schema crush

a modular framework for semantic schema matching that aligns heterogeneous biomedical schemas to fhir standards using calibrated matchers, curated knowledge, and optional llm-assisted review.

built on expert-curated fhir aggregator mappings (gdc, htan) with human-in-the-loop feedback and guarded calibration.

data statement

this repository ships source code, expert-curated mapping tables, pre-trained calibrators, and documentation. it contains no patient-level data. the htan, tcga, and geo exports used during development are excluded by .gitignore and must be obtained from their original sources. see examples/fetch_geo.py for a reproducible download of the public geo datasets.

install

pip install -r requirements.txt

or

pip install -e .

usage

map a csv file to fhir:

python examples/map_csv.py data.csv --entity patient -o mappings.json

entity types:

• patient -> Patient, Condition, Observation
• sample -> Specimen, Observation
• file -> DocumentReference, Observation

output:

[
  {"source": "patient_id", "target": "Patient.identifier", "confidence": 1.0},
  {"source": "diagnosis", "target": "Condition.code", "confidence": 0.85}
]

options:

python examples/map_csv.py data.csv -e patient              # with csv profiler (default)
python examples/map_csv.py data.csv -e patient --no-profile # skip profiling
python examples/map_csv.py data.csv -e patient --no-llm-profile  # heuristics only
python examples/map_csv.py data.csv -e sample -o out.json   # save to file
python examples/map_csv.py data.csv -e file -n 5            # limit to first 5 columns

run demos:

python examples/demo_claude_agent.py

geo data workflow

download public GEO datasets and map them to FHIR.

1. fetch geo data

# list available datasets
python examples/fetch_geo.py --list

# download one dataset (default: GSE71729)
python examples/fetch_geo.py GSE71729

# download all pancreatic cancer datasets
python examples/fetch_geo.py --all

this downloads to data/geo/:

• GSE*_metadata.csv - full sample metadata
• GSE*_clinical.csv - parsed clinical characteristics
• GSE*_expression.csv - gene expression matrix (if available)

curated pancreatic datasets: GSE62452, GSE28735, GSE15471, GSE21501, GSE57495, GSE71729

2. map to fhir

# map clinical columns to FHIR fields
python examples/map_csv.py data/geo/GSE71729_clinical.csv -e sample -o mappings.json

3. review mappings

output shows source -> target with confidence:

[
  {"source": "sample_id", "target": "Specimen.identifier", "confidence": 1.0},
  {"source": "tumor_subtype", "target": "Observation.valueCodeableConcept", "confidence": 0.85},
  {"source": "survival_months", "target": "Observation.valueQuantity", "confidence": 0.85},
  {"source": "death_event_1death_0censor", "target": "Patient.deceasedBoolean", "confidence": 0.95}
]

example: full pipeline

# 1. fetch GEO data
python examples/fetch_geo.py GSE71729

# 2. map with profiling (interprets cryptic column names)
python examples/map_csv.py data/geo/GSE71729_clinical.csv -e sample

# 3. save mappings to file
python examples/map_csv.py data/geo/GSE71729_clinical.csv -e sample -o mappings.json

csv profiling

the csv profiler analyzes your data before mapping to understand:

• use case: survival analysis, variant tracking, lab results, staging/grading, etc.
• column relationships: survival_time + death_event pairs, tnm groupings
• cryptic column names: death_event_1death_0censor -> "binary survival indicator (1=death, 0=censored)"

this context helps the llm make better mapping decisions for ambiguous fields.

example profile output:

{
  "use_case": "survival_analysis",
  "analysis_purpose": "clinical survival data from geo for pancreatic cancer cohort",
  "column_groups": {
    "survival": ["survival_months", "death_event_1death_0censor"],
    "staging": ["stage", "t_stage", "n_stage"]
  },
  "recommendations": {
    "death_event_1death_0censor": "binary survival indicator -> Patient.deceasedBoolean (1=true, 0=false)"
  }
}

core architecture

layer	component	description
data	mappings/flat.py	flatmappingdatabase with source/destination/contentvalue structures
knowledge	knowledge/mapping_rules/	curated mapping rules (gdc, htan -> fhir)
embedders	tools/embeddings/	biobert (biomedical) + magneto (schema-trained)
matchers	tools/matchers/	biobertmatcher, magnetomatcher, rulematcher
calibration	orchestrator/calibration.py	tier-aware confidence calibration
agent	orchestrator/agents/	claudeagent with llm tool-calling (optional)
feedback	learning/feedback_store.py	hitl decisions for evaluation and guarded retraining
retrieval	learning/mapping_vector_store.py	chromadb semantic index (rebuildable from sqlite)

curated knowledge sources

source	description
gdc	genomic data commons -> fhir mappings
htan	human tumor atlas network -> fhir mappings
others	additional fhir aggregator sources

these datasets provide expert-curated source -> fhir mappings. schema crush does not fine-tune models on this data; it uses it to build a canonical mapping database and to calibrate matcher confidence.

fhir aggregator data (used for calibration)

source	patients	specimens	observations	documents
gdc	44,736	593,840	807,834	1,121,816
cda	159,047	742,505	833,168	-
htan	2,080	7,532	214,853	196,158
gtex	980	43,559	1	49
icgc	400	813	401	15,063
1000genome	3,500	3,500	1	48
cellosaurus	1,677	1,717	1	-

3-tier matching strategy

tier	task	example
entity	table -> fhir resource	case -> Patient
field	column -> fhir path	participant_id -> Patient.identifier
content	value -> fhir code	"Adenocarcinoma" -> snomed ct 35917007

implementation status

component	status	notes
flatmappingdatabase	done	o(1) lookup, sqlite cache
biobert embedder	done	dmis-lab/biobert-v1.1
magneto embedder	done	schema-trained on gdc
rulematcher	done	96.9% accuracy
biobert matcher	done	overconfident (needs calibration)
magneto matcher	done	best for field matching
claudeagent	done	llm with tool-calling + fast path
calibration system	done	context-aware backoff calibration
knowledgebase	done	unified loader for all knowledge
vector store	done	chromadb for similarity search
pearl orchestrator	partial	state machine defined, needs updates
feedback store	done	sqlite-backed with traceability
hitl interface	missing	web/cli ui for review
adaptive weights	missing	auto-adjust tool weights
cli integration	missing	schema_crush match source.csv

matcher performance (legacy - pre-calibration)

matcher	precision@1	recall@5	accuracy	notes
rulematcher	97%	97%	96.9%	best - uses knowledge base
magneto	25%	65%	13.3%	good for field names
biobert	5%	15%	8.2%	overconfident, needs calibration

see calibration system section below for current tier-aware results

calibration system

what is calibrated confidence?

a classifier is calibrated when its predicted confidence equals its actual accuracy: if a model says "90% confident", it should be correct 90% of the time. most ml models are overconfident — they output high scores even when wrong.

calibration learns a mapping from raw scores to true probabilities using held-out data:

P(correct | confidence = c) ≈ c   (perfectly calibrated)

we measure calibration quality using expected calibration error (ECE):

ECE = Σ (|Bₘ|/n) · |acc(Bₘ) - conf(Bₘ)|

where Bₘ are confidence bins, acc() is accuracy within bin, conf() is mean confidence. lower ECE = better calibrated. a perfectly calibrated model has ECE = 0.

reliability diagrams visualize this: plot accuracy vs confidence per bin — a calibrated model follows the diagonal.

references: platt scaling (platt, 1999), temperature scaling (guo et al., 2017), histogram binning (zadrozny & elkan, 2001).

how confidence is computed

confidence scores come from different sources depending on the matching path:

path	confidence source	calibrated?
exact match	1.0 hardcoded — found verbatim in knowledge base	n/a (always correct)
fuzzy match	fuzzywuzzy string similarity ratio (0-1)	no (empirically reliable >0.85)
embedding match	cosine similarity from biobert/magneto	yes — mapped via calibration curves
llm fallback	model's self-reported confidence	no (uncalibrated)

example:

sample_id -> 1.0    # exact lookup in flat_mappings.db
tissue -> 0.9       # fuzz.ratio("tissue", "TumorTissueType") ≈ 90%
tumor_grade -> 0.87 # magneto cosine sim → calibrated to 87% true accuracy
survival -> 0.85    # llm stated "85% confident"

calibration implementation

calibration maps raw embedding matcher scores to actual accuracy. uses backoff-key scheme to handle sparse contexts.

how it works

1. binning: divide confidence [0,1] into 10 bins, track accuracy per bin
2. backoff keys: matcher:tier:schema:context → fallback to more general keys when data is sparse
3. eligibility: a key needs 300+ samples and 100+ positives to be used (prevents overfitting)

key structure:

matcher : tier   : schema : context
   │        │        │        │
magneto : field  :  gdc   : specimen

backoff chain (most specific → global fallback):

magneto:field:gdc:specimen  ->  magneto:field:gdc:*  ->  magneto:field:*:*  ->  magneto:*:*:*

calibration plots

generated in examples/ and calibrators/calibration_logs/:

plot	shows
calibration_reliability.png	predicted vs actual accuracy per matcher (diagonal = perfect)
calibration_*_contexts.png	global vs tier-specific curves + key data distribution
calibration_key_stats.png	sample counts per key, which keys are eligible
*_flat_calibration.png	per-tier breakdown (entity, field, content)

current results (jan 2026)

matcher	tier	accuracy	ece	status
rule	entity	97.6%	0.005	excellent
rule	field	92.0%	0.08	well-calibrated
rule	content	99.2%	0.008	near-perfect
biobert	entity	5.9%	0.79	overconfident
biobert	field	13.3%	0.74	overconfident
biobert	content	68.0%	0.26	moderate
magneto	entity	13.4%	0.14	moderate
magneto	field	23.3%	0.27	moderate
magneto	content	72.4%	0.04	well-calibrated

calibration dataset

metric	value
total sources	2,346
total destinations	2,563
entity tier samples	984
field tier samples	941
content tier samples	421
content values (coded)	1,557

schemas included: gdc, htan, cda, icgc, gtex, 1000genome, cellosaurus

entity candidates (10 FHIR resources):

Condition, Device, DocumentReference, Medication, MedicationAdministration,
Observation, Patient, ResearchStudy, ServiceRequest, Specimen

why rule matcher excels: uses exact/fuzzy matching against curated mappings from gdc/htan transformers. entity tier now matches source → FHIR resource (not full path), improving from 52% to 97.6%.

reference field coverage: subject_ref 92.3%, focus_ref 18.2%, specimen_ref 9.8%

retrain calibrators

python calibrators/calibrate_flat_mappings.py --embeddings
python examples/plot_calibration.py

data flow

source schema (csv/json)
        |
        v
+------------------+
|  flatmappingdb   |<-- expert rules (gdc, htan, chembl)
+--------+---------+
         |
   +-----+-----+
   v     v     v
 rule  biobert magneto   <-- matchers
   |     |     |
   +-----+-----+
         |
         v
+------------------+
|   calibrators    |<-- tier-aware confidence
+--------+---------+
         |
         v (only for uncertain cases)
+------------------+
|   claudeagent    |<-- llm tool-calling
+--------+---------+
         |
         v
  fhir mapping output

key optimizations

feature	benefit
fast path	skip llm for exact rule matches (~93% of fields)
expert embeddings	pre-computed vectors for known sources
calibrated scores	confidence reflects true accuracy
few-shot context	similar mappings passed to llm

pearl agent workflow (historical)

this workflow describes an earlier theoretical experimental orchestration model and is not currently active in the production system. current execution uses deterministic matcher + calibration pipelines with optional llm assistance.

perceive -> reason -> act -> hitl -> learn -> (next tier or end)

• perceive: extract schema metadata
• reason: generate matches using weighted embedder combination
• act: filter and rank matches by confidence
• hitl: queue medium confidence (85-95%) matches for human review
• learn: collect metrics and update from feedback

confidence levels (historical)

• high: score >= 95% (auto-accept)
• medium: score 85-95% (requires hitl)
• low: score < 85% (filtered out)

current system uses calibrated confidence from backoff-key calibration

file structure

schema_crush/
├── tools/
│   ├── embeddings/           # biobert, magneto wrappers
│   ├── matchers/             # basematcher interface + implementations
│   └── fhir_schema_tool.py   # linkml fhir schema explorer
├── orchestrator/
│   ├── agents/
│   │   ├── claude_agent.py   # llm with tool-calling + fhir rules
│   │   ├── csv_profiler.py   # use-case detection + recommendations
│   │   └── tools.py          # tool definitions for agent
│   ├── pearl_agent.py        # pearl workflow (langgraph)
│   └── calibration.py        # confidence calibration
├── mappings/                 # flatmappingdatabase, loaders
├── knowledge/
│   ├── mapping_rules/        # gdc, htan parsers
│   └── rules/                # fhir transformation + template rules (md)
├── learning/                 # knowledgebase, vectorstore
├── mcp/                      # mcp server (14 tools)
└── data/resources/           # gdc/htan json mappings, linkml schema

loaders

loader	input	output	use case
flat_loader	sqlite db	FlatMappingDatabase	primary loader - o(1) lookup for all mappings
curated_loader	data/resources/gdc_mapping/*.json	sources + destinations	expert-curated gdc/htan->fhir rules
fhir_aggregator_loader	fhir ndjson files	SourceDestinationPair list	extract patterns from real fhir data
project_loader	project configs	schema metadata	load source schemas for mapping

data flow: curated_loader + fhir_aggregator_loader → normalizer -> flat_loader (sqlite)

mcp server

expose schema_crush as an mcp (model context protocol) server for claude desktop/code.

run server

python -m schema_crush.mcp.server

or add to claude desktop config (~/.config/claude/claude_desktop_config.json):

{
  "mcpServers": {
    "schema-crush": {
      "command": "python",
      "args": ["-m", "schema_crush.mcp.server"],
      "cwd": "/path/to/schema_crush"
    }
  }
}

tools (14)

tool	description	location
profiling
profile_csv	analyze csv use-case, interpret cryptic column names, get mapping recommendations	orchestrator/agents/csv_profiler.py
matchers
biobert_match	semantic matching using biobert embeddings	tools/matchers/biobert_matcher.py
magneto_match	schema-trained matching using magneto	tools/matchers/magneto_matcher.py
rule_match	exact/fuzzy matching against curated rules	tools/matchers/rule_matcher.py
lookups
lookup_mapping	find all mappings for a source term	learning/knowledge_base.py
find_similar	find similar source terms in knowledge base	learning/mapping_vector_store.py
fhir schema
explore_fhir_resource	get fields and structure of a fhir r5 resource	tools/fhir_schema_tool.py
search_fhir_fields	search for fhir fields by keyword	tools/fhir_schema_tool.py
terminology
search_snomed	search snomed ct codes by term	tx.fhir.org API
search_loinc	search loinc codes by term	clinicaltables.nlm.nih.gov API
search_ontology	search ontologies (nci thesaurus, etc.)	ebi.ac.uk/ols4 API
feedback
record_feedback	record user corrections to mappings	learning/feedback_store.py
get_feedback_stats	get feedback statistics	learning/feedback_store.py
reference
get_transformation_rules	get fhir transformation rules	orchestrator/agents/claude_agent.py

example queries

"where does tumor_grade map to in FHIR?"
-> calls lookup_mapping, returns Observation.valueCodeableConcept.text + SNOMED codes

"what fields does Patient have?"
-> calls explore_fhir_resource

"find SNOMED code for adenocarcinoma"
-> calls search_snomed, returns 35917007

"how do I map staging to FHIR?"
-> calls get_transformation_rules with section=staging

knowledge layer

transformation rules

fhir transformation rules consolidated from gdc, cda, htan, icgc transformers.

document	location	purpose
transformation rules	knowledge/rules/fhir_transformation_rules.md	full documentation (700+ lines)
template rules	knowledge/rules/fhir_template_rules.md	fhir patterns from jinja templates
mcp operational	inline in mcp/server.py	quick lookup via get_transformation_rules

sections covered: patient demographics, condition/diagnosis, staging hierarchy, snomed codes, observation patterns, specimen hierarchy, documentreference, medicationadministration, id minting, extensions.

vector store (chromadb)

chromadb is used as a derived semantic retrieval index to support:

• find_similar lookups
• few-shot context for llm-assisted review

chromadb is fully rebuildable from flat_mappings.db and is not a learning or feedback store. canonical truth always lives in sqlite.

location: schema_crush/data/db/chroma/

feedback store

sqlite-backed store for hitl decisions with full traceability.

field	purpose
user_id	who made the decision
timestamp	when (iso utc)
source + source_context	what was being mapped
proposed_target	system proposal
ground_truth	user correction (if any)
decision	accept/reject/correct
matcher + tier + confidence	matcher context

location: schema_crush/data/db/feedback.db

exports:

• export_for_calibration() -> retrain calibrators with user decisions
• export_new_mappings() -> add corrections to knowledge base

retrain with feedback:

python calibrators/calibrate_flat_mappings.py --feedback

current limitations: feedback is incorporated into calibration in a one-way manner. planned safeguards include holdout splits, minimum sample thresholds, metric regression checks (ece/brier), and versioned retraining.

what's missing

planned	status	notes
mapping workbench	design done	drag-drop ui for hitl review, see docs/MAPPING_WORKBENCH.md
fhir aggregator training	not started	learn from real fhir data (patterns, codes, references)
rest api	not started	fastapi wrapper around mcp tools
chromadb persistence	done	rebuildable index stored on disk
synthia integration	not started	synthetic fhir data generation
fine-tuning pipeline	not started	triplet loss training
hitl clustered feedback	not started	group similar matches for bulk review
ontology mining	not started	auto-discover from snomed/loinc
federation	not started	external fhir server validation
context layout refactor	not started	move agent identity, pattern recognition, and transformation rules out of inline python strings in claude_agent.py into knowledge/identity/, knowledge/rules/ (split per source: gdc, cda, htan, icgc), and knowledge/templates/. lets mcp/server.py:get_transformation_rules use directory listing instead of header-splitting a python string
hosted bioscience connectors	not started	this project predates the claude bioscience connectors (chembl, uniprot, and related life-science resources). several bulk downloads and local caches here exist only because those lookups had to be done offline. revisit the ontology and reference-resource paths to query hosted connectors on demand instead of shipping or downloading bulk data

documentation

document	contents
docs/schema_crush_overview.md	technical overview and abstract, start here
docs/architecture_current.md	current architecture, entry points, and data flow
docs/PROMPT_ENGINEERING_ARCHITECTURE.md	multi-agent prompt design
docs/MAPPING_WORKBENCH.md	design proposal for a hitl review ui, not implemented
demo/schema_crush_tutorial.ipynb	executable tutorial with stored outputs
demo/WALKTHROUGH.md	20 to 30 minute technical walkthrough

the tutorial is jupytext-paired: demo/schema_crush_tutorial.py is the source of record and demo/schema_crush_tutorial.ipynb is generated from it.

citation

if you use schema crush in your work, please cite it:

Sanati, N. (2026). Schema Crush: calibrated semantic schema matching for biomedical data to FHIR (Version 1.2.0) [Computer software]. Zenodo. https://doi.org/10.5281/zenodo.22713617

@software{sanati_schema_crush,
  author    = {Sanati, Nasim},
  title     = {Schema Crush: calibrated semantic schema matching for
               biomedical data to FHIR},
  year      = {2026},
  publisher = {Zenodo},
  doi       = {10.5281/zenodo.22713617},
  url       = {https://github.com/teslajoy/schema_crush}
}

10.5281/zenodo.22713617 is the concept doi and always resolves to the latest release. to cite this exact version instead, use 10.5281/zenodo.22713618.

structured metadata lives in CITATION.cff, which github uses to render the "cite this repository" button.

license

mit, see LICENSE.

output files (legacy)

current cli outputs json to stdout or file via -o

• *_mappings.json: final source to target mappings
• *_scores.json: detailed scores with embedder contributions
• *_reasoning.txt: agent decision log

testing

pytest tests/
