UPXO

UPXO (UKAEA Poly-XTAL Operations) is an open-source Pythonic computational framework for generating, analysing, manipulating, meshing, visualising, and exporting representative polycrystalline grain structures for materials science. Although primarily developed for applications pertaining to multi-scale computational studies of nuclear structural materials, it can also solve a wide range of such problems in the Aerospace and Automobile sectors.

UPXO can enable you to create complex 2D and 3D poly-crystalline grain-structures suitable for Finite Element (FE) simulations, microstructure characterisation, and data-driven materials research involving such computational domains.

Funding: This work has been funded by STEP, a major technology and infrastructure programme led by UK Industrial Fusion Solutions Ltd (UKIFS), which aims to deliver the UK's prototype fusion power plant and a path to the commercial viability of fusion.

A dedicated wiki has been created to help users. Please find it here

Installation

pip install upxo

Install with all optional extras (interactive plots, FE meshing, EBSD import):

pip install upxo[all]

Or select specific extras:

Requires Python >= 3.13. See the Getting Started wiki page for environment setup guides.

Tested environments

Dependency versions: the install and checks were run with every direct dependency at its declared minimum (numpy 2.2.6, scipy 1.16.2, numba 0.62.1, pandas 2.3.3, matplotlib 3.10.6, pyvista 0.46.3, scikit-image 0.25.2, scikit-learn 1.7.2, shapely 2.1.1, networkx 3.5) and with the newest releases available on 2026-10-06 (numpy 2.5.3, scipy 1.18.1, numba 0.68.0, pandas 3.0.6, matplotlib 3.11.2, pyvista 0.49.0, scikit-image 0.26.0, scikit-learn 1.9.1, shapely 2.1.2, networkx 3.7). The full table, the install routes tested and further notes are on the Dependencies wiki page.

Notes:

• netlsd is published as a source distribution only. pip builds it during the install, which needs setuptools if build isolation is turned off.
• On Windows with long paths disabled, an environment whose site-packages path is about 150 characters or more fails to install, because of a long file name inside the jedi dependency. Create the environment in a shorter path.
• A pip-installed UPXO writes pipeline output (reports, raw exports, Abaqus files) under ./data in the working directory, not inside the Python environment. A source checkout writes to <checkout>/data.

Canonical package metadata is in pyproject.toml (pip install . / python -m build). Optional requirements.txt mirrors core deps only; use extras (upxo[all]) for DefDAP, meshing backends, etc.

Quick Start

from upxo.ggrowth.mcgs import mcgs

# Run a 2D Monte Carlo grain growth simulation
pxt = mcgs(input_dashboard='path/to/input_dashboard.xls')
pxt.simulate()
pxt.detect_grains()

# Access the grain structure at the final saved time slice
gs = pxt.gs[pxt.m[-1]]
print(f"Number of grains: {gs.n}")

More end-to-end examples (2D/3D generation, hierarchical and twinned microstructures, meshing, visualisation) are in the Workflows documentation.

Demo notebooks are not in the pip wheel. They are maintained in the separate UPXO-demos repository (MIT license); see the Demo Notebooks wiki.

Core capabilities

• Generation of grain structures — Voronoi tessellation and Monte Carlo simulation (Potts model); hierarchical lath microstructures; twinned FCC microstructures.
• Characterisation and Analysis — morphology, texture, and topological properties.
• Manipulation Tools — feature removal, introduction, modification, and replacement.
• Representativeness Assessment — morphological, textural, and topological assessment.
• FE Meshing — grain boundary geometry conformant and non-conformant Finite Element meshes.
• Data Interface — import, export, and management of grain structure data; EBSD integration.
• Visualisation — tools for plotting 2D and 3D microstructures.

Microstructures Supported

UPXO can produce a broad range of synthetic grain structures, including:

• Equiaxed polycrystals generated from tessellation methods
• Elongated and directionally structured grains
• Hierarchical microstructures — lath-based morphologies with packets, blocks, and sub-blocks (Ferritic-Martensitic steels)
• Twinned microstructures — Sigma-3 annealing and deformation twins in FCC materials (Cu, CuCrZr, OFHC-Cu)
• Texture-guided crystal orientation assignment
• EBSD-derived microstructure input and validation
• Multi-scale grain arrangements

Applications

UPXO is intended to cater to the needs of research involving microstructure-based modelling of structural materials.

Typical applications include:

Nuclear materials research

Synthetic microstructures can be generated for nuclear fusion relevant structural materials, enabling computational investigations of irradiation-induced degradation and microstructural evolution.

Aerospace and automotive materials

Non-equiaxed, gradient grain morphologies representative of manufacturing processes such as rolling, extrusion, forging, additive manufacturing, and welding may be produced in UPXO.

Data-driven materials modelling

Large ensembles of statistically representative microstructures can be generated and analysed, supporting machine-learning approaches and surrogate modelling.

Research in grain growth kinetics

Researchers can take advantage of the easy to use pipelines and templates to run existing or custom Pott's model Monte-Carlo simulation algorithms. The frameworks provide multiple entry points to study the grain growth kinetics, such as (a) Energetics (b) Ensemble properties of space partitioning (statistical - morphological, topological and spatial)

Cite As

If you use UPXO in your research, please cite:

Sunil Anandatheertha, Vikram Phalke, Eralp Demir, Chris Hardie, UKAEA Poly-XTAL operations (UPXO V1.0): An open-source Python package for generating, assessment and meshing of poly-crystalline grain structures, SoftwareX, Volume 34, 2026, 102736, ISSN 2352-7110, https://doi.org/10.1016/j.softx.2026.102736

@article{anandatheertha2026upxo1pnt1,
  title   = {UKAEA Poly-XTAL operations (UPXO V1.0): An open-source Python package for
             generating, assessment and meshing of poly-crystalline grain structures},
  author  = {Anandatheertha, Sunil and Phalke, Vikram and Demir, Eralp and Hardie, Chris},
  journal = {SoftwareX},
  volume  = {34},
  pages   = {102736},
  year    = {2026},
  issn    = {2352-7110},
  doi     = {10.1016/j.softx.2026.102736}
}

Need Help Getting Started?

If you are from an academic institution and feel UPXO could be useful to your project or use case, and need personal help, don't hesitate to contact Dr. Sunil Anandatheertha — I will be happy to help you set up and offer help in using UPXO.

📧 vaasu.anandatheertha@ukaea.uk

License

UPXO is distributed under the GNU General Public License v3.0 (GPL-3.0) for open-source and academic use.

Companies, industrial users, and other organisations wishing to use UPXO in commercial or proprietary applications may obtain a separate commercial license.

For commercial licensing enquiries, please contact:

• Dr. Sunil Anandatheertha (Email: vaasu.anandatheertha@ukaea.uk) and
• Dr. Chris Hardie (Email: chris.hardie@ukaea.uk)

Additional licensing information is provided in COMMERCIAL.md.
