Non-trivial conversion of STL files into STEP files.
Project description
Intelligent conversion from STL to STEP
This cli program converts STL files into STEP file in a non-trivial way. It segments the mesh into basic shapes. That means, the generated STEP file isn't only a bunch of triangles, it has planes, cylinders, spheres etc. resulting in less memory usage and it is friendlier to CAD and CAM.
Experimental state: Only planes are implemented! Holes are not supported!
Installation
pip3 install stl2step
Usage
python3 -m stl2step myfile.stl
The out file is named similar to the input file: myfile.step, because it only replaces .stl with .step.
Autor
Stefan Helmert stefan@entroserv.de
License
AGPL v3
