simdrive 1.0.0a6

MCP-native iOS simulator + real-device automation. Agent-first: your MCP client drives via 31 vision-first tools — simdrive does not require an API key.

simdrive

MCP-native iOS simulator driver. Agent-first: your MCP client (Claude Code, Cline, etc.) drives via 31 tools — simdrive does not bring its own LLM.

30-second quickstart

pip install --pre simdrive
simdrive trial start --email [e-mail] --offline-dev
simdrive   # runs the MCP server on stdio

Then in Claude Code (or any sampling-capable MCP client), add to your MCP config:

{
  "mcpServers": {
    "simdrive": { "command": "simdrive" }
  }
}

Restart your MCP client. Ask your agent:

Take a screenshot of my booted iPhone simulator

That's it. No API key required for the MCP flow. No XCTest, no daemon, no selectors.

Trial note: --offline-dev issues a 14-day Ed25519-signed local license without contacting any cloud server — safe for sandboxes, CI, and offline development.

What you get

• Agent-first, no API key required. simdrive doesn't make its own LLM call. Your driving agent's credentials, your driving agent's reasoning. simdrive stays pure tools. run_journey delegates back to the connected MCP client via MCP sampling — no ANTHROPIC_API_KEY needed.
• Vision-first observation. Every observe returns a screenshot plus an annotated copy with numbered set-of-marks. Your agent picks a mark number and taps it — no mental reconstruction from accessibility JSON.
• Recording + replay round-trip. record_start → drive naturally → record_stop writes a self-contained YAML+PNG bundle. replay re-runs it drift-aware (SSIM advisory; structural_checks are the regression gate — see Known limitations).
• Real-device support. observe, logs, and app lifecycle work against paired iPhones/iPads via session_start({target: "device"}). Touch input routes through WebDriverAgent (WDA) on the roadmap.
• 31 documented tools covering lifecycle, observation, input, recording/replay, logs, performance, diagnostics, and robustness.

Why agent-first matters

You stay in your editor. Your agent drives the sim in the background — taps don't steal focus, your keyboard doesn't get hijacked.

Automating an iOS simulator from inside an LLM session has historically required:

• A Swift XCTest runner that breaks every Xcode release
• An accessibility tree your agent has to mentally reconstruct from JSON dumps
• Bespoke selectors (label:"Sign in") that drift with every UI change
• Watchdogs killing your runner mid-test

simdrive replaces all of that with: screenshot in, click out. Your agent already understands screenshots — the LLM is the selector engine.

Crucially: simdrive does not call an LLM itself. When run_journey needs reasoning, it delegates back to your MCP client via MCP sampling. You supply the model and the credentials — simdrive supplies the tools.

Install

pip install --pre simdrive

Requirements:

• macOS with Xcode + iOS Simulator (for native HID input)
• A booted simulator — simdrive will use a running one or boot one for you

simdrive runs in the background by default — taps and keystrokes go straight to the simulator without raising its window or stealing your keyboard focus. Verify via session_status (mode: "background").

Wire into your MCP client

Add to your .mcp.json (Claude Code, Cline, or any MCP-capable client):

{
  "mcpServers": {
    "simdrive": { "command": "simdrive" }
  }
}

Restart your client. The 31 simdrive MCP tools are now available.

Quickstart interaction

You: open Settings on iPhone 17 Pro and turn on Airplane Mode.

Agent (using simdrive):
  → session_start({device: "iPhone 17 Pro", app_bundle_id: "com.apple.Preferences"})
  → observe()                              # screenshot + annotated copy with numbered marks
  → tap({text: "Airplane Mode"})           # by visible text
  → observe()                              # sees the toggle
  → tap({mark: 12})                        # by mark number from the annotation
  → observe()                              # confirms it's green

You can also tap({x, y}) for specific pixel coords (great for replay) or tap({stable_id: "abc123"}) for hash-stable element resolution across observes:

Form	Use it for
{text: "..."}	Buttons, labels, anything with visible text
{mark: N}	When the agent has just looked at the annotated screenshot
{stable_id: "..."}	Replay-safe: survives mark reshuffling between observes
{x, y}	Deterministic replays, icons without text

That's the whole loop. No selectors. No waits. No XCTest.

Tool surface (31 MCP tools)

Group	Tools
Lifecycle (3)	session_start, session_end, session_status
Observe (1)	observe
Act (5)	tap, swipe, type_text, press_key, clear_field
Record/Replay (5)	record_start, record_stop, replay, list_replays, validate_replay
Logs (1)	logs
Performance (4)	perf, perf_baseline, perf_compare, memory
Diagnostics (5)	doctor, app_state, apps, crashes, list_devices
Robustness (4)	dismiss_first_launch_alerts, pre_grant_permissions, set_appearance, dismiss_sheet
Version (1)	version
Journey runner (2)	run_journey (MCP sampling), version

Coordinates are always in screenshot pixel space — same pixels the agent sees in the most recent observe.

Recording + replay

record_start({name: "checkout-flow"})
  ... agent does the flow naturally, calling tap/swipe/type_text ...
record_stop()  # writes ~/.simdrive/recordings/checkout-flow/recording.yaml

Later:

replay({name: "checkout-flow", on_drift: "halt"})

Each step is gated on visual similarity: if the live screen has drifted from the recorded pre-screenshot, the replay halts (halt), warns and continues (warn), or proceeds blind (force). The recording is a self-contained YAML+PNG bundle you can commit to your repo.

Important: SSIM threshold is advisory — structural assertions are the actual regression gate. See Known limitations for details.

Testing

pip install simdrive[dev]
pytest                          # unit tests, no sim required
pytest -m live                  # live tests against TestKitApp

Live tests boot a fresh TestKitApp session per test and exercise every tool: tap by text/mark/coords, type into focused fields, swipe-to-scroll, alert dismissal, record + replay with drift detection.

Known limitations + workarounds

type_text first-character drop (HID timing)

The first character occasionally drops when typing into a fresh text field (e.g. simdrive typed → Smdrive). Cause: HID injection beats the field's keyboard-focus settle.

Workaround: pass tap_first=True to type_text, or call tap on the target field immediately before typing. The keyboard focus will settle, then injection lands cleanly.

# Safe pattern for any text field
type_text({text: "simdrive", tap_first: True})

SSIM threshold is advisory; structural_checks is the regression gate

Recordings store an SSIM threshold (default 0.85). Replay drift below the SSIM threshold is reported but does NOT fail a step — the journey YAML's structural_checks (element presence, content assertions) are the actual regression gate.

Why: OPDS content, time-of-day clocks, library-list ordering, and appearance changes all shift pixels without changing app behavior. SSIM was designed as a visual decoration signal; structural assertions are what actually catch regressions. Don't chase pixel drift as if it were a behavioral regression — check struct-check in replay output instead.

dismiss_sheet covers system sheets only

dismiss_sheet swipes down on system-presented modal sheets (UIPresentationController-backed). It does not dismiss SwiftUI half-sheets (.sheet modifier with .presentationDetents([.medium])) — those use a different presentation backend.

Workaround: for SwiftUI half-sheets, use swipe from a point near the top of the sheet's drag handle to a point well below — the sheet's gesture recognizer drives the dismissal. Or tap the sheet's explicit close button if one exists.

# SwiftUI half-sheet: swipe from drag handle to below the sheet
swipe({from_x: 390, from_y: 300, to_x: 390, to_y: 800})

set_appearance may need an app respring

set_appearance (light / dark) tells the simulator to switch, but in-flight UI may not redraw until the app respringboards. Most apps observe traitCollectionDidChange correctly; some apps with custom theme handling cache colors at launch.

Workaround: if the appearance change doesn't propagate, call session_end then session_start to relaunch the app, or test against a fresh launch.

set_appearance({appearance: "dark"})
# If the app doesn't respond:
session_end()
session_start({...})   # fresh launch sees the correct appearance

Additional limitations

For Dynamic Island modals, xctrace deep profiling, MFA/2FA codes, background-mode keyboard visibility, and real-device input scope — see docs/LIMITATIONS.md.

Migration from specterqa-ios

If you're arriving from a specterqa-ios link or a 16.x install, see docs/MIGRATION.md.

What this isn't

• Not a CI replacement (yet). Designed for interactive agent sessions; CI integration is a follow-up.
• Not a fork of XCTest. simdrive deliberately avoids Apple's testing stack to stay durable across Xcode releases.
• Not a managed SaaS for running iOS tests. simdrive is BYOK (bring your own keys) — your agent, your credentials, your simulator.

License

Elastic License 2.0. Free for personal/internal use. Prohibits offering simdrive as a competing managed service. Built by SyncTek.
