schema-miner 3.2.7

SCHEMA-MINER^pro: Scientific Schema Mining and Ontology Grounding with LLMs

Schema-Miner is a command-line and Python package for mining scientific JSON schemas from process specifications and research literature. It supports a human-in-the-loop workflow for schema refinement and an ontology-grounding step that enriches schema fields with QUDT quantity and unit metadata.

Use this PyPI page for installation and CLI orientation. For the full workflow, figures, notebooks, and project background, see:

• Project page: https://sciknoworg.github.io/schema-miner/
• Documentation: https://schema-miner.readthedocs.io/en/latest/
• Source code: https://github.com/sciknoworg/schema-miner

Installation

pip install schema-miner

Schema-Miner requires Python 3.12 or newer.

To install from source:

git clone https://github.com/sciknoworg/schema-miner.git
cd schema-miner
pip install -r requirements.txt

Minimal Configuration

Copy the example environment file and edit it:

cp .env.example .env

Required workflow settings:

# Active provider — options: OPENAI | SAIA | OPENROUTER | OLLAMA | HUGGINGFACE
# Use SAIA for any other endpoint exposing an OpenAI-compatible API
LLM_PROVIDER = '<Your LLM provider here>'
LLM_MODEL = '<Your model here>'                          # e.g. mistral-large-3-675b-instruct-2512, gemma-3-27b-it

# OpenAI
OPENAI_API_KEY = '<your-openai-api-key>'
OPENAI_ORGANIZATION_ID = '<your-openai-organization-id>' # Optional, only needed if you have multiple organizations in OpenAI

# SAIA / Any OpenAI-compatible endpoint
# Schema-Miner supports any service exposing an OpenAI-compatible API.
# Provide your API key and the base URL for your preferred provider.
SAIA_API_KEY = '<your-api-key>'
SAIA_BASE_URL = 'https://chat-ai.academiccloud.de/v1'   # GWDG/SAIA (Germany)

# OpenRouter
OPENROUTER_API_KEY = '<your-openrouter-api-key>'
OPENROUTER_BASE_URL = 'https://openrouter.ai/api/v1'

# Ollama  (leave blank if running locally on the same machine)
OLLAMA_BASE_URL = '<OLLAMA Server Base URL>'

# HuggingFace
HuggingFace_Access_Token = '<your-huggingface-access-token>'
HUGGINGFACE_USE_LOCAL = False                            # True = load model locally (GPU recommended) | False = use Inference API

CLI Quick Start

Run one workflow step at a time:

# Stage 1: generate an initial schema from the process specification
schema-miner --stage 1

# Stage 2: refine with a curated paper corpus and optional expert feedback
schema-miner --stage 2 --schema results/stage-1/<model>.json --papers 3

# Stage 3: finalize with a broader paper corpus
schema-miner --stage 3 --schema results/stage-2/<model>.json --papers all

# Ontology grounding: enrich the final schema with QUDT metadata
schema-miner --ontology-grounding agentic --schema results/stage-3/<model>.json

Common options:

Option	Meaning
--stage 1	Initial schema mining from STAGE1_SPECS_PATH.
--stage 2	Preliminary refinement using STAGE2_PAPERS_PATH; requires --schema.
--stage 3	Final refinement using STAGE3_PAPERS_PATH; requires --schema.
--schema <path>	Input JSON schema for stages 2, 3, or ontology grounding.
--expert-feedback <text-or-file>	Optional feedback for stages 2 and 3.
--papers <N or all>	Paper batch size for stages 2 and 3.
--ontology-grounding prompt	Prompt-based QUDT grounding.
--ontology-grounding agentic	Agentic QUDT grounding with lexical and semantic lookup.

Generated schemas, intermediate outputs, grounded schemas, and logs are written under RESULTS_PATH.

CLI Usage Scenarios

Check the Installed CLI

schema-miner --help
schema-miner --version

Stage 1: Initial Schema Mining

Use this when you have a process specification and want the first JSON schema.

Required .env values:

• PROCESS_NAME
• PROCESS_DESCRIPTION
• STAGE1_SPECS_PATH
• RESULTS_PATH
• LLM provider and credentials

Run:

schema-miner --stage 1

The command reads STAGE1_SPECS_PATH and writes the initial schema to RESULTS_PATH.

Stage 2: Preliminary Refinement

Use this when you have a Stage 1 schema and a small curated paper corpus.

Required inputs:

• STAGE2_PAPERS_PATH in .env
• --schema pointing to the Stage 1 JSON schema

Process one paper per batch:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json

Process with inline expert feedback for the first batch:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json \
    --expert-feedback "Add units for temperature and pressure fields."

Process with expert feedback from a file:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json \
    --expert-feedback data/stage1/feedback/<model>.txt

Process papers in fixed-size batches:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json --papers 3

Process all curated papers in one batch:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json --papers all

Process papers in fixed-size batches with initial inline expert feedback:

schema-miner --stage 2 --schema data/stage1/schema/<model>.json --papers 3 \
    --expert-feedback "Add units for temperature and pressure fields."

Stage 3: Final Refinement

Use this when you have the final Stage 2 schema and a broader validation/refinement corpus.

Required inputs:

• STAGE3_PAPERS_PATH in .env
• --schema pointing to the final Stage 2 JSON schema

All CLI usage patterns are the same as for Stage 2. One example is shown below.

Run papers in batches of 5 with initial expert feedback from a file:

schema-miner --stage 3 --schema results/stage-2/<model>.json --papers 5 \
    --expert-feedback data/stage-2/feedback/<model>.txt

Stage 4: Ontology Grounding

Use this when you have a final schema and want QUDT quantity/unit grounding.

Prompt-based grounding:

schema-miner --ontology-grounding prompt --schema results/stage-3/<model>.json

Agentic grounding:

schema-miner --ontology-grounding agentic --schema results/stage-3/<model>.json

Tutorial Notebooks

Notebook	Inference mode
Hugging Face local GPU	Local model
KISSKI SAIA	Remote OpenAI-compatible API
OpenRouter	Remote OpenAI-compatible API

Contact

Collaboration inquiries: Jennifer D'Souza, jennifer.dsouza [at] tib.eu.

Development questions or bug reports: open an issue or contact Sameer Sadruddin, sameer.sadruddin [at] tib.eu.

License

Schema-Miner is released under the MIT License.
