Scaler Distribution Framework

Project description

Citi

Citi/scaler

Efficient, lightweight, and reliable distributed computation engine.

PyPI - Version


Scaler provides a simple, efficient, and reliable way to perform distributed computing using a centralized scheduler, with a stable and language-agnostic protocol for client and worker communications.

import math
from scaler import Client

with Client(address="tcp://127.0.0.1:2345") as client:
    # Compute a single task using `.submit()`
    future = client.submit(math.sqrt, 16)
    print(future.result())  # 4

    # Submit multiple tasks with `.map()`
    results = client.map(math.sqrt, [(i,) for i in range(100)])
    print(sum(results))  # 661.46

Scaler is a suitable Dask replacement, offering significantly better scheduling performance for jobs with a large number of lightweight tasks while improving on load balancing, messaging, and deadlocks.

Features

  • Distributed computing across multiple cores and multiple servers
  • Python reference implementation, with language-agnostic messaging protocol built on top of Cap'n Proto and ZeroMQ
  • Graph scheduling, which supports Dask-like graph computing, with optional GraphBLAS support for very large graph tasks
  • Automated load balancing, which automatically balances load from busy workers to idle workers, ensuring uniform utilization across workers
  • Automated task recovery from worker-related hardware, OS, or network failures
  • Support for nested tasks, allowing tasks to submit new tasks
  • top-like monitoring tools
  • GUI monitoring tool

Installation

Scaler is available on PyPI and can be installed using any compatible package manager.

$ pip install scaler

# or with graphblas and uvloop support
$ pip install scaler[graphblas,uvloop]

Quick Start

The official documentation is available at citi.github.io/scaler/.

Scaler has 3 main components:

  • A scheduler, responsible for routing tasks to available computing resources.
  • A set of workers that form a cluster. Workers are independent computing units, each capable of executing a single task.
  • Clients running inside applications, responsible for submitting tasks to the scheduler.

Start local scheduler and cluster programmatically in code

A local scheduler and a local set of workers can be conveniently started using SchedulerClusterCombo:

from scaler import SchedulerClusterCombo

cluster = SchedulerClusterCombo(address="tcp://127.0.0.1:2345", n_workers=4)

...

cluster.shutdown()

This will start a scheduler with 4 workers on port 2345.

Setting up a computing cluster from the CLI

The scheduler and workers can also be started from the command line with scaler_scheduler and scaler_cluster.

First, start the Scaler scheduler:

$ scaler_scheduler tcp://127.0.0.1:2345
[INFO]2023-03-19 12:16:10-0400: logging to ('/dev/stdout',)
[INFO]2023-03-19 12:16:10-0400: use event loop: 2
[INFO]2023-03-19 12:16:10-0400: Scheduler: monitor address is ipc:///tmp/127.0.0.1_2345_monitor
...

Then, start a set of workers (a.k.a. a Scaler cluster) that connects to the previously started scheduler:

$ scaler_cluster -n 4 tcp://127.0.0.1:2345
[INFO]2023-03-19 12:19:19-0400: logging to ('/dev/stdout',)
[INFO]2023-03-19 12:19:19-0400: ClusterProcess: starting 4 workers, heartbeat_interval_seconds=2, object_retention_seconds=3600
[INFO]2023-03-19 12:19:19-0400: Worker[0] started
[INFO]2023-03-19 12:19:19-0400: Worker[1] started
[INFO]2023-03-19 12:19:19-0400: Worker[2] started
[INFO]2023-03-19 12:19:19-0400: Worker[3] started
...

Multiple Scaler clusters can be connected to the same scheduler, providing distributed computation over multiple servers.

-h lists the available options for the scheduler and the cluster executables:

$ scaler_scheduler -h
$ scaler_cluster -h

Submitting Python tasks using the Scaler client

Knowing the scheduler address, you can connect and submit tasks from a client in your Python code:

from scaler import Client


def square(value: int):
    return value * value


with Client(address="tcp://127.0.0.1:2345") as client:
    future = client.submit(square, 4) # submits a single task
    print(future.result()) # 16

Client.submit() returns a standard Python future.

Graph computations

Scaler also supports graph tasks, for example:

from scaler import Client


def inc(i):
    return i + 1


def add(a, b):
    return a + b


def minus(a, b):
    return a - b


graph = {
    "a": 2,
    "b": 2,

    # the input to task c is the output of task a
    "c": (inc, "a"),  # c = a + 1 = 2 + 1 = 3
    "d": (add, "a", "b"),  # d = a + b = 2 + 2 = 4
    "e": (minus, "d", "c")  # e = d - c = 4 - 3 = 1
}

with Client(address="tcp://127.0.0.1:2345") as client:
    result = client.get(graph, keys=["e"])
    print(result)  # {"e": 1}

Nested computations

Scaler allows tasks to submit new tasks while being executed. Scaler also supports recursive task calls.

from scaler import Client


def fibonacci(client: Client, n: int):
    if n == 0:
        return 0
    elif n == 1:
        return 1
    else:
        a = client.submit(fibonacci, client, n - 1)
        b = client.submit(fibonacci, client, n - 2)
        return a.result() + b.result()


with Client(address="tcp://127.0.0.1:2345") as client:
    future = client.submit(fibonacci, client, 8)
    print(future.result()) # 21

IBM Spectrum Symphony integration

A Scaler scheduler can interface with IBM Spectrum Symphony to provide distributed computing across Symphony clusters.

$ scaler_symphony_cluster tcp://127.0.0.1:2345 ScalerService --base-concurrency 4

This will start a Scaler worker that connects to the Scaler scheduler at tcp://127.0.0.1:2345 and uses the Symphony service ScalerService to submit tasks.

Symphony service

A service must be deployed in Symphony to handle the task submission.

Here is an example of a service that can be used
class Message(soamapi.Message):
    def __init__(self, payload: bytes = b""):
        self.__payload = payload

    def set_payload(self, payload: bytes):
        self.__payload = payload

    def get_payload(self) -> bytes:
        return self.__payload

    def on_serialize(self, stream):
        payload_array = array.array("b", self.get_payload())
        stream.write_byte_array(payload_array, 0, len(payload_array))

    def on_deserialize(self, stream):
        self.set_payload(stream.read_byte_array("b"))

class ServiceContainer(soamapi.ServiceContainer):
    def on_create_service(self, service_context):
        return

    def on_session_enter(self, session_context):
        return

    def on_invoke(self, task_context):
        input_message = Message()
        task_context.populate_task_input(input_message)

        fn, *args = cloudpickle.loads(input_message.get_payload())
        output_payload = cloudpickle.dumps(fn(*args))

        output_message = Message(output_payload)
        task_context.set_task_output(output_message)

    def on_session_leave(self):
        return

    def on_destroy_service(self):
        return

Nested tasks

Nested task originating from Symphony workers must be able to reach the Scaler scheduler. This might require modifications to the network configuration.

Nested tasks can also have unpredictable resource usage and runtimes, which can cause Symphony to prematurely kill tasks. It is recommended to be conservative when provisioning resources and limits, and monitor the cluster status closely for any abnormalities.

Base concurrency

Base concurrency is the maximum number of unnested tasks that can be executed concurrently. It is possible to surpass this limit by submitting nested tasks which carry a higher priority. Important: If your workload contains nested tasks the base concurrency should be set to a value less to the number of cores available on the Symphony worker or else deadlocks may occur.

A good heuristic for setting the base concurrency is to use the following formula:

base_concurrency = number_of_cores - deepest_nesting_level

where deepest_nesting_level is the deepest nesting level a task has in your workload. For instance, if you have a workload that has a base task that calls a nested task that calls another nested task, then the deepest nesting level is 2.

Performance

uvloop

By default, Scaler uses Python's built-in asyncio event loop. For better async performance, you can install uvloop (pip install uvloop) and supply uvloop for the CLI argument --event-loop or as a keyword argument for event_loop in Python code when initializing the scheduler.

scaler_scheduler --event-loop uvloop tcp://127.0.0.1:2345
from scaler import SchedulerClusterCombo

scheduler = SchedulerClusterCombo(address="tcp://127.0.0.1:2345", event_loop="uvloop", n_workers=4)

Monitoring

From the CLI

Use scaler_top to connect to the scheduler's monitor address (printed by the scheduler on startup) to see diagnostics/metrics information about the scheduler and its workers.

$ scaler_top ipc:///tmp/127.0.0.1_2345_monitor

It will look similar to top, but provides information about the current Scaler setup:

scheduler          | task_manager         |   scheduler_sent         | scheduler_received
      cpu     0.0% |   unassigned       0 |   ObjectResponse      24 |          Heartbeat 183,109
      rss 37.1 MiB |      running       0 |         TaskEcho 200,000 |    ObjectRequest      24
                   |      success 200,000 |             Task 200,000 |               Task 200,000
                   |       failed       0 |       TaskResult 200,000 |         TaskResult 200,000
                   |     canceled       0 |   BalanceRequest       4 |    BalanceResponse       4
--------------------------------------------------------------------------------------------------
Shortcuts: worker[n] cpu[c] rss[m] free[f] working[w] queued[q]

Total 10 worker(s)
                 worker agt_cpu agt_rss [cpu]   rss free sent queued | object_id_to_tasks
W|Linux|15940|3c9409c0+    0.0%   32.7m  0.0% 28.4m 1000    0      0 |
W|Linux|15946|d6450641+    0.0%   30.7m  0.0% 28.2m 1000    0      0 |
W|Linux|15942|3ed56e89+    0.0%   34.8m  0.0% 30.4m 1000    0      0 |
W|Linux|15944|6e7d5b99+    0.0%   30.8m  0.0% 28.2m 1000    0      0 |
W|Linux|15945|33106447+    0.0%   31.1m  0.0% 28.1m 1000    0      0 |
W|Linux|15937|b031ce9a+    0.0%   31.0m  0.0% 30.3m 1000    0      0 |
W|Linux|15941|c4dcc2f3+    0.0%   30.5m  0.0% 28.2m 1000    0      0 |
W|Linux|15939|e1ab4340+    0.0%   31.0m  0.0% 28.1m 1000    0      0 |
W|Linux|15938|ed582770+    0.0%   31.1m  0.0% 28.1m 1000    0      0 |
W|Linux|15943|a7fe8b5e+    0.0%   30.7m  0.0% 28.3m 1000    0      0 |
  • scheduler section shows scheduler resource usage
  • task_manager section shows count for each task status
  • scheduler_sent section shows count for each type of messages scheduler sent
  • scheduler_received section shows count for each type of messages scheduler received
  • function_id_to_tasks section shows task count for each function used
  • worker section shows worker details, , you can use shortcuts to sort by columns, and the * in the column header shows which column is being used for sorting
    • agt_cpu/agt_rss means cpu/memory usage of worker agent
    • cpu/rss means cpu/memory usage of worker
    • free means number of free task slots for this worker
    • sent means how many tasks scheduler sent to the worker
    • queued means how many tasks worker received and queued

From the web UI

scaler_ui provides a web monitoring interface for Scaler.

$ scaler_ui ipc:///tmp/127.0.0.1_2345_monitor --port 8081

This will open a web server on port 8081.

Slides and presentations

We showcased Scaler at FOSDEM 2025. Check out the slides here.

Contributing

Your contributions are at the core of making this a true open source project. Any contributions you make are greatly appreciated.

We welcome you to:

Please review our community contribution guidelines and functional contribution guidelines to get started 👍.

Code of Conduct

We are committed to making open source an enjoyable and respectful experience for our community. See CODE_OF_CONDUCT for more information.

License

This project is distributed under the Apache-2.0 License. See LICENSE for more information.

Contact

If you have a query or require support with this project, raise an issue. Otherwise, reach out to opensource@citi.com.

Project details


Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Source Distribution

scaler-1.9.9.tar.gz (6.5 MB view details)

Uploaded Source

Built Distributions

scaler-1.9.9-cp313-cp313-manylinux_2_28_x86_64.whl (843.6 kB view details)

Uploaded CPython 3.13manylinux: glibc 2.28+ x86-64

scaler-1.9.9-cp312-cp312-manylinux_2_28_x86_64.whl (843.6 kB view details)

Uploaded CPython 3.12manylinux: glibc 2.28+ x86-64

scaler-1.9.9-cp311-cp311-manylinux_2_28_x86_64.whl (843.6 kB view details)

Uploaded CPython 3.11manylinux: glibc 2.28+ x86-64

scaler-1.9.9-cp310-cp310-manylinux_2_28_x86_64.whl (843.6 kB view details)

Uploaded CPython 3.10manylinux: glibc 2.28+ x86-64

File details

Details for the file scaler-1.9.9.tar.gz.

File metadata

  • Download URL: scaler-1.9.9.tar.gz
  • Upload date:
  • Size: 6.5 MB
  • Tags: Source
  • Uploaded using Trusted Publishing? Yes
  • Uploaded via: twine/6.1.0 CPython/3.13.2

File hashes

Hashes for scaler-1.9.9.tar.gz
Algorithm Hash digest
SHA256 cc1189b8db1ffab08c94c534f991abc847bb05d70e0703c244fde7502d4fd82f
MD5 63b95e81445ccd7d24f941d0be9b03f7
BLAKE2b-256 9155fdb65933f1e2703699494b9eed1f36cbd1398cfe1a1819c27d64dbb12974

See more details on using hashes here.

Provenance

The following attestation bundles were made for scaler-1.9.9.tar.gz:

Publisher: pypi.yml on Citi/scaler

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

File details

Details for the file scaler-1.9.9-cp313-cp313-manylinux_2_28_x86_64.whl.

File metadata

File hashes

Hashes for scaler-1.9.9-cp313-cp313-manylinux_2_28_x86_64.whl
Algorithm Hash digest
SHA256 3e77be94411754c4aad2640c65e6319a042f72606a14230fce12804163d5d1fc
MD5 f00565c74e60a9876560f9481e1380f6
BLAKE2b-256 dd898c261ef760f95ca00acb21a2875f156f7ead729d1e426d9371187c23dc04

See more details on using hashes here.

Provenance

The following attestation bundles were made for scaler-1.9.9-cp313-cp313-manylinux_2_28_x86_64.whl:

Publisher: pypi.yml on Citi/scaler

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

File details

Details for the file scaler-1.9.9-cp312-cp312-manylinux_2_28_x86_64.whl.

File metadata

File hashes

Hashes for scaler-1.9.9-cp312-cp312-manylinux_2_28_x86_64.whl
Algorithm Hash digest
SHA256 150cfd08998b8d8ea7544bbfdedf148fa4b9746cc094fc4c7614d87d702fc97c
MD5 0862f0a970d0c40d8cbb49a4d494ce68
BLAKE2b-256 7f63f093dcf659923befe5cd804a02275917988bd2da1412b6cd613a919f7d09

See more details on using hashes here.

Provenance

The following attestation bundles were made for scaler-1.9.9-cp312-cp312-manylinux_2_28_x86_64.whl:

Publisher: pypi.yml on Citi/scaler

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

File details

Details for the file scaler-1.9.9-cp311-cp311-manylinux_2_28_x86_64.whl.

File metadata

File hashes

Hashes for scaler-1.9.9-cp311-cp311-manylinux_2_28_x86_64.whl
Algorithm Hash digest
SHA256 ebe7dcb73d50cade835ac4a5370edbc6d70ee3c059941d14eb11ddd7526fc23a
MD5 eb390efcb37690e951175cd381e847a3
BLAKE2b-256 a2775b7b9879f1c2bdb0b95cdc5553a53965361203a601b7ff739b3633a03dda

See more details on using hashes here.

Provenance

The following attestation bundles were made for scaler-1.9.9-cp311-cp311-manylinux_2_28_x86_64.whl:

Publisher: pypi.yml on Citi/scaler

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

File details

Details for the file scaler-1.9.9-cp310-cp310-manylinux_2_28_x86_64.whl.

File metadata

File hashes

Hashes for scaler-1.9.9-cp310-cp310-manylinux_2_28_x86_64.whl
Algorithm Hash digest
SHA256 76f85afdde3ac1c518b4e3055eeb01f548ddf5a490d852f1ba5bfc8878ea2ea3
MD5 e7754a86935d1d4354d47c042f3de6b8
BLAKE2b-256 774240c81eb07518e1d7c6c65d6d527a72a71f7a0e5cc637f17147fd795bc4c9

See more details on using hashes here.

Provenance

The following attestation bundles were made for scaler-1.9.9-cp310-cp310-manylinux_2_28_x86_64.whl:

Publisher: pypi.yml on Citi/scaler

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

Supported by

AWS Cloud computing and Security Sponsor Datadog Monitoring Fastly CDN Google Download Analytics Pingdom Monitoring Sentry Error logging StatusPage Status page
