torchmeter 0.1.0

"Torchmeter ⏲️: Your all-in-one tool for Pytorch model analysis, measuring Params, FLOPs/MACs(aka. MACC or MADD), Memory cost, Inference time and Throughput 🚀"

🚀 𝒀𝒐𝒖𝒓 𝑨𝒍𝒍-𝒊𝒏-𝑶𝒏𝒆 𝑻𝒐𝒐𝒍 𝒇𝒐𝒓 𝑷𝒚𝒕𝒐𝒓𝒄𝒉 𝑴𝒐𝒅𝒆𝒍 𝑨𝒏𝒂𝒍𝒚𝒔𝒊𝒔 🚀

• Docs: https://docs.torchmeter.top (Backup link 🔗)
• Intro: Provides comprehensive measurement of Pytorch model's Parameters, FLOPs/MACs, Memory-Cost, Inference-Time and Throughput with highly customizable result display ✨

𝒜. 𝐻𝒾𝑔𝒽𝓁𝒾𝑔𝒽𝓉𝓈

① 𝒁𝒆𝒓𝒐-𝑰𝒏𝒕𝒓𝒖𝒔𝒊𝒐𝒏 𝑷𝒓𝒐𝒙𝒚

• Acts as drop-in decorator without any changes of the underlying model
• Seamlessly integrates with Pytorch modules while preserving full compatibility (attributes and methods)

② 𝑭𝒖𝒍𝒍-𝑺𝒕𝒂𝒄𝒌 𝑴𝒐𝒅𝒆𝒍 𝑨𝒏𝒂𝒍𝒚𝒕𝒊𝒄𝒔

Holistic performance analytics across 5 dimensions:

1. Parameter Analysis

   • Total/trainable parameter quantification
   • Layer-wise parameter distribution analysis
   • Gradient state tracking (requires_grad flags)

2. Computational Profiling

   • FLOPs/MACs precision calculation
   • Operation-wise calculation distribution analysis
   • Dynamic input/output detection (number, type, shape, ...)

3. Memory Diagnostics

   • Input/output tensor memory awareness
   • Hierarchical memory consumption analysis

4. Inference latency & 5. Throughput benchmarking

   • Auto warm-up phase execution (eliminates cold-start bias)
   • Device-specific high-precision timing
   • Inference latency & Throughput Benchmarking

③ 𝑹𝒊𝒄𝒉 𝒗𝒊𝒔𝒖𝒂𝒍𝒊𝒛𝒂𝒕𝒊𝒐𝒏

1. Programmable tabular report

   • Dynamic table structure adjustment
   • Style customization and real-time rendering
   • Real-time data analysis in programmable way

2. Rich-text hierarchical operation tree

   • Style customization and real-time rendering
   • Smart module folding based on structural equivalence detection for intuitive model structure insights

④ 𝑭𝒊𝒏𝒆-𝑮𝒓𝒂𝒊𝒏𝒆𝒅 𝑪𝒖𝒔𝒕𝒐𝒎𝒊𝒛𝒂𝒕𝒊𝒐𝒏

• Real-time hot-reload rendering: Dynamic adjustment of rendering configuration for operation trees, report tables and their nested components
• Progressive update: Namespace assignment + dictionary batch update

⑤ 𝑪𝒐𝒏𝒇𝒊𝒈-𝑫𝒓𝒊𝒗𝒆𝒏 𝑹𝒖𝒏𝒕𝒊𝒎𝒆 𝑴𝒂𝒏𝒂𝒈𝒆𝒎𝒆𝒏𝒕

• Centralized control: Singleton-managed global configuration for dynamic behavior adjustment
• Portable presets: Export/import YAML profiles for runtime behaviors, eliminating repetitive setup

⑥ 𝑷𝒐𝒓𝒕𝒂𝒃𝒊𝒍𝒊𝒕𝒚 𝒂𝒏𝒅 𝑷𝒓𝒂𝒄𝒕𝒊𝒄𝒂𝒍𝒊𝒕𝒚

• Decoupled pipeline: Separation of data collection and visualization
• Automatic device synchronization: Maintains production-ready status by keeping model and data co-located
• Dual-mode reporting with export flexibility:
  • Measurement units mode vs. raw data mode
  • Multi-format export (CSV/Excel) for analysis integration

ℬ. 𝐼𝓃𝓈𝓉𝒶𝓁𝓁𝒶𝓉𝒾𝑜𝓃

[!NOTE] 𝑪𝒐𝒎𝒑𝒂𝒕𝒊𝒃𝒊𝒍𝒊𝒕𝒚

• OS: windows / linux / macOS
• Python: >= 3.8
• Pytorch: >= 1.7.0

① 𝑻𝒉𝒓𝒐𝒖𝒈𝒉 𝑷𝒚𝒕𝒉𝒐𝒏 𝑷𝒂𝒄𝒌𝒂𝒈𝒆 𝑴𝒂𝒏𝒂𝒈𝒆𝒓

the most convenient way, suitable for installing the released latest stable version

# pip series
pip/pipx/pipenv install torchmeter

# Or via conda
conda install torchmeter

# Or via uv
uv add torchmeter

# Or via poetry
poetry add torchmeter

# Other managers' usage please refer to their own documentation

② 𝑻𝒉𝒓𝒐𝒖𝒈𝒉 𝑩𝒊𝒏𝒂𝒓𝒚 𝑫𝒊𝒔𝒕𝒓𝒊𝒃𝒖𝒕𝒊𝒐𝒏

Suitable for installing released historical versions

1. Download .whl from PyPI or Github Releases.

2. Install locally:

   # Replace x.x.x with actual version
   pip install torchmeter-x.x.x.whl


③ 𝑻𝒉𝒓𝒐𝒖𝒈𝒉 𝑺𝒐𝒖𝒓𝒄𝒆 𝑪𝒐𝒅𝒆

Suitable for who want to try out the upcoming features (may has unknown bugs).

git clone https://github.com/TorchMeter/torchmeter.git
cd torchmeter

# If you want to install the released stable version, use this:
# Don't forget to eplace x.x.x with actual version
git checkout vx.x.x  # Stable

# If you want to try the latest development version(alpha/beta), use this:
git checkout master  # Development version

pip install .

𝒞. 𝒢𝑒𝓉𝓉𝒾𝓃𝑔 𝓈𝓉𝒶𝓇𝓉𝑒𝒹

Refer to tutorials for all scenarios

‌① 𝑫𝒆𝒍𝒆𝒈𝒂𝒕𝒆 𝒚𝒐𝒖𝒓 𝒎𝒐𝒅𝒆𝒍 𝒕𝒐 𝒕𝒐𝒓𝒄𝒉𝒎𝒆𝒕𝒆𝒓

Implementation of ExampleNet

import torch.nn as nn

class ExampleNet(nn.Module):
    def __init__(self):
        super(ExampleNet, self).__init__()

        self.backbone = nn.Sequential(
            self._nested_repeat_block(2),
            self._nested_repeat_block(2)
        )

        self.gap = nn.AdaptiveAvgPool2d(1)

        self.classifier = nn.Linear(3, 2)

    def _inner_net(self):
        return nn.Sequential(
            nn.Conv2d(10, 10, 1),
            nn.BatchNorm2d(10),
            nn.ReLU(),
        )

    def _nested_repeat_block(self, repeat:int=1):
        inners = [self._inner_net() for _ in range(repeat)]
        return nn.Sequential(
            nn.Conv2d(3, 10, 3, stride=1, padding=1),
            nn.BatchNorm2d(10),
            nn.ReLU(),
            *inners,
            nn.Conv2d(10, 3, 1),
            nn.BatchNorm2d(3),
            nn.ReLU()
        )

    def forward(self, x):
        x = self.backbone(x)
        x = self.gap(x)
        x = x.squeeze(dim=(2,3))
        return self.classifier(x)

import torch.nn as nn
from torchmeter import Meter
from torch.cuda import is_available as is_cuda

# 1️⃣ Prepare your pytorch model, here is a simple examples
underlying_model = ExampleNet() # see above for implementation of `ExampleNet`

# Set an extra attribute to the model to show
# how torchmeter acts as a zero-intrusion proxy later
underlying_model.example_attr = "ABC"

# 2️⃣ Wrap your model with torchmeter
model = Meter(underlying_model)

# 3️⃣ Validate the zero-intrusion proxy

# Get the model's attribute
print(model.example_attr)

# Get the model's method
# `_inner_net` is a method defined in the ExampleNet
print(hasattr(model, "_inner_net"))

# Move the model to other device (now on cpu)
print(model)
if is_cuda():
    model.to("cuda")
    print(model) # now on cuda

② 𝑮𝒆𝒕 𝒊𝒏𝒔𝒊𝒈𝒉𝒕𝒔 𝒊𝒏𝒕𝒐 𝒕𝒉𝒆 𝒎𝒐𝒅𝒆𝒍 𝒔𝒕𝒓𝒖𝒄𝒕𝒖𝒓𝒆

from rich import print

print(model.structure)

③ 𝑸𝒖𝒂𝒏𝒕𝒊𝒇𝒚 𝒎𝒐𝒅𝒆𝒍 𝒑𝒆𝒓𝒇𝒐𝒓𝒎𝒂𝒏𝒄𝒆 𝒇𝒓𝒐𝒎 𝒗𝒂𝒓𝒊𝒐𝒖𝒔 𝒅𝒊𝒎𝒆𝒏𝒔𝒊𝒐𝒏𝒔

# Parameter Analysis
# Suppose that the `backbone` part of ExampleNet is frozen
_ = model.backbone.requires_grad_(False)
print(model.param)
tb, data = model.profile('param', no_tree=True)

# Before measuring calculation you should first execute a feed-forward
# you do **not** need to concern about the device mismatch,
# just feed the model with the input.
import torch
input = torch.randn(1, 3, 32, 32)
output = model(input)

# Computational Profiling
print(model.cal) # `cal` for calculation
tb, data = model.profile('cal', no_tree=True)

# Memory Diagnostics
print(model.mem) # `mem` for memory
tb, data = model.profile('mem', no_tree=True)

# Performance Benchmarking
print(model.ittp) # `ittp` for inference time & throughput
tb, data = model.profile('ittp', no_tree=True)

# Overall Analytics
print(model.overview())

④ 𝑬𝒙𝒑𝒐𝒓𝒕 𝒓𝒆𝒔𝒖𝒍𝒕𝒔 𝒇𝒐𝒓 𝒇𝒖𝒓𝒕𝒉𝒆𝒓 𝒂𝒏𝒂𝒍𝒚𝒔𝒊𝒔

# export to csv
model.profile('param', show=False, save_to="params.csv")

# export to excel
model.profile('cal', show=False, save_to="../calculation.xlsx")

⑤ 𝑨𝒅𝒗𝒂𝒏𝒄𝒆𝒅 𝒖𝒔𝒂𝒈𝒆

1. Attributes/methods access of underlying model
2. Automatic device synchronization
3. Smart module folding
4. Performance gallery
5. Customized visulization
   • for statistics overview
   • for operation tree
   • for tabular report
6. Best practice of programmable tabular report
   • Real-time structure adjustment
   • Real-time data analysis
7. Instant export and postponed export
8. Centralized configuration management
9. Submodule exploration

𝒟. 𝒞𝑜𝓃𝓉𝓇𝒾𝒷𝓊𝓉𝑒

Thank you for wanting to make TorchMeter even better!

There are several ways to make a contribution:

• Asking questions
• Reporting bugs
• Contributing code

Before jumping in, let's ensure smooth collaboration by reviewing our 📋 contribution guidelines first.

Thanks again !

[!NOTE] @Ahzyuan: I'd like to say sorry in advance. Due to my master's studies and job search, I may be too busy in the coming year to address contributions promptly. I'll do my best to handle them as soon as possible. Thanks a lot for your understanding and patience!

ℰ. 𝒞𝑜𝒹𝑒 𝑜𝒻 𝒞𝑜𝓃𝒹𝓊𝒸𝓉

Refer to official code-of-conduct file for more details.

• TorchMeter is an open-source project built by developers worldwide. We're committed to fostering a friendly, safe, and inclusive environment for all participants.

• This code applies to all community spaces including but not limited to GitHub repositories, community forums, etc.

ℱ. 𝐿𝒾𝒸𝑒𝓃𝓈𝑒

TorchMeter is released under the AGPL-3.0 License, see the LICENSE file for the full text. Please carefully review the terms in the LICENSE file before using or distributing TorchMeter. Ensure compliance with the licensing conditions, especially when integrating this project into larger systems or proprietary software.
