tp-requestflows 2026.5.18

A Python library for sending raw HTTP requests in a predefined sequence configured via a rules.json file. Supports automatic re-login when the session token expires

TP-RequestFlows - PyPI

A Python library for sending raw HTTP requests in a predefined sequence configured via a rule file. Supports automatic re-login when the session token expires

---

Installation

From PyPI:

pip install TP-RequestFlows

From Source:

git clone https://github.com/TPCyberSec/TP-RequestFlows.git --branch <Branch/Tag>
cd TP-RequestFlows
python -m build
python -m pip install dist/tp_requestflows-<version>-py3-none-any.whl

---

Basic Usage

run_flows(

FlowRules,
add_object = dict(),
update_object = dict(),
delete_object = dict(),
update_object_mode = "replace",
ReqTimeout = 60,
ReqDelaytime = 0,
sleeptime = 20,
separator = "||",
parse_index = "$",
dupSign_start = "{{{",
dupSign_end = "}}}",
ordered_dict = False,
skipDuplicated = True,
update_content_length = True,
proxy_server = None,
verbose = True

)

• FlowRules: Dictionary containing flow configuration or path to JSON file (rules.json). Can be dict, OrderedDict, jdks.JSON_DUPLICATE_KEYS, or a file path.

  When using a folder, the folder must contain raw HTTP request files (raw-[reqNum].req) and the rules.json file:

  FlowName/
  ├── raw-1.req
  ├── raw-2.req
  ├── raw-[reqNum].req
  └── rules.json


• add_object: Add parameters to QueryParams, HTTPHeaders, HTTPCookies, RequestBody of requests at runtime.

• update_object: Update parameter values for RequestMethod, PathParams, QueryParams, RequestFragment, HTTPVersion, HTTPHeaders, HTTPCookies, RequestBody of requests at runtime.

• delete_object: Remove parameters from QueryParams, HTTPHeaders, HTTPCookies, RequestBody of requests at runtime.

• ReqTimeout: Timeout in seconds for each HTTP request.

• ReqDelaytime: Delay (in seconds) between consecutive requests.

• sleeptime: If response time exceeds or equals this value, the RT will be highlighted in red.

• separator, parse_index, dupSign_start, dupSign_end, ordered_dict, skipDuplicated: Refer to the json-duplicate-keys project for handling complex JSON with duplicate keys.

• update_content_length: Automatically updates the Content-Length header when modified.

• proxy_server: Optional invisible proxy configuration for routing all HTTP requests through a proxy. Format: { "host": "PROXY-HOST", "port": PROXY-PORT }.

• verbose: Show debug information and request status during execution.

Detailed configuration of rules.json

The rules.json file defines the flow logic and dynamic behavior for the sequence of raw HTTP requests. It consists of three primary sections:

• environments: Configure reusable variables and import Python modules.
• flows: Define each HTTP request and how parameters are dynamically populated.
• PATTERN_SuccessFlows (optional): Regex used to verify a successful response.

Structure overview:

{
  "environments": {
	"libs": [ ... ],
	"vars": { ... }
  },
  "flows": {
	"[reqNum]": {
	  "Host": "...",
	  "Port": ...,
	  "Scheme": "...",
	  "Coding": "utf-8",
	  "PathParams": { ... },
	  "QueryParams": { ... },
	  "HTTPHeaders": { ... },
	  "HTTPCookies": { ... },
	  "RequestBody": { ... }
	},
	...
  },
  "PATTERN_SuccessFlows": "..."
}

Section details:

• environments

  • libs (optional): A list of Python modules to dynamically import. Useful for using built-in functions or custom logic in variable definitions.

    "libs": [
      "from TP_Generator import Utils",
      "from urllib.parse import quote"
    ]


  • vars: Define reusable variables that can be used as placeholders ({varName}) in the flow. Each variable can be configured in one of three ways:
    • Static Values: provide a fixed string value with "runCode": false

      "static_user": {
        "value": "admin",
        "runCode": false
      }


    • Dynamic Values via Python Expression: use "runCode": true and provide a Python expression in "value". The expression is evaluated at runtime with access to:
      • Flows: A dictionary of all previous request/response data.
      • Imported modules in libs

      "csrf_token": {
        "value": "re.search('name=\"csrf\" value=\"(.*?)\"', Flows['1']['rawResponse']).group(1)",
        "runCode": true
      }


    • Dynamic Values with Condition: A variable in vars can be defined dynamically by looping through a list with an optional condition:

      • LOOPVAR: An expression that returns a list of items to iterate.

      • CONDITION: A Python expression evaluated on each item.

      • value: An expression that extracts the desired value from the first item that satisfies the condition (evaluated using LOOPDATA).

      • LOOPDATA (implicit): Automatically refers to the current item in the loop.

      • "runCode": true: Required to evaluate LOOPVAR, CONDITION, and value as executable code.

        Behavior:

        • Evaluates LOOPVAR to get a list.
        • Iterates through the list:
          • Sets LOOPDATA to the current item.
          • If CONDITION evaluates to True, evaluates value and immediately stops the loop.
        • If no item matches, the result will be None.

        Example:

        "accNo": {
          "LOOPVAR": "TP_HTTP_RESPONSE_PARSER(Flows['1']['rawResponse']).response_body.get('data||accList')['value']",
          "CONDITION": "int(LOOPDATA['balanceAval']) > 1000",
          "value": "LOOPDATA['accNo']",
          "runCode": true
        }


        Explanation:

        • Iterates through the accList in the response body.
        • Finds the first account with balanceAval > 1000.
        • Assigns accNo to that account's accNo.
        • If no such account exists, accNo will be None.

• flows: The flows section defines the actual HTTP request sequence. Each key ("1", "2", ...) represents a request step and contains request components such as host, port, headers, body, and more.

  "1": {
    "Host": "example.com",
    "Port": 443,
    "Scheme": "https",
    "Coding": "utf-8",
    "PathParams": {
      "userId": "{user_id}"
    },
    "QueryParams": {
      "page": "1"
    },
    "HTTPHeaders": {
      "Authorization": "Bearer {access_token}"
    },
    "HTTPCookies": {
      "session": "abc123"
    },
    "RequestBody": {
      "name": "John Doe",
      "email": "{user_email}"
    }
  }


  Common fields:

  Field	Description
  Host	Target host name (e.g. "example.com")
  Port	Target port (e.g. 443 for HTTPS)
  Scheme	Either "http" or "https"
  Coding
  PathParams	Values to replace path variables (e.g. /user/<userId>)
  QueryParams	URL query parameters (e.g. ?page=2)
  HTTPHeaders	HTTP headers to include
  HTTPCookies	Cookies to include in the request
  RequestBody	Request payload for POST/PUT requests

  Placeholders in the form {varName} are automatically replaced with variables from environments.vars.

• PATTERN_SuccessFlows (optional): Defines a regular expression used to check whether the flow executed successfully. This regex is applied to the raw response body of the last flow.

  "PATTERN_SuccessFlows": "Welcome, admin"


  If the pattern matches, the response is considered successful. Useful in automation and scripting scenarios.

Example

import TP_RequestFlows

TP_RequestFlows.run_flows("./FlowName")

---

Advanced Usage

AutoLogin - Automatic Re-login on Session Expiry

The AutoLogin feature in TP-RequestFlows allows the tool to automatically detect session expiration and re-authenticate by executing a predefined login flow. It extracts new session-related values (such as cookies or tokens) and retries the failed request using updated credentials — without any manual intervention

How AutoLogin Works

The AutoLogin process consists of three core components:

• ObtainSessionTokenFlow: Path to a folder that contains the login flow used to re-authenticate. This folder must include a rules.json file and one or more raw-*.req files representing the login requests.
• Matcher: Determines whether the session is considered expired based on the response content of any flow step
  • PATTERN: A list of regular expressions applied to the response (including headers and body).
  • CONDITION: Either "AND" or "OR"
    • "AND": All patterns must match.
    • "OR": At least one pattern must match.
• Extractors: Python expressions that extract tokens or session cookies from the login flow response. These expressions are evaluated at runtime and use the special variable Flows_AutoLogin, which stores the raw request/response data of the login flow.
  • Example:

    TP_HTTP_RESPONSE_PARSER(Flows_AutoLogin['2']['rawResponse']).response_cookies.get('session')['value']


Example Configuration

"AutoLogin": {
  "ObtainSessionTokenFlow": ".\\TestData\\Flows\\Gin_Juice_Shop\\Login",
  "Matcher": {
    "CONDITION": "AND",
    "PATTERN": [
  	"HTTP/(1\\.1|2) 302 Found",
  	"Location: /login"
    ]
  },
  "Extractors": {
    "AWSALB": "TP_HTTP_RESPONSE_PARSER(Flows_AutoLogin['2']['rawResponse']).response_cookies.get('AWSALB')['value']",
    "AWSALBCORS": "TP_HTTP_RESPONSE_PARSER(Flows_AutoLogin['2']['rawResponse']).response_cookies.get('AWSALBCORS')['value']",
    "session": "TP_HTTP_RESPONSE_PARSER(Flows_AutoLogin['2']['rawResponse']).response_cookies.get('session')['value']"
  }
}

Variable Scope and Usage

• All values extracted by the Extractors section are injected into the global variable scope under the special namespace AUTO_LOGIN.
• To use them in your main flow, reference them using the syntax: AUTO_LOGIN||<varName>
• Example:

  "HTTPCookies": {
    "session": "AUTO_LOGIN||session"
  }


  This tells the engine to use the session cookie obtained during AutoLogin instead of a static value

add_object - Add new parameters dynamically at runtime

The add_object parameter allows you to dynamically add new key-value pairs into specific components of any request in the flow, without modifying the original raw file or rules.json

Structure:

add_object = {
  "1": {
    "QueryParams": {
  	"newQueryParam-Name1": value1,
  	"newQueryParam-Name2": value2,
  	...
    },
    "HTTPHeaders": {
  	"newHTTPHeader-Name1": value1,
  	"newHTTPHeader-Name2": value2,
  	...
    },
    "HTTPCookies": {
  	"newHTTPCookie-Name1": value1,
  	"newHTTPCookie-Name2": value2,
  	...
    },
    "RequestBody": {
  	"newBodyParam-Name1": value1,
  	"newBodyParam-Name2": value2,
  	...
    }
  },
  "[reqNum]": {
    "QueryParams": { ... },
    "HTTPHeaders": { ... },
    "HTTPCookies": { ... },
    "RequestBody": { ... }
  },
  ...
}

• The top-level keys ("1", "2", ...) correspond to the flow step (i.e., request number).
• Each inner object can contain one or more of:
  • QueryParams
  • HTTPHeaders
  • HTTPCookies
  • RequestBody
• Values can be:
  • Static strings (e.g., "test123").
  • Variable name (e.g., csrf_token).

Example:

add_object = {
  "1": {
    "QueryParams": {
  	"debug": "true"
    },
    "HTTPHeaders": {
  	"X-Custom-Header": "InjectedValue"
    }
  },
  "3": {
    "RequestBody": {
  	"extraField": csrf_token
    }
  }
}

This will:

• Add debug=true to the query string of request 1.
• Inject X-Custom-Header: InjectedValue into headers of request 1.
• Add an extraField to the request body of request 3 using a variable name csrf_token.

update_object – Modify existing parameters in real-time

The update_object parameter allows you to dynamically change existing values of various components in a request, overriding what's defined in the raw files or rules.json

Structure:

update_object = {
  "1": {
    "RequestMethod": "request method",
    "RequestPath": "request path",
    "PathParams": {
  	"PathParam-Name1": value1,
  	"PathParam-Name2": value2,
  	...
    },
    "QueryParams": {
  	"QueryParam-Name1": value1,
  	"QueryParam-Name2": value2,
  	...
    },
    "RequestFragment": "request fragment",
    "HTTPVersion": " http version",
    "HTTPHeaders": {
  	"HTTPHeader-Name1": value1,
  	"HTTPHeader-Name2": value2,
  	...
    },
    "HTTPCookies": {
  	"HTTPCookie-Name1": value1,
  	"HTTPCookie-Name2": value2,
  	...
    },
    "RequestBody": {
  	"BodyParam-Name1": value1,
  	"BodyParam-Name2": value2,
  	...
    }
  },
  "[reqNum]": {
    "RequestMethod": "...",
    "RequestPath": "...",
    "PathParams": { ... },
    "QueryParams": { ... },
    "RequestFragment": "...",
    "HTTPVersion": "...",
    "HTTPHeaders": { ... },
    "HTTPCookies": { ... },
    "RequestBody": { ... }
  },
  ...
}

• The top-level keys ("1", "2", ...) refer to request numbers.
• Fields listed will replace existing values with the new ones provided.

Example:

update_object = {
  "2": {
    "RequestMethod": "PUT",
    "QueryParams": {
  	"sort": "desc"
    },
    "HTTPHeaders": {
  	"User-Agent": "MyCustomAgent/1.0"
    }
  }
}

This will:

• Change the HTTP method of request 2 to PUT.
• Override sort query param with "desc".
• Replace the User-Agent header value with "MyCustomAgent/1.0".

delete_object – Remove specific parameters from requests

The delete_object parameter lets you delete specific keys from request components (Query, Header, Cookie, Body), which is useful for stripping out unnecessary or sensitive data

Structure:

delete_object = {
  "1": {
    "QueryParams": [
  	"QueryParam-Name1",
  	"QueryParam-Name2",
  	...
    ],
    "HTTPHeaders": [
  	"HTTPHeader-Name1",
  	"HTTPHeader-Name2",
  	...
    ],
    "HTTPCookies": [
  	"HTTPCookie-Name1",
  	"HTTPCookie-Name2",
  	...
    ],
    "RequestBody": [
  	"BodyParam-Name1",
  	"BodyParam-Name2",
  	...
    ]
  },
  "[reqNum]": {
    "QueryParams": [ ... ],
    "HTTPHeaders": [ ... ],
    "HTTPCookies": [ ... ],
    "RequestBody": [ ... ]
  },
  ...
}

• For each field, provide a list of keys to remove.
• Only applicable to:
  • QueryParams
  • HTTPHeaders
  • HTTPCookies
  • RequestBody

Example:

delete_object = {
  "1": {
    "QueryParams": ["debug"],
    "HTTPCookies": ["tracking_id"]
  }
}

This will:

• Remove the debug query parameter from request 1.
• Remove the tracking_id cookie from request 1.

---

Contributors

---

CHANGELOG

TP-RequestFlows v2026.5.18

• Updated: The structure of the AUTOLOGIN value
• Added: update_object_mode replace (replace the current value with a new value), append (add the new value to the end of the current value), prepend (add the new value to the beginning of the current value)

TP-RequestFlows v2025.7.1

• Fixed: Improve and fix some issues

TP-RequestFlows v2025.5.18

• Added: Support for dynamic variable declaration in vars using list iteration with conditions (LOOPVAR, CONDITION, value, LOOPDATA, runCode).
• Fixed: Several encoding issues when sending or processing request data.

TP-RequestFlows v2025.4.30

• Raw Request Flow Execution via rules.json and raw-*.req files.
• Dynamic Variable Injection using {varName} syntax in requests.
• Python Expression Support in variable definitions (runCode: true) with access to previous flows (Flows) and imported libs.
• AutoLogin Mechanism:
  • Detects session expiration using regex matchers.
  • Re-authenticates via a predefined login flow.
  • Injects new session values using AUTO_LOGIN||<varName> syntax.
• Regex-Based Success Detection using PATTERN_SuccessFlows.
• Request Modification at Runtime:
  • add_object: Inject new headers, params, cookies, or body fields.
  • update_object: Modify existing request components (method, headers, etc.).
  • delete_object: Strip specific fields from requests.
• Proxy Support: Optional proxy routing per request.
• Automatic Content-Length Update when body is modified.
• Verbose Mode for detailed runtime logging and debugging.
• Custom Request Timing:
  • ReqTimeout: Set request timeout.
  • ReqDelaytime: Delay between requests.
  • sleeptime: Highlight slow responses.
• Duplicate JSON Keys parsing via json-duplicate-keys module.

---
