toonbuilder 0.1.1

Convert JSON and XML files to TOON, a schema-aware data formatting for LLM prompts.

toonbuilder

Convert JSON and XML files to TOON, a schema-aware data formatting for LLM prompts.

[!IMPORTANT] The original author of the TOON data formatting is xxx and an implementation of a TOON conversion system in Python already exists (https://github.com/toon-format/toon-python). This serves as a more thorough implementation of the package.

Table of Contents

• Why Toon?
• Installation
• Quick Start
• Usage
• API Reference
• Contributing
• License

Why Toon?

TOON (Token-Oriented Object Notation) is a compact, human-readable data format specifically designed to minimize token usage in Large Language Model (LLM) prompts while maintaining full compatibility with JSON's data model.

The Problem with Traditional Formats

When working with LLMs, every token counts—both for cost and context window limitations. Traditional data formats like JSON and XML are verbose and token-expensive:

JSON Example (verbose):

{
  "users": [
    {
      "id": 1,
      "name": "Alice",
      "role": "admin",
      "active": true
    },
    {
      "id": 2,
      "name": "Bob",
      "role": "user",
      "active": true
    },
    {
      "id": 3,
      "name": "Charlie",
      "role": "user",
      "active": false
    }
  ]
}

TOON Example (compact):

users[3]{id,name,role,active}:
  1,Alice,admin,true
  2,Bob,user,true
  3,Charlie,user,false

Key Benefits

• Approximately 40% token reduction: TOON uses far fewer tokens than JSON, with the biggest savings for tabular data.
• Higher LLM retrieval accuracy: In multi-model benchmarks TOON achieved 73.9% accuracy compared with JSON’s 69.7%.
• Lossless, bidirectional conversion: Converts to and from JSON and XML without losing information.
• LLM-friendly schema: Explicit array lengths ([N]) and field headers ({fields}) provide clear structure that helps models parse reliably.
• Tabular optimization: Uniform arrays of objects are collapsed into CSV-style rows for compactness and efficiency.
• Human-readable layout: YAML-like indentation keeps the format easy to read and debug.

When to Use TOON

TOON excels when you have:

• Large datasets with uniform structures (e.g., database records, API responses)
• Arrays of objects with consistent fields
• Token-limited LLM contexts where every token matters
• Need for both human readability and machine efficiency

When to Stick with JSON/XML

• Deeply nested, non-uniform structures with low tabular eligibility
• Existing systems that require native JSON/XML compatibility
• Applications where parsing performance is more critical than token efficiency

For more details, see the official TOON specification.

Installation

Install toonbuilder from PyPI using pip:

pip install toonbuilder

Or using pip3:

pip3 install toonbuilder

Requirements

• Python 3.7 or higher
• No external dependencies required (uses only Python standard library)

Development Installation

To install from source for development:

git clone https://github.com/0xPolybit/toonbuilder.git
cd toonbuilder
pip install -e .

Quick Start

JSON to TOON Conversion

from toonbuilder import json_to_toon

# Convert JSON string to TOON
json_data = {
    "users": [
        {"id": 1, "name": "Alice", "role": "admin"},
        {"id": 2, "name": "Bob", "role": "user"}
    ]
}

toon_output = json_to_toon.encode(json_data)
print(toon_output)
# Output:
# users[2]{id,name,role}:
#   1,Alice,admin
#   2,Bob,user

# Convert TOON back to JSON
original_data = json_to_toon.decode(toon_output)
print(original_data)

XML to TOON Conversion

from toonbuilder import xml_to_toon

# Convert XML string to TOON
xml_string = """
<users>
    <user>
        <id>1</id>
        <name>Alice</name>
        <role>admin</role>
    </user>
    <user>
        <id>2</id>
        <name>Bob</name>
        <role>user</role>
    </user>
</users>
"""

toon_output = xml_to_toon.encode(xml_string)
print(toon_output)

# Convert TOON back to XML
xml_output = xml_to_toon.decode(toon_output)
print(xml_output)

File Conversion

from toonbuilder import json_to_toon, xml_to_toon

# JSON file conversion
json_to_toon.encode_file("input.json", "output.toon")
json_to_toon.decode_file("output.toon", "restored.json")

# XML file conversion
xml_to_toon.encode_file("input.xml", "output.toon")
xml_to_toon.decode_file("output.toon", "restored.xml")

Usage

Converting Python Data Structures

JSON Module

from toonbuilder import json_to_toon

# Encode Python dict/list to TOON string
data = {
    "name": "Project Alpha",
    "version": "1.0.0",
    "dependencies": ["numpy", "pandas", "scipy"],
    "config": {
        "debug": True,
        "timeout": 30
    }
}

toon_string = json_to_toon.encode(data)
print(toon_string)
# Output:
# name: Project Alpha
# version: 1.0.0
# dependencies[3]: numpy,pandas,scipy
# config:
#   debug: true
#   timeout: 30

# Decode TOON string back to Python dict
restored_data = json_to_toon.decode(toon_string)

XML Module

from toonbuilder import xml_to_toon

# Encode XML string to TOON
xml_data = """<?xml version="1.0"?>
<catalog>
    <book id="bk101">
        <author>Gambardella, Matthew</author>
        <title>XML Developer's Guide</title>
        <price>44.95</price>
    </book>
    <book id="bk102">
        <author>Ralls, Kim</author>
        <title>Midnight Rain</title>
        <price>5.95</price>
    </book>
</catalog>"""

toon_string = xml_to_toon.encode(xml_data)
print(toon_string)

# Decode back to XML
xml_output = xml_to_toon.decode(toon_string)

Working with Files

Automatic File Extension Handling

When you don't specify an output file path, toonbuilder automatically uses the input filename with the appropriate extension:

from toonbuilder import json_to_toon, xml_to_toon

# These will create data.toon from data.json
json_to_toon.encode_file("data.json")

# These will create data.xml from data.toon
xml_to_toon.decode_file("data.toon")

Custom Output Paths

# Specify custom output paths
json_to_toon.encode_file("input.json", "output/converted.toon")
xml_to_toon.encode_file("config.xml", "toon_files/config.toon")

Custom Indentation

# Use tabs instead of spaces
json_to_toon.encode_file("data.json", "data.toon", indent_str="\t")

# Use 4 spaces for indentation
toon_output = json_to_toon.encode(data, indent_str="    ")

Advanced Usage

Handling Complex Nested Structures

from toonbuilder import json_to_toon

complex_data = {
    "company": "Tech Corp",
    "employees": [
        {
            "id": 1,
            "name": "Alice Johnson",
            "department": "Engineering",
            "skills": ["Python", "JavaScript", "Go"],
            "salary": 120000,
            "active": True
        },
        {
            "id": 2,
            "name": "Bob Smith",
            "department": "Engineering",
            "skills": ["Java", "Kotlin", "SQL"],
            "salary": 115000,
            "active": True
        },
        {
            "id": 3,
            "name": "Carol White",
            "department": "Design",
            "skills": ["Figma", "Photoshop", "Illustrator"],
            "salary": 95000,
            "active": False
        }
    ],
    "metadata": {
        "updated": "2025-12-04",
        "version": 2
    }
}

# TOON format efficiently handles tabular employee data
toon_output = json_to_toon.encode(complex_data)
print(toon_output)

Error Handling

from toonbuilder import json_to_toon, xml_to_toon
import json

# Handle missing files
try:
    json_to_toon.encode_file("nonexistent.json")
except FileNotFoundError as e:
    print(f"Error: {e}")

# Handle invalid JSON
try:
    with open("invalid.json", "w") as f:
        f.write("{invalid json content}")
    json_to_toon.encode_file("invalid.json")
except json.JSONDecodeError as e:
    print(f"Invalid JSON: {e}")

# Handle invalid TOON format
try:
    json_to_toon.decode("malformed [ toon content")
except ValueError as e:
    print(f"Invalid TOON format: {e}")

API Reference

json_to_toon Module

encode(data, indent_level=0, indent_str=" ")

Convert Python data structures to TOON format.

Parameters:

• data (Any): Python object to encode (dict, list, str, int, float, bool, None)
• indent_level (int): Starting indentation level (default: 0)
• indent_str (str): String used for one level of indentation (default: two spaces)

Returns: str - TOON formatted string

Example:

data = {"name": "Alice", "age": 30}
toon_str = json_to_toon.encode(data)

decode(toon_text)

Convert TOON format to Python data structures.

Parameters:

• toon_text (str): TOON formatted string

Returns: Any - Python object (dict, list, primitives)

Example:

data = json_to_toon.decode("name: Alice\nage: 30")

encode_file(json_file_path, toon_file_path=None, indent_str=" ")

Read JSON file and write TOON output.

Parameters:

• json_file_path (str | Path): Input JSON file path
• toon_file_path (str | Path | None): Output TOON file path (default: same name with .toon extension)
• indent_str (str): Indentation string (default: two spaces)

Raises:

• FileNotFoundError: If input file doesn't exist
• json.JSONDecodeError: If input contains invalid JSON

decode_file(toon_file_path, json_file_path=None, indent=2)

Read TOON file and write JSON output.

Parameters:

• toon_file_path (str | Path): Input TOON file path
• json_file_path (str | Path | None): Output JSON file path (default: same name with .json extension)
• indent (int): Number of spaces for JSON indentation (default: 2)

Raises:

• FileNotFoundError: If input file doesn't exist
• ValueError: If input contains invalid TOON format

xml_to_toon Module

encode(data, indent_level=0, indent_str=" ")

Convert XML data to TOON format.

Parameters:

• data (str | Element | ElementTree): XML data to encode
• indent_level (int): Starting indentation level (default: 0)
• indent_str (str): String used for one level of indentation (default: two spaces)

Returns: str - TOON formatted string

Example:

xml_str = "<person><name>Alice</name><age>30</age></person>"
toon_str = xml_to_toon.encode(xml_str)

decode(toon_text, root_name="root")

Convert TOON format to XML string.

Parameters:

• toon_text (str): TOON formatted string
• root_name (str): Name for root element if needed (default: "root")

Returns: str - XML formatted string

Example:

xml_str = xml_to_toon.decode("person:\n  name: Alice\n  age: 30")

encode_file(xml_file_path, toon_file_path=None, indent_str=" ")

Read XML file and write TOON output.

Parameters:

• xml_file_path (str | Path): Input XML file path
• toon_file_path (str | Path | None): Output TOON file path (default: same name with .toon extension)
• indent_str (str): Indentation string (default: two spaces)

Raises:

• FileNotFoundError: If input file doesn't exist
• xml.etree.ElementTree.ParseError: If input contains invalid XML

decode_file(toon_file_path, xml_file_path=None, root_name="root")

Read TOON file and write XML output.

Parameters:

• toon_file_path (str | Path): Input TOON file path
• xml_file_path (str | Path | None): Output XML file path (default: same name with .xml extension)
• root_name (str): Name for root element if needed (default: "root")

Raises:

• FileNotFoundError: If input file doesn't exist
• ValueError: If input contains invalid TOON format

Features

• Lossless Conversion: Full bidirectional conversion between JSON/XML and TOON
• Zero Dependencies: Uses only Python standard library
• Type Preservation: Maintains data types (strings, numbers, booleans, null)
• Tabular Optimization: Automatically detects and optimizes uniform arrays
• Path Objects: Supports both string paths and pathlib.Path objects
• UTF-8 Support: Full Unicode support for international characters
• Pretty Formatting: Human-readable indentation and structure
• XML Attributes: Preserves XML attributes using @attribute notation
• Error Messages: Clear, descriptive error messages for debugging

Examples

Real-World Use Case: API Response

from toonbuilder import json_to_toon

# Typical API response
api_response = {
    "status": "success",
    "total": 150,
    "page": 1,
    "results": [
        {"id": 1, "product": "Laptop", "price": 999.99, "stock": 15},
        {"id": 2, "product": "Mouse", "price": 24.99, "stock": 150},
        {"id": 3, "product": "Keyboard", "price": 79.99, "stock": 45}
    ]
}

# Convert to TOON for LLM prompt
toon_format = json_to_toon.encode(api_response)
print(toon_format)
# Output:
# status: success
# total: 150
# page: 1
# results[3]{id,product,price,stock}:
#   1,Laptop,999.99,15
#   2,Mouse,24.99,150
#   3,Keyboard,79.99,45

# Now you can use this in your LLM prompt with ~40% fewer tokens!

Database Records

from toonbuilder import json_to_toon

# Database query results
db_records = {
    "query": "SELECT * FROM users WHERE active = true",
    "count": 3,
    "records": [
        {"user_id": 101, "username": "alice_dev", "email": "[e-mail]", "created": "2024-01-15", "active": True},
        {"user_id": 102, "username": "bob_admin", "email": "[e-mail]", "created": "2024-02-20", "active": True},
        {"user_id": 103, "username": "carol_user", "email": "[e-mail]", "created": "2024-03-10", "active": True}
    ]
}

# Efficiently encode for LLM analysis
toon_output = json_to_toon.encode(db_records)

Contributing

Contributions are welcome! Here's how you can help:

1. Fork the repository
2. Create a feature branch: git checkout -b feature/amazing-feature
3. Make your changes: Add features, fix bugs, or improve documentation
4. Run tests: Ensure all tests pass (coming soon)
5. Commit your changes: git commit -m 'Add amazing feature'
6. Push to the branch: git push origin feature/amazing-feature
7. Open a Pull Request

Development Setup

# Clone the repository
git clone https://github.com/0xPolybit/toonbuilder.git
cd toonbuilder

# Install in development mode
pip install -e .

# Make your changes and test them
python -c "from toonbuilder import json_to_toon; print(json_to_toon.encode({'test': 'data'}))"

Guidelines

• Follow PEP 8 style guidelines
• Add docstrings to all functions and classes
• Include type hints where appropriate
• Update README.md if you add new features
• Be respectful and constructive in discussions

License

This project is licensed under the MIT License - see the LICENSE file for details.

Acknowledgments

• TOON Format Specification: Thanks to the toon-format team for creating and maintaining the TOON specification
• Community: Thanks to all contributors and users who help improve this library

Links

• TOON Specification: https://github.com/toon-format/spec
• TOON Playground: https://toonformat.dev/playground
• Report Issues: https://github.com/0xPolybit/toonbuilder/issues
• PyPI Package: https://pypi.org/project/toonbuilder/

FAQ

Q: Is TOON compatible with all JSON data?
A: Yes! TOON supports the complete JSON data model with lossless conversion.

Q: Can I use this in production?
A: Yes, the library uses only Python's standard library with no external dependencies.

Q: Does TOON work with all LLMs?
A: TOON is designed to be universally compatible with any LLM. Benchmarks show improved accuracy across Claude, GPT, Gemini, and Grok models.

Q: How much token reduction can I expect?
A: It depends on your data structure. Uniform arrays see ~40% reduction, while deeply nested objects may see less benefit. Use the TOON Playground to test your specific data.

Q: Is XML attribute order preserved?
A: XML attributes are preserved during conversion, though Python dictionaries may reorder them during processing.

---

Made with ❤️ for the LLM community
