Twitch VOD → Premiere Pipeline

Record a Twitch stream. Get back a Premiere-ready master, a proxy, and a word-timed transcript you can cut from.

Records Twitch streams live in chunks — or downloads a past VOD through the identical pipeline — and hands you everything you need to start editing:

• a Premiere-ready master, stream-copied from the broadcast so nothing is re-encoded;
• its proxy, named so Premiere's Attach Proxies finds it;
• a Static Transcript JSON with per-word timings, which is what turns on text-based editing;
• an editor report (report.md) of what happened, with timestamps, best moments, Shorts candidates, and chat-backed evidence of what landed;
• the Deepgram word stream the rest is derived from, and the verbatim API responses beside it;
• SRT captions and a plain-text transcript;
• a censor list of the terms from your master list that actually occur.

You can also pull any range out of a broadcast while it is still recording, and route everything through an HTTP/SOCKS proxy to reach Twitch from a region it has withdrawn from.

It records and it transcribes. It does not cut: no automatic edit, no decisions made on your behalf about what to remove. What it gives you is a clean master and a transcript good enough to cut from.

Requirements

Windows is the platform it is proven on against real recordings; macOS and Linux run the same pipeline and dashboard from a terminal, with the same test suite in CI. The desktop app window and Start Menu registration are Windows-only. python -m vodpipe doctor tells you what it can find and what is missing.

Contents

• Quick start · What lands on disk · Downloading a past VOD
• Getting it into Premiere — read this if a transcript "does not work"
• What you get, and what you do with it · How it works, and why
• Ads · Why a recording can be 720p · Recording from a withheld-source region
• Disk safety · Configuration · Tests · Layout
• Reliability behaviour · Known limits · Contributing · License

Quick start

From a clone — the full thing, including the desktop app:

vodpipe.cmd doctor          # check the environment
vodpipe.cmd install         # compile VODPipeline.exe and register it with Windows
vodpipe.cmd                 # open the desktop app (Chromium/Chrome window)

Or from PyPI, if you only want the recorder and the dashboard:

pip install vodpipe
vodpipe doctor
vodpipe dashboard

The wheel carries the pipeline and the dashboard, and no dependencies — there is nothing for pip to resolve. It does not carry packaging/, so vodpipe install has no host.cs to compile and says so; the Windows desktop app needs a clone. A pip install keeps its config.json, .work/ and logs/ in the per-user data directory (%LOCALAPPDATA%\vodpipe, ~/Library/Application Support/vodpipe, or ~/.local/share/vodpipe); a clone keeps them beside the code. VODPIPE_HOME overrides either.

On macOS or Linux, from a clone:

brew install ffmpeg streamlink        # or apt install ffmpeg && pipx install streamlink
python3 -m vodpipe doctor
python3 -m vodpipe dashboard          # opens the dashboard in your default browser

There is no app window there: python3 -m vodpipe app is the same as dashboard, and Ctrl+C stops it. Proxies use h264_videotoolbox on a Mac when proxies.encoder is auto, and libx264 anywhere without a hardware encoder ffmpeg can drive.

After install, Windows shows VOD Pipeline in the Start Menu and in Settings → Apps. Double-click VODPipeline.exe, or Start VOD Pipeline.vbs, for the same thing without a console. The window is Chromium or Google Chrome in app mode — never Edge.

vodpipe.cmd dashboard still runs the local web server only, if you want a browser tab instead of a window.

Then in the dashboard: paste your Deepgram key under Settings, add a channel, and either press Record or leave auto ticked so it starts on its own when that channel goes live. Refresh (R or F5) re-checks live status immediately rather than waiting for the watcher interval; the page itself does not reload.

To run it without a browser:

vodpipe.cmd record somechannel            # waits until the channel goes live
vodpipe.cmd record somechannel --now      # start this instant, live or not
vodpipe.cmd record somechannel --minutes 90
vodpipe.cmd vod https://www.twitch.tv/videos/123456789   # download a past VOD
vodpipe.cmd vod 123456789 --start 1:30:00 --duration 45:00   # just part of it
vodpipe.cmd sessions
vodpipe.cmd snapshot <session-id> --last 10
vodpipe.cmd transcribe "C:\path\to\any.mp4"
vodpipe.cmd republish <session-id>        # rebuild exports from the stored words

What lands on disk

Desktop\twitch-vods\<channel>\<session-id>\
  index.md                 ← start here: what to open, in the order you open it
  master\                  ← import this folder into Premiere
    <channel>_<session>_c000.mp4          ← the untouched recording
    Proxies\
      <channel>_<session>_c000_Proxy.mp4  ← auto-deleted after 1 day
  transcripts\
    c000\                  ← only the four things you actually open
      report.md            ← editor report: read this first
                             (timeline, best moments, Shorts, titles)
      premiere.json        ← Static Transcript, enables text-based editing
      transcript.srt       ← captions
      censor-words.txt     ← terms from your master list that actually occur
      source\              ← what the pipeline reads and you rarely do
        words.json         ← the word stream every export is rebuilt from
        transcript.json    ← segments + words, for anything you build yourself
        transcript.txt     ← timestamped plain text
        chat.json          ← Twitch chat for this chunk (live IRC or VOD comments)
        chat.txt           ← the same, readable
        moments.json       ← content-aware chat peaks (laugh / hype / clip-call)
        exports.json       ← which generation the files beside it belong to
        deepgram\          ← the provider's verbatim responses, one per request
          0001.json  0002.json  ...
  snapshots\
    <channel>_<session>_snap_..._001432.mp4
    snapshots.json
  live\                    ← working .ts files, removed once remuxed
  logs\
  session.json             ← machine-readable state

The split is by how often you open a file, not by what kind of file it is. A folder is browsed, not searched, so everything sitting in a chunk folder competes for attention with premiere.json — the one file that has to be easy to find. The four at the top are the ones an edit actually starts from; source/ holds the plumbing, which is there so a transcript can be rebuilt or checked, not so you can read it.

Both halves are written by a single transaction, so they can never disagree: a crash mid-publish cannot leave a premiere.json describing words that source/words.json no longer contains.

Masters stay until you delete them. Proxies self-clean after proxies.retention_days.

Downloading a past VOD

A Twitch VOD goes through the exact same pipeline as a live recording. streamlink pipes the archived video into the same ffmpeg segmenter, so you get keyframe-aligned masters, auto-attached proxies, per-chunk word-timed premiere.json transcripts, censor lists and objective rundowns — identical Premiere-ready output, from an archive instead of a live edge.

From the dashboard: paste a VOD URL (or its numeric id) into Download a VOD and press Download. It appears in Recording now with a VOD badge while it downloads and then drops into Sessions like any other recording; you can even snapshot a range out of it while it is still downloading.

From the command line:

vodpipe.cmd vod https://www.twitch.tv/videos/123456789
vodpipe.cmd vod 123456789                       # a bare id works too
vodpipe.cmd vod 123456789 --start 1:30:00 --duration 45:00

--start and --duration accept seconds or an HH:MM:SS clock and fetch only that slice of a long VOD (streamlink's --hls-start-offset / --hls-duration). Leave them off for the whole thing.

The broadcaster's name is read from the VOD's own metadata, so the session lands under that channel's folder beside its live recordings; if the name can't be resolved it falls back to vod_<id>. Downloads run on their own lock (vod-<id>), so a VOD download and a live recording of the same channel — or two different VODs — can run at once, and the same VOD cannot be downloaded twice concurrently. A VOD that Twitch will not serve (deleted, subscriber-only, or geo-blocked with no proxy set) is refused up front rather than left as an empty session; set network.proxy for the geo-blocked case (see Recording from a withheld-source region).

Getting it into Premiere

Masters and proxies. Import the master folder. Then select the clips → right-click → Proxy → Attach Proxies…. Proxies are written as <mastername>_Proxy.mp4 inside a Proxies subfolder, which is Adobe's own naming convention, so the attach dialog matches them automatically.

There is no .epr ingest preset in this repo. Adobe's .epr is an opaque binary format that cannot be reliably synthesised, so the pipeline satisfies the same goal the honest way — by writing proxies that Premiere's built-in Attach Proxies already recognises. If you would rather have Premiere generate them on ingest, point its ingest preset at the master folder and turn proxies.enabled off.

Text-based editing. Each chunk's transcript lives in transcripts/c00N/ beside the master of the same number.

Double-click the master in the Project panel so it opens in the Source Monitor, then Window > Text → Transcript tab → ... menu → Import > Import Static Transcript and choose that chunk's premiere.json.

The Source Monitor step is the one that matters. Premiere binds an imported transcript to whatever is loaded there. Import it with a sequence active, or against the clip instance already sitting in a timeline, and you get a transcript that is not attached to any clip — it reads fine, it filters fine, and text-based editing has nothing to cut, because as far as Premiere is concerned the words and the footage are unrelated objects. The file is identical in both cases and Premiere does not say which happened. If a transcript feels disconnected from its clip, this is why: undo the import, load the master in the Source Monitor, and import again.

An SRT gives you captions but not text-based editing — that is why premiere.json exists and why every word carries its own start and duration.

Put the clip in a sequence before you try to delete anything. Importing the transcript against a clip in the Source Monitor gives you a readable, searchable, filterable transcript — but Delete, Extract and Lift stay greyed out, because those operations remove frames from a sequence and a source clip has no sequence to remove them from. Drag the master to a timeline, select the clip, and work from the Transcript panel with that sequence active. This catches everyone once; it is a property of Premiere, not of the file.

Filler words are transcribed, not tagged. Every "uh" and "um" appears in the transcript as an ordinary word, so the text matches the audio and a cut made from it lands where you expect. Select one and delete it like any other word.

Premiere's delete all fillers is not supported, deliberately. This pipeline used to write Adobe's filler tag onto the words it was confident about. Premiere ignored them — the Filter menu reported "no filler words detected" against files carrying hundreds of tags — and the feature was removed on 2026-08-17 rather than left in as something that looks configured and does nothing. Bulk deletion was the wrong shape for this footage anyway: it cuts on word boundaries, which is audible on a hesitation that runs into the next word, and one wrong call in a thousand silently removes real speech. Filler removal is a manual edit; the transcript's job is to make each one easy to find, which a verbatim transcript does.

Turn transcription.filler_words off if you would rather have clean reading copy than a verbatim transcript. That one is a Deepgram request parameter, so changing it does require re-transcribing — Deepgram was previously told not to write those sounds down.

Censoring. Premiere censors from a word list you supply; nothing inside the transcript file drives it. Open censor-words.txt, copy the terms, and paste them into Text panel → Transcript → Filter → Censored words. The file only lists terms from your master list that were actually spoken in that chunk, so it stays short.

What you get, and what you do with it

Everything below lands per chunk, in transcripts/<chunk>/. Nothing here is a judgement about your footage — that is the point.

In the chunk folder — the four you open:

In source/ — what the pipeline reads:

You never have to go into source/ to edit. It is there so a transcript can be rebuilt, checked against what the provider actually returned, or read a different way later.

Why both words.json and deepgram/

words.json is the stream everything else is built on, and it is normalised: sorted, de-overlapped, and with same-start collisions resolved by dropping one of the pair. Downstream that is exactly what you want — but it means the file is not quite what Deepgram said.

deepgram/ keeps what Deepgram said, one file per request, before anything was made of it. It answers the question the normalised file cannot: did we lose that word, or was it never there? It also lets a future reading of the same responses be built without paying for the audio again. About 15 KB per request, so roughly 1.5 MB for a two-hour chunk; turn it off with transcription.keep_raw_responses if you would rather not have it.

There is no automatic edit

An earlier version of this tool cut a second copy of every chunk with the silences, fillers and false starts removed. It worked — measured on a real chunk it took 58:52 down to 46:15, it never clipped a word, and its joins did not click. It was removed deliberately, and the reasoning is worth keeping:

• an automatic cut has to be checked, and checking a 46-minute file means watching it;
• the cost is real and permanent — forty minutes of encoding and several gigabytes per chunk, for a derivative one generation removed from a stream copy;
• and the thing it saves you is the easy part. Finding the dead air is not what makes editing slow.

What survives is the part that was actually useful: a verbatim transcript, with the hesitations in it, timed to the word, so a cut you make lands where you expect it to. If you want an automatic cut, that lives in a separate, unpublished tool — this same pipeline with the cut still in it, decided by a language model. It is not part of this project and is not on the roadmap for it.

How it works, and why

Recording. streamlink writes the live stream to stdout; ffmpeg's segment muxer stream-copies it into chunks. No re-encode, so CPU stays free and quality is whatever Twitch sent.

Record means "record when there is something to record". Pressing Record on a channel that is live starts immediately. On a channel that is not, it arms the channel instead — nothing is launched, no session directory is claimed, no lock is taken — and the watcher starts the real recording on the pass that first sees it live. The row shows an amber dot and Cancel until then.

This matters because streamlink is configured to retry forever, which is right once a stream exists (a broadcast that drops for a minute is waited out) and wrong at the very start. Previously, Record on an offline channel produced a session sitting at recording with an empty chunk for as long as the app ran, and the dashboard reported it as recording, because as far as the pipeline was concerned it was.

Arming outranks the per-channel auto setting — it is an explicit instruction given after that setting was chosen — and armed channels are probed even with the watcher switched off, and even if they were never added to the watch list. A request that fails to start for a transient reason (a momentary disk dip) stays armed and is retried.

There is a backstop for the case where the live check was simply wrong: if not one byte of video arrives within recording.startup_timeout_seconds (default 120), the attempt is abandoned and says so. Only zero bytes counts — once anything has been written the stream existed, and from then on retrying is exactly the behaviour we want.

On the command line, vodpipe.cmd record <channel> waits the same way; pass --now to start immediately regardless.

Chunks land on keyframes. The segment muxer cannot cut a copied stream mid-GOP, so it rolls forward to the next keyframe. Every master therefore starts on a keyframe — there is a test asserting exactly this.

Chunks are recorded as MPEG-TS, then remuxed to MP4. This is the decision the whole design hangs on. An MP4 has no index until it is closed, so a live MP4 is unreadable — you could not transcribe it, and you could not cut a snapshot out of it. MPEG-TS is readable while it is still being appended to. When a chunk closes it is remuxed (container rewrite only, no re-encode) into an MP4 that Premiere is happy with, and the .ts is reclaimed.

Transcription runs during the recording, not after it. Audio is sliced out of the growing .ts every few minutes and sent to Deepgram, which returns word-level timings natively. That is what removes the forced-alignment stage the old C# tool needed, and it is why exports land about a minute after a chunk closes instead of six.

Slice seams. Consecutive slices deliberately overlap by a few seconds, so a word straddling the boundary is heard whole by at least one of them. The two streams are then joined at the earliest point in the overlap where neither has a word in flight. Earliest rather than widest, deliberately: everything after the seam comes from the newer slice, and the newer slice is the better one throughout the overlap because the older one had its audio truncated at that very point — its last word is often clipped (wor for world). Cutting as early as is safe hands the whole contested region to the transcription that actually heard all of it.

Chunk seams need a different answer. Two chunks are two separate files transcribed independently, so overlapping slices cannot help: a word spoken across the join is heard by neither side in full, and comes out as wor at the end of one and ld at the start of the next — or vanishes from both. When a chunk closes, the pipeline transcribes a short passage (default 6s either side) built from the tail of the previous file and the head of the new one, and hands each word to whichever chunk it was mostly spoken in. That gives one deterministic owner per word, so a straddling word appears once, whole, and never twice. Anything within a fraction of a second of the join is replaced by that reading; anything further in that the seam pass did not cover is left exactly as it was, because ASR is not deterministic and a second pass failing to repeat a word is not evidence the word was never said. A seam pass that returns nothing changes nothing. Cost is one extra short request per chunk boundary, and it can be turned off in Settings.

One consequence worth knowing: the previous chunk's rundown.md is not regenerated afterwards. It was written from a transcript that differs by at most a word at the very end, and rewriting rundowns hours after the fact would cost far more than that is worth.

Snapshots are non-destructive. The recorder's ffmpeg keeps writing untouched; the snapshot only ever opens that file for reading. A range that crosses a chunk boundary is cut from both files and joined, so "the last 20 minutes" works even when the current chunk is two minutes old. Copy mode returns in seconds but can only start on a keyframe (≈2s of lead-in on Twitch); tick frame-exact to re-encode for a precise start.

The range has to be covered end to end before anything is cut — a session missing a chunk in the middle is refused with the gap named, rather than quietly producing a shorter file that jumps. The duration reported afterwards is probed from the finished file, not echoed back from the request, so a short export is visible instead of hidden. Cuts are queued on their own worker pool and the dashboard answers 202 Accepted immediately; while one is reading a .ts, the remux that would normally reclaim that file waits for it to finish.

Work is scheduled in three pools, not one queue. Rolling transcription, chunk finalisation and remuxes are capture-critical and get their own workers. Proxy transcodes and rundowns are heavy but disposable and get another. Snapshots are user-initiated and get a third. With a single FIFO, a quarter-hour claude -p call could sit in front of the transcript slice for a channel that was still recording.

Proxies are hardware-encoded via h264_amf on an AMD GPU when one is available — verified by actually encoding two seconds of test pattern, because a build listing an encoder does not prove the GPU accepts it — and fall back to libx264 otherwise.

Reports run through Claude Code (claude -p) or Grok Build (grok -p) — see below.

Chat is captured for live broadcasts over IRC and for VODs through the same GraphQL comments API TwitchDownloader uses. Per-chunk source/chat.json plus a content-aware moment analysis (laugh emotes, copypasta, clip-calls — not just chat speed) are handed to the report engine. A chat failure never fails a recording.

Report engine

A report is one background call per chunk. Two engines, both local subscription CLIs:

summary.model is passed through as the model flag. Leave it blank: Claude Code picks from the subscription; Grok uses its CLI default, which is currently Grok 4.6 (reported in usage as grok-4.6-build). The old alias grok-build is not a valid model id on Grok CLI and is rewritten to blank on load.

The two engines are asked in different shapes, because they are different things. Claude Code is a completion: the transcript arrives on stdin, tools are off, and the report is what it writes to stdout. Grok Build is an agent, and asking it as though it were a completion does not work — above roughly 24 KB the CLI does not put a --prompt-file in the conversation at all. It offloads the prompt to a file and hands the model a stub to read its way out of, so a two-hour transcript can only be answered by a model that is allowed to read a file and given the turns to do it. So Grok is handed a throwaway working directory containing transcript.md, an instruction small enough to arrive inline, and exactly four tools (read_file, list_dir, grep, write); it writes report.md and the pipeline reads that file back. summary.max_turns (default 40) bounds the loop; the reference two-hour chunk uses eight turns.

A failed attempt is retried up to summary.max_retries times (default 3), all attempts sharing the one summary.timeout_seconds deadline — a non-zero exit is not classifiable from outside, so the retry is unconditional and bounded.

Why Grok gets a file instead of stdout. Its headless mode prints every assistant message, so stdout is the model's narration (“I'll start by reading the transcript…”) run together with the answer. Reading the report back from the file the model was told to write is the only way to get the report without the process notes welded onto the front. See models.GrokCliModel for the recording that established this.

Paid HTTP APIs were tried and withdrawn. On 2026-08-18 a seven-hour recording hit You’ve hit your session limit and lost that chunk’s report, so the engine was made pluggable across the Anthropic, Kimi, DeepSeek and OpenAI APIs. The paid APIs then failed on the ordinary case, twice in one night: Kimi refused one report for exceeding an organization concurrency of one — against a pipeline whose whole shape is background jobs — and refused the next as high risk content, having been handed a Twitch transcript. They were removed on 2026-08-19. A fallback that fails on the ordinary case is not a fallback. grok-cli is a second subscription CLI, the same shape as claude-cli, not a paid HTTP API.

If your config.json still names one of the removed APIs, it is rewritten to claude-cli on load rather than refused, and the API keys beside it are dropped from the file on the next save.

Ads

Twitch Turbo + an OAuth token is the mechanism. Paste the token into Settings and it is passed as --twitch-api-header=Authorization=OAuth <token>. Turbo covers every channel, which matters because the channel list is arbitrary.

Nothing is ever cut out of your recording to remove ads. That is deliberate, and it is worth explaining because an earlier version of this pipeline got it wrong.

streamlink's Twitch plugin already filters ad segments out of the stream before it reaches us — TwitchHLSStreamWriter.should_filter_segment() returns segment.ad, so ad segments are dropped, not forwarded. Ad content is therefore not present in the file we record, and no interval of that file corresponds to an ad. An earlier build watched streamlink's log for ad messages and cut the matching time ranges out of transcripts and masters. Two things made that actively harmful:

• There was nothing there to cut, so every "ad range" removed real content.
• "Will skip ad segments" is logged unconditionally when the HLS reader starts, for every stream. Matching it opened a phantom ad range at the top of every recording.

So ad log lines are now recorded as operational metadata only — you can see them in session.json and index.md with an approximate broadcast position, and they influence nothing. There is no ad-free master output and no transcription exclusion, and tests/test_ads.py exists specifically to stop that mapping being reintroduced.

If a Turbo-less recording does contain ad content, cut it in Premiere. A correct automated version of this would need to identify ads from the recorded packets themselves, not from log lines about segments that were already discarded.

Why a recording can be 720p

This one cost four two-hour masters before it was noticed, so it is documented in full.

A session recorded on 2026-08-13 from a large English-language channel produced four chunks at 1280×720. The pipeline was configured with quality: "best" and did exactly the right thing — the ladder Twitch served simply had nothing better on it. From the session's own logs/streamlink.log:

[cli][info] Available streams: audio_only, 160p (worst), 360p, 480p, 720p60 (best)
[cli][info] Opening stream: 720p60 (hls)

The cause is the connection's country. Fetching the raw Usher master playlist directly on 2026-08-14 showed that every variant Twitch offered, on every channel tested, was marked IVS-VARIANT-SOURCE="transcode" — the broadcaster's own full-quality source rendition was never offered at all. The same playlist carried USER-COUNTRY="KR". Connecting from Japan through a VPN restores the source rendition, and with it 1080p60 source quality. That was confirmed directly.

With source withheld, all that remains is the channel's transcode ladder, and which stack a channel is on then decides the ceiling:

That second row is why the cap is easy to misdiagnose: some channels do reach 1080p60 from an affected region, so a spot check on the wrong channel suggests everything is fine.

Things that were tested and made no difference:

• --twitch-supported-codecs h264,h265,av1 — identical ladder, so this is not Twitch's HEVC/AV1 enhanced-broadcasting tiers being filtered out.
• --twitch-force-client-integrity — identical ladder.
• Subscriber-gated quality — streamlink logs "requires a subscription" when that is the cause, and that warning appears nowhere in 43,000 lines of the session log.
• Being a RERUN. Twitch does cap reruns, but these were genuine live broadcasts.

So: to record at source quality from an affected region, route Twitch through another one — either a full VPN or the built-in network.proxy setting (an HTTP/SOCKS proxy applied to every streamlink call; see Recording from a withheld-source region). A Twitch OAuth token is still worth setting for ad avoidance, but it is not what gates resolution.

What the pipeline does about it now. It can't raise a ceiling Twitch imposes, but it will never let one pass silently again:

• Both streamlink lines are parsed and stored on the session as quality_selected and quality_available, so any recording can be explained afterwards from session.json.
• Each chunk records the measured width/height read back off the finished master, which is ground truth rather than a rendition name.
• recording.min_height (default 1080) is the resolution you expect. A capture below it raises a warning on the session — shown on the dashboard row without expanding it, and at the top of index.md.
• That warning distinguishes the two causes, because they need different responses: "Twitch offered nothing better" (no setting can help) versus "720p60 taken but 1080p60 was available" (a real defect — check recording.quality).
• recording.on_low_quality is warn by default. Set it to refuse to abort instead; warn is the default because a 720p capture of a one-time broadcast beats no capture.
• recording.quality accepts a streamlink fallback chain, e.g. 1080p60,best.

Recording from a withheld-source region

Twitch withholds the source rendition from IPs in some countries it no longer operates in. South Korea, which it left in February 2024, is the documented case, and the one the evidence below was gathered from. From such an IP the best you can record is whatever transcode the channel happens to have — 720p60 on many large channels. The full evidence is in "Why a recording can be 720p" above. There are two ways to get back to source quality, and both work for live capture and VOD downloads:

A network proxy (network.proxy) — the light-weight option. Set an HTTP or SOCKS proxy in Settings (or config.json) and every streamlink request — live capture, VOD download, and the live-status probe — is routed through it, so only Twitch traffic leaves the country and the rest of the machine stays on its normal connection. It accepts http(s):// and socks4/4a/5/5h:// URLs, e.g.:

socks5://127.0.0.1:1080          # e.g. an SSH dynamic tunnel: ssh -D 1080 user@jp-host
http://user:pass@proxy.example:3128

Prefer socks5h:// for a SOCKS proxy so DNS is resolved on the proxy side too. vodpipe.cmd doctor prints whether a proxy is configured. A proxy endpoint that cannot sustain the throughput below shows up as buffering, not an error.

A full VPN — the heavy option. A VPN endpoint in an unaffected region (Japan was the one tested, on 2026-08-14) restores source quality at 1080p60. It routes the whole machine and needs no pipeline setting.

An earlier version of this file claimed capture worked at full quality from an affected region without either. It does not. That conclusion came from spot-checking channels that happened to have a 1080p60 transcode, which masked the missing source rendition.

Everything else is geography-neutral: Deepgram is reachable globally, claude -p runs locally against your subscription, and the dashboard is loopback-only. Two things to keep in mind when recording over a VPN:

• Throughput matters. Source 1080p60 is roughly 7 GB/hr sustained. A VPN endpoint that cannot hold that will show up as buffering and dropped segments, not as an error.
• A VPN drop is survivable. streamlink is configured to retry indefinitely (--retry-streams 5 --retry-max 0), so a brief reconnection is waited out rather than ending the session. The startup watchdog only fires when zero bytes have ever arrived, so it will not kill a recording that has already started.

Twitch Turbo remains the pipeline's only ad avoidance, and a billing address in a region Twitch has withdrawn from may affect buying it. That costs coverage at ad breaks, not resolution. See the Ads section.

Re-check with streamlink https://twitch.tv/<a live channel> if Twitch's regional behaviour changes; look at whether the ladder reaches source quality, not just at whether it reaches 1080p.

Disk safety

One drive, no second disk, so there are two guards:

• Free-space floor (default 50 GB): a new chunk will not open below it. The session ends cleanly at the current chunk boundary instead.
• Hard reserve (default 10 GB): crossing this aborts mid-chunk, because a disk that fills while ffmpeg is writing costs the whole chunk rather than the tail of it.

At roughly 7 GB/hr for 1080p60, the default floor leaves about 7 hours of headroom.

Configuration

Everything lives in config.json — next to the app in a clone, in the per-user data directory for a pip install (see Quick start) — gitignored, created on first save. config.example.json documents the common keys; the full set of defaults, with comments, is in vodpipe/config.py.

Secrets resolve config first, then environment (DEEPGRAM_API_KEY, TWITCH_OAUTH_TOKEN), so a shell export works too.

The validator is total and transactional — a rejected save changes nothing — and it is strict about unknown keys, so a typo is refused rather than silently ignored. The one exception is a retired key: edit.* settings written by the build that had the automatic cut are dropped on load rather than refused, so switching to this build does not leave you with an application that will not start on its own settings file. They are gone from the file after the next save.

Tests

python -m unittest discover -s tests -t .

Most are instant; the integration tests run the real pipeline against a synthetic stream — a local ffmpeg process stands in for streamlink and emits MPEG-TS on stdout, which is byte-for-byte what the recorder consumes in production. The VOD end-to-end test drives download_vod through the same synthetic stream. No API key and no network access are needed anywhere in the suite.

Layout

Reliability behaviour

What happens when things go wrong, since a recorder is judged on its bad days:

• Stopping kills streamlink only, so ffmpeg reads EOF and finalises the chunk it is on. The final tail and its true duration survive. Ctrl+C on the dashboard exits through normal control flow and drains queued work before the process ends. Stopping a channel that is merely armed cancels the pending request instead.
• A recording only ever starts against a live channel, and abandons the attempt if no video arrives at all. A session at recording means video is being written.
• Stopping is not a failure. Terminating streamlink closes the pipe under ffmpeg mid-packet, so ffmpeg exits AVERROR_INVALIDDATA. That is the consequence of stopping, not a bad recording, and it is no longer folded into the session status — every hand-stopped session used to be marked failed while holding complete, validated masters. An ffmpeg exit nobody asked for is still surfaced, and per-chunk failures are recorded against the chunk either way.
• A transcript is only marked complete once its coverage reaches the chunk's duration. Falling behind — an API outage, a late key, queue congestion — leaves it explicitly incomplete rather than published as finished. Catch-up is bounded and stops the moment a pass fails to advance.
• A .ts is deleted only after its MP4 is read from end to end. The header check — readable video stream, plausible duration, matching stream inventory — is not enough on its own: on 2026-08-18 two masters passed it while carrying a single wrong byte in their index, one silently truncating playback to 44% of the file and the other misaddressing every sample after a certain point. Both looked perfect to ffprobe's summary, and both had their .ts deleted. So before a master is published, its packets are counted: it must read without ffmpeg reporting a single error, and its video must deliver as many frames as the file itself claims to hold. One full pass, 3–14s for a two-hour chunk here against a 30–40s remux, and it is the only check that can see this. recording.verify_master turns it off; if you do that, turn on recording.keep_ts_after_remux.
• A failed remux is tried again (recording.remux_attempts, default 3). A remux is deterministic work over bytes already on disk, so a failure is either permanent — and costs a bounded couple of minutes to confirm — or a one-off. A one-off used to cost the master permanently: one chunk of that same recording died on an ffmpeg assertion, and re-running the identical command over the identical bytes afterwards produced a perfect master.
• A short proxy names the master, not the encoder. If an encode stops early, the master is read through before anything is blamed. Both proxies of a damaged master used to be reported as "h264_amf failed on real media", fall back to libx264, and spend another five minutes proving software could not read the file either — an encoder cannot encode frames its input will not hand over.
• Masters are stream-copy H.264 with explicit stream mapping. A non-H.264 source is refused rather than silently re-encoded or dropped, and extra audio tracks are carried through instead of being lost to ffmpeg's default selection.
• Publishing a transcript replaces the whole set. If a re-transcription legitimately comes back empty, the previous premiere.json, .srt and censor list are removed rather than left for Premiere to import. If it fails, nothing is touched: the words file is restored from its stash and the exports are rebuilt from it, so a failed attempt costs you nothing.
• A transcript that could not be read back is never written. words.json is checked against its own reader before it is serialised, so a publish that would produce a file nothing can load fails instead — leaving the previous outputs in place. A file that will not load is worse than a failed publish: recovery and retranscribe both read it, and neither can do anything with a file that will not parse.
• A rundown does not outlive the transcript it describes. If the transcript no longer has enough speech to summarise, the stale rundown.md goes with it. Turning summaries off does not delete work already done — that is a different thing entirely.
• A rundown gets more than one attempt. summary.max_retries (default 3, all attempts sharing summary.timeout_seconds) applies to both engines. claude -p runs against your Claude subscription and therefore shares its usage limits, so a busy recording day can produce a transient refusal; one of those should not be the end of the rundown. If every attempt fails, the error shown is whatever the engine actually said, on stdout or stderr — and for grok -p, why it stopped (stopReason) as well.
• A report queued for a stitched chunk waits for its chat. Stitching a chunk boundary changes the transcript generation of both chunks it touches, which makes the older report stale. The re-queue goes through the same chat gate as ordinary finalisation, so a chunk whose chat is still downloading is not reported twice — once without the audience and again with it.
• A network stall does not kill the recording. Only video and audio are captured. Twitch also sends a timed_id3 metadata stream whose timestamps are not corrected across an HLS sequence gap; copying it meant one dropped connection could abort ffmpeg mid-recording. It was discarded at remux anyway, so nothing is lost by never taking it. Corrupt input packets are dropped rather than treated as fatal.
• The app icon has one source. docs/logo.png is the only icon anyone edits. python packaging/prebuild.py regenerates the .ico, the PNGs and the dashboard favicon from it, and stamps the source's digest beside them so the test suite fails if they fall behind. It runs automatically before every vodpipe install, which also rebuilds the host whenever the icon (or the manifest, or the version) has changed and tells Windows to drop its cached icon afterwards.
• Restarting reconciles what is on disk. Interrupted recordings get remuxed, stale .partial files are removed, invalid masters are rebuilt, and a second restart does nothing further.
• Disk guards: no new chunk below the floor, session aborts below the hard reserve, and proxy/remux work is refused rather than filling the drive under a live recording.
• One recorder per channel, enforced in-process and by a lock file across processes.

Known limits

• No automated ad removal. See the Ads section — that is a deliberate correction, not an omission.
• Copy-mode snapshots start on a keyframe, so expect up to ~2s of lead-in unless you tick frame-exact (which re-encodes and is slower). The reported duration is the file's, so it will read slightly longer than the range you asked for.
• Chunk-boundary repair costs one extra ASR request per boundary and runs after the new chunk's transcript is complete. The previous chunk's rundown is not regenerated for it.
• Adobe's transcript language list is a closed enum of 29 codes. A regional variant it does not list resolves to the same language (fr-ca → fr-fr, en-au → en-gb); a language it does not support at all is written ??-??, Adobe's own value for "unknown", rather than being relabelled en-us. Premiere will not offer text-based editing for a ??-?? transcript — that is preferable to claiming English speech that is not English.
• Fillers are transcribed but never tagged, so Premiere's delete all fillers finds nothing. Premiere ignored the tags when they were written; see the Premiere section.
• Nothing is cut for you. No silence removal, no filler removal, no censoring of the media — the censor list is a list, and Premiere does the censoring. This build produces a master and the material to edit it with, and stops there.
• The rundown is only as good as the transcript. Crosstalk, music and heavy accents all degrade it, and the prompt instructs the model to say so rather than guess.
• claude -p shares your subscription usage limits.
• No .epr proxy ingest preset is shipped — see the Premiere section for why and for what is shipped instead.
• The dashboard has no authentication and therefore refuses to bind anywhere but loopback. It checks Origin/Host and requires JSON content type, which stops a malicious web page driving it, but anyone with an account on this machine can use it.
• On macOS and Linux there is no desktop app: the dashboard runs in a terminal and opens in your browser. "Show in folder" uses Finder or xdg-open; the latter cannot select a file, so it opens the folder instead. Real recordings have only been run on Windows.

Contributing

Contributions are welcome. Start with CONTRIBUTING.md — it covers the setup (there is almost none), how to run the suite, and the three failure modes this codebase actually has.

Two documents are worth reading before proposing a change:

• CLAUDE.md is the project's engineering memory. Every non-obvious decision is recorded there with the failure that caused it, including several features that were built and then deliberately removed. Most "obvious improvements" have already been tried and are written up with the reason they were reverted.
• docs/DESIGN.md is the dashboard's design system. The palette is contrast-tested in CI, so a colour picked by eye will fail the suite.

Please report security issues privately — see SECURITY.md. By taking part you agree to the Code of Conduct.

Releases

Every release attaches the compiled VODPipeline.exe, an sdist, a wheel and a SHA256SUMS.txt, all built by the release workflow from the tagged commit rather than uploaded by hand — see the latest release and CHANGELOG.md.

The same wheel and sdist go to PyPI as vodpipe, published by a workflow over PyPI's Trusted Publishing — no API token is stored in this repository.

The executable is an unsigned .NET Framework 4 host, so Windows SmartScreen warns on first run. You can compile it yourself with packaging\build.cmd — that is exactly what the workflow does.

License

MIT. Use it, change it, ship it.

This project drives ffmpeg, streamlink and Deepgram; each carries its own licence and terms, and recording a broadcast is your responsibility under Twitch's terms and the law where you are.
