toyopuc-computerlink 0.1.8

Python client library for TOYOPUC computer-link communication over TCP and UDP

Computer Link Protocol for Python

A user-focused Python library for JTEKT TOYOPUC Computer Link communication. The recommended entry points are the high-level ToyopucDeviceClient class and the async helper functions in toyopuc.

For asyncio code, prefer:

• ToyopucConnectionOptions
• open_and_connect
• normalize_address
• parse_device_address
• try_parse_device_address
• format_device_address
• read_typed
• write_typed
• write_bit_in_word
• read_named
• poll
• read_words_single_request
• read_dwords_single_request
• read_words_chunked
• read_dwords_chunked

Quick Start

Installation

pip install toyopuc-computerlink

Latest release metadata and downloads are available at https://pypi.org/project/toyopuc-computerlink/.

Synchronous Example

from toyopuc import ToyopucDeviceClient

with ToyopucDeviceClient("192.168.250.100", 1025) as client:
    value = client.read("P1-D0000")
    print(f"P1-D0000 = {value}")

    client.write("P1-D0001", 1234)
    client.write("P1-M0000", 1)

    snapshot = client.read_many(["P1-D0000", "P1-D0001", "P1-M0000"])
    print(snapshot)

Asynchronous Example

import asyncio
from toyopuc import ToyopucConnectionOptions, open_and_connect, read_named, read_typed, write_typed

async def main() -> None:
    options = ToyopucConnectionOptions(host="192.168.250.100", port=1025, timeout=3.0, retries=0)
    async with await open_and_connect(options) as plc:
        speed = await read_typed(plc, "P1-D0100", "F")
        print(f"speed = {speed}")

        await write_typed(plc, "P1-D0200", "L", -500)

        values = await read_named(plc, ["P1-D0000", "P1-D0100:F", "P1-D0000.0"])
        print(values)

asyncio.run(main())

Basic area families P/K/V/T/C/L/X/Y/M/S/N/R/D require a P1-, P2-, or P3- prefix.

Supported PLC Registers

Start with these public high-level families first:

• prefixed word/register areas: P1-D0000, P1-S0000, P1-N0100, P1-R0000
• prefixed bit/control areas: P1-M0000, P1-X0000, P1-Y0000
• extension areas: ES0000, EN0000
• FR storage: FR000000
• typed and bit views: P1-D0100:S, P1-D0200:D, P1-D0300:F, P1-D0000.3

See the full public table in Supported PLC Registers.

Public Docs

• Getting Started
• Supported PLC Registers
• Latest Communication Verification
• User Guide
• Model Ranges
• Sample Guide

Start with these sample programs:

• samples/high_level_minimal.py
• samples/high_level_basic.py
• samples/high_level_all_sync.py
• samples/high_level_all_async.py
• samples/high_level_udp.py

Maintainer-only notes and retained evidence live under internal_docs/.

Common User Tasks

• normalize one address string: normalize_address("p1-d0000", profile="TOYOPUC-Plus:Plus Standard mode")
• parse one typed address string: parse_device_address("p1-d0100:f", profile="Generic")
• format stored address metadata: format_device_address(parsed_address)
• review model/profile ranges: ToyopucDeviceCatalog.get_device_matrix("PC10G:PC10 mode")
• read or write one device: client.read("P1-D0000"), client.write("P1-M0000", 1)
• read a mixed snapshot: client.read_many([...]) or await read_named(plc, [...])
• read 32-bit or float values: client.read_dword(...), client.read_float32(...), await read_typed(..., "D" / "L" / "F")
• change one flag bit inside a word: await write_bit_in_word(plc, "P1-D0100", bit_index=3, value=True)
• read contiguous areas with explicit intent: await read_words_single_request(...), await read_words_chunked(...)
• read or write FR storage: client.read_fr(...), client.write_fr(..., commit=True)

Development & CI

run_ci.bat
release_check.bat

License

Distributed under the MIT License.
