stackcore 0.3.3

A lightweight Python package for mechanical tolerance stack‑up analysis.

Precision at the core: total tolerance stack‑up, intelligently fused.

StackCore is a lightweight Python package for mechanical tolerance stack‑up analysis, integrating Monte Carlo simulation and data‑driven intelligence.

---

🚀 Features

• 🧮 Tolerance stack‑up under control: manage multi‑component linear and geometric assemblies.
• 🔁 Monte Carlo engine: generate distributions, confidence ranges, and worst‑case scenarios.
• 📊 Flexible output: summary stats, histograms, and data visualization tools.
• 🔌 Clean APIs: Stack, PStack, MStack
• 🛠️ Designed for engineers: zone‑independent, boundary‑aware, CAD/tool‑agnostic.

---

📥 Installation

pip install stackcore

Usage

To import the stackcore module, use

import stackcore

The main component, the Stack can be imported as follows:

from stackcore import Stack

The Stack Component taks a few key arguments:

Main Plane

The main plane is defined by a set of 3 points, and defines the main plane that the tolerance stack up will measure against. Here's an example:

m=np.array([[3,  2, -1],
            [0,  3,  3],
            [-1, 2,  4]])

Components

The components variable contains a dictioary of planes and their respective tolerances, with many various tolerance types such as displacement and radial (axis). Here's an example:

components = [
             {'plane': np.array([[-8, 1, 5],
                                 [-4, 7, 3],
                                 [-3, 2, 6]]),
              'tolerances': [{'type': 'cylindrical',
                              'tol': [-0.1, +0.1],
                              'axis': np.array([[0,0,1],
                                                [0,0,1],
                                                [-.7, -0.9, 0.]])},
                              {'type': 'displacement',
                               'tol' : [-0.1, +0.1],
                               'axis': np.array([[0,0,1],
                                                 [0,0,1],
                                                 [-.7, -0.9, 0.]])}]}
]

Metrics

The metrics variable contains a dictionary of the targeted metrics and their reference type. The 2 tolerance types currently supported are 'Angular' and 'Linear' Here's an example:

metrics = [
    { 'name': 'alpha',
      'type': 'Angular'
    }
]

Path

The path variable defines where any generated figures should be stored. Here's an example:

path = 'path/to/figures/'

Parallel Processing

For faster processing, the PStack object is provided that uses the numba package to parallelize the loops in the monte carlo simulation. To use the PStack, import it using:

from stackcore import PStack

All of the same functions of the Stack object are available in the PStack object.

Metrology

(v0.3.0) StackCore now supports component compatibility testing via metrology data. To access this, use the MStack object, which takes the same inputs as the serial and parallel stacks above. To use the MStack object:

from stackcore import Mstack

For metrology, the component input looks a little different. Each component is defined by 3 points, and each point has its own metrology (∂x, ∂y, ∂z) associated with it. Here's an example:

[
        {
            "name": "Component",
            "points": [
                {
                    "coordinates": [
                        -20,
                        10,
                        6
                    ],
                    "dx": 1.0,
                    "dy": -1.0,
                    "dz": 0.0
                },
                {
                    "coordinates": [
                        -15,
                        12,
                        5
                    ],
                    "dx": 0.0,
                    "dy": 0.2,
                    "dz": 0.3
                },
                {
                    "coordinates": [
                        -3,
                        5,
                        6
                    ],
                    "dx": -1.0,
                    "dy": 0.01,
                    "dz": -0.4
                }
            ]
        }
    ]

For a full example, see example.py

Stackfuse

To use a GUI interface, see StackFuse: A Fusion360 add-in that connects with stackcore to create an intuitive way to tolerance and analyze mechanical assemblies.
