tscope 0.1.4

A simple Python oscilloscope for displaying 1-dim dynamic data in the command line

TerminalScope

A very simple Python oscilloscope for displaying 1-dim dynamic data in the command line.

• Easy to integrate (no third-party libraries required)
• Support for multiple variables with different colors and symbols
• Lightweight and cross-platform compatibility (Windows, macOS, Linux, etc.)
• Typical use cases:
  • Accessing your Raspberry Pi via SSH and wanting to display sensor data in real-time
  • Debugging your motor PID controller and needing a simple graphical user interface

Installation

Requirements

• Python 3.7+
• No external dependencies
• Compatible with any terminal that supports ANSI color codes

From PyPI

pip install tscope

From Source

git clone https://github.com/sszxc/TerminalScope.git
cd TerminalScope
pip install -e .

Quick Start

import math
import time
from tscope import TerminalScope

# Create a scope with 3 variables
scope = TerminalScope(["sin(x)", "cos(x)", "ramp"], data_range=(-2, 2))

# Plot data
for i in range(100):
    x = i * 0.1
    scope.plot([math.sin(x), math.cos(x), x % 2 - 1])
    time.sleep(0.1)

License

This project is licensed under the MIT License - see the LICENSE file for details.
