sensirion-uart-sps30 1.0.0

SHDLC driver for the Sensirion SPS30 sensor family

Python UART Driver for Sensirion SPS30

This repository contains the Python driver to communicate with a Sensirion SPS30 sensor over UART using the SHDLC protocol.

Click here to learn more about the Sensirion SPS30 sensor.

Connect the sensor

You can connect your sensor over the provided USB cable. For special setups check out the sensor pinout in the section below.

Sensor pinout

Pin	Cable Color	Name	Description	Comments
1	red	VDD	Supply Voltage	5V
2	green	RX	UART: Transmission pin for communication
3	yellow	TX	UART: Receiving pin for communication
4		SEL	Interface select	Leave floating to select SHDLC
5	black	GND	Ground

Documentation & Quickstart

See the documentation page for an API description and a quickstart example.

Contributing

Check coding style

The coding style can be checked with flake8:

pip install -e .[test]  # Install requirements
flake8                  # Run style check

In addition, we check the formatting of files with editorconfig-checker:

pip install editorconfig-checker==2.0.3   # Install requirements
editorconfig-checker                      # Run check

License

See LICENSE.
