topozarr 0.1.8

Create Multiscale Zarr stores

Python library companion to the TypeScript web mapping tool zarr-layer. Use it to create GeoZarr-compliant multiscales / pyramids / overviews for Zarr stores for use with web mapping.

Follows the zarr-conventions:

• multiscales — pyramid structure and resolution levels
• proj: — coordinate reference system (CRS)
• spatial: — affine transform, bounding box, and dimension names

Warning: experimental

Installation

uv add topozarr
# or
pip install topozarr

Multiscales are computed by topozarr-core, a small Rust kernel installed automatically as a wheel. The tutorial extra includes everything needed to run the examples below:

uv add 'topozarr[tutorial]'
# or
pip install 'topozarr[tutorial]'

Example

import xarray as xr
import xproj  # for CRS assignment
from topozarr import create_pyramid

# Load the air_temperature Xarray tutorial dataset
ds = xr.tutorial.open_dataset('air_temperature').drop_encoding()

# Assign a CRS
ds = ds.proj.assign_crs(spatial_ref="EPSG:4326")
print(ds)

pyramid = create_pyramid(
    ds,
    levels=2,
    x_dim="lon",
    y_dim="lat",
    method="mean",  # "mean" (default) | "max" | "min" | "sum" | "nearest"
)
print(pyramid.encoding)

# write
pyramid.write("pyramid.zarr")

levels is the total number of resolution levels, including the original. Level 0 is the original (highest) resolution; by default each subsequent level is coarsened by a factor of 2 per spatial dimension, so the last level is the coarsest.

create_pyramid returns a write plan; pyramid.write(store) does the work.

Not every dataset needs overviews! For lower resolution Zarr stores use attach_geozarr_metadata to add GeoZarr attrs and recommend_encoding for chunking/sharding heuristics for web mapping.

from topozarr import attach_geozarr_metadata, recommend_encoding

ds = attach_geozarr_metadata(ds, x_dim="lon", y_dim="lat")
ds.to_zarr(
    "flat.zarr",
    zarr_format=3,
    consolidated=False,
    encoding=recommend_encoding(ds, x_dim="lon", y_dim="lat"),
)

Coming from ndpyramid

The library ndpyramid also builds multiscale Zarr stores. However, it was built as a companion for carbonplan-maps, which requires the source data to be reprojected to EPSG:3857, square (e.g. 128x128), slippy-map-tile-compliant shapes. The newer mapping library, zarr-layer, relaxes these requirements significantly, which simplifies multiscales creation and allows topozarr to be much simpler and more flexible. This project is essentially a coarsen call and some metadata in a trenchcoat.

If you need a different grid, do it before and hand the result to create_pyramid.

Contributing

Clone the repo, install with the test dependency group, and run the tests:

git clone https://github.com/carbonplan/topozarr
cd topozarr
uv sync --group test
uv run pytest -n auto

Run conformance tests against the GeoZarr spec (requires the conformance group):

uv sync --group conformance
uv run pytest -n auto -m conformance

Lint and format:

uv run prek run --all-files

To regenerate the demo datasets in S3 (requires AWS credentials), install the tutorial extra and run the build script:

uv sync --group test --extra tutorial
uv run python scripts/build_demo_data.py --help

Building from source requires a Rust toolchain for the topozarr-core kernel. See the contributing docs for conformance tests, linting, and demo-data scripts.

License

MIT — see the LICENSE file for details.
