spikecurate

author: steeve laquitaine - laquitainesteeve@gmail.com

Curate sorted single-unit quality from SpikeInterface extractors, using a fractional-logistic classifier trained on SpikeInterface quality metrics.

Given a recording, a ground-truth sorting, a sorter's output, the sorter's own single-unit calls, and expert good/bad labels for a subset of those units, spikecurate engineers quality-metric features, trains a classifier of accurately- vs. poorly-sorted single units, and reports its cross-validated precision/recall.

Install

pip install -e .

Documentation

Full API reference (built with Sphinx from the docstrings in src/spikecurate/): https://steevelaquitaine.github.io/spikecurate/

Rebuilds automatically on every push to master (.github/workflows/docs.yml). To build it locally:

pip install -e .[docs]
sphinx-build -b html docs docs/_build/html

Demo notebook

demo/demo_03.ipynb walks through FractionalLogisticClassifier's API - train, crossval_evaluate, predict, score - using the real, already-engineered feature dataset checked into this repo at dataset/single_unit_quality_dataset.csv. No SpikeInterface extractors needed, just pandas + spikecurate:

pip install -e .
python -m ipykernel install --user --name spikecurate --display-name spikecurate
jupyter notebook demo/demo_03.ipynb

Usage

import spikecurate

result = spikecurate.run(
    recording=recording,          # spikeinterface RecordingExtractor
    sorting_true=sorting_true,    # spikeinterface ground-truth SortingExtractor
    sorting=sorting,              # spikeinterface SortingExtractor (e.g. Kilosort4)
    we_save_path="waveforms/single_units",
    single_unit_ids=single_unit_ids,   # e.g. sorting.unit_ids[sorting.get_property("KSLabel") == "good"]
    good_unit_ids=good_unit_ids,       # subset of single_unit_ids, >80% agreement with ground truth
    bad_unit_ids=bad_unit_ids,         # remaining subset of single_unit_ids
    predict_unit_ids=single_unit_ids[:10],  # units to classify with the trained model; defaults to all
    job_kwargs=dict(n_jobs=-1, progress_bar=True),
)

result["feature_correlations"]           # pd.DataFrame: feature correlation matrix
result["results"]["metric_stats"]        # median/std/95% CI precision & recall, cross-validated
result["model"]                          # FractionalLogisticClassifier, trained on the full dataset
result["predictions"]                    # DataFrame indexed by unit id: probability, predicted_label, predicted_quality

The classifier's own API

spikecurate.run is a convenience pipeline built on top of FractionalLogisticClassifier, which has a scikit-learn-flavored API and is usable standalone (e.g. to retrain/re-predict without redoing waveform extraction, or to classify units engineered outside spikecurate.run):

from spikecurate.model import FractionalLogisticClassifier

model = FractionalLogisticClassifier(predictors)   # predictors: result["data"]["predictors"]
model.crossval_evaluate(dataset)                    # cross-validated precision/recall (each fold trains its own fit)
model.train(dataset)                                 # fit on the full labeled dataset; returns self
model.predict(features)                              # DataFrame: probability, predicted_label, predicted_quality
model.score(dataset)                                 # precision/recall of the trained model against dataset's own labels

features passed to predict just needs unit id as its index and the columns in model.predictors - it doesn't need a quality_label column (that's the whole point: predicting labels for units you don't already have labels for).

Other pipeline stages are also usable standalone:

from spikecurate.features import load_dataset
from spikecurate.plotting import plot_precision_recall

Testing

• tests/test_pipeline.py: end-to-end smoke test of spikecurate.run() against synthetic SpikeInterface data. Runs on every push/PR (.github/workflows/tests.yml).
• tests/test_classification.py: pins the classifier's numeric output (crossval_evaluate, train+score, predict) against dataset/single_unit_quality_dataset.csv - the same real engineered dataset demo_03.ipynb walks through - so a future change to the model/crossval/predict code that silently changes results, not just one that crashes, gets caught. Needs no SpikeInterface extractors, so it's fast. Runs on every push to master (.github/workflows/regression.yml).

Citation

If you use this package, please consider citing:

Laquitaine, S., Imbeni, M., Tharayil, J., Isbister, J. B., & Reimann, M. W. (2024). Spike sorting biases and information loss in a detailed cortical model. bioRxiv. https://doi.org/10.1101/2024.12.04.626805

@article{laquitaine2024spikesorting,
  title   = {Spike sorting biases and information loss in a detailed cortical model},
  author  = {Laquitaine, Steeve and Imbeni, Milo and Tharayil, Joseph and Isbister, James B. and Reimann, Michael W.},
  journal = {bioRxiv},
  year    = {2024},
  doi     = {10.1101/2024.12.04.626805},
  url     = {https://www.biorxiv.org/content/10.1101/2024.12.04.626805v1}
}

License

GNU General Public License v3.0 - see LICENSE.

Notes

• Requires a principal_components extension on the WaveformExtractor (computed automatically by spikecurate.run) - the silhouette quality metric depends on it.
• good_unit_ids and bad_unit_ids must partition single_unit_ids exactly (every single unit gets exactly one label) - spikecurate.run will raise AssertionError otherwise.
• features.load_dataset always returns dataset sorted by unit id (dataset.sort_index()). FractionalLogisticClassifier.crossval_evaluate's cross-validation splits train/test by row position (random.sample(range(n), n_train)), so for a given dataset and seeds, results are reproducible only if row order is pinned - passing an unsorted dataset (e.g. one you built yourself, in whatever order the sorting extractor's unit ids happened to come in) will still run, but won't reproduce the same split as the same content sorted differently.
