🏴‍☠️ Trafalgar Log

Trafalgar Log is a Python Framework that standardize JSON Logs and make it easy to use. Its main goal is to abstract log implementation for tools that parse JSON data in log events, such as Splunk, Kibana, CloudWatch Logs, etc. This framework was built on top of the packages logging and python-json-logger.

🧬 Log Structure

Below is a detailed section about each field printed when you use Trafalgar Log:

⚔️ Table legend

⚙️ Configuration

🌌 Environment variables

For Trafalgar Log work in your application, you need to add these environment variables:

• TRA_LOG_APP_NAME (mandatory): this is the environment variable that will be used as the app field in the log event.
• TRA_LOG_DOMAIN (mandatory): this is the environment variable that will be used as the domain field in the log event.
• TRA_LOG_HAKI (optional): this will be used to set the log level for the logging; the accepted values for this variable are as follows:
  • INFO
  • DEBUG
  • WARNING
  • ERROR
  • CRITICAL
  • NOTSET For more information, please visit Logging Levels.
• TRA_LOG_SHAMBLES (optional): if your application has sensitive data being logged, you might want to list all fields that hold these sensitive data and set this variable with them. For example, if your application logs a brazilian document ID (CPF) and a log event have a field called "CPF" and another field called "password", you can mask its content by setting your environment variable like this: TRA_LOG_SHAMBLES="cpf,password" (note that each field is comma separated). The log event will be printed like this:

  {
    "app": "readme-docs",
    "flow": "writing documentation",
    "code_line": "main.py - <module>:29",
    "correlation_id": "552f5139-5da9-4e89-8c1b-9d2a81f9461c",
    "date_time": "2022-09-18 19:25:43.749",
    "domain": "victoraugustofd",
    "instance_id": "347f2d8d-0bde-485e-a120-513e972a3cee",
    "log_code": "Database",
    "log_message": "Getting contributor data from database.",
    "payload": {
      "cpf": "*",
      "password": "*",
      "contributor_name": "Trafalgar Law"
    },
    "severity": "INFO",
    "timestamp": 1663539943749
  }


  Trafalgar Log already has some fields that are always shambled, such as "password", "senha" and "contraseña".

👨‍💻 Logging events 👩‍💻

Here are some examples of all types os logs that Trafalgar Log can print (this is just a code snippet only to exemplify how to use this package):

from trafalgar_log.core.logger import Logger
from docs.out.adapters import DatabaseAdapter
from docs.core.exceptions import DocsBusinessError
from typing import Optional

database_port = DatabaseAdapter()


def get_contributor_data(contributor_id: str) -> Optional[dict]:
  try:
    Logger.info(log_code="Database",
                log_message="Getting contributor data from database.",
                payload=f"Contributor id: {contributor_id}")
    contributor_data = database_port.get_contributor_data(contributor_id)

    # It is optional to name the arguments, since the order log_code,
    # log_message and paylod are respected.
    Logger.info("Database", "Contributor found on database.", contributor_data)

    if contributor_data.get("test_field"):
      Logger.debug("Database", "Debugging method.", contributor_data.get("test_field"))

    if contributor_data.get("status") != "ACTIVE":
      Logger.warn("Database", "Contributor not active.", contributor_data.get("status"))

    return contributor_data
  except DocsBusinessError as business_error:
    Logger.error("Database", f"Error getting contributor data: {str(business_error)}", f"Contributor id: {contributor_id}")
  except Exception as exception:
    Logger.critical("Database", f"Exception getting contributor data: {str(exception)}", f"Contributor id: {contributor_id}")
  finally:
    return None

🤔 Optional fields

The three optional fields below should be set at the beginning of the process, so all subsequent log events share the same data.

• correlation_id: this field should be filled with an already predefined correlation_id that someone passed to the application. If this is not set at the beginning of the execution, Trafalgar Log will generate one with the method uuid.uuid4().

  Implementation:

  from trafalgar_log.core.logger import Logger

  Logger.set_correlation_id("put here the correlation_id received or create one")


• flow: if not set, Trafalgar Log will set this field as NOT_SET.

  Implementation:

  from trafalgar_log.core.logger import Logger

  Logger.set_flow("put here the desired flow")


• instance_id: if not set, Trafalgar Log will set this field as NOT_SET.

  Implementation:

  from trafalgar_log.core.logger import Logger

  Logger.set_instance_id("put here the desired instance_id")


❗ Exception logging

Every time that you want to log an exception, you should use the method Logger.error() or Logger.critical() for two reasons:

1. Best practices;
2. Trafalgar Log is prepared to capture the stacktrace of the exception with this two methods and print as an array of strings, as in the example below:

{
  "app": "readme-docs",
  "flow": "writing documentation",
  "code_line": "main.py - <module>:34",
  "correlation_id": "545723a8-1ed8-4886-80d6-9fdb7250351e",
  "date_time": "2022-09-20 23:03:15.976",
  "domain": "victoraugustofd",
  "instance_id": "417f06d6-06ce-47a6-9151-86afb93c3265",
  "log_code": "Generating exception",
  "log_message": "Trying to get an invalid key from a dict.",
  "payload": "",
  "severity": "ERROR",
  "timestamp": 1663725795976,
  "stacktrace": [
      "Traceback (most recent call last):",
      "  File \"D:\\Documents\\Victor\\Git\\GitHub\\victoraugustofd\\trafalgar-log\\main.py\", line 32, in <module>",
      "    os.environ[\"a\"]",
      "  File \"D:\\Program Files\\Python\\lib\\os.py\", line 679, in __getitem__",
      "    raise KeyError(key) from None",
      "KeyError: 'a'"
  ]
}
