buffer_dtypes or init_jit.

# Code for other stuffs...

# Get observation space from environment
obs = make_env(env_id=ATARI_GAME, n_envs=1, framestack=4).observation_space

# Get the buffer datatype settings via find_buffer_dtypes
compression = "rle-jit"
buffer_dtypes = find_buffer_dtypes(obs_shape=obs.shape, elem_dtype=obs.dtype, compression_method=compression)

# Now, safe to initialize multi-processing environments!
env = SubprocVecEnv(...)

Cite This Project

If you use this project in your research or work, please cite:

@article{Huang2025EnhancingRL,
  title={Enhancing Reinforcement Learning in 3D Environments through Semantic Segmentation: A Case Study in ViZDoom},
  author={Hugo Huang},
  journal={ArXiv},
  year={2025},
  volume={abs/2511.11703},
  url={https://arxiv.org/abs/2511.11703},
}

I really appreciate it :-)
