vector-datalib 1.4.0b0

VECTOR: N-dimensional coordinate database with O(1) lookups

VECTOR - VECTOR Encodes Coordinates To Optimize Retrieval

A lightweight vector database library for Python that organizes data using mathematical coordinate systems. Built with domain-driven architecture and designed for single-file storage with O(1) lookup performance.

Project Philosophy

Vector embraces the "coordinate-based data organization" approach where every table must have an X-axis as the primary key, with other attributes representing relationships between dimensions. This creates a natural mathematical model for data organization:

• X-axis (Central Axis): Primary key and coordinate system foundation
• Y, Z, J... (Dimensional Spaces): Additional attributes that define relationships
• Coordinate Mappings: Functions that map between dimensional spaces
• Vector Points: Individual data records positioned in the coordinate space

Key Features

Vector Mathematics Foundation

• Coordinate System Architecture: Data organized around mathematical coordinate principles
• Dimensional Spaces: Scalable N-dimensional data representation without structural changes
• O(1) Lookup Performance: Coordinate indexing for instant data retrieval
• Value Deduplication: Automatic optimization of storage through value deduplication in dimensional spaces

Domain-Driven Architecture

• Clean Architecture: Separation of domain logic, application services, and infrastructure
• Coordinate Abstractions: Rich domain objects representing mathematical concepts
• Immutable Value Objects: Thread-safe coordinate and mapping representations
• Repository Patterns: Clean data access interfaces

Quick Start

Installation

# Clone the repository
git clone <repository-url>
cd vector

# Install in development mode
pip install -e .

# Or install from PyPI
pip install vector-datalib

Basic Usage

Async-First API with Context Managers

import asyncio
from vector_datalib import VectorDB

async def main():
    # Create database with async context manager
    async with VectorDB("my_data.db") as db:
        # 1. UPSERT: Insert or update (one method for both!)
        await db.upsert(101, {"age": 25, "name": "Alice"})
        await db.upsert(102, {"age": 30, "name": "Bob"})
        await db.upsert(101, {"age": 26, "name": "Alice"})  # Updates Alice

        # 2. LOOKUP: O(1) coordinate-based retrieval
        name = await db.lookup(101, "name")
        print(f"Employee 101: {name}")  # Employee 101: Alice

        # 3. DELETE: Remove records with automatic cleanup
        await db.delete(102)  # Bob is gone, values cleaned up

        # Batch operations for concurrency
        await db.batch_upsert([
            (104, {"name": "Diana", "age": 28}),
            (105, {"name": "Eve", "age": 32}),
            (106, {"name": "Frank", "age": 27})
        ])

        # Database automatically saved on exit

asyncio.run(main())

The Entire API:

• await upsert(key, attributes) - Insert or update
• await lookup(key, dimension) - Read data (O(1))
• await delete(key) - Remove with cleanup
• await batch_upsert(records) - Concurrent insert/update
• await batch_lookup(queries) - Concurrent reads
• await batch_delete(keys) - Concurrent deletes
• await save() - Manual save (auto-saves on exit)
• await get_stats() - Database statistics

Advanced Patterns

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("analytics.db") as db:
        # Concurrent batch upserts
        records = [(i, {"value": i, "squared": i**2}) for i in range(1000)]
        coordinates = await db.batch_upsert(records)
        print(f"Inserted {len(coordinates)} records concurrently")

        # Batch lookups (all concurrent)
        user_queries = [(101, "name"), (102, "age"), (103, "department")]
        results = await db.batch_lookup(user_queries)

        # LRU caching automatically optimizes repeated lookups
        name1 = await db.lookup(101, "name")  # Database + cache
        name2 = await db.lookup(101, "name")  # Cache hit (instant)

        # Batch deletes with cleanup
        to_delete = [i for i in range(0, 1000, 2)]  # Delete evens
        deleted_count = await db.batch_delete(to_delete)
        print(f"Deleted {deleted_count} records")

        # Manual save (optional - auto-saves on context exit)
        await db.save()

        # Database statistics
        stats = await db.get_stats()
        print(f"Database: {stats['vector_points']} points, {stats['dimensions']} dimensions")

asyncio.run(main())

Concurrency Benefits:

• batch_upsert(): All upserts execute concurrently using asyncio.gather()
• batch_lookup(): All lookups execute concurrently
• batch_delete(): All deletes execute concurrently with automatic value cleanup
• Cache-safe: asyncio.Lock prevents race conditions
• Non-blocking I/O: Uses aiofiles for async file operations

Architecture

Vector follows clean architecture principles with mathematical domain modeling:

src/vector_datalib/
├── domain/
│   ├── coordinates/            # X-axis coordinate system (primary key)
│   ├── spaces/                 # Y, Z, J... dimensional spaces
│   ├── mappings/               # Functions between dimensional spaces
│   └── __init__.py
├── application/
│   ├── main.py                 # Main database API
│   └── __init__.py
├── infrastructure/
│   ├── storage/                # .db file persistence
│   └── __init__.py
├── meta.py                     # Version and metadata
└── __init__.py                 # Public API exports

Domain Layer

• CentralAxis: Manages X-coordinate system and primary key constraints
• DimensionalSpace: Handles Y, Z, J... dimensions with value deduplication
• CoordinateMapping: Maps relationships between dimensional spaces
• VectorPoint: Represents individual data records as coordinate positions

Application Layer

• VectorDB: Main database interface providing the scripting API
• Coordinate Operations: Insert, lookup, update operations on coordinate system
• Dimensional Management: Dynamic expansion and contraction of coordinate spaces

Infrastructure Layer

• VectorFileStorage: Handles .db file format with JSON and gzip compression
• Persistence Management: Atomic save/load operations with metadata

Mathematical Model

Coordinate System Design

All tables in Vector must follow the coordinate system principle:

• X-axis (Primary Key): Central coordinate that uniquely identifies each vector point
• Dimensional Relationships: Other attributes represent relationships between the X-coordinate and various dimensional spaces

# Mathematical representation:
# Point P at coordinate X has relationships to multiple dimensions
# P(x) = {Y: f_y(x), Z: f_z(x), J: f_j(x), ...}
# where f_axis represents the mapping function for each dimension

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("data.db") as db:
        await db.upsert(101, age=25, name="Alice", city="Boston")
        # Creates: P(101) = {age: f_age(101)=25, name: f_name(101)="Alice", city: f_city(101)="Boston"}

        # Async lookup
        record = await db.lookup(101)
        print(record)  # {"age": 25, "name": "Alice", "city": "Boston"}

asyncio.run(main())

Value Deduplication

Vector automatically optimizes storage by deduplicating values within dimensional spaces:

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("data.db") as db:
        await db.upsert(101, age=25, name="Alice")
        await db.upsert(102, age=25, name="Bob")     # age=25 stored once
        await db.upsert(103, age=25, name="Charlie") # age=25 referenced

        # Storage optimization: age=25 stored once, referenced by multiple coordinates

        # All lookups return the correct values
        records = await db.batch_lookup([101, 102, 103])
        print(f"Records: {records}")  # All have age=25, but stored once internally

asyncio.run(main())

N-Dimensional Scalability

Add new dimensions without structural changes:

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("data.db") as db:
        # Start with 2 dimensions
        await db.upsert(101, age=25, name="Alice")

        # Expand to 3 dimensions (just upsert with new fields)
        await db.upsert(102, age=30, name="Bob", city="Boston")

        # Expand to N dimensions dynamically
        await db.upsert(103, age=25, name="Charlie", city="Boston", department="Engineering")

        # Query across dimensions
        charlie = await db.lookup(103)
        print(f"Charlie: {charlie}")

asyncio.run(main())

Performance Characteristics

Time Complexity

• Upsert: O(1) average case with hash-based coordinate indexing (async)
• Lookup: O(1) direct coordinate access + cache check (async)
• Delete: O(1) tombstoning with no coordinate shifting (async)
• Dimensional Expansion: O(1) addition of new coordinate relationships
• Batch Operations: O(n) with concurrent execution via asyncio.gather()

Storage Optimizations

• MessagePack Serialization: 2-3x smaller files than JSON
• LZ4 Compression: Blazing fast compression
• Async I/O: Non-blocking file operations with aiofiles
• LRU Caching: In-memory caching for frequently accessed data with asyncio.Lock
• Concurrent Safety: asyncio.Lock prevents race conditions in cache and storage
• Tombstoning: O(1) deletion without coordinate shifting overhead
• Tombstone Slot Reuse: Deleted coordinate slots are recycled for new inserts
• Reference Counting: Automatic cleanup of unreferenced values
• Context Managers: Automatic resource management and cleanup (async with __aenter__/__aexit__)

Space Complexity

• Value Deduplication: Automatic optimization reduces memory usage
• Coordinate Indexing: Hash-based storage for constant-time access
• LZ4 Compression: Fast compression for persistent storage efficiency
• Sparse Storage: Tombstones minimize wasted space

Async-First Architecture

Design Philosophy

Vector uses a simplified async-first API design:

• All I/O operations are async:

  • upsert() - Insert or update (single method for both)
  • lookup() - Cache + coordinate retrieval
  • delete() - Tombstoning with automatic cleanup
  • save() / load() - File persistence
  • batch_upsert() / batch_lookup() / batch_delete() - Concurrent operations
  • get_stats() - Database statistics

• No insert() vs update() confusion: Only upsert() for writes

• No verification needed: Internal consistency maintained automatically

• Batching in facade: Concurrent operations handled by main API

Concurrency Features

• Non-blocking I/O: aiofiles for async file operations
• Concurrent batching: asyncio.gather() for parallel operations
• Cache safety: asyncio.Lock prevents race conditions
• No blocking locks: Removed threading.RLock and filelock
• Tombstoning: O(1) deletion without coordinate shifting

Migration from Older API

If migrating from older mixed sync/async API:

# Old (mixed sync/async):
with VectorDB("data.db") as db:
    db.insert(101, {"name": "Alice", "age": 25})  # Sync
    name = await db.lookup(101)  # Async
    await db.update(101, age=26)  # Async

# New (async-first with upsert):
async with VectorDB("data.db") as db:
    await db.upsert(101, name="Alice", age=25)  # Async upsert
    name = await db.lookup(101)  # Async lookup
    await db.upsert(101, name="Alice", age=26)  # Async upsert (update)

File Format

.db File Structure

Vector uses a binary file format with MessagePack serialization and LZ4 compression for optimal performance:

┌─────────────────────────────────────┐
│           LZ4 Compressed            │
│  ┌───────────────────────────────┐  │
│  │      MessagePack Binary       │  │
│  │  ┌─────────────────────────┐  │  │
│  │  │ metadata                │  │  │
│  │  │ central_axis            │  │  │
│  │  │ dimensional_spaces      │  │  │
│  │  │ coordinate_mappings     │  │  │
│  │  └─────────────────────────┘  │  │
│  └───────────────────────────────┘  │
└─────────────────────────────────────┘

Structure contents:

• metadata: Version, timestamps, statistics
• central_axis: Vector points, coordinate map, free slots for reuse
• dimensional_spaces: Value domains with deduplication
• coordinate_mappings: Coordinate-to-value-id mappings with reference counts

Development

Requirements

• Python 3.11+
• Dependencies: msgpack, aiofiles, lz4, bidict

Coordinate System Examples

User Management System

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("users.db") as db:
        # X-coordinate: User ID, Y-dimension: Profile data
        await db.upsert(1001, name="Alice Johnson", age=28, department="Engineering")
        await db.upsert(1002, name="Bob Smith", age=32, department="Sales")
        await db.upsert(1003, name="Charlie Brown", age=28, department="Engineering")

        # O(1) user lookup (async)
        user = await db.lookup(1001)
        print(f"User: {user}")

        # Update using upsert - add new dimensional relationships
        await db.upsert(1001, name="Alice Johnson", age=28, department="Engineering",
                       salary=75000, location="Boston")

asyncio.run(main())

Product Catalog

import asyncio
from vector_datalib import VectorDB

async def main():
    async with VectorDB("products.db") as db:
        # X-coordinate: Product ID, Y/Z dimensions: Product attributes
        await db.upsert(2001, name="Laptop", price=999.99, category="Electronics")
        await db.upsert(2002, name="Mouse", price=29.99, category="Electronics")
        await db.upsert(2003, name="Desk", price=299.99, category="Furniture")

        # Value deduplication automatically optimizes "Electronics" category storage

        # Concurrent batch lookup
        products = await db.batch_lookup([2001, 2002, 2003])
        print(f"Products: {products}")

asyncio.run(main())

Best Practices

Simplified API Usage

• One write method: await db.upsert() handles both insert and update
• No insert() vs update() confusion: upsert does it all
• Automatic cleanup: delete() removes unused values automatically
• Tombstoning: O(1) deletion with no coordinate shifting
• Always use async context managers: async with VectorDB() as db:
• Batch for concurrency: Use batch_* methods for multiple operations
• Async everywhere: All I/O operations are async for consistency

Coordinate System Design

• Always use X-axis as primary key: This maintains the mathematical foundation
• Design dimensional relationships: Think about how attributes relate to coordinates
• Leverage value deduplication: Repeated values in dimensions are automatically optimized
• Plan for dimensional expansion: Design coordinate spaces that can grow dynamically

Performance Optimization

• Leverage batch operations: Use concurrent batching for multiple operations
• LRU cache awareness: Repeated lookups are cached automatically
• Appropriate coordinate ranges: Choose coordinate values that distribute well
• Monitor dimensional growth: Large numbers of unique values reduce deduplication benefits
• Use asyncio best practices: Don't block the event loop in your code

Data Organization

• Logical coordinate grouping: Group related data with nearby coordinates when possible
• Consistent dimensional naming: Use clear, consistent names for dimensional spaces
• Document coordinate meanings: Maintain documentation of what each coordinate represents

Troubleshooting

Common Issues

Large file sizes with compressed storage:

• Check for high dimensional diversity (many unique values)
• Consider coordinate space reorganization for better deduplication

Performance degradation:

• Monitor the number of unique values in dimensional spaces
• Consider splitting large coordinate spaces into multiple databases

Contributing

1. Fork the repository
2. Create a feature branch following the coordinate system principles
3. Implement changes with proper domain modeling
4. Ensure mathematical consistency in coordinate operations
5. Submit a pull request

License

This project is licensed under the Apache 2.0 License - see the LICENSE file for details.

Vector Mathematics

Vector database design is inspired by mathematical vector spaces where:

• Coordinates define position: X-axis establishes the coordinate system foundation
• Dimensions represent relationships: Each dimension shows how data relates to coordinates
• Mappings preserve structure: Functions between dimensions maintain mathematical consistency
• Scalability through expansion: N-dimensional growth without architectural changes

The name "Vector" reflects this mathematical foundation where data points exist as vectors in a coordinate space, with the X-axis serving as the primary coordinate system and other dimensions representing the vector's components in different spaces.

---

Organize your data with mathematical precision. Scale with coordinate clarity.

Built for developers who appreciate clean architecture and mathematical elegance.
