Swage

Turn variable-sized dense segments into efficient GPU tile tasks.

Swage is an experimental Python-embedded GPU compiler built on MLIR and LLVM. You write a Triton-like kernel that describes what happens to one logical segment; Swage is designed to derive fixed-size GPU tile tasks and generate NVIDIA GPU code through MLIR, LLVM, and NVPTX.

Status: pre-alpha, M8 internal split-CTA qualification complete. The canonical fixed vector-add kernel remains the public execution subset. Internal segmented sum, max, and stable ragged-softmax modules lower to a sequential CPU oracle and one CTA per segment on NVIDIA GPUs. For one canonical identity segmented sum, private M7 and M8 paths run direct warp/CTA work and split oversized segments into partial and merge CTAs. Public segment syntax and public segmented launch remain planned. See Current status for the exact boundary.

The programming model

The executable fixed-block vector-add subset is deliberately Triton-like. It infers its narrow ABI from PyTorch CUDA tensors and Python integers (n maps to sl.int32):

import swage as sw
import swage.language as sl
import torch


@sw.jit
def add_kernel(x_ptr, y_ptr, output_ptr, n, BLOCK: sl.constexpr):
    pid = sl.program_id(0)
    offsets = pid * BLOCK + sl.arange(0, BLOCK)
    mask = offsets < n
    x = sl.load(x_ptr + offsets, mask=mask, other=0.0)
    y = sl.load(y_ptr + offsets, mask=mask, other=0.0)
    sl.store(output_ptr + offsets, x + y, mask=mask)


length = 1024
block = 128
x = torch.randn(length, device="cuda", dtype=torch.float32)
y = torch.randn(length, device="cuda", dtype=torch.float32)
output = torch.empty_like(x)
add_kernel.launch(
    arguments={
        "x_ptr": x,
        "y_ptr": y,
        "output_ptr": output,
        "n": length,
    },
    constexprs={"BLOCK": block},
    grid=((length + block - 1) // block,),
)
torch.testing.assert_close(output, x + y)

The PyPI wheel installs the importable swage package. It does not contain the native mlir_swage package or compiler build output. Both launch() and emit_mlir() require a bindings-enabled native build and its build-tree mlir_swage package. Install the optional PyTorch dependency with pip install "swage-compiler[pytorch]". launch() is keyword-only, asynchronous, returns None, and uses the current PyTorch CUDA stream. emit_mlir() remains compile-only, and its explicit signature= form remains available without PyTorch. Direct kernel calls remain unavailable. PTX emission is an internal runtime operation, not a public API.

The research target is the segment API: one segment-local program, from which the compiler derives packing, bucketing, partitioning, partial reductions, and static or persistent scheduling as the runtime segment-length distribution changes:

@sw.jit
def segmented_softmax(values_ptr, offsets_ptr, output_ptr):
    sid = sl.segment_id(0)
    segment = sl.segment(values_ptr, offsets_ptr, sid)

    x = sl.load_segment(segment)
    maximum = sl.max(x)
    numerator = sl.exp(x - maximum)
    denominator = sl.sum(numerator)

    sl.store_segment(output_ptr, segment, numerator / denominator)

Architecture

Python @sw.jit kernel
        │  restricted Python AST
        ▼
Swage semantic MLIR
        ├── M3 fixed vector add → gpu / nvvm / LLVM IR
        │                        → PTX → CUDA Driver API
        │                        → current PyTorch stream
        ├── M4 segmented sum/max → sequential scf/memref CPU oracle
        │                         → one CTA per segment → NVPTX
        ├── M5 ragged softmax → max → exponential sum → normalize/store
        │                      → internal CPU and one-CTA GPU qualification
        ├── M6 identity segmented sum → SwagePlan classify
        ├── M7 private materialization → stable warp/CTA task IDs
        │                              → one fused mixed GPU kernel
        └── M8 private split path → ordered CTA chunks up to 4096 elements
                                  → partial scratch sums → merge CTAs

The three-level vocabulary is load-bearing: a segment is a logical, runtime-sized, internally dense data object; a task is a schedulable unit of execution; a tile is a fixed-size physical unit processed by a warp or CTA. See docs/concepts/segments-tiles-tasks.md.

Current status

The M5 differential suite covers all-empty, all-singleton, many-tiny, few-huge, one-outlier, and alternating-empty segment distributions. The runner is internal: it retains the five-argument values, offsets, output, value-count, and segment-count ABI, validates host-visible metadata, and does not widen swage.language, emit_mlir(), or public launch().

The M6 planning conversion admits only the capture-free, map-free, single-stage identity segmented sum. It adds a private planning companion that records warp then CTA as the legal policy order. M7 privately clones the semantic module, runs that conversion, reads the recorded threshold, and classifies validated runtime metadata into stable warp and CTA segment-ID lists. Pure policies use the same task-ID ABI. Mixed execution uses one 128-thread kernel with four one-segment warp slots per warp block followed by one block per CTA task.

M8 keeps warp and CTA as the complete policy list and adds private task decomposition for segments longer than 4096 elements. The classifier emits ordered absolute input chunks followed by one compact scratch-range merge per split segment. Mixed execution launches direct work, all partial CTAs, then all merge CTAs on the same current stream. The exact and nontrivial f32 suites pass against PyTorch and the CPU oracle on NVIDIA RTX A6000 sm_86. This is a correctness qualification only; the frozen M7 benchmark and its 1.05 gate are unchanged.

The frozen bimodal benchmark on NVIDIA RTX A6000 sm_86 measured medians of 0.067584 ms for pure warp, 0.070656 ms for pure CTA, and 0.063488 ms for mixed execution. Its mixed-to-best-pure ratio is 0.939394, passing the predeclared maximum of 1.05. This qualifies only the private canonical identity-sum path. It does not add public segment syntax or public segmented execution.

The research question: can one segment-local program automatically produce competitive warp, CTA, split-CTA, and persistent schedules as the runtime segment-length distribution changes? Swage did not invent ragged tensors, segmented reductions, persistent kernels, or tile programming; the intended contribution is the automatic derivation of the schedule from one segment-local kernel.

Getting started

# CPU-only: build the pinned LLVM/MLIR (once, ~1 hour), then Swage
./scripts/fetch_llvm.sh
./scripts/build_llvm.sh
./scripts/build_swage.sh        # builds swage-opt and runs the lit suite

# Python package and tests
make setup
make test

The native bindings require the pinned LLVM/MLIR install with its Python bindings enabled. Run ninja -C build check-swage-python after the native build; it sets the build-tree PYTHONPATH for mlir_swage. On Linux with PyTorch CUDA and libcuda, the M3 subset can then compile and launch the fixed vector add. The internal native suite also qualifies M4 segmented sum and max plus M5 ragged softmax. The public launch path has no CUDA toolkit dependency.

See the runnable M3 walkthrough. A GPU is not required for the CPU and compile-only development paths.

More

• DESIGN.md: architecture and design invariants
• ROADMAP.md: phased plan and honest phase status
• CONTRIBUTING.md: contributor paths, CPU-only onboarding
• docs/adr/: architecture decision records

License

MIT. See LICENSE.
