vertebrae 1.0.0

A framework for Benchmarking feature extractors and transfer-learning backbones.

Vertebrae

vertebrae is a Python package for evaluating feature extractors and transfer-learning backbones on labeled datasets. It supports dense and sparse precomputed embeddings, scikit-learn pipelines, custom callable extractors, ONNX models, local PyTorch and Keras modules, segmentation token workflows, optional embedding compression, and optional model families spanning Hugging Face, sentence-transformers, timm, torchvision, OpenCLIP/SigLIP, TensorFlow Hub, JAX/Flax, tree ensembles, graph models, and hosted embedding APIs. It can also evaluate labeled embedding units such as document regions, tokens, frames, keypoints, depth cells, and latent slots emitted directly by a model.

The package uses OverlapIndex as its primary separation metric and adds a Separatix complexity diagnostic to reports when an evaluated embedding clears a configurable overlap-quality threshold. The full evaluation flow wraps those diagnostics with practical dataset handling, named target and hierarchy views, caching, memory-aware subsampling, stability analysis, artifact-backed execution, custom embedding metrics, report generation, and repeated monitoring of live representations during training.

SciPy sparse matrices and sparse arrays are normalized to CSR and remain sparse through classification, multi-label, regression, and stability scoring, and when passed into Separatix. Multi-label targets may also be supplied as sparse binary indicator matrices.

Evaluation flow

The benchmark protocols share extraction, artifact, compression, and reporting infrastructure while keeping their scoring semantics separate.

flowchart TB
    data["Dataset and protocol metadata"] --> extract["Extract or load embeddings<br/>single or multi-output; row-aligned when needed"]
    extract --> artifacts["Reusable raw artifacts<br/>and optional compression variants"]
    artifacts --> protocol{"Configured evaluation protocol"}

    protocol --> labeled["Labeled embeddings<br/>OverlapIndex, stability, gated Separatix"]
    protocol --> retrieval["Exact query-gallery retrieval<br/>NDCG, recall, precision, mAP, MRR"]
    protocol --> zero_shot["Fixed-prompt zero-shot<br/>top-k classification and sample overlap"]

    labeled --> results["Practical results<br/>Python objects, DataFrames, JSON, Markdown"]
    retrieval --> results
    zero_shot --> results

Installation

pip install vertebrae

For local development:

poetry install --with dev

Optional Hugging Face and sentence-transformers support:

pip install "vertebrae[hf]"

Optional Hugging Face audio support only:

pip install "vertebrae[audio]"

Optional Hugging Face time-series support only:

pip install "vertebrae[timeseries]"

Optional Hugging Face video support only:

pip install "vertebrae[video]"

Optional local PyTorch model support:

pip install "vertebrae[torch]"
pip install "vertebrae[timm]"
pip install "vertebrae[torchvision]"
pip install "vertebrae[openclip]"

Optional dependencies for the Fashion-MNIST visual example suite:

pip install "vertebrae[visuals]"

Optional local Keras model support:

pip install "vertebrae[keras]"
pip install "vertebrae[tensorflow]"
pip install "vertebrae[tensorflow-hub]"

Optional ONNX Runtime support:

pip install "vertebrae[onnx]"

Optional JAX/Flax, tree ensemble, and graph model support:

pip install "vertebrae[jax]"
pip install "vertebrae[trees]"
pip install "vertebrae[graph]"

Optional distributed execution backends:

pip install "vertebrae[ray]"
pip install "vertebrae[dask]"
pip install "vertebrae[distributed]"

Optional cloud artifact stores:

pip install "vertebrae[s3]"
pip install "vertebrae[gcs]"
pip install "vertebrae[cloud]"

Quick Start

Precomputed embeddings

from vertebrae import BenchmarkDataset, Evaluator, DatasetIdentity
from vertebrae.extractors import PrecomputedExtractor

dataset = BenchmarkDataset.from_embeddings(embeddings=Z, labels=y, identity=DatasetIdentity.declared("example-dataset", "1"))
extractor = PrecomputedExtractor(name="baseline_embeddings")

result = Evaluator(dataset=dataset, extractor=extractor).run()

print(result.to_dataframe())
result.save_json("result.json")
result.save_markdown("report.md")

Every root dataset requires an explicit DatasetIdentity. A declared identity is the recommended production choice; change its revision whenever the dataset content, ordering, targets, groups, or annotations change. Manifest identity hashes only a caller-provided source manifest. Full content hashing and ephemeral UUID identity are available only through the explicit DatasetIdentity.from_content() and DatasetIdentity.ephemeral() constructors. Path-based datasets are never scanned or hashed automatically. See Dataset identity.

Sparse matrices are supported as embedding inputs as well.

By default, vertebrae also runs a Separatix complexity diagnostic when the evaluated embedding reaches overlap_macro >= 0.80. That extra diagnostic does not affect ranking. It adds report guidance about what kind of downstream classifier complexity the labeled geometry appears to need.

Multi-label classification datasets are supported through the same constructors. Use per-sample label sequences or a binary indicator matrix with label_names:

from vertebrae import DatasetIdentity
dataset = BenchmarkDataset.from_embeddings(
    embeddings=Z,
    labels=[
        ("outdoor", "vehicle"),
        ("outdoor", "vehicle"),
        ("indoor",),
        ("indoor",),
        ("outdoor", "animal"),
        ("animal",),
    ],
    identity=DatasetIdentity.declared("example-dataset", "1"),
)

result = Evaluator(dataset=dataset, extractor=PrecomputedExtractor()).run()

OverlapIndex receives a dense multi-label indicator target internally, and Separatix runs with target_mode="multilabel".

Regression targets are supported when explicitly requested so numeric class identifiers are not accidentally interpreted as continuous targets:

from vertebrae import DatasetIdentity
dataset = BenchmarkDataset.from_arrays(
    X=samples,
    y=targets,
    modality="tabular",
    target_type="regression",
    target_names=["quality_score"],
    identity=DatasetIdentity.declared("example-dataset", "1"),
)

result = Evaluator(dataset=dataset, extractor=extractor).run()

Regression scoring uses ContinuousOverlapIndex through vertebrae's internal scoring adapter and appears in reports as continuous overlap diagnostics.

Multiple target views

When one embedding should be compared against several aligned targets, register named target views on the dataset and enable them in Benchmark. Views can be classification, multi-label, or regression targets; each is reported as a separate result variant.

from vertebrae import Benchmark, BenchmarkDataset, TargetView, TargetViewConfig, DatasetIdentity

dataset = BenchmarkDataset.from_embeddings(embeddings=Z, labels=leaf_labels, identity=DatasetIdentity.declared("example-dataset", "1"))
dataset = dataset.with_target_views(
    [
        TargetView(name="coarse", targets=coarse_labels),
        TargetView(name="quality", targets=quality_scores, target_type="regression"),
    ]
)

result = Benchmark(
    dataset,
    [extractor],
    target_view_config=TargetViewConfig(enabled=True, views=("coarse", "quality")),
).run()

For taxonomies represented as label paths, use with_label_hierarchy(...) and LabelViewConfig instead. output_views and output_levels can route named extractor outputs to the target or hierarchy view that they should evaluate.

Classification labels keep exact typed semantic identity in the dataset and label catalog. For example, integer 1 and string "1" are separate classes even though their ordinary string forms match. Metric adapters receive marked semantic-key strings in both local and artifact-backed runs, while results retain the original typed values, stable internal keys, and disambiguated display text in the catalog. Hierarchy paths are encoded structurally rather than by joining values with a delimiter.

Optional embedding compression

from vertebrae import BenchmarkDataset, EmbeddingCompressionConfig, Evaluator, DatasetIdentity
from vertebrae.extractors import PrecomputedExtractor

dataset = BenchmarkDataset.from_embeddings(embeddings=Z, labels=y, identity=DatasetIdentity.declared("example-dataset", "1"))
extractor = PrecomputedExtractor(name="baseline_embeddings")

compression = EmbeddingCompressionConfig(
    enabled=True,
    method="prefix_truncate",
    n_components=256,
    assume_matryoshka=True,
)

result = Evaluator(
    dataset=dataset,
    extractor=extractor,
    compression_config=compression,
).run()

Supported compression methods include pca, incremental_pca, truncated_svd, random projections, prefix_truncate, and quantize.

The network-free-after-download fashion_mnist_visual_suite.py also illustrates the storage-quality tradeoffs of PCA and quantization on a trained penultimate embedding. Each point shows the measured OverlapIndex score against encoded bytes per sample; the dashed line marks the non-dominated frontier.

Scikit-learn pipelines

from sklearn.decomposition import TruncatedSVD
from sklearn.feature_extraction.text import TfidfVectorizer
from sklearn.pipeline import Pipeline
from sklearn.preprocessing import Normalizer

from vertebrae import BenchmarkDataset, Evaluator, DatasetIdentity
from vertebrae.extractors import SklearnExtractor

pipeline = Pipeline(
    [
        ("tfidf", TfidfVectorizer(ngram_range=(1, 2), min_df=2)),
        ("svd", TruncatedSVD(n_components=128, random_state=42)),
        ("norm", Normalizer()),
    ]
)

dataset = BenchmarkDataset.from_arrays(texts, labels, modality="text", identity=DatasetIdentity.declared("example-dataset", "1"))
extractor = SklearnExtractor(
    name="tfidf_svd",
    pipeline=pipeline,
    # This manually versioned identity opts the fitted live pipeline into reuse.
    cache_identity="tfidf-svd-v1",
)

result = Evaluator(dataset=dataset, extractor=extractor).run()

Local PyTorch models

import numpy as np
import torch

from vertebrae import BenchmarkDataset, Evaluator, DatasetIdentity
from vertebrae.extractors import TorchExtractor

model = torch.load("/path/to/local_model.pt", map_location="cpu")
model.eval()


def collate_fn(batch):
    return torch.as_tensor(np.asarray(batch), dtype=torch.float32)


def output_fn(raw_output):
    return raw_output if isinstance(raw_output, torch.Tensor) else raw_output["embeddings"]


dataset = BenchmarkDataset.from_arrays(features, labels, modality="tabular", identity=DatasetIdentity.declared("example-dataset", "1"))
extractor = TorchExtractor(
    name="local_torch",
    model=model,
    collate_fn=collate_fn,
    output_fn=output_fn,
    device="cpu",
    checkpoint_paths=["/path/to/local_model.pt"],
    cache_identity="local-torch-model-v1",
    recipe_data={"checkpoint": "/path/to/local_model.pt"},
)

result = Evaluator(dataset=dataset, extractor=extractor).run()

Local Keras models

import numpy as np

from vertebrae import BenchmarkDataset, Evaluator, DatasetIdentity
from vertebrae.extractors import KerasExtractor


def collate_fn(batch):
    return np.asarray(batch, dtype=np.float32)


dataset = BenchmarkDataset.from_arrays(features, labels, modality="tabular", identity=DatasetIdentity.declared("example-dataset", "1"))
extractor = KerasExtractor(
    name="local_keras",
    model=model,
    collate_fn=collate_fn,
    call_method="call",
    checkpoint_paths=["/path/to/model.keras"],
    cache_identity="local-keras-model-v1",
    recipe_data={"checkpoint": "/path/to/model.keras"},
)

result = Evaluator(dataset=dataset, extractor=extractor).run()

checkpoint_paths contributes content-digested provenance and profiling evidence; a path copied only into recipe_data is descriptive metadata. Because these adapters receive already-loaded live model objects, the path cannot prove that the in-memory weights match the file, so reusable caching still requires a maintained cache_identity. Torch extraction defaults to evaluation plus inference mode and restores the model's prior training state afterward. Notebook-local, nested, or otherwise nonportable adapter functions likewise require an explicit identity.

Hugging Face audio backbones

from vertebrae import BenchmarkDataset, CacheConfig, Evaluator, DatasetIdentity
from vertebrae.extractors import HFAudioExtractor

dataset = BenchmarkDataset.from_audio_arrays(
    audio=waveforms,
    labels=labels,
    sampling_rate=16_000,
    identity=DatasetIdentity.declared("example-dataset", "1"),
)
extractor = HFAudioExtractor(
    name="wav2vec2_base",
    model_id="facebook/wav2vec2-base",
    pooling="mean",
)

# This introductory model ID is intentionally unpinned, so do not reuse its output.
result = Evaluator(
    dataset=dataset,
    extractor=extractor,
    cache_config=CacheConfig(enabled=False),
).run()

Hugging Face multi-modal models

from vertebrae import BenchmarkDataset, CacheConfig, Evaluator, DatasetIdentity
from vertebrae.extractors import HFMultimodalExtractor

dataset = BenchmarkDataset.from_multimodal(
    inputs={"image": images, "caption": captions},
    labels=labels,
    modalities={"image": "image", "caption": "text"},
    identity=DatasetIdentity.declared("example-dataset", "1"),
)

extractor = HFMultimodalExtractor(
    name="clip_like",
    model_id="openai/clip-vit-base-patch32",
    input_modalities={"image": "image", "caption": "text"},
    outputs=[
        {"name": "image_branch", "source": "image", "model_output": "image_embeds"},
        {"name": "text_branch", "source": "text", "model_output": "text_embeds"},
        {"name": "fused", "source": "fused", "model_output": "pooler_output"},
    ],
)

# This introductory model ID is intentionally unpinned, so do not reuse its output.
result = Evaluator(
    dataset=dataset,
    extractor=extractor,
    cache_config=CacheConfig(enabled=False),
).run()

Hugging Face time-series backbones

from vertebrae import BenchmarkDataset, CacheConfig, Evaluator, DatasetIdentity
from vertebrae.extractors import HFTimeSeriesExtractor

dataset = BenchmarkDataset.from_time_series(
    series=series,
    labels=labels,
    identity=DatasetIdentity.declared("example-dataset", "1"),
)
extractor = HFTimeSeriesExtractor(
    name="patchtst",
    model_id="some-local-or-hf-timeseries-model",
    pooling="mean",
)

# This placeholder may resolve to mutable remote state.
result = Evaluator(
    dataset=dataset,
    extractor=extractor,
    cache_config=CacheConfig(enabled=False),
).run()

Hugging Face video backbones

from vertebrae import BenchmarkDataset, CacheConfig, Evaluator, DatasetIdentity
from vertebrae.extractors import HFVideoExtractor

dataset = BenchmarkDataset.from_video_arrays(
    frames=clips,
    labels=labels,
    frame_rate=24.0,
    identity=DatasetIdentity.declared("example-dataset", "1"),
)
extractor = HFVideoExtractor(
    name="videomae_base",
    model_id="MCG-NJU/videomae-base",
    pooling="mean",
    num_frames=16,
)

# This introductory model ID is intentionally unpinned, so do not reuse its output.
result = Evaluator(
    dataset=dataset,
    extractor=extractor,
    cache_config=CacheConfig(enabled=False),
).run()

Multi-extractor comparison

from vertebrae import Benchmark

benchmark = Benchmark(dataset)
benchmark.add_extractor(tfidf_extractor)
benchmark.add_extractor(sentence_transformer_extractor)
benchmark.add_extractor(custom_extractor)

result = benchmark.run()
print(result.to_dataframe())

You can also benchmark multiple embedding outputs from the same backbone without duplicating extractor classes. This is useful for comparing intermediate layers, pooling strategies, or multi-head outputs from one model. When the dataset has hierarchy metadata from with_label_hierarchy(...), outputs can be routed to different hierarchy levels:

from vertebrae import Benchmark, CacheConfig, LabelViewConfig
from vertebrae.extractors import HFVisionExtractor

benchmark = Benchmark(
    dataset,
    label_view_config=LabelViewConfig(
        output_levels={
            "mid_cls": "family",
            "final_cls": "leaf",
        },
    ),
    # The example model IDs below are intentionally unpinned.
    cache_config=CacheConfig(enabled=False),
)
benchmark.add_extractor(
    HFVisionExtractor(
        name="mnist_vit",
        model_id="farleyknight-org-username/vit-base-mnist",
        outputs=[
            {"name": "final_cls", "pooling": "cls"},
            {"name": "mid_cls", "pooling": "cls", "hidden_layer": 6},
        ],
        image_mode="rgb",
        batch_size=8,
    )
)

result = benchmark.run()
print(result.to_dataframe()[["extractor", "label_view", "overlap_macro"]])

Each configured output is scored as its own result variant, so this run produces rows such as mnist_vit:mid_cls[level=family] and mnist_vit:final_cls[level=leaf]. See examples/hf_vision_mnist.py for a fuller example that compares multi-output Hugging Face vision embeddings alongside a classical scikit-learn image baseline. For a more realistic image workflow, examples/caltech101_vision_foundation_models.py downloads a laptop-sized Caltech-101 subset with a few related category pairs, compares DINOv2 with a tiny supervised ViT baseline, and can include gated DINOv3 embeddings when VERTABRAE_INCLUDE_DINOV3=1 is set.

Representation monitoring during training

RepresentationMonitor repeatedly runs a fresh labeled Benchmark against live extractors while your code retains control of training, cadence, checkpoints, and optimization. Named outputs make it possible to inspect representation separation as a function of both training progress and layer depth.

from vertebrae import (
    ConsoleReporter,
    EvaluationHistoryConfig,
    RepresentationMonitor,
)

monitor = RepresentationMonitor(
    fixed_probe_dataset,
    [live_torch_extractor],
    history_config=EvaluationHistoryConfig(
        storage="disk",
        path="representation-history.jsonl",
    ),
    reporters=[ConsoleReporter()],
)

for epoch in range(epochs):
    train_one_epoch(model)
    monitor.evaluate(epoch=epoch, metadata={"loss": training_loss})

history = monitor.history.to_dataframe()

Every call executes the configured benchmark stack and always recomputes embeddings, even if an enabled cache is supplied. Use a fixed held-out probe dataset and control evaluation cost through cadence, stability, and Separatix settings. The append-only JSONL format supports protocol-validated resume and read-only loading. Restoring the matching live model, optimizer, epoch, and step remains the caller's responsibility. See the representation monitoring guide and the network-free examples/representation_monitoring.py Torch workflow.

The network-free-after-download fashion_mnist_visual_suite.py trains a compact two-block convolutional network and applies the same protocol to real Fashion-MNIST evaluations. It carves a fixed, stratified validation set out before training, leaves the official test set untouched, and disables Separatix and stability repeats so each figure focuses on the raw OverlapIndex diagnostic. For complementary visual examples of the underlying metrics, see the OverlapIndex and Separatix repositories.

Representation trajectories

Two spatial convolutional representations and the learned 128-dimensional embedding are evaluated before training and every two optimizer steps over three epochs. The same layer identities and colors connect the network diagram to the monitoring curves. Fashion-MNIST's visually related apparel classes make it possible to compare how local features and the task-specific embedding evolve at different depths.

Hierarchical label views

The same representations are evaluated against nested department, garment-group, and exact-class label views before and after training.

Reproduce the monitoring, hierarchy, and compression figures with:

poetry install -E visuals
poetry run python examples/fashion_mnist_visual_suite.py

Retrieval and matching

RetrievalBenchmark evaluates frozen query embeddings against an explicit gallery and graded relevance judgments. It is an exact, training-free ranking protocol and is separate from ordinary labeled OverlapIndex benchmarking.

from vertebrae import RetrievalBenchmark, RetrievalConfig, RetrievalDataset, DatasetIdentity
from vertebrae.extractors import PrecomputedExtractor

dataset = RetrievalDataset.from_embeddings(
    query_embeddings,
    gallery_embeddings,
    relevance=[("query-1", "document-9", 2.0)],
    query_ids=["query-1"],
    gallery_ids=["document-9"],
    identity=DatasetIdentity.declared("example-dataset", "1"),
)

result = RetrievalBenchmark(
    dataset,
    [PrecomputedExtractor("candidate")],
    retrieval_config=RetrievalConfig(primary_metric="ndcg@10"),
).run()

Relevance can be a NumPy/scipy query-by-gallery matrix or sparse (query_id, gallery_id, grade) records. Nested Python lists are records; construct nested-list matrices explicitly with RetrievalDataset.from_relevance_matrix(...). Every query must retain an eligible positive after exclusions. Reports include NDCG, precision, recall, hit rate, MRR, mAP, and similarity diagnostics. See the retrieval guide for branch-aware extractors, bidirectional scoring, exclusions, compression, and artifact workflows.

Fixed-prompt zero-shot alignment

For contrastive extractors with independently encodable sample and text branches, ZeroShotBenchmark evaluates whether fixed class prompts address the dataset in the model's shared embedding space. It trains no head and requires explicit prompts. The zero-shot rank and ordinary sample-embedding overlap are reported side by side; they are not combined into a universal backbone score. See docs/zero_shot.md and the network-free examples/zero_shot_callable.py workflow.

Use ZeroShotCandidate(extractor, sample_branch, text_branch) when compared models use different branch names. OpenCLIP keeps its image-only ordinary default while its native text_branch remains available for zero-shot. Callable adapters cache only when their functions have portable paths or an explicit cache_identity.

Retrieval and zero-shot compression keep both sides in one representation space. Learned retrieval transforms are fitted on the gallery and applied to queries; learned zero-shot transforms are fitted on samples and applied to prompt embeddings. The CLI exposes these paired workflows through compress-retrieval and compress-zero-shot.

Custom embedding metrics

Every benchmark always records the built-in overlap metric. You can score the same full embedding batch with additional metrics and choose one as the ranking criterion. A custom metric returns a finite aggregate score and may include JSON-safe diagnostics, warnings, and metadata.

For protocol parity, categorical labels and groups passed to custom metrics are marked semantic-key strings locally and on distributed workers; regression targets remain numeric. Read original typed provenance and display values from target_metadata["label_catalog"] when needed.

from vertebrae import Benchmark, CallableMetric

def domain_margin(embeddings, labels, *, groups=None, seed=None):
    return {"score": 0.87, "diagnostics": {"rule": "domain margin"}}

result = Benchmark(
    dataset,
    [extractor],
    metrics=[CallableMetric("domain_margin", domain_margin)],
    primary_metric="domain_margin",
).run()

The overlap result remains available in every ExtractorResult and continues to drive stability and Separatix. For artifact or CLI workflows, use an importable callable path such as my_project.metrics:domain_margin; see the scoring guide and the distributed-readiness guide.

Dense segmentation tokens

Dense segmentation evaluation scores spatial feature cells after they are aligned to semantic mask labels. It measures representation organization for retained tokens; it is not an IoU, mask-accuracy, or boundary-quality metric.

Both dense spatial outputs and other structured model outputs become ordinary labeled embedding rows before scoring:

flowchart TB
    spatial_source["Spatial path<br/>image, semantic mask, declared feature grid"] --> spatial_align["Assign cells by mask coverage<br/>filter ambiguity and sample deterministically"]
    structured_source["Structured path<br/>parent sample, unit annotations, emitted rows"] --> structured_align["Select and align emitted rows<br/>to declared unit annotations"]

    spatial_align --> rows["Materialized BenchmarkDataset rows<br/>embeddings, targets, parent groups, provenance"]
    structured_align --> rows
    rows --> scoring["Standard labeled-embedding scoring<br/>OverlapIndex, stability, gated Separatix"]

from vertebrae import (
    Benchmark,
    CallableSpatialExtractor,
    SegmentationConfig,
    SegmentationDataset,
    SpatialLayout,
    SpatialOutputSpec,
)

dataset = SegmentationDataset.from_arrays(
    images=images,
    semantic_masks=masks,
    identity=DatasetIdentity.declared("example-dataset", "1"),
)

extractor = CallableSpatialExtractor(
    "encoder",
    transform_fn=extract_spatial_features,
    output_specs=[
        SpatialOutputSpec(
            name="stage_4",
            layout=SpatialLayout(grid_height=14, grid_width=14),
        )
    ],
)

result = Benchmark(
    dataset=dataset,
    extractors=[extractor],
    segmentation_config=SegmentationConfig(max_tokens_per_class=10_000),
).run()

See docs/segmentation.md for background handling, ambiguity filtering, instance caps, grouped diagnostics, and precomputed segmentation embeddings.

Structured units from native model outputs

Structured extractors flatten one declared per-parent unit matrix into a grouped embedding dataset, preserving unit provenance and parent groups. This supports representation diagnostics for regions, tokens, frames, keypoints, depth cells, and latent slots. It does not substitute task-native metrics such as mAP, IoU, WER/CER, OKS, depth error, or reconstruction quality.

Unit annotations may use single-label, multi-label, or one-/multi-target regression targets, provided every parent uses the same resolved schema. Local unit IDs may repeat across parents; materialization generates parent-aware global IDs and retains the supplied value as local_unit_id in provenance. Dense and scipy sparse per-parent matrices are supported without premature densification.

from vertebrae import Benchmark, BenchmarkDataset, UnitAnnotation, DatasetIdentity
from vertebrae.extractors import CallableStructuredExtractor, StructuredOutputSpec

dataset = BenchmarkDataset.from_arrays(X=pages, y=document_labels, modality="image", identity=DatasetIdentity.declared("example-dataset", "1"))
dataset = dataset.with_unit_annotations(
    [
        UnitAnnotation(labels=["heading", "body"]),
        UnitAnnotation(labels=["heading", "body"]),
    ],
    unit_type="document_region",
)

extractor = CallableStructuredExtractor(
    name="layout_encoder",
    transform_fn=extract_region_embeddings,  # one 2D matrix per page
    output_specs=[StructuredOutputSpec(name="regions", unit_type="document_region")],
)
result = Benchmark(dataset, [extractor]).run()

When the model emits unmatched rows (for example special tokens or sampled frames), supply an explicit alignment rule such as drop_special_rows(leading=1) or select_frame_rows(...). Typed adapters are also available for detection/layout, sequence labeling, keypoints, depth, and latent slots. See the dataset guide and the extractor guide, alongside the runnable examples/structured_*.py workflows.

Supported Workflows

vertebrae is designed for:

• precomputed dense or sparse embeddings,
• NumPy arrays and pandas DataFrames,
• single-label classification, multi-label classification (including sparse binary indicators), and explicit regression targets,
• hierarchy label views and named target views for scoring the same embeddings against different targets,
• graph-node, graph-edge, entity, pair, triplet-derived, and generic labeled-unit embedding diagnostics,
• scikit-learn transformers and pipelines,
• custom Python callable extractors,
• dense segmentation token materialization from spatial feature maps,
• structured unit materialization from native token, frame, region, keypoint, depth, or latent-slot outputs, with explicit alignment when rows do not already match,
• Hugging Face text backbones through HFTextExtractor,
• Hugging Face vision backbones through HFVisionExtractor,
• Hugging Face audio backbones through HFAudioExtractor,
• Hugging Face image-text and other structured multi-modal backbones through HFMultimodalExtractor,
• Hugging Face video backbones through HFVideoExtractor,
• Hugging Face time-series backbones through HFTimeSeriesExtractor,
• sentence-transformers through SentenceTransformerExtractor,
• timm, torchvision, OpenCLIP, SigLIP, TensorFlow Hub, JAX/Flax, tree-leaf, graph, and hosted embedding API extractors,
• local PyTorch modules through TorchExtractor,
• local Keras modules through KerasExtractor,
• local ONNX Runtime sessions through ONNXExtractor,
• single-output and multi-output extractor evaluation,
• repeated time-by-layer representation monitoring for live extractors,
• single-extractor evaluation,
• multi-extractor comparisons,
• JSON and Markdown reports,
• repeated-run stability analysis,
• optional Separatix complexity diagnostics in local and artifact-backed reports,
• custom full-batch embedding metrics with a selectable primary ranking metric,
• exact, training-free query--gallery retrieval and matching with explicit graded relevance,
• fixed-prompt, training-free zero-shot semantic alignment for compatible text-aligned models,
• optional embedding compression and compressed-variant comparisons,
• local embedding caching and reproducible artifacts,
• artifact-backed distributed embedding and scoring through the vertebrae CLI,
• artifact-backed Benchmark.run() dispatch through explicit local, Ray, and Dask backends,
• local paths, s3://..., and gs://... artifact stores.

Distributed CLI commands include vertebrae plan, vertebrae fit-extractor, vertebrae embed-shard, vertebrae merge-embeddings, vertebrae write-labels, vertebrae write-groups, vertebrae materialize-segmentation, vertebrae materialize-structured, vertebrae compress, vertebrae score, vertebrae plan-retrieval, vertebrae embed-retrieval-shard, vertebrae merge-retrieval-embeddings, vertebrae write-retrieval-relevance, vertebrae compress-retrieval, vertebrae score-retrieval, vertebrae plan-zero-shot, vertebrae embed-zero-shot-shard, vertebrae merge-zero-shot-embeddings, vertebrae write-zero-shot-protocol, vertebrae compress-zero-shot, vertebrae score-zero-shot, vertebrae zero-shot-from-artifacts, vertebrae diagnose-complexity, vertebrae score-repeats, vertebrae collect-scores, vertebrae benchmark-from-artifacts, vertebrae slurm-array, vertebrae slurm-score-array, and vertebrae run-embedding-shards.

All CLI pickle inputs, including fitted-extractor bundles, are trusted-input-only. Artifact-backed embedding workers are transform-only: the driver or fit-extractor fits once on the complete selected dataset before shard dispatch.

Reusable artifacts use cache identity schema v2: hashes cover complete typed values. Array manifest v2 commits immutable digest-named array data, while composite artifact manifest v2 commits an array plus metadata or labels plus metadata as one coherent publication. Readers validate component sizes and SHA-256 digests as well as array shape, dtype, storage format, and sparse nnz.

Callable/live-model extractors that cannot prove a stable identity still evaluate but bypass cache reuse and record cache_status="bypassed_unsafe_identity". Reuse requires an explicit cache_identity, a model identifier that is itself a content-digested local path, or a remote revision pinned to a full immutable commit hash. Merely declaring a checkpoint beside an already-loaded live model does not prove that the object contains those weights. Importable callable identities include referenced modules, helper callables, and exact global configuration; optional backend versions also participate in extractor recipes. Raw-cache eligibility propagates to compression and every derived artifact: disabling raw caching or using an unsafe identity cannot produce a reusable derived cache. Superseded cache identity and array/composite manifest schemas are intentionally not read; standalone JSON and label store APIs remain current.

Streaming-safe extractors are transformed in independent batches. Every batch must return the same unique output names, row counts, feature widths, dtypes, dense/sparse form, recipes, metadata contracts, and parent coverage. Extractors declaring streaming_safe=False receive one full transform call instead.

For Ray or Dask cluster runs, the configured cache_dir can be either a shared local path or a cloud object-store URI such as s3://team-bucket/vertebrae/run-001 or gs://team-bucket/vertebrae/run-001. Workers need credentials for the selected store.

Reports and Results

Resource profiling can be enabled when deployment cost is part of representation selection:

from vertebrae import ResourceProfilingConfig

result = Benchmark(
    dataset,
    extractors=[small_backbone, large_backbone],
    resource_profiling_config=ResourceProfilingConfig(enabled=True),
).run()

print(result.to_dataframe())
print([item.name for item in result.quality_cohort()])

The profile observes the benchmark's real local extraction calls. It reports first-call and warm latency, observed throughput, host memory, supported device/model footprints, and logical raw/compressed embedding storage. It does not change quality ranking. A cache hit remains a cache hit and reports inference as unmeasured; use CacheConfig(force_recompute=True) when a fresh inference measurement is required.

Native model/device adapters cover local Torch, Keras, ONNX, Hugging Face, sentence-transformers, timm, torchvision, OpenCLIP/SigLIP, graph-model, and TensorFlow Hub and JAX/Flax extractors. Device peaks are reported only for a successfully reset single-device profiling window; cache hits, multi-device Torch, and JAX allocator limits remain explicitly unavailable. Checkpoint sizes come only from explicit paths; model identifiers and external caches are never scanned implicitly. Reports distinguish complete, partial, unavailable, and CPU-not-applicable evidence.

Retrieval and zero-shot benchmarks accept the same embedding and profiling configs and report independent endpoint profiles. Artifact-backed workers persist local observations; merged results use a distinct distributed profile with worker-first latency and aggregate compute throughput rather than presenting worker data as one local run. Embedding storage reports both logical bytes and the actual persisted array-object size when available.

Latency values are meaningful only with their recorded batch size, device, precision, and synchronization context. They are workload observations, not hardware-normalized scores or controlled load tests.

Each benchmark run returns structured results that include:

• dataset summary,
• extractor summary and recipe metadata,
• overlap scores plus per-class, per-label, or per-target diagnostics,
• Separatix recommendation, confidence, and report details when the overlap gate passes,
• label-view, target-view, segmentation, structured-unit, grouping, and target-type metadata when present,
• every configured metric result and the selected primary ranking metric,
• compression metadata and compressed dimensions,
• stability summaries,
• warnings and recommendations,
• reproducibility metadata.

Only results whose selected metric declares aggregate_valid=True participate in rankings, quality cohorts, top recommendations, or resource comparisons. When no valid aggregate remains, reports say that ranking is unavailable instead of promoting an invalid result.

Results can be rendered directly to Markdown or JSON:

result.save_json("result.json")
result.save_markdown("report.md")

You can also convert rankings into a DataFrame with result.to_dataframe().

Compression-aware results include the compression method and compressed dimension, and quantized runs preserve calibration metadata in the structured result payload.

Separatix is stored as the default classifier-complexity report field. JSON output preserves the full Separatix report. Markdown and DataFrame views surface the main recommendation, confidence, and compact explanation fields that are usually the most actionable.

Separatix is also the source of probe-style summary fields, so vertebrae does not fit a second probe system alongside the complexity diagnostic.

The key component of the report is the performance and comparison table. The following is the current output generated by examples/sklearn_wine_pipeline.py.

rank	extractor	primary_metric	primary_score	overlap_macro	stability_interval	weakest_class	best_probe	probe_metric	probe_score	embedding_dim	recommendation
1	wine_standard_scaler_all_features	overlap	0.9232	0.9232	0.9058-0.9279	class_1	linear	balanced_accuracy	0.9812	13	strong_candidate
2	wine_standard_scaler_pca_6	overlap	0.9179	0.9179	0.9051-0.9368	class_1	kernel_approx	balanced_accuracy	0.9767	6	strong_candidate
3	wine_minmax_pca_2	overlap	0.9079	0.9079	0.9366-0.9455	class_1	smooth_poly	balanced_accuracy	0.9756	2	strong_candidate
4	wine_quantile_pca_1	overlap	0.4554	0.4554	0.3455-0.4554	class_2				1	poor_frozen_representation_weak_class_attention

The full generated table also includes target_view, label_view, overlap_score, overlap_weighted, compression fields, and Separatix fields. The compact table above keeps the README readable while preserving the values used for the ranking.

By default, extractors are ranked by overlap. When a custom primary_metric is configured, they are ranked by that metric instead; the overlap columns remain available for representation diagnostics and Separatix gating.

For classification and multi-label targets, discrete OverlapIndex scores are bounded to [0, 1]: 1.0 indicates perfect class separation and 0.0 indicates perfect class overlap. The discrete score is not permutation-null calibrated, so 0.5 has no special null interpretation. ContinuousOverlapIndex uses the separate regression calibration described in the scoring documentation.

The easiest way to interpret the report is:

• Start with primary_metric and primary_score. By default these are overlap; with a custom metric they identify the configured ranking signal.
• Inspect overlap_macro and per-class overlap scores as the standard vertebrae representation diagnostic, even when another metric ranks the candidates.
• Use the vertebrae recommendation field as a quick summary of representation quality under the benchmark protocol.
• Use separatix_recommendation and separatix_confidence to understand what kind of downstream classifier complexity the labeled embedding seems to imply once the representation is already reasonably separated.
• When Separatix columns are blank, the diagnostic was disabled, did not clear the overlap gate, or did not return that field. Check the per-extractor skip reason before interpreting the blank.
• Treat best_probe, probe_metric, and probe_score as Separatix-derived quick-check columns. They are blank when Separatix is disabled, skipped, or does not report a baseline probe score. The metric is target-aware rather than always being accuracy.

Problem classes change the interpretation and detail columns, not the overall report workflow:

problem class	target metadata	detailed overlap output	typical probe metric
single-label classification	class names and counts	per-class and pairwise scores	balanced accuracy
multi-label classification	label names, cardinality, and density	per-label scores	macro/micro F1 or sample Jaccard
regression	target names and target statistics	per-target continuous overlap	R² or a regression-specific metric
hierarchy or named target views	active view and available views	one ranked result per evaluated view	follows the projected target type
dense segmentation	source-image groups and token provenance	per-class token overlap	classification metric when applicable

Two other network-free examples exercise the same report schema with different target types:

problem class	generated by	extractor	overlap_macro	weakest target	recommendation
multi-label classification	examples/multilabel_precomputed_embeddings.py	toy_multilabel_embeddings	0.0000	outdoor	poor_frozen_representation_weak_class_attention
structured regression	examples/structured_depth.py	depth_samples:depth_cells	0.9732		continuous_structure_above_null

The toy multi-label result is intentionally not presented as a strong representation: its labels cross the three embedding clusters, and the report correctly flags the weak result. The structured-depth result evaluates continuous target structure; it is not an RMSE or depth-estimation benchmark.

See results and reports for the complete schema and the additional metadata retained for multi-output, structured, relational, and zero-shot workflows.

In the per-extractor Markdown section, Separatix also adds:

• a plain-language recommendation text,
• a decision path showing the main diagnostic branches,
• normalized summary scores such as signal, overlap, linearity, nonlinearity, and reliability,
• warnings and skipped diagnostics when part of the complexity audit did not run.

As a rule of thumb, a strong overlap score plus linear_likely_sufficient usually points to an embedding that should work well with simple downstream classifiers, while a strong overlap score plus smooth_nonlinear_recommended or kernel_or_local_recommended suggests the embedding is promising but may benefit from a more flexible decision boundary.

Optional Extractors

Optional integrations are available through extras such as torch, keras, tensorflow, onnx, hf, timm, torchvision, openclip, tensorflow-hub, jax, trees, and graph:

• TorchExtractor
• KerasExtractor
• ONNXExtractor
• SentenceTransformerExtractor
• HFTextExtractor
• HFVisionExtractor
• HFAudioExtractor
• HFTimeSeriesExtractor
• HFVideoExtractor
• HFMultimodalExtractor
• TimmVisionExtractor
• TorchvisionVisionExtractor
• OpenCLIPExtractor
• SigLIPExtractor
• TFHubExtractor
• JAXFlaxExtractor
• TreeLeafEmbeddingExtractor
• GraphModelExtractor
• HostedEmbeddingExtractor
• CallableSpatialExtractor
• PrecomputedSpatialExtractor
• CallableStructuredExtractor
• PrecomputedStructuredExtractor

These workflows rely on optional dependencies and lazy imports, so the core package stays lightweight. See examples/onnx_extractor.py for a local ONNX export workflow. See examples/hf_vision_mnist.py for a laptop-friendly comparison that runs MNIST handwritten digit data through final and mid-layer Hugging Face vision embeddings, and examples/caltech101_vision_foundation_models.py for a single-label Caltech-101 workflow with automatic local data reuse/downloads and a less trivial default class slice. See examples/sklearn_wine_pipeline.py for a network-free real-data scikit-learn pipeline comparison. See docs/feature_extractors.md for the full extractor matrix and install mapping, docs/segmentation.md for dense spatial workflows, and docs/compression.md for compression options and guidance.

Command Line Interface

vertebrae includes a CLI for deterministic embedding shard planning and artifact merging in local or batch-style workflows. Distributed orchestration commands accept --backend local|ray|dask, with --ray-address and --dask-address available for cluster connections. Cloud artifact stores use the same --cache-dir flag, plus provider options such as --s3-endpoint-url, --s3-profile, --s3-region, and --gcs-project. The CLI can also derive compressed embedding artifacts with vertebrae compress, materialize structured unit artifacts with vertebrae materialize-structured, and evaluate importable custom metrics through repeatable vertebrae score --metric module:callable options. Run vertebrae --help to see the available commands.

Notes

• The package targets Python >=3.9,<3.15.
• The public API is centered on BenchmarkDataset, EmbeddingUnitDataset, SegmentationDataset, RetrievalDataset, ZeroShotDataset, Evaluator, Benchmark, RetrievalBenchmark, ZeroShotBenchmark, structured and spatial adapters, extractor wrappers, metric adapters, config dataclasses, and structured result objects.

License

The source code is licensed under the GNU Affero General Public License v3.0 or later (AGPLv3-or-later). Commercial licenses are available; please contact the maintainer through GitHub.
