terminalboard

A pure-terminal TensorBoard viewer — with an AI assistant built in.

Watch your live training curves right inside any terminal — locally or SSH'd into a remote box — and chat with your runs in plain English. Scalars, text, histograms (heatmap or distribution bands), PR curves and an HParams table, drawn as crisp Unicode/braille. No browser, no X11, no port forwarding.

The usual remote-TensorBoard dance is ssh -L 6006:… + a browser, or giving up and grep-ing the logs. terminalboard reads the event files directly and draws them in the terminal — a plain SSH session is all you need (and it's just as nice locally).

Contents — Install · Highlights · Usage · Plot types & controls · AI assistant · Configuration · Design · Roadmap

Install

pip install terminalboard            # one small dependency (plotext); Python 3.9+
terminalboard path/to/tb_logs        # live dashboard in any terminal

# remote training box? just SSH in first — no port forwarding needed:
#   ssh remote
#   terminalboard path/to/tb_logs

Or run it without installing: uvx terminalboard <logdir> (or pipx run terminalboard <logdir>).

Optional extras:

git clone https://github.com/yexLing/terminalboard.git
cd terminalboard
pip install -e '.[tb,llm,dev]'        # editable, with all extras + test tools
python examples/gen_demo_logs.py      # writes ./demo_logs/ (3 runs, every type)
terminalboard demo_logs

Highlights

• 📈 Every TensorBoard type, as terminal text — scalar curves, text summaries, histograms (heatmap or distribution bands), PR curves, and a runs × hyperparameters HParams table.
• 🔍 Built for comparison — multi-experiment overlay with stable colors, smoothing, log-Y, step↔time, zoom, a powerful tag/experiment filter grammar, and a drill-down detail view with a value cursor.
• 🤖 AI assistant (a) — a multi-session chat (sidebar or full-screen) that sees your live view + all log data, answers questions and operates the dashboard for you, with any LLM provider. Opt-in, audited, privacy-conscious.
• 🪶 Light by default — the default install is one small dependency (plotext) and a self-contained pure-Python event parser; tensorboard and litellm are optional extras.
• ✨ Smooth TUI — flicker-free repaints (alternate screen + synchronized output), live tailing, per-logdir saved view state, a config file, CSV export.

Usage

terminalboard LOGDIR [options]

  LOGDIR / --logdir   directory of TensorBoard event files (scanned recursively)
  --tb                parse with the tensorboard library (needs [tb]); the
                      built-in pure-Python parser is the default
  --tags GLOB         filter tags, e.g. 'train/*loss*,val/*' (live-editable: t)
  --experiments GLOB  filter experiments/runs (live-editable: f)
  --smooth ALPHA      EMA smoothing weight in [0,1) (default: 0.6; 0 disables)
  --grid RxC          panels per page (default: 2x3)
  --interval SECONDS  live refresh interval (default: 2.0)
  --once              render a single frame and exit
  --list              list all tags and exit

terminalboard logs                       # live dashboard
terminalboard logs --tags 'train/*loss*' # filter to loss curves
terminalboard logs --grid 2x2            # 4 panels per page
terminalboard logs --once                # one frame and exit (good for CI/cron)

Plot types

A page can mix any of these — each panel adapts to its tag's kind:

• Scalars — line/braille curves (multiple experiments overlaid).
• Text summaries — the latest text shown in a panel.
• Histograms — a heatmap over steps, or distribution bands (percentiles over steps) with b.
• PR curves — precision-vs-recall curves (pr_curves plugin).
• HParams — a full-screen runs × hyperparameters × metrics table (P).

Controls (live mode)

AI assistant

Optional — pip install 'terminalboard[llm]'.

Press a to open a chat with your runs. The model both drives the dashboard (filter, pick a type, smooth, zoom, open a tag, open HParams…) and analyzes your results — in one turn. For example:

• "show only validation losses, smoothed" → applies the filter + smoothing
• "which run is overfitting?" → a short train-vs-val comparison
• "open the pr curve and tell me if it's good" → opens it and gives a verdict

It's a multi-session chat — sidebar (the dashboard re-tiles beside it) or full-screen (^F). It sees your live view (focused/visible tags, counts, mode) plus all log data, streams the answer with light markdown, and keeps sessions per-logdir (/new, /next, /rename, …; Esc closes). Actions are a fixed, typed whitelist — it can't run shell or touch files.

Powered by LiteLLM, so any provider works. On first use a setup form lets you search a model (type deepseek, qwen, claude, gpt… → ↑/↓ + Enter, or type any custom/self-hosted string) and enter the matching API key. A small/cheap model is plenty here:

(API base stays blank for hosted providers; set it only for your own OpenAI-compatible server — vLLM, Ollama, Azure…)

⚠️ Privacy: queries send your tag names + metric summaries to the chosen provider, and tag names can leak architecture details. If that matters, use a local model (ollama/...) so nothing leaves your machine. The feature is off until you configure it, and your API key is stored locally (~/.local/state/terminalboard/llm.json, chmod 600).

Configuration

Set defaults in ~/.config/terminalboard.toml (or $TERMINALBOARD_CONFIG); CLI flags override them. Needs Python 3.11+ (tomllib) or tomli.

[terminalboard]
smooth = 0.6
grid = "2x3"
xaxis = "step"     # or "time"
logy = false
tags = "train/*"
# experiments = "baseline | scaling"
# csv_dir = "~/tb-exports"   # pre-filled folder in the CSV (w) save prompt
# restore = true             # save/restore per-logdir view state (default: on)

Your filters, zoom, smoothing, axis, order and focus are saved per-logdir on quit and restored next time (under $XDG_STATE_HOME, default ~/.local/state). Explicit CLI flags win; --reset-view starts fresh; restore = false disables it.

Design

1. Read the event files (events.out.tfevents.*), scanned recursively for multiple runs, into a typed series model.
2. Render the selected tags as Unicode/braille text — curves, text panels, histogram heatmaps/bands, PR curves — tiled into a grid that fits the terminal.
3. Watch the logdir and re-render when new data lands. Repaints are flicker-free (alternate screen buffer + synchronized output, DEC 2026) and an idle dashboard isn't repainted at all.
4. Ask (optional): the assistant gets a compact summary of your current view
   • log data, replies in the chat, and turns natural language into the same typed actions the keys drive.

Two parsing backends: the default is a self-contained pure-Python TFRecord + protobuf-wire parser (tiny install, fast startup, ideal for a thin remote box). --tb uses the official tensorboard EventAccumulator instead (needs [tb]; falls back to the built-in parser with a note if absent).

Roadmap

Done: pure-Python + --tb parsers · scalars, text, histograms (heatmap/distribution), PR curves, HParams table · multi-experiment overlay, zoom, drill-down cursor, filter grammar · log-Y, step↔time, config diff, CSV export, config file + saved view state · AI chat assistant (any provider, searchable model picker) · published to PyPI.

Next: assistant pull-tools agent loop (reads data on demand) · redaction mode for sensitive tag names · a non-interactive --analyze report.

Contributing

python3 -m venv .venv
.venv/bin/pip install -e '.[tb,llm,dev]'
.venv/bin/pytest -q
.venv/bin/terminalboard demo_logs --once

Issues and PRs welcome. Releases are documented in RELEASING.md; the version is single-sourced from terminalboard/__init__.py.

If terminalboard saves you a port-forward, please ⭐ the repo — it helps.

License

MIT.
