tucan 0.5.0

Unformatter Tool to allow parsing and analysis of code base.

TUCAN (Tool to Unformat, Clean, and Analyze) is a code parser for scientific codebases. Its target languages are:

• Very old FORTRAN
• Recent FORTRAN
• Python (Under development)
• C/C++ (Early development)

Installation

You can instal it from PyPI with:

pip install tucan

You can also install from the sources from one of our gitlab mirrors.

What is does?

Remove coding archaisms

First it is a code cleaner. For example, this loop in `tranfit.f', a piece of CHEMKIN II package in good'old FORTRAN77. (Do not worry, recent Chemkin is not written that way, probably) :

(547)      DO 2000 K = 1, KK-1
(548)         DO 2000 J = K+1, KK
(549)            DO 2000 N = 1, NO
(550)               COFD(N,J,K) = COFD(N,K,J)
(551) 2000 CONTINUE

Is translated with the command tucan clean tranfit.f as :

(547-547)        do 2000 k  =  1,kk-1
(548-548)           do 2000 j  =  k+1,kk
(549-549)              do 2000 n  =  1,no
(550-550)                 cofd(n,j,k)  =  cofd(n,k,j)
(551-551)              end do ! 2000
(551-551)           end do ! 2000
(551-551)        end do ! 2000

The cleaned version is a simpler code for further analysis passes, like computing cyclomatic complexity, extracting structures, etc...

Extracting code structure

Here we start from a file of neko, an HPC code in recent Fortran, finalist for the Gordon Bell Prize in 2023.

tucan struct htable.f90 provides a nested dictionary of the code structure. Here is a part of the output:

(...)
type htable.h_tuple_t :
    At path ['htable', 'h_tuple_t'], name h_tuple_t, lines 47 -> 52
    Nb. Statements  6
    Nb. lines of code  6
    Ctls. Pts. (McCabe)    0          | 0          Int. avg.
    Halstead Difficulty    8.25       | 8.25       Int. avg.
    Maintainability Index  94.17      | 94.17      Int. avg.
    Average indents        2.2        | 2.2        Int. avg.
    Halstead time          48 sec     | 48 sec     Ext. avg.
    Structural complexity  6          | 6          Ext. avg.
    Nb. of Loops           0          | 0          Ext. avg.

procedure htable.htable_t.hash :
    At path ['htable', 'htable_t', 'hash'], name htable.htable_t.hash, lines 60 -> 60
    Nb. Statements  1
    Nb. lines of code  1
    Ctls. Pts. (McCabe)    0          | 0          Int. avg.
    Halstead Difficulty    0          | 0          Int. avg.
    Maintainability Index  378.29     | 378.29     Int. avg.
    Average indents        0          | 0          Int. avg.
    Halstead time          0 sec      | 0 sec      Ext. avg.
    Structural complexity  4          | 4          Ext. avg.
    Nb. of Loops           0          | 0          Ext. avg.
    Refers to 1 callables:
       - htable.hash

procedure htable.htable_t.htable_clear :
    At path ['htable', 'htable_t', 'htable_clear'], name htable.htable_t.htable_clear, lines 61 -> 61
    Nb. Statements  1
    Nb. lines of code  1
    Ctls. Pts. (McCabe)    0          | 0          Int. avg.
    Halstead Difficulty    0          | 0          Int. avg.
    Maintainability Index  378.29     | 378.29     Int. avg.
    Average indents        0          | 0          Int. avg.
    Halstead time          0 sec      | 0 sec      Ext. avg.
    Structural complexity  4          | 4          Ext. avg.
    Nb. of Loops           0          | 0          Ext. avg.
    Refers to 1 callables:
       - htable.htable_clear

procedure htable.htable_t.htable_free :
    At path ['htable', 'htable_t', 'htable_free'], name htable.htable_t.htable_free, lines 62 -> 62
    Nb. Statements  1
    Nb. lines of code  1
    Ctls. Pts. (McCabe)    0          | 0          Int. avg.
    Halstead Difficulty    0          | 0          Int. avg.
    Maintainability Index  378.29     | 378.29     Int. avg.
    Average indents        0          | 0          Int. avg.
    Halstead time          0 sec      | 0 sec      Ext. avg.
    Structural complexity  4          | 4          Ext. avg.
    Nb. of Loops           0          | 0          Ext. avg.
    Refers to 1 callables:
       - htable.htable_free
(...)
module htable :
    At path ['htable'], name htable, lines 36 -> 1482
    Nb. Statements  1079
    Nb. lines of code  1447
    Ctls. Pts. (McCabe)    0          | 3.01       Int. avg.
    Halstead Difficulty    4          | 15.25      Int. avg.
    Maintainability Index  -28.7      | 76.61      Int. avg.
    Average indents        1          | 2.36       Int. avg.
    Halstead time          28 sec     | 7.87 hrs   Ext. avg.
    Structural complexity  1          | 474        Ext. avg.
    Nb. of Loops           0          | 18         Ext. avg.
    Refers to 89 contains:
       - htable.h_tuple_t
       - htable.htable_t
       - htable.interface66
       - htable.htable_i4_t
       - htable.htable_i8_t
       - htable.htable_r8_t
(...)

(This output will change as we update and improve tucan in the next versions!)

This information allows the creation and manipulation of graphs to extract the structure of the code

Interpreting Conditional Inclusions "IF DEFS".

An other example of tucan is the analysis of ifdefs in C or FORTRAN:

#ifdef FRONT
        WRITE(*,*) " FRONT is enabled " ! partial front subroutine
        SUBROUTINE dummy_front(a,b,c)
        WRITE(*,*) " FRONT 1"     ! partial front subroutine
#else
        SUBROUTINE dummy_front(a,d,e)
        WRITE(*,*) " FRONT 2"       ! partial front subroutine
#endif
        END SUBROUTINE

        SUBROUTINE dummy_back(a,b,c)
#ifdef BACK
        WRITE(*,*) " FRONT is enabled " ! partial front subroutine
        WRITE(*,*) " BACK 1"    ! partial back subroutine
        END SUBROUTINE
#else
        WRITE(*,*) " BACK 2"    ! partial back subroutine
        END SUBROUTINE
#endif

Depending on the pre-definition of variables FRONT and BACK, this code snippet can be read in four ways possible. Here are usages:

tucan cpp-clean templates_ifdef.f yields:

        SUBROUTINE dummy_front(a,d,e)
        WRITE(*,*) " FRONT 2"       ! partial front subroutine
        END SUBROUTINE

        SUBROUTINE dummy_back(a,b,c)


        WRITE(*,*) " BACK 2"    ! partial back subroutine
        END SUBROUTINE

tucan cpp-clean templates_ifdef.f -v FRONT yields:

        WRITE(*,*) " FRONT is enabled " ! partial front subroutine
        SUBROUTINE dummy_front(a,b,c)
        WRITE(*,*) " FRONT 1"     ! partial front subroutine


        END SUBROUTINE

        SUBROUTINE dummy_back(a,b,c)


        WRITE(*,*) " BACK 2"    ! partial back subroutine
        END SUBROUTINE

tucan cpp-clean templates_ifdef.f -v FRONT,BACK yields:

         WRITE(*,*) " FRONT is enabled " ! partial front subroutine
        SUBROUTINE dummy_front(a,b,c)
        WRITE(*,*) " FRONT 1"     ! partial front subroutine


        END SUBROUTINE

        SUBROUTINE dummy_back(a,b,c)
        WRITE(*,*) " BACK is enabled " ! partial front subroutine
        WRITE(*,*) " BACK 1"    ! partial back subroutine
        END SUBROUTINE

scanning ifdef variables

A simpler usage of tucan : scan the current ifdefs variables. Still on neko in the /src folder (an old version though) :

/neko/src >tucan cpp-scan-pkge .
 - Recursive path gathering ...
 - Cleaning the paths ...
 - Analysis completed.
 - Global ifdef variables : HAVE_PARMETIS, __APPLE__
 - Local to device/opencl/check.c : CL_ERR_STR(err)
 - Local to math/bcknd/device/opencl/opr_opgrad.c : CASE(LX), STR(X)
 - Local to math/bcknd/device/opencl/opr_dudxyz.c : CASE(LX), STR(X)
 - Local to common/sighdl.c : SIGHDL_ALRM, SIGHDL_USR1, SIGHDL_USR2, SIGHDL_XCPU
 - Local to math/bcknd/device/opencl/opr_conv1.c : CASE(LX), STR(X)
 - Local to math/bcknd/device/opencl/opr_cfl.c : CASE(LX), STR(X)
 - Local to krylov/bcknd/device/opencl/pc_jacobi.c : CASE(LX), STR(X)
 - Local to math/bcknd/device/opencl/ax_helm.c : CASE(LX), STR(X)
 - Local to bc/bcknd/device/opencl/symmetry.c : MAX(a,
 - Local to gs/bcknd/device/opencl/gs.c : GS_OP_ADD, GS_OP_MAX, GS_OP_MIN, GS_OP_MUL
 - Local to sem/bcknd/device/opencl/coef.c : DXYZDRST_CASE(LX), GEO_CASE(LX), STR(X)
 - Local to math/bcknd/device/opencl/opr_cdtp.c : CASE(LX), STR(X)

This feature is useful to see all potential variables that surcharge your codebase via conditional inclusions.

More about tucan

Tucan is used by anubis, our open-source tool to explore the git repository of a code, and marauder's map our open-source tool to show codes structures by in-depth vizualisation of callgraphs and code circular-packing .
