Welcome to TorchCrop

Introduction

torchcrop is a fully differentiable reimplementation of the LINTUL-5 crop growth model (Wolf, 2012). Every step of the simulation — from sowing to harvest — produces valid torch.autograd gradients, so mechanistic crop processes can be combined seamlessly with learnable components (neural residuals, learned stress responses, parameter networks) and calibrated end-to-end with standard torch.optim optimizers.

Features

• Differentiable Lintul5 — daily forward-Euler simulation of phenology, radiation interception, photosynthesis, partitioning, leaf/stem/root dynamics, water balance, and NPK demand, uptake, and soil availability, all as torch.nn.Modules. Supports potential (IOPT=1), water-limited (IOPT=2), and water-and-NPK-limited (IOPT=3/4) production modes, with optional automatic irrigation.
• Batch-first — every state, parameter and driver carries a leading batch dimension [B, ...] so that many sites, years, or parameter sets can be simulated in parallel on GPU.
• 23 bundled crop presets — torchcrop.available_crops() lists species (wheat, maize, rice, soybean, potato, sugar beet, …); load one via CropParameters(crop_name="wheat").
• Gradient-based calibration — torchcrop.calibration provides a constraint-aware (bounds, dtype, table-ordinate, ordering), transform-based CalibrationManager for fitting crop parameters to observations.
• Hybrid modeling hooks — a HybridManager wiring layer accepts declarative ResidualSpecs (see default_slots()) to inject NeuralResidual corrections at named points in the pipeline, plus drop-in LearnedStressFactor and ParameterNet modules.
• External irrigation/fertiliser — pass explicit irrigation: [B, T] and fertilizer: [B, T, 3] schedules to model(...), overriding the internal table-driven application on a per-day basis.
• Smooth options — stage-based branching (DVS < 1, maturity, etc.) can be switched between hard torch.where and sigmoid blends for second-order smoothness.
• Gradient-checked primitives — differentiable AFGEN-style interpolation and soft FST helpers (LIMIT, INSW, NOTNUL) pass torch.autograd.gradcheck.

Installation

pip install torchcrop

Quickstart

import torch
import torchcrop
from torchcrop.utils.io import make_constant_weather

weather = make_constant_weather(batch_size=2, n_days=150)
model = torchcrop.Lintul5Model()
output = model(weather, start_doy=60)

print(output.yield_)        # [B] final storage-organ biomass (g m-2)
print(output.lai.shape)     # [B, T+1] LAI trajectory
print(output.dvs.shape)     # [B, T+1] development stage trajectory

Gradient-based parameter calibration

torchcrop.calibration turns bounded crop/soil/site parameters into optimizable latents, keeping them inside their physical range by construction:

import torch
from torchcrop import CalibrationManager, Lintul5Model, ParameterSpec

model = Lintul5Model(crop_params=torchcrop.CropParameters().to(dtype=torch.float64)).double()
manager = CalibrationManager(
    model, specs=[ParameterSpec(name="crop.scale_factor_rue", bounds=(0.5, 1.5))]
)
optimizer = torch.optim.Adam(manager.parameters(), lr=1e-2)

for _ in range(50):
    optimizer.zero_grad()
    manager.materialize()  # write the current latents into model.crop_params
    out = model(weather.to(torch.float64), start_doy=60)
    loss = ((out.yield_ - observed_yield) ** 2).mean()
    loss.backward()
    optimizer.step()

See docs/examples/04_calibration/ for a full worked example.

Hybrid modeling

Inject a neural residual on top of a named point in the mechanistic pipeline via a declarative ResidualSpec:

from torchcrop.nn import ResidualSpec

model = torchcrop.Lintul5Model(
    residual_specs=[
        ResidualSpec(
            "photosynthesis.gtotal",
            "rate_factor",
            context=("lai", "dvs", "davtmp", "tranrf", "nstress"),
            scale=0.15,
        ),
    ],
)

torchcrop.nn.default_slots() returns the recommended catalogue of observable-tied slots (photosynthesis, water stress, partitioning, leaf senescence); pass a hand-picked subset rather than the whole list unless every pathway is observable. All parameters — mechanistic and neural — are surfaced by model.parameters() and can be optimized jointly.

Package layout

torchcrop/
├── model.py                   # Lintul5Model(nn.Module)
├── engine.py                  # SimulationEngine time-stepping loop
├── config.py                  # RunConfig
├── parameters/                # CropParameters / SoilParameters / SiteParameters
│                              # + 23 bundled crop presets (crop_data/*.yaml)
├── drivers/weather.py         # WeatherDriver [B, T, C]
├── states/model_state.py      # ModelState / DiagnosticState tensor containers
├── processes/                 # Biophysical processes (astro, phenology,
│                              # irradiation, evapotranspiration,
│                              # co2_transpiration, water_balance,
│                              # photosynthesis, partitioning, leaf_dynamics,
│                              # stem_dynamics, root_dynamics, nutrient_demand,
│                              # soil_nutrients, heat_stress, stress)
├── functions/                 # Differentiable primitives (AFGEN, FST, smoothing)
├── nn/                        # NeuralResidual, LearnedStressFactor, ParameterNet,
│                              # HybridManager / ResidualSpec wiring layer
├── calibration/                # CalibrationManager, ParameterSpec,
│                              # ConstraintGroup, transforms
└── utils/                     # I/O, visualisation, validation helpers

Examples

Worked notebooks under docs/examples/ (rendered into the docs site):

• 01_potential/ — potential production (winter wheat)
• 02_water_limited/ — water-limited production (winter wheat)
• 03_water_and_nutrient_limited/ — water + N and water + NPK limited production
• 04_calibration/ — gradient-based parameter calibration
• 05_hybrid/ — hybrid ML residual corrections (reserved, notebook in progress)
• 06_daily_timestep/ — low-level, day-by-day API usage
• others/data_prep.ipynb — preparing the Brandenburg example dataset

Development

pytest                    # run the test suite
flake8 torchcrop tests    # lint
black torchcrop tests     # format
pre-commit run --all-files

References

• Wolf, J. (2012). User guide for LINTUL5. Wageningen UR. https://models.pps.wur.nl/lintul-5-crop-growth-simulation-model-potential-water-limited-n-limited-and-npk-limited-conditions
• WUR-AI. diffWOFOST — Differentiable WOFOST crop model. https://github.com/WUR-AI/diffWOFOST
