ShotQuill
A fast, privacy-respecting screenshot & annotation tool for macOS — with Linux and Windows GUI plus cross-platform CLI/MCP support.
From hotkey to share-ready image in seconds. Point at a window, drag a precise region, or capture every display—then annotate, pixelate sensitive areas, extract text, copy, save, or pin the result without breaking your flow.
- Everything you expect from a screenshot app — capture a window, region, screen, or every display; then annotate, pixelate, extract text, copy, save, or pin the result, with auto-save and auto-copy when you want them.
- CLI and MCP support built in — automate capture, OCR, diffs, and replayable
sessions with the
squillCLI, or give AI agents controlled screen access through the built-in MCP server. - App blocklists and allowlists — keep sensitive apps out of every capture, or restrict capture to approved apps only, with the same rules enforced across the GUI, CLI, and MCP server.
Jump to: Highlights · Platforms · Install · Usage · Scripting & agents (CLI · MCP) · App blocklist · App allowlist · Configuration · Troubleshooting · Privacy · Tech stack · Development · Packaging · Uninstall · Roadmap · Contributing
Highlights
- Two capture hotkeys, both customizable:
-
Capture (
⌥A) — one overlay; the pointer picks the mode:- click a window — grab just it, real pixels even when partly covered;
- click empty space — the whole screen;
- drag — a region, with a live size readout and a pixel loupe (magnified pixels + crosshair + position/colour) for precise edges.
The hovered target is spotlit against the dimmed desktop. An optional delay (Settings → Highlight window after, off by default) fully highlights a window first, lifting its pixels out from under any overlap.
-
Full screen (
⌥S) — every display at once, instantly.
-
- Configurable after-capture flow — open the annotation editor by default, or make captures hands-free by auto-saving, auto-copying, or both.
- Annotation editor — rectangles, ellipses, arrows, lines, freehand pen, highlighter, text, and mosaic pixelation for visual obfuscation. Mosaic removes the original per-pixel detail from the exported image but retains block-average information; use the solid-fill CLI / blocklist controls for high-risk secrets instead.
- On-device OCR — pull text out of a shot, fully offline, no network, no API
key. macOS requests Simplified Chinese and English from Apple Vision; Linux
uses whichever matching Tesseract language packs are installed. Experimental
Windows OCR uses the user's installed WinRT OCR languages and requires the
optional
windows-ocrextra in a pip install. - Scriptable & agent-ready — a headless CLI
(
squill capture/window list/display list/ocr/diff/session/doctor/mcp, plusblocklist/allowlist— each command documents its stdout, with exit codes as the contract) and a built-in MCP server that gives AI agents eyes on your screen.captureprints one output path by default; programmatic captures are audit-logged on a best-effort basis. See Scripting & agents. - Pin to screen — float an annotated shot on top of the desktop for reference;
drag to move, double-click or
Escto dismiss. - Bilingual UI — English / 中文, switchable in Settings (defaults to English).
- Menu-bar resident — no Dock clutter; optional launch-at-login.
Platform support
| Platform | Core support | Notes |
|---|---|---|
| macOS 13+ | Full GUI, smart capture, editor, global hotkeys, window enumeration, on-device OCR, CLI / MCP | Primary and most complete platform; ScreenCaptureKit capture on macOS 14+, with a CoreGraphics fallback on macOS 13. |
| Linux / X11 | Full GUI, editor, CLI / MCP, window enumeration, global hotkeys, blocklist redaction | OCR requires Tesseract and the desired language packs. |
| Linux / Wayland | GUI and editor; capture for GUI / CLI / MCP uses xdg-desktop-portal and the compositor's picker |
No window enumeration by design; global hotkeys require GlobalShortcuts portal support. |
| Windows | GUI, editor, CLI / MCP, Win32 window enumeration, global hotkeys, launch at login | Release ZIP is x64 and omits OCR; the experimental WinRT backend requires the windows-ocr extra in a pip install. |
Install
macOS
Homebrew (recommended):
brew install --cask wardmos/tap/shotquill
brew upgrade --cask shotquill keeps it current. The cask selects the guarded
PKG CLI component, which puts both shotquill and squill under
/usr/local/bin for CLI / MCP use. Direct PKG and Homebrew installs therefore
use the same links rather than installing duplicate CLIs. Because this installs
a system package under /Applications, macOS or Homebrew may request
administrator authorization.
Direct download: grab the .pkg from
Releases — arm64 for Apple
Silicon, x86_64 for Intel Macs, or universal2 if unsure (works on both,
roughly twice the size) — open it and follow Installer. The component page
always installs ShotQuill in /Applications; Command Line Interface is
selected by default so shotquill and squill are added under /usr/local/bin.
Deselect it for an app-only installation. Each release ships a .sha256 sidecar
so you can verify the download. Installer choices do not remove components from
an older installation: to change an existing CLI-enabled install to app-only,
use the built-in uninstaller and then reinstall with CLI deselected.
shasum -a 256 -c ShotQuill-*.pkg.sha256
The default release build contains an ad-hoc-signed app in an unsigned, unnotarized installer so the developer can stay anonymous. Gatekeeper may block the downloaded package. After trying to open it once, go to System Settings → Privacy & Security and choose Open Anyway only if you trust the release and its verified checksum.
The component checkbox cannot control authorization by itself. Both
/Applications and /usr/local/bin are system locations, so macOS decides
whether to request a password, Touch ID, or other administrator approval when
you click Install. It may request approval even when the CLI is not selected.
Linux
Two channels, pick by what you need:
| You want… | Use |
|---|---|
| The menu-bar GUI + CLI + MCP | pipx (or pip) install from PyPI |
| Just the CLI / MCP in one single-file launcher | x86_64 AppImage from Releases |
pipx (recommended for the GUI):
pipx install shotquill # menu-bar app, plus `shotquill` and `squill`
squill desktop install # add ShotQuill to your app menu (pipx-only step)
shotquill # launch the menu-bar app
pipx upgrade shotquill keeps it current. pip install --user shotquill works
too if you prefer pip — in that case the .desktop launcher and icon land
under ~/.local/share automatically, so you can skip the desktop install
step. (pipx stores data files inside its private venv, which the desktop
doesn't search, hence the one-liner.)
AppImage (CLI / MCP only, x86_64): download the .AppImage from
Releases, chmod +x, run.
It bundles Python + the headless Qt components (no QtWidgets, no GUI) in one
file, but deliberately uses the host's EGL / GL, D-Bus, and xkbcommon runtime
libraries. A typical graphical desktop already has them; a minimal Ubuntu /
Debian system may need libegl1 libgl1 libdbus-1-3 libxkbcommon0. Built on
Ubuntu 22.04 → glibc 2.35 floor (Ubuntu 22.04+ / Debian 12+).
Download the matching .sha256 sidecar and verify it before running:
sha256sum -c ShotQuill-*.AppImage.sha256
Wayland users also need xdg-desktop-portal plus a portal backend for
your desktop (xdg-desktop-portal-gnome, -kde, or -wlr) — squill doctor
will tell you when screenshot or GlobalShortcuts support is missing. X11
users need nothing extra.
Linux GUI notes. ShotQuill needs a system tray to run. GNOME 42+ shipped without legacy tray support — install the AppIndicator and KStatusNotifierItem Support extension; KDE, XFCE, MATE, and Cinnamon already include a tray. Global hotkeys (
Alt+A,Alt+S) work on X11. On Wayland they use the GlobalShortcuts portal when available; otherwise ShotQuill reports the missing portal support so you can use the tray menu or bind a compositor-level shortcut.
Windows
Download ShotQuill-*-windows-x64.zip from
Releases, unzip it, and run
ShotQuill.exe for the tray GUI. The same bundle includes squill.exe for the
CLI and MCP server.
Download the matching .sha256 sidecar and compare the two values before
extracting the ZIP:
Get-FileHash .\ShotQuill-*-windows-x64.zip -Algorithm SHA256
Get-Content .\ShotQuill-*-windows-x64.zip.sha256
Windows OCR is experimental: its WinRT integration has not yet been validated against a live engine and it recognizes languages installed in the user's Windows profile rather than a fixed English / Chinese pair. The required Python WinRT projections are optional and are not included in the default package or release ZIP. To test it with a pip install, use:
pip install "shotquill[windows-ocr]"
Usage
ShotQuill runs in the menu bar. Click its icon for the menu, or use the global hotkeys from anywhere.
Capture hotkeys
| Action | macOS | Linux / Windows | Notes |
|---|---|---|---|
| Capture | ⌥A |
Alt+A |
Click a window to grab it, click empty space for full screen, or drag for a region. Esc / right-click cancels. |
| Full-screen | ⌥S |
Alt+S |
All displays composited into one image, instantly. |
Both are remappable in Settings — any combination of modifiers (⌘ ⌃ ⌥ ⇧
on macOS, Super+ Ctrl+ Alt+ Shift+ on Linux/Windows) plus a key. Hotkey labels
in the tray menu and Settings render natively per platform (Apple keycap glyphs
on macOS, text labels on Linux/Windows).
Linux / Wayland: global hotkeys use the
xdg-desktop-portalGlobalShortcuts interface when your compositor supports it. If not, ShotQuill raises a notification so you can use the tray menu, or bind a compositor-level shortcut tosquill capture(full screen) /squill capture --interactive(the compositor's own picker frames a window, region, or screen).
What happens after a capture
By default ShotQuill opens the annotation editor after a capture. You can make captures hands-free in Settings → After capture by enabling auto-save, auto-copy, or both:
| Auto-save | Auto-copy | Result |
|---|---|---|
| ✅ | ✅ | Saved and copied, no editor. |
| ✅ | — | Saved only. |
| — | ✅ | Copied only. |
| — | — | Opens the annotation editor instead (default). |
Annotation editor
When both auto-output toggles are off (or whenever you want to mark a shot up), the editor opens with a toolbar:
- Tools: select, rectangle, ellipse, arrow, line, pen, highlighter, mosaic, text — with adjustable color and stroke width, plus undo / redo.
- Copy Text runs OCR on the capture and copies the recognized text.
- Pin floats the annotated shot on top of the desktop.
Keyboard:
| Key | Action |
|---|---|
Space |
Copy to the clipboard, then close |
Enter |
Save to your folder, then close |
⌘Z / ⌘⇧Z (macOS); Ctrl+Z / Ctrl+Shift+Z (Linux / Windows) |
Undo / redo |
Esc |
Close without saving |
The copy and save keys are configurable in Settings, and each can be
disabled individually. Settings rejects keys that would clash with the
built-in editor shortcuts (copy/save/undo/redo/Esc), with each other,
or with a global capture hotkey.
Saved files
Captures are written to ~/Pictures/ShotQuill by default (configurable), named
with a timestamp — e.g. ShotQuill 2026-06-04 14.30.00.png. Choose PNG or
JPG in Settings.
Scripting & agents
ShotQuill has a headless CLI — shotquill, or the short alias squill — and a
built-in MCP server, so shell scripts and AI agents can capture, read, and record
the screen without the GUI:
squill capture --app safari -o shot.png # capture a window to a file
squill ocr --window-id 42 --contains Login # capture + assert on-screen text (exit 20 if absent)
squill session start --agent builder # begin a replayable session trace
squill mcp # serve the Model Context Protocol over stdio
Running it bare launches the GUI; with a subcommand it stays headless. capture
writes one file and prints its path by default; listing, OCR, diff, doctor, and
session commands emit their documented text or JSON instead. Warnings go to
stderr, and exit codes are the contract. The same capture / read / record loop
is exposed to MCP clients as twelve tools.
A typical JSON-style MCP host configuration is:
{
"mcpServers": {
"shotquill": { "command": "squill", "args": ["mcp"] }
}
}
Some hosts use TOML or their own settings UI, but the command and argument stay the same.
→ Full reference: docs/scripting.md — the stdout/exit-code
contract, capture flags (--json / --max-width / --deterministic / --mask /
--reveal),
OCR assertions, best-effort PII redaction (capture --redact-pii,
session frame --scan-pii / --redact-pii, session export --fail-on-pii —
OCR the frame and mask or flag likely emails, cards, SSNs before output),
the flight recorder + OpenTelemetry trace export, and the MCP
tools. The exit-code contract is also printed in every squill … --help.
App blocklist
Name apps that must never be captured — a password manager, your keychain — and ShotQuill refuses to capture their windows and redacts them out of full-screen and region captures (an opaque block painted over the pixels, not an overlay, so nothing sensitive survives in the image). This covers the GUI, the CLI, and the MCP server alike.
Manage it from Settings → Blocked apps… (on macOS, pick from the running apps), from the command line, or by hand-editing the JSON file directly:
squill blocklist add --bundle-id com.1password.1password
squill blocklist add --name keychain # app-name substring
squill blocklist list # --json for machines
squill blocklist remove --name keychain
The list is a plain JSON file, read by every surface so one rule protects them all:
- macOS:
~/Library/Application Support/shotquill/blocklist.json - Windows:
%APPDATA%\shotquill\blocklist.json - elsewhere:
$XDG_CONFIG_HOME/shotquill/blocklist.json
{
"version": 1,
"rules": [
{ "bundle_id": "com.1password.1password" },
{ "name": "keychain" }
]
}
A window is blocked when any rule matches it: bundle_id matches the owning
app's identifier exactly (case-insensitive — usually more stable than its
display name, but still matching metadata rather than a verified security
identity), or name matches its app name as a case-insensitive substring
(handy for a quick edit). squill doctor prints
the active rules; a blocked capture exits 6 (the MCP capture tool returns
error type: "blocked"); refusals and redactions are audit-logged on a best-effort basis.
Know the boundary — this is privacy hygiene, not a security control. Anything running as you can capture the screen by other means, so the blocklist defends against an over-eager or prompt-injected agent reaching for a password manager through ShotQuill, not against a determined adversary with code execution. Two honest limits: a full-screen capture can only be redacted where windows can be enumerated (macOS and X11; not under Wayland, which forbids it — blocklist-protected whole-screen / interactive captures are refused there rather than captured plainly), and an unreadable blocklist file fails closed (captures are refused until you fix it).
App allowlist
The inverse of the blocklist, and a tighter leash. The blocklist names what may never be captured; the allowlist, when you enable it, flips the default — ShotQuill then captures only the apps you list and refuses everything else. It is especially useful for agents driving the CLI or MCP: pin the allowlist to the one or two apps a task needs and the agent cannot wander off and screenshot your mail, chats, or desktop. Disabled by default, so it never gets in the way until you ask for it.
Manage it from Settings → Allowed apps… (tick the box to turn it on), from the command line, or by hand-editing the JSON file:
squill allowlist add --bundle-id com.apple.Terminal
squill allowlist add --name firefox # app-name substring
squill allowlist enable # turn the restriction on
squill allowlist list # shows enabled state + rules (--json)
squill allowlist disable # back to normal capture
squill allowlist remove --name firefox
Enforcement covers the GUI, CLI, and MCP alike — the same as the blocklist. In the GUI, full-screen capture (and the region / full-screen modes of smart capture) are refused with a tray note, and smart capture only lets you pick a window that's on the list; non-allowed windows are skipped just like blocklisted ones.
When the allowlist is enabled:
- a window or app capture is refused unless its target is on the list;
- a whole-screen capture (full-screen, region, or display) is refused
outright — its "only these apps" promise cannot be kept for a grab of
everything, so the caller must target a specific window (
--window-id) or app (--app); - a refused capture exits
6(the MCPcapturetool returns errortype: "blocked"), and refusals are audit-logged ascapture_not_allowedon a best-effort basis.
It stacks with the blocklist: a window must be both off the blocklist and
on the allowlist to be captured. The rule shape is identical to the blocklist
(bundle_id exact match, or name substring). The file lives next to the
blocklist:
- macOS:
~/Library/Application Support/shotquill/allowlist.json - Windows:
%APPDATA%\shotquill\allowlist.json - elsewhere:
$XDG_CONFIG_HOME/shotquill/allowlist.json
{
"version": 1,
"enabled": true,
"rules": [
{ "bundle_id": "com.apple.Terminal" },
{ "name": "firefox" }
]
}
Two things to know: an allowlist that is enabled with no rules allows
nothing — a deliberate full lockdown, surfaced by squill doctor and the
editor rather than left as mysterious blanket refusals; and like the blocklist
it fails closed — an unreadable file, or a by-id capture on a backend that
cannot enumerate windows to verify the target, is refused rather than passed
through. The same boundary applies: this constrains ShotQuill's own capture
paths against an over-eager or prompt-injected agent, not an adversary with code
execution.
For agents: the allowlist can only be changed from the CLI or the GUI — it is deliberately not exposed over MCP, so an agent on the leash cannot loosen its own. Set it up before handing control over.
Configuration
Open Settings… from the menu-bar icon:
- Language — English / 中文.
- Save folder & image format (PNG / JPG).
- Hotkeys for both capture modes.
- Highlight window after — a delay before the hovered window fully lights up in smart capture, lifting its pixels out from under any overlap (off by default).
- Editor finish keys — the in-editor copy and save keys (Space / Enter by default), each with its own enable toggle.
- Adjust region with arrow keys (on) — keep a region crop nudgeable in the editor until the first annotation lands.
- Edit in place (on) — open the editor frameless over the dimmed screen, rather than as a normal titled window.
- Toolbar buttons — icon and text, icon only, or text only (icon only by default).
- After capture — auto-save and/or auto-copy toggles (above).
- Include mouse pointer (off) — composite the cursor into captures.
- Blocked apps… — manage the app blocklist (apps that are never captured).
- Allowed apps… — manage the app allowlist (when enabled, the only apps that can be captured; off by default).
- Debug mode (off) — write detailed local logs for troubleshooting.
- Launch at login — installs the platform's per-user startup entry
(LaunchAgent on macOS, XDG autostart on Linux, the
Runkey on Windows). - Flash on capture (on) and Sound on capture (off) — capture feedback.
Troubleshooting
macOS
Captures come out black or empty. macOS is withholding screen content:
grant Screen Recording in System Settings → Privacy & Security, then
restart ShotQuill (macOS only applies the grant to freshly launched
processes). For the CLI/MCP, remember the permission is attributed to the
invoking app — your terminal or agent host — not to ShotQuill itself;
squill doctor reports exactly which grant is missing.
A hotkey is silently dead. Another app may own the same combo — macOS
gives no error; the events simply never arrive. Remap it in Settings. ShotQuill
uses Carbon RegisterEventHotKey, so global capture hotkeys do not require Input
Monitoring.
The installer or ShotQuill is blocked on first launch. That's Gatekeeper on the unsigned/unnotarized direct package — see Install for the Privacy & Security override.
Linux
ShotQuill exits at startup with "needs a system tray". The Qt application
came up, but no system-tray host is running. GNOME 42+ ships without legacy
tray support — install the AppIndicator and KStatusNotifierItem Support
extension and log out / in. KDE, XFCE, MATE, and Cinnamon include a tray by
default. The squill CLI and MCP server still work even without a tray.
Global hotkeys do nothing on Wayland. ShotQuill uses the
xdg-desktop-portal GlobalShortcuts interface there, because Wayland blocks
classic out-of-band key grabs. If your compositor or portal backend does not
implement GlobalShortcuts, ShotQuill reports that at startup. Workarounds: use
the tray menu, or bind a compositor-level shortcut to squill capture
(full screen → file) in your desktop's keyboard settings.
Captures fail with "Wayland blocks out-of-band grabs". Install
xdg-desktop-portal and a backend for your desktop:
xdg-desktop-portal-gnome, -kde, or -wlr. squill doctor will report
when the portal is reachable.
squill ocr errors with "Tesseract is not installed" on Linux. Install the
tesseract-ocr package (and language data such as tesseract-ocr-eng /
tesseract-ocr-chi-sim) from your distribution; squill doctor reports OCR as
available once the tesseract binary is on PATH. macOS uses Apple Vision and
needs no extra install.
squill window list fails with "no EWMH-compatible window manager is running"
(or "cannot connect to the X server"). X11 enumeration reads the window
manager's EWMH properties, so it needs a running, EWMH-compliant WM (virtually
all modern ones are) and a reachable display. Under Wayland it stays
unsupported by design — the compositor refuses to let an app enumerate other
apps' windows. Full-screen and region capture work regardless; on Wayland,
smart capture uses the compositor's portal picker instead of ShotQuill's own
window-highlighting overlay.
Smart capture's window highlight never appears under Wayland. Same reason as above — without window enumeration ShotQuill cannot outline a window itself. The Wayland smart-capture action opens the compositor's picker instead; on X11/macOS/Windows, ShotQuill keeps its own hover highlight/direct window picking. Because the portal returns pixels but not the selection's desktop coordinates, the editor opens as a normal window after a Wayland smart capture.
Audit log
Which agent captured what? Read the audit log:
tail -f ~/Library/Logs/shotquill/audit.log # macOS (also in Console.app)
tail -f "${XDG_STATE_HOME:-$HOME/.local/state}/shotquill/audit.log" # Linux
Get-Content "$env:LOCALAPPDATA\shotquill\Logs\audit.log" -Wait # Windows PowerShell
Each JSONL entry records the action, target, destination, and the process
chain that drove it (via: "cli" or "mcp"). On macOS and Linux, the same
line is also mirrored to the unified log / journald, which user-space processes
can't rewrite; Windows currently keeps the JSONL log only. Audit logging is
best-effort so a failing log sink never blocks a capture.
Still stuck? Run squill doctor, then review its output before sharing it:
the report can include local paths, blocklist / allowlist rule labels, display
geometry, and the name of the process responsible for macOS Screen Recording.
Redact anything sensitive before pasting it into a public
GitHub issue.
Privacy
ShotQuill is built to be trustworthy, and it's open source so you can verify it:
- No keylogging. The global-hotkey listener only checks for your configured shortcut combos; it never records, stores, or forwards keystrokes.
- OCR is on-device. Text recognition uses Apple Vision on macOS, Tesseract on Linux, and the experimental WinRT backend on Windows — nothing is uploaded, and the available languages follow each backend as described above.
- Redaction has explicit boundaries. Opaque blocklist,
--mask, and detected PII fills overwrite pixels. Mosaic is visual obfuscation: the export omits the original per-pixel detail but retains block averages, so do not rely on it to hide high-risk secrets. - PII can be redacted automatically. Programmatic captures can OCR a frame
and mask likely personal data — emails, card numbers, SSNs — before it ever
leaves ShotQuill (
squill capture --redact-pii,session frame --scan-pii/--redact-pii,session export --fail-on-pii). It is best-effort, not a guarantee, and runs fully on-device. See Scripting & agents. - Sensitive apps can be blocklisted. Name a password manager (or any app) and ShotQuill refuses to capture its windows and paints it out of full-screen shots — for the GUI, CLI, and agents alike. See App blocklist.
- Agents can be put on an allowlist. Flip the default the other way: enable the app allowlist and ShotQuill captures only the apps you name, refusing every other window and every whole-screen grab — a tight leash for an agent on the CLI or MCP, off by default.
- No telemetry. ShotQuill makes no network requests of its own.
- Programmatic captures are accountable. Scripts and AI agents using the CLI or the MCP server go through the same OS consent as any app — macOS attributes Screen Recording to the invoking app, so the permission dialog names the real controller — and programmatic captures are audit-logged on a best-effort basis (metadata only, never pixels) in a local JSONL file. macOS and Linux also mirror entries to the OS-managed log store; Windows currently keeps the JSONL log only. The MCP server is strictly opt-in and, by design, returns captures to the agent's model — see Scripting & agents for what that means.
Tech stack
Python 3.10+ + PySide6 (Qt) for a self-drawn, cross-platform UI:
| Concern | macOS | Linux | Windows |
|---|---|---|---|
| GUI / editor canvas | PySide6 (Qt Widgets + Graphics View) | same | same |
| Screen capture | ScreenCaptureKit (macOS 14+), CGWindowList* fallback |
X11: QScreen.grabWindow; Wayland: xdg-desktop-portal over QtDBus |
QScreen.grabWindow (per-window via user32) |
| Window enumeration | CGWindowList (always available) |
X11: EWMH over python-xlib; Wayland: by design refuses |
user32 EnumWindows (Z-order top-level windows) |
| Global hotkeys | Carbon RegisterEventHotKey (no Input Monitoring needed) |
X11: pynput; Wayland: xdg-desktop-portal GlobalShortcuts when available |
pynput Win32 listener (no permission needed) |
| Launch at login | per-user LaunchAgent |
XDG ~/.config/autostart/shotquill.desktop |
per-user Run key (HKCU\…\CurrentVersion\Run) |
| Image processing | Qt (QImage) |
same | same |
| OCR | pyobjc → Apple Vision (Simplified Chinese + English requested) |
tesseract CLI (installed language packs) |
Experimental WinRT Windows.Media.Ocr (user-profile languages; optional windows-ocr extra) |
Platform-specific code (capture, hotkeys, OCR, autostart) sits behind small
base.py interfaces, so the editor and output layers stay portable and adding a
new OS means implementing those interfaces rather than touching the UI.
Development
python -m venv .venv && source .venv/bin/activate
pip install -e ".[dev]"
python -m shotquill # launch the menu-bar app
ruff check src tests # lint
ruff format --check src tests # formatting
pytest # tests
For local packaging smoke builds, see Packaging.
Screen capture, global hotkeys, and full-screen overlays depend on the target desktop session, so platform backends need smoke testing on their OS. Pure logic and Qt widgets can be developed and tested headlessly with
QT_QPA_PLATFORM=offscreenwhere appropriate. Window-activation scenarios (tests/test_activation_macos.py) only run under a real macOS window server — the macOS CI leg, or a Mac withoutQT_QPA_PLATFORMset — because the offscreen platform performs no activation arbitration at all.
Project layout
src/shotquill/
├── app.py # menu-bar app: tray icon, hotkey → capture → output wiring
├── cli.py # `squill` argument parsing & exit-code contract
├── command_spec.py # single source for CLI commands and MCP tool schemas
├── headless.py # shared no-GUI capture/OCR core used by cli.py and mcp.py
├── mcp.py # `squill mcp` — zero-dependency MCP stdio server
├── audit.py / paths.py # audit trail for programmatic captures; platform dirs
├── record.py / otlp.py # replayable sessions, filmstrips, archives, and traces
├── pii.py / redact.py # best-effort PII masks and app-window redaction
├── config.py / i18n.py # QSettings-backed prefs; EN/中文 string table
├── imaging.py # raw capture pixels → QImage
├── capture/ # base.py + macos.py, x11.py/qtgrab.py, wayland.py, windows.py
├── hotkeys/ # base.py + macos.py (Carbon), linux.py, wayland.py, windows.py
├── ocr/ # base.py interface; macos.py, linux.py, windows.py
├── output/ # saver.py (files), clipboard.py
├── autostart/ # base.py + macos.py, linux.py, windows.py
└── ui/ # editor, canvas, tools, smart capture overlay, settings, pin
Platform-independent logic is tested headlessly, and the
capture/hotkeys/ocr/autostart backends hide behind
base.py interfaces so a new OS is a new backend, not a UI rewrite.
Platform permissions
macOS — on first run, grant this in System Settings → Privacy & Security:
- Screen Recording — required to capture the screen and enumerate windows.
Global capture hotkeys use Carbon RegisterEventHotKey, so they do not require
Input Monitoring. ShotQuill's Settings dialog shows the live status of Screen
Recording, with a button that jumps straight to the right privacy pane.
Linux / X11 — no special permission is required: the X server lets every
client read the screen and listen for keys. xhost-style restrictions, an
extreme SELinux/AppArmor profile, or a remote session without forwarding can
each break capture; squill doctor reports what's missing.
Linux / Wayland — capture goes through xdg-desktop-portal: the first
capture pops a system dialog asking which screen / window to share, and the
choice is remembered for the session. Global hotkeys go through the
GlobalShortcuts portal when the compositor implements it; there is no separate
per-app keylogging-style permission to grant.
Uninstall
macOS
ShotQuill can inspect the active installation channel and preview everything an uninstall would change:
squill uninstall --dry-run
squill uninstall # preview, then ask for confirmation
squill uninstall --yes # skip the prompt in an interactive terminal
The same action is available from Settings → Uninstall ShotQuill… for a direct PKG installation. Homebrew installations are handed back to Homebrew and show the command below instead of allowing the app to delete Brew-owned files:
brew uninstall --cask shotquill # Homebrew install
The uninstall flow removes only the validated ShotQuill app, its protected one-shot helper, its two guarded CLI links, the three package receipts that exist, and its launch-at-login entry. After administrator authorization, the protected coordinator has already replaced or closed every App-backed process. It binds the app, helper, and CLI-link identities before authorization, then rechecks the bundle identifier, code-signature integrity, ownership, filesystem boundaries, content generation, ACLs, and literal link targets before deleting anything. Cancelling authorization, or a failure before app removal, reopens ShotQuill. A partial cleanup after app removal instead shows recovery steps; the CLI waits and returns the final result. Settings, blocklist/allowlist rules, logs, recorded sessions, screenshots, and custom save folders are preserved.
During a PKG-based Homebrew upgrade, a running ShotQuill is reopened by Homebrew and recreates an enabled launch-at-login entry. If ShotQuill was not running during the upgrade, open it once afterward to restore that entry from the preserved setting.
Before the first upgrade from the older DMG-based cask, quit ShotQuill manually,
run brew upgrade --cask shotquill, and reopen it afterward. The legacy cask did
not yet contain the automatic quit/reopen coordinator. Do not install a direct
PKG over that still-registered legacy cask. If that mixed state already exists,
upgrade or reinstall the current cask once so Homebrew records the PKG-based
uninstall coordinator, then uninstall normally.
If a current PKG installation reports that its protected helper is missing or
unsafe, reinstall the same or newer ShotQuill PKG first, then use the built-in
uninstaller. Do not execute an unverified helper with sudo.
For an older direct-PKG release that never shipped the protected helper, install the current PKG over it and then use the built-in uninstaller. This is safer than manually deleting receipt-listed paths, which may have been replaced by another tool since the older package was installed.
ShotQuill keeps no hidden state beyond these per-user files — remove them for
a clean slate. Headless captures without an explicit output path use a private
shotquill/ subdirectory under the OS temporary directory; remove it too for
immediate cleanup instead of waiting for the OS to reclaim temporary files.
| What | Where |
|---|---|
| Settings | ~/Library/Preferences/com.wardmos.ShotQuill.plist |
| Launch-at-login agent | ~/Library/LaunchAgents/com.wardmos.shotquill.plist (only if enabled in Settings) |
| Blocklist | ~/Library/Application Support/shotquill/blocklist.json |
| Allowlist | ~/Library/Application Support/shotquill/allowlist.json |
| Audit log | ~/Library/Logs/shotquill/ |
| Recorded sessions | ~/Library/Application Support/shotquill/records/ |
| Temporary CLI/MCP captures | $TMPDIR/shotquill/ (normally OS-managed) |
| Your screenshots | ~/Pictures/ShotQuill/ (or your configured folder) — yours to keep |
Linux
pipx uninstall shotquill # pipx install
# or delete the downloaded .AppImage
| What | Where |
|---|---|
| Settings | ~/.config/wardmos/ShotQuill.conf (QSettings INI) |
| Autostart entry | ~/.config/autostart/shotquill.desktop (only if enabled in Settings) |
| Blocklist | ${XDG_CONFIG_HOME:-~/.config}/shotquill/blocklist.json |
| Allowlist | ${XDG_CONFIG_HOME:-~/.config}/shotquill/allowlist.json |
| Audit log | ${XDG_STATE_HOME:-~/.local/state}/shotquill/ |
| Recorded sessions | ${XDG_DATA_HOME:-~/.local/share}/shotquill/records/ |
| pipx desktop launcher | ${XDG_DATA_HOME:-~/.local/share}/applications/shotquill.desktop (if squill desktop install was run) |
| pipx desktop icon | ${XDG_DATA_HOME:-~/.local/share}/icons/hicolor/scalable/apps/shotquill.svg (if squill desktop install was run) |
| Temporary CLI/MCP captures | ${TMPDIR:-/tmp}/shotquill/ (normally OS-managed) |
| Your screenshots | ~/Pictures/ShotQuill/ (or your configured folder) — yours to keep |
Windows
Delete the unzipped release folder, or uninstall the Python package if you installed with pip.
| What | Where |
|---|---|
| Settings | HKCU\Software\wardmos\ShotQuill (QSettings registry store) |
| Launch-at-login entry | HKCU\Software\Microsoft\Windows\CurrentVersion\Run (only if enabled in Settings) |
| Blocklist | %APPDATA%\shotquill\blocklist.json |
| Allowlist | %APPDATA%\shotquill\allowlist.json |
| Audit/debug logs | %LOCALAPPDATA%\shotquill\Logs\ |
| Recorded sessions | %LOCALAPPDATA%\shotquill\records\ |
| Temporary CLI/MCP captures | %TEMP%\shotquill\ (normally OS-managed) |
| Your screenshots | Pictures\ShotQuill\ (or your configured folder) — yours to keep |
Roadmap
- Scrolling / long-page capture
Completed work is summarized in Highlights and the platform sections above; version-by-version changes are available in GitHub Releases.
Contributing
Issues and pull requests are welcome. Please run ruff check, ruff format, and
pytest before submitting; CI runs the same on Linux, macOS, and Windows.
License
Apache-2.0. Copyright (C) 2026 wardmos.
ShotQuill bundles Qt via PySide6, which is licensed under the LGPLv3; the corresponding license notices are included with distributed builds.
Download files
Download the file for your platform. If you're not sure which to choose, learn more about installing packages.
Source Distribution
Built Distribution
Filter files by name, interpreter, ABI, and platform.
If you're not sure about the file name format, learn more about wheel file names.
Copy a direct link to the current filters
File details
Details for the file shotquill-0.1.1.tar.gz.
File metadata
- Download URL: shotquill-0.1.1.tar.gz
- Upload date:
- Size: 463.8 kB
- Tags: Source
- Uploaded using Trusted Publishing? Yes
- Uploaded via:
twine/6.1.0 CPython/3.13.13
File hashes
| Algorithm | Hash digest | |
|---|---|---|
| SHA256 |
8ef2c2a6e4367de3600b80784525aaf7948bcca31901ebc7e9f2ac9ff302e0ef
|
|
| MD5 |
f16781c4d91d7d01078ed84ab679207c
|
|
| BLAKE2b-256 |
c8f80bd98335df172111a2ffdf860d81789985e94320e60ecde7fe24705570ee
|
Provenance
The following attestation bundles were made for shotquill-0.1.1.tar.gz:
Publisher:
release.yml on wardmos/shotquill
-
Statement:
-
Statement type:
https://in-toto.io/Statement/v1 -
Predicate type:
https://docs.pypi.org/attestations/publish/v1 -
Subject name:
shotquill-0.1.1.tar.gz -
Subject digest:
8ef2c2a6e4367de3600b80784525aaf7948bcca31901ebc7e9f2ac9ff302e0ef - Sigstore transparency entry: 2461222675
- Sigstore integration time:
-
Permalink:
wardmos/shotquill@f265651f483483425e40c34f2682f3888c9f931d -
Branch / Tag:
refs/tags/v0.1.1 - Owner: https://github.com/wardmos
-
Access:
public
-
Token Issuer:
https://token.actions.githubusercontent.com -
Runner Environment:
github-hosted -
Publication workflow:
release.yml@f265651f483483425e40c34f2682f3888c9f931d -
Trigger Event:
push
-
Statement type:
File details
Details for the file shotquill-0.1.1-py3-none-any.whl.
File metadata
- Download URL: shotquill-0.1.1-py3-none-any.whl
- Upload date:
- Size: 302.2 kB
- Tags: Python 3
- Uploaded using Trusted Publishing? Yes
- Uploaded via:
twine/6.1.0 CPython/3.13.13
File hashes
| Algorithm | Hash digest | |
|---|---|---|
| SHA256 |
e9fa1a67d65df114836e4198985c7a720e596b495724b6b4c6050369a9374863
|
|
| MD5 |
4faa29c9bc37832c9d5a596fc0b03292
|
|
| BLAKE2b-256 |
a3274c793c12522599c8cfab50f6f5e67e575ecb1e1e5228bf74263a68b46a56
|
Provenance
The following attestation bundles were made for shotquill-0.1.1-py3-none-any.whl:
Publisher:
release.yml on wardmos/shotquill
-
Statement:
-
Statement type:
https://in-toto.io/Statement/v1 -
Predicate type:
https://docs.pypi.org/attestations/publish/v1 -
Subject name:
shotquill-0.1.1-py3-none-any.whl -
Subject digest:
e9fa1a67d65df114836e4198985c7a720e596b495724b6b4c6050369a9374863 - Sigstore transparency entry: 2461222887
- Sigstore integration time:
-
Permalink:
wardmos/shotquill@f265651f483483425e40c34f2682f3888c9f931d -
Branch / Tag:
refs/tags/v0.1.1 - Owner: https://github.com/wardmos
-
Access:
public
-
Token Issuer:
https://token.actions.githubusercontent.com -
Runner Environment:
github-hosted -
Publication workflow:
release.yml@f265651f483483425e40c34f2682f3888c9f931d -
Trigger Event:
push
-
Statement type:
