segnomms 0.2.1

Advanced QR code generation plugin for Segno with custom shapes, styling, and interactivity

SegnoMMS

⚠️ Beta Software Notice: SegnoMMS is currently in beta. While the core functionality is stable and extensively tested, APIs may change between minor versions. We recommend pinning to specific versions for production use and reviewing the CHANGELOG before upgrading.

Advanced QR code generation plugin for Segno with custom shapes, styling, interactivity, and comprehensive Pydantic integration for type-safe configuration management. Powers the QR code generation at qrcodemms.com.

Features

• 🔧 Pydantic-Powered Configuration: Complete type safety with automatic validation, JSON Schema generation, and structured data models throughout the entire codebase
• 🎨 Custom Shapes: Multiple shape options for QR modules (dots, rounded, squares, diamonds, squircles, etc.)
• ⚡ Interactive Elements: CSS classes for hover effects, tooltips, and click handling
• 🔗 Connected Modules: Smart shape connection for adjacent modules (pill shapes, flowing designs)
• 🎯 Per-Component Styling: Different shapes for different QR components (finder patterns, data modules, etc.)
• 🎨 CSS Variables: Dynamic styling through CSS custom properties
• ♿ Comprehensive Accessibility: WCAG compliance, ARIA labels, stable IDs, pattern-specific labeling, and screen reader optimization
• 🛡️ Type Safety: Full type checking, constraint validation, and IDE support for all parameters
• 📊 Structured Data: Rich data models instead of dictionaries with computed properties and validation
• 🔌 API Integration: JSON Schema generation perfect for FastAPI, OpenAPI, and external tools

Installation

Using pip

pip install segnomms

For Development (Recommended: Using uv)

SegnoMMS uses uv for ultra-fast dependency management:

# Install uv (if not already installed)
pip install uv

# Clone and setup
git clone https://github.com/systmms/segnomms.git
cd segnomms

# Install with uv (10-100x faster than pip!)
uv sync
uv pip install -e .

# Or use the Makefile
make setup

Traditional pip development setup:

git clone https://github.com/systmms/segnomms.git
cd segnomms
pip install -e .

Usage

import segno
from segnomms import write

# Create QR code
qr = segno.make('Hello World')

# Generate interactive SVG with custom shapes
write(qr, 'output.svg',
    scale=10,
    shape='rounded',
    data_shape='dot',
    finder_shape='rounded',
    finder_inner_shape='square',
    merge='soft',  # Connect adjacent modules
    interactive=True
)

Accessibility Features

import segno
from segnomms import write
from segnomms.a11y.accessibility import AccessibilityConfig, create_enhanced_accessibility

# Generate QR code with comprehensive accessibility
qr = segno.make('Accessible QR Code')
accessibility_config = create_enhanced_accessibility()

write(qr, 'accessible.svg',
    scale=10,
    shape='rounded',
    accessibility=accessibility_config
)

# Custom accessibility configuration
from segnomms.a11y.accessibility import AccessibilityConfig, AccessibilityLevel

custom_a11y = AccessibilityConfig(
    id_prefix="qr",
    target_compliance=AccessibilityLevel.AAA,
    enable_aria=True,
    include_pattern_labels=True,
    enable_keyboard_navigation=True,
    root_label="Interactive QR Code"
)

write(qr, 'custom-accessible.svg', accessibility=custom_a11y)

Shape Options

Basic Shapes

• square - Classic square modules
• circle - Circular dots
• rounded - Rounded squares
• dot - Small dots with gaps
• diamond - Diamond shapes
• hexagon - Hexagonal modules
• star - Star shapes
• plus - Plus/cross shapes

Connection Styles

• none - No connection between modules
• pill - Connect horizontal/vertical neighbors into pills
• flow - Smooth flowing connections
• merge - Fully merge connected regions

Interactive Features

• Hover highlighting
• Click handlers via data attributes
• Tooltips showing module information
• Custom CSS classes per module type

Requirements

• Python >= 3.10 (tested through Python 3.14)
• Segno >= 1.5.2 (tested with 1.5.2, 1.6.0, and 1.6.6)
• Pydantic >= 2.7,<3 (for configuration validation and JSON Schema)

Optional Dependencies

• For accessibility features: All included in base installation
• For development: use make setup (uv) or uv sync to install all development dependencies

Quick Start

import segno
from segnomms import write

# Create a QR code with custom shapes
qr = segno.make("https://example.com")
write(qr, "output.svg", shape="circle", dark="#1a1a2e", scale=10)

Configuration Management

SegnoMMS features comprehensive Pydantic-powered configuration with automatic validation, type safety, and JSON Schema generation throughout the entire codebase:

Type-Safe Configuration with Full Validation

from segnomms.config.models.core import RenderingConfig
from segnomms.validation.models import CompositionValidatorConfig
from segnomms.algorithms.models import ClusteringConfig
from pydantic import ValidationError

# Main configuration with automatic validation
config = RenderingConfig.from_kwargs(
    shape='squircle',
    corner_radius=0.3,
    connectivity='8-way',
    merge='soft'
)

# Component-specific validation models
validator_config = CompositionValidatorConfig(
    qr_version=7,
    error_level='M',
    matrix_size=45
)

clustering_config = ClusteringConfig(
    min_cluster_size=5,
    density_threshold=0.7,
    connectivity_mode='8-way'
)

# Invalid values raise clear validation errors with helpful messages
try:
    bad_config = RenderingConfig.from_kwargs(shape='invalid', scale=-5)
except ValidationError as e:
    for error in e.errors():
        print(f"{error['loc']}: {error['msg']}")

Structured Data Models Throughout

from segnomms.core.models import NeighborAnalysis
from segnomms.algorithms.models import ClusterInfo
from segnomms.validation.models import ValidationResult
from segnomms.core.detector import ModuleDetector
from segnomms.config.models.core import RenderingConfig

# Example setup
config = RenderingConfig.from_kwargs()
# Create a minimal QR matrix for version 1 (21x21)
matrix = [[True] * 21 for _ in range(21)]
detector = ModuleDetector(matrix, version=1)
row, col = 10, 10

# Structured returns instead of dictionaries
analysis = detector.get_weighted_neighbor_analysis(row, col)
print(f"Flow direction: {analysis.flow_direction}")
print(f"Connectivity: {analysis.connectivity_strength}")

# Rich cluster information with computed properties
cluster = ClusterInfo(
    positions=[(0,0), (0,1), (1,0)],
    bounds=(0, 0, 1, 1),
    module_count=3,
    density=0.75,
    aspect_ratio=1.0,
    is_rectangular=False
)
print(f"Cluster size: {cluster.width}x{cluster.height}")
print(f"Fill ratio: {cluster.fill_ratio}")

# Comprehensive validation results
from segnomms.validation import CompositionValidator
validator = CompositionValidator(qr_version=1, error_level='M', matrix_size=21)
result = validator.validate_all(config)
print(f"Valid: {result.valid}")
print(f"Issues: {result.total_issues}")

JSON Schema Generation & Integration

from segnomms.config.models.core import RenderingConfig
from segnomms.algorithms.models import ClusteringConfig

# Generate JSON Schema for any configuration
schema = RenderingConfig.model_json_schema()
clustering_schema = ClusteringConfig.model_json_schema()

# Rich schemas with constraints and descriptions
print(schema['properties']['scale'])
# Output: {'type': 'integer', 'minimum': 1, 'maximum': 100, 'description': 'Size of each module in pixels'}

# Perfect for FastAPI integration
try:
    from fastapi import FastAPI
    app = FastAPI()

    @app.post("/qr/generate")
    def generate_qr(config: RenderingConfig):
        return {"svg": f"<svg>Generated QR with {config.geometry.shape}</svg>"}

    @app.get("/qr/schema")
    def get_schema():
        return RenderingConfig.model_json_schema()
    print("FastAPI integration ready")
except ImportError:
    print("FastAPI not available - install with: pip install fastapi")

Configuration Serialization & Presets

from segnomms.config.models.core import RenderingConfig
from segnomms.algorithms.models import ClusteringConfig

# Create example configurations
config = RenderingConfig.from_kwargs(shape='squircle', corner_radius=0.4)
clustering_config = ClusteringConfig()

# Serialize any configuration to JSON
json_string = config.model_dump_json()
cluster_json = clustering_config.model_dump_json()

# Restore from JSON with validation
restored_config = RenderingConfig.model_validate_json(json_string)
restored_cluster = ClusteringConfig.model_validate_json(cluster_json)

# Create configuration presets
PRESET_MODERN = RenderingConfig.from_kwargs(
    shape='squircle',
    corner_radius=0.4,
    connectivity='8-way',
    merge='soft'
)

PRESET_CLASSIC = RenderingConfig.from_kwargs(
    shape='square',
    connectivity='4-way',
    merge='none'
)

IDE Support & Type Safety

All models provide complete type hints and IDE auto-completion:

from segnomms.config.models.core import RenderingConfig

# Full IDE support with type checking
def process_qr(config: RenderingConfig) -> str:
    # IDE knows all available fields and their types
    scale: int = config.scale
    shape: str = config.geometry.shape
    # Automatic validation ensures type safety
    return f"<svg>Generated SVG with {shape} at scale {scale}</svg>"

License

SegnoMMS is open source software licensed under the MIT License. See the LICENSE file for details.

Acknowledgments

• Built for Segno - Pure Python QR Code generator by Lars Heuer
• "QR Code" is a registered trademark of DENSO WAVE INCORPORATED

Commercial Use

This plugin is free for both personal and commercial use. You can use it in commercial products, SaaS applications, or any other projects without restrictions.

Development

Setting Up the Development Environment

Recommended: Using uv (fast, no additional setup)

git clone https://github.com/systmms/segnomms.git
cd segnomms
make setup  # Uses uv for fast dependency installation

Alternative: Using pip

git clone https://github.com/systmms/segnomms.git
cd segnomms
pip install -e .

Optional: Using Nix for reproducible environments

For advanced users who prefer Nix-based development environments:

1. Install Nix and direnv
2. Run the setup script:

   ./repo/setup-dev-env.sh


3. The environment will activate automatically when entering the project directory

Note: Nix setup is optional and not required for most development workflows.

Development Commands

Use make help to discover all available commands:

make help           # Show all available commands
make test           # Run full test suite
make test-quick     # Quick unit tests during development
make lint           # Run all linting checks
make docs           # Build Sphinx documentation
make benchmark      # Run performance benchmarks

Key commands organized by category:

• Setup: make setup, make clean
• Testing: make test, make test-unit, make test-integration, make test-visual
• Quality: make lint, make format
• Documentation: make docs, make docs-serve
• Performance: make benchmark, make benchmark-memory

GitHub Actions Testing

Test GitHub Actions workflows locally using act:

# List available workflows
act -l

# Run all workflows
act

# Run specific workflow
act -W .github/workflows/test.yml

# Lint workflow files
actionlint

The project includes comprehensive GitHub Actions workflows for testing and validation.

Git Hooks (Lefthook)

The project uses Lefthook for git hooks to ensure code quality:

• actionlint: Validates GitHub Actions workflow syntax
• black: Python code formatting
• isort: Python import sorting
• flake8: Python linting

Install hooks:

lefthook install

Hooks run automatically on commit. To run manually:

lefthook run pre-commit

Architecture

Based on the Segno plugin architecture:

• Entry point: segnomms.plugin:write
• Plugin registration via setuptools entry points
