Pose QML (sidepose)

QML-friendly, headless pose processing with simple anchors for overlaying items on people, bones, and faces.

Sample outputs

Quick screencasts of the overlay running on sample videos:

• Single person: sample_outputs/out_single_person.mp4
• Two people: sample_outputs/out_multi.mp4

Features

• Headless PoseProcessor (QObject) for frames from VideoOutput/camera.
• QML anchors: PoseKeypointAnchor, PoseBoneAnchor, PoseFaceAnchor to position any QML item.
• PoseSpace wrapper auto-computes mapping (like VideoOutput.contentRect) so anchors just work.
• Multi-platform model cache with automatic download of MediaPipe pose models.

Requirements

• Python 3.10+
• PySide6 (Qt 6)
• MediaPipe Tasks (via the mediapipe Python package)

Install deps (example):

python3 -m pip install -U pip
pip install PySide6 mediapipe numpy

Quick start (minimal demo)

Run the example app:

python3 -m example.main

What it does:

• Plays example/sample.mp4 in a VideoOutput.
• Starts PoseProcessor and overlays keypoints, bones, and a face mask using anchors inside PoseSpace.
• On first run, downloads the default model (pose_landmarker_full.task) into a cache.

Publishing (maintainers)

This project ships wheels and sdists via GitLab CI:

• Create a tag for TestPyPI (e.g., v0.2.0-rc1) to trigger the testpypi job.
• Create a tag like v0.2.0 to enable the manual PyPI publish job.
• Provide CI variables: TWINE_USERNAME (usually token), TWINE_PASSWORD_TESTPYPI, TWINE_PASSWORD_PYPI.

Automatic model handling

You don’t need to specify a model path. If modelAssetPath is empty:

• Sidepose defaults to pose_landmarker_full and downloads it the first time.
• You can override with a name (pose_landmarker_lite|full|heavy), a local path, or a URL (file://, https://).

Cache location:

• Env override: SIDEPOSE_CACHE_DIR.
• Windows: %LOCALAPPDATA%/sidepose/models (fallback: %USERPROFILE%/AppData/Local/sidepose/models).
• macOS: ~/Library/Caches/sidepose/models.
• Linux: $XDG_CACHE_HOME/sidepose/models or ~/.cache/sidepose/models.

Minimal QML snippet

import QtQuick
import QtQuick.Window
import QtMultimedia
import Pose 1.0
import "../sidepose/qml/Pose"

Window {
	width: 1280
	height: 720
	visible: true

	VideoOutput {
		id: view
		anchors.fill: parent
		fillMode: VideoOutput.PreserveAspectFit
	}

	MediaPlayer {
		id: player
		source: Qt.resolvedUrl("sample.mp4")
		autoPlay: true
		loops: MediaPlayer.Infinite
		videoOutput: view
	}

	PoseProcessor {
		id: pose
		videoSink: view.videoSink
		backend: "mediapipe"
		useGpu: true
	}

	PoseSpace {
		anchors.fill: parent
		processor: pose

		Repeater {
			model: 33
			delegate: PoseKeypointAnchor {
				processor: pose
				keypoint: index
				Rectangle {
					anchors.centerIn: parent
					width: 6; height: 6; radius: 3
					color: "#FF4081"
				}
			}
		}

		Repeater {
			model: 12
			delegate: PoseBoneAnchor {
				processor: pose
				bone: index
				height: 4
				Rectangle {
					anchors.fill: parent
					color: "#40C4FF"
					radius: 2
				}
			}
		}

		PoseFaceAnchor {
			processor: pose
			strategy: Pose.FaceStrategy.EyesEars
			rotationFrom: Pose.FaceRotation.EarLine
			scaleFactor: 1.0
			Image {
				anchors.fill: parent
				source: Qt.resolvedUrl("face_mask.png")
				fillMode: Image.PreserveAspectFit
			}
		}
	}
}

Troubleshooting

• If the model fails to load, check your internet connection on first run, or set SIDEPOSE_CACHE_DIR to a writable directory.
• If QML types aren’t found, ensure register_qml_types() is called in your runner (example/main.py does this).
• For CPU fallback when GPU init fails, the processor automatically retries; see logs for details.

License

MIT
