swarm-contrastive-decomposition 0.1.7

Decomposition of Neurophysiological Time Series Signals with a Particle Swarm Optimised Independence Estimator

Swarm-Contrastive Decomposition 🧠

A Python package for decomposition of neurophysiological time series signals using a Particle Swarm Optimised Independence Estimator for Blind Source Separation.

Table of Contents 📚

• Installation
• Quick Start
• Usage
• Configuration
• Test Data
• Contributing
• License
• Citation
• Contact

Installation 🛠️

From PyPI (Recommended)

pip install swarm-contrastive-decomposition

From GitHub (Latest Development Version)

pip install git+https://github.com/AgneGris/swarm-contrastive-decomposition.git

From Source

git clone https://github.com/AgneGris/swarm-contrastive-decomposition
cd swarm-contrastive-decomposition
pip install -e .

Verify Installation

python -c "import scd; print(f'SCD version: {scd.__version__}')"

Quick Start 🚀

import scd

# Train with default configuration
dictionary, timestamps = scd.train("data/input/emg.npy")

# Save results
scd.save_results("data/output/emg.pkl", dictionary)

Usage

Basic Usage

import scd

# Use a predefined configuration
dictionary, timestamps = scd.train(
    "path/to/your/data.mat",
    config_name="surface"  # or "default", "intramuscular"
)

scd.save_results("output.pkl", dictionary)

With Configuration Overrides

import scd

# Override specific parameters
dictionary, timestamps = scd.train(
    "data/input/emg.npy",
    config_name="surface",
    max_iterations=100,  # override for quick testing
    output_final_source_plot=True
)

Step-by-Step Control

import scd

# Load configuration
config = scd.load_config("surface")

# Load data
neural_data = scd.load_data("data/input/emg.npy", device=config.device)

# Preprocess
neural_data = scd.preprocess_data(neural_data, config)

# Train model
dictionary, timestamps = scd.train_model(neural_data, config)

# Save results
scd.save_results("output.pkl", dictionary)

Supported Data Formats

• .mat — MATLAB files (specify the variable name with key parameter)
• .npy — NumPy arrays

# For .mat files with custom variable name
dictionary, timestamps = scd.train("data.mat", key="emg_data")

# For .npy files
dictionary, timestamps = scd.train("data.npy")

Data should have shape (time, channels) or (channels, time) — the loader will automatically transpose if needed.

Configuration ⚙️

Configurations are defined in scd/configs.json. Available presets:

Config Name	Use Case	Sampling Rate	Description
default	General purpose	10240 Hz	Balanced settings for most EMG data
surface	Surface EMG	10240 Hz	Optimized for surface recordings
intramuscular	Intramuscular EMG	10240 Hz	Higher iterations for fine-wire recordings

Configuration Parameters

Parameter	Description	Default
device	"cuda" for GPU or "cpu"	"cuda"
acceptance_silhouette	Quality threshold for source acceptance	0.85
extension_factor	Typically 1000 / num_channels. Higher values may improve results	25
low_pass_cutoff	Low-pass filter cutoff frequency (Hz)	4400
high_pass_cutoff	High-pass filter cutoff frequency (Hz)	10
sampling_frequency	Sampling frequency of your signal (Hz)	10240
start_time	Start time for signal trimming (s). Use 0 for beginning	0
end_time	End time for signal trimming (s). Use -1 for entire signal	-1
max_iterations	Maximum decomposition iterations	200
max_firing_rate_hz	Expected maximum motoneuron firing rate (Hz). Used to derive the temporal-separation bound on extension_factor and to validate reset_peak_separation_ms	50.0
peel_off_window_size_ms	Window size for spike-triggered average (ms). peel_off_window_size in samples is derived automatically as ms × fs / 1000	20
reset_peak_separation_ms	Minimum distance between two detected peaks in the source signal (ms), converted to samples as ms × fs / 1000. Must be less than the minimum ISI at max_firing_rate_hz	4.0
output_final_source_plot	Generate plot of final sources	false
use_coeff_var_fitness	Use coefficient of variation fitness. true for EMG, false for intracortical	true
remove_bad_fr	Filter sources with firing rates < 2 Hz or > 100 Hz	true
clamp_sources	Clamp source amplitudes to ±30 σ during ICA to suppress outliers	true

Custom Configuration

Add your own configuration to scd/configs.json:

{
    "my_experiment": {
        "device": "cuda",
        "acceptance_silhouette": 0.80,
        "extension_factor": 30,
        "sampling_frequency": 2048,
        ...
    }
}

Then use it:

dictionary, timestamps = scd.train("data.mat", config_name="my_experiment")

Extension Factor Constraints

The extension factor K is validated automatically against two mathematical constraints before each run.

Variables

Symbol	Meaning
K	Extension factor (extension_factor config parameter)
M	Number of clean channels = total channels − bad_channels
L	MUAP length in samples = floor(15 ms × fs / 1000)
N	Assumed number of sources = 30 (fixed assumption)
T	Minimum inter-spike interval = floor(fs / max_firing_rate_hz) samples

Constraint 1 — Model Identifiability

Starting from the over-determination condition for the extended mixing matrix:

K · M  ≥  N · (K + L − 1)

Rearranging (requires M > N):

K · (M − N)  ≥  N · (L − 1)
K  ≥  ceil( N · (L − 1) / (M − N) )   →   K_min

K_min is the minimum K needed for the extended system to be theoretically identifiable (more observations than unknowns in the mixing model). In practice, the sparse-EMG assumption means the algorithm can converge below this bound; a UserWarning is issued rather than an error when K < K_min.

Constraint 2 — Temporal Separation

The observation window for a single spike spans L + K − 1 samples after extension. It must be shorter than the fastest expected inter-spike interval T:

L + K − 1  <  T
K  ≤  T − L   →   K_max

A ValueError is raised if K > K_max, because temporal aliasing between adjacent spikes is guaranteed.

Valid range and automatic validation

K_min  ≤  K  ≤  K_max

At the default sampling frequency of 10 240 Hz with max_firing_rate_hz = 50:

Quantity	Value
L (15 ms @ 10 240 Hz)	153 samples
T (50 Hz max_firing_rate_hz)	204 samples
K_max	51

All built-in presets (default K=25, intramuscular K=20, surface K=5) satisfy K ≤ 51.

Tip: If your recordings include faster-firing units (e.g. 70 Hz), set max_firing_rate_hz accordingly — this tightens K_max and prevents temporal aliasing at that firing rate.

Programmatic access

from scd import compute_extension_factor_bounds

k_min, k_max = compute_extension_factor_bounds(
    num_channels=64,
    bad_channels=[56],          # 63 clean channels
    sampling_frequency=10240,
)
print(f"Valid K range: [{k_min}, {k_max}]")

Test Data 🧪

The repository includes test data to verify your installation:

• File: data/input/emg.npy
• Type: Surface EMG
• Sampling rate: 10240 Hz
• Configuration: Use "surface" config

import scd

# Run with test data
dictionary, timestamps = scd.train(
    "data/input/emg.npy",
    config_name="surface"
)

print(f"Found {len(dictionary)} motor units")

Contributing 🤝

We welcome contributions! Here's how you can contribute:

1. Fork the repository
2. Create a feature branch (git checkout -b feature/newfeature)
3. Commit your changes (git commit -m 'Add some newfeature')
4. Push to the branch (git push origin feature/newfeature)
5. Open a pull request

License 📜

This project is licensed under the CC BY-NC 4.0 License.

Citation

If you use this code in your research, please cite our paper:

@article{grison2024particle,
  author={Grison, Agnese and Clarke, Alexander Kenneth and Muceli, Silvia and Ibáñez, Jaime and Kundu, Aritra and Farina, Dario},
  journal={IEEE Transactions on Biomedical Engineering},
  title={A Particle Swarm Optimised Independence Estimator for Blind Source Separation of Neurophysiological Time Series},
  year={2024},
  volume={},
  number={},
  pages={1-11},
  doi={10.1109/TBME.2024.3446806},
  keywords={Recording; Time series analysis; Sorting; Vectors; Measurement; Electrodes; Probes; Independent component analysis; particle swarm optimisation; blind source separation; intramuscular electromyography; intracortical recording}
}

@article{grison2025unlocking,
  title={Unlocking the full potential of high-density surface EMG: novel non-invasive high-yield motor unit decomposition},
  author={Grison, Agnese and Mendez Guerra, Irene and Clarke, Alexander Kenneth and Muceli, Silvia and Ib{\'a}{\~n}ez, Jaime and Farina, Dario},
  journal={The Journal of Physiology},
  volume={603},
  number={8},
  pages={2281--2300},
  year={2025},
  publisher={Wiley Online Library}
}
