Waveframe Guard

Stop unsafe AI and automated actions before they execute.

Waveframe Guard is an execution-boundary SDK. It wraps sensitive actions, resolves compiled authority, evaluates through CRI-CORE, and only runs the action when the outcome is allowed.

Current release: 0.16.1.

Guard does not generate actions.
Guard does not author governance.
Guard does not replace Cloud.
Guard decides whether this action may run now.

Install

pip install waveframe-guard==0.16.1

No Ollama installation or Waveframe repository checkout is required. Keep the customer's existing model, agent framework, and tool functions; Guard wraps the tool that can cause a real-world change.

30-second integration

With the Cloud environment variables from the next section configured, wrap an existing Python function directly:

import os
from waveframe_guard import Guard

guard = Guard.cloud(
    authority=os.environ["WAVEFRAME_AUTHORITY_REF"],
    runtime_id=os.environ["WAVEFRAME_RUNTIME_ID"],
    environment=os.environ["WAVEFRAME_RUNTIME_ENVIRONMENT"],
    actor_identity={
        "id": os.environ["WAVEFRAME_ACTOR_ID"],
        "type": "agent",
        "role": os.environ["WAVEFRAME_ACTOR_ROLE"],
    },
)

guarded_allocate = guard.tool(
    action="allocate_budget",
    target="account_id",
    include_arguments=("amount",),
)(your_existing_allocate_budget)

Call or register guarded_allocate wherever the original function was used. Guard evaluates immediately before the existing mutation and remains separate from model calls and agent orchestration.

Five-minute Cloud quickstart

Start in an empty directory. No Ollama installation or Waveframe repository checkout is involved:

mkdir guard-quickstart
cd guard-quickstart
python -m venv .venv
.\.venv\Scripts\Activate.ps1
python -m pip install waveframe-guard==0.16.1
Invoke-WebRequest https://raw.githubusercontent.com/Waveframe-Labs/Waveframe-Guard/main/examples/external_agent_quickstart.py -OutFile quickstart.py

The example expects an active published authority that allows a 500-unit allocate_budget action for the configured actor role and requires missing approval evidence at 10,000 units or above. Configure the runtime credential, runtime identity, actor identity, and exact authority reference:

$env:WAVEFRAME_CLOUD_URL="https://cloud.waveframelabs.com"
$env:WAVEFRAME_CLOUD_ORGANIZATION_ID="acme"
$env:WAVEFRAME_CLOUD_API_KEY="<runtime credential>"
$env:WAVEFRAME_RUNTIME_ID="budget-agent-runtime"
$env:WAVEFRAME_RUNTIME_ENVIRONMENT="development"
$env:WAVEFRAME_ACTOR_ID="budget-agent"
$env:WAVEFRAME_ACTOR_ROLE="allocator"
$env:WAVEFRAME_AUTHORITY_REF="budget-quickstart@1.0.0"
python quickstart.py

Expected terminal proof:

runtime_id=budget-agent-runtime
actor_id=budget-agent
authority_ref=budget-quickstart@1.0.0
allowed_decision=allowed
blocked_decision=blocked
mutation_count=1
exactly_once=True
allowed_package_id=<Cloud package identifier>
allowed_receipt_id=<Cloud receipt identifier>
allowed_proof_sha256=<Cloud proof digest>
blocked_package_id=<Cloud package identifier>
blocked_receipt_id=<Cloud receipt identifier>
blocked_proof_sha256=<Cloud proof digest>

The allowed callback mutates once. The blocked callback never runs. Open Console Activity or Executions to verify both decisions under the same runtime, actor, and bound authority.

The integration inside the quickstart is the same wrapper used around an existing agent tool:

from waveframe_guard import Guard

guard = Guard.cloud(
    authority="repository-change-policy@1.0.0",
    environment="production",
    actor_identity={
        "id": "release-agent",
        "type": "agent",
        "role": "repository-maintainer",
    },
)

@guard.tool(
    action="allocate_budget",
    target="account_id",
    include_arguments=("amount",),
    agent={"framework": "custom-python"},
)
def allocate_budget(account_id: str, amount: int):
    return your_existing_mutation(account_id, amount)

The three choices are intentionally independent:

• actor_identity identifies the agent or human attempting the action.
• authority selects the explicit, versioned policy Guard will enforce.
• agent records optional framework and model metadata for Console and audit evidence.

Guard.cloud(...) can retrieve one atomic Ledger v2 publication from GET /v1/authorities/{authority_ref}/publication, validate its cloud_authority_publication.v1 envelope, and verify it before enforcing any action. The response binds the bundle, receipt, logical references, registry, and envelope as one tenant-scoped publication. Existing organization/API-key authentication is unchanged. Legacy v1 authorities retain their existing contract endpoint through a narrow publication-not-found fallback; a contract-only v2 response still fails closed. Guard uses runtime_id= when provided and otherwise uses actor_identity["id"] as the runtime identity. Guard registers that runtime, sends its first heartbeat, and exposes the observational result as guard.runtime_connection. Guard still evaluates locally before calling the wrapped function. Afterward, it preserves the decision and attests whether the wrapped callback executed, failed, or did not run.

The runtime credential may be passed explicitly as Guard.cloud(cloud_url=..., runtime_credential=..., authority=...); the existing cloud_api_key= argument and WAVEFRAME_CLOUD_API_KEY environment variable remain supported. Organization and runtime identity configuration are unchanged.

Application code supplies no runtime facts, hashes, bundles, or Ledger validator calls. A cold resolution performs one publication request and the complete verification chain. Warm evaluation performs no additional request and no heavy Ledger validation. Existing v1, finance, local-resolver, and Guard 0.16 behavior remains compatible.

Long-running processes may call guard.heartbeat() from their existing health loop. Cloud reporting failures are returned as structured status and never change Guard's local decision or cause an allowed callback to run twice.

Evidence preservation uses a 10-second timeout by default. Configure it only when needed: Guard.cloud(..., preservation_timeout_seconds=15.0). Guard never retries an ambiguous preservation write automatically, because Cloud may already have committed the immutable evidence.

Tool arguments are excluded from preserved evidence by default. Add only safe, decision-relevant names to include_arguments; prompts, tokens, file contents, and other sensitive values should remain excluded.

By default, an allowed tool returns the wrapped function's original value and a blocked tool raises, which fits normal agent framework tool registration. Set return_result=True with raise_on_block=False when an integration needs the same structured Guard envelope for both decisions.

Works with existing agents

@guard.tool(...) is framework-neutral. It wraps an ordinary Python callable, so the model may be hosted or local and the orchestration layer may be a custom agent, LangGraph, CrewAI, an OpenAI tool loop, or another framework. Guard does not generate the tool call and does not require the model to emit Guard-specific JSON.

A framework-neutral adapter only registers the already-guarded callable:

guarded_tool = guard.tool(action="publish_release", target="repository")(publish_release)
agent_tools.register(name="publish_release", callable=guarded_tool)

agent_tools represents the customer's existing registry. It may call the model and choose tools, but only guarded_tool can reach publish_release, so Guard remains the enforcement boundary rather than becoming the agent framework.

The wrapper derives a normalized proposal from the real function call, asks Guard to evaluate it against the selected authority, and invokes the original function only when admissible. A blocked call never reaches the original function.

Target scope

Target scope controls which resources an automated action may or may not change. A compiled authority can allow README.md while denying the deployment/ prefix:

{
  "target_requirements": {
    "allow": [{"match": "exact", "value": "README.md"}],
    "deny": [{"match": "prefix", "value": "deployment/"}]
  }
}

Guard enforces the compiler-defined target requirements against the normalized target from the actual tool call before the callback runs. Rules are literal and case-sensitive; deny rules win. Missing or malformed scope, or a missing/invalid target when scope is present, fails closed. Authorities with no target requirements retain their legacy target-free behavior.

CRI-CORE Contract Compiler v0.4.0 defines deterministic target requirements; Guard consumes the compiled authority artifact unchanged and enforces it. It does not compile policy. The native Ledger v2 path uses the base governance-ledger>=0.7.0,<0.8.0 base package for publication verification; it tests the public 0.7.0 minimum and never uses Ledger's guard extra. Immutable artifact schema versions, not a single patch-level package pin, define the v2 validation boundary.

Five-minute Ledger v2 repository example

Ledger translates the company policy with its trusted repository-changes/1.0.0 domain pack and publishes the versioned authority bundle plus receipt. Configure the existing resolver once for the publication registry, then protect the repository mutation:

from waveframe_guard import Guard
from waveframe_guard.authority.adapters import LocalRegistryResolver

resolver = LocalRegistryResolver(workspace_root=".")

guard = Guard.local(
    authority="repository-authority@1.0.0",
    authority_resolver=resolver,
    actor_identity={
        "id": "repository-agent",
        "type": "agent",
        "role": "repository-maintainer",
    },
)

@guard.tool(action="modify", target="path")
def write_file(path: str):
    return your_existing_write(path)

write_file("README.md")                   # allowed; callback runs once
write_file("deployment/production.yml")  # blocked; callback never runs

Guard verifies the complete publication before the authority is cached or used. It then supplies only the fact names and types selected by the published domain pack. Guard does not read or interpret policy prose. Fact derivation and enforcement are deterministic and fail closed.

Guard verifies the exact Ledger-published authority, derives only schema-approved runtime facts, and binds every decision to immutable evidence. The evidence binds the complete bundle, receipt, contract, domain pack, runtime fact schema, Constraint IR, and derived fact set. Execution attestations report callback invocation and completion truthfully; after a callback exception, mutation state remains unknown rather than being guessed.

Application code does not open bundle or receipt files, calculate hashes, construct runtime facts, or call Ledger validators. The resolver retrieves the complete publication package by identity; physical storage layout remains an implementation detail behind that boundary.

Native v2 support initially covers only repository-changes/1.0.0. Other domains require their own separately trusted domain pack and Guard fact provider; finance and existing integrations continue through the legacy v1 compatibility path.

Guard does not interpret policy prose and contains no AI, NLP model, heuristic policy interpretation, or runtime inference. Ledger and a trusted domain pack produce authority. Only the repository-change fact provider is native in this release; other domains require separately trusted domain packs and deterministic fact providers. Guard contains the additive complete-v2 Cloud publication client protocol, but current released Cloud has not implemented that endpoint. Cloud PR #133 is the follow-on implementation. This release provides the client/protocol boundary and does not claim hosted availability.

Ledger's published governance-ledger[guard]==0.7.0 extra still represents its previously released Guard 0.15 compatibility pairing. Install waveframe-guard==0.16.1 directly for this release. Guard itself depends only on the public Ledger base package through governance-ledger>=0.7.0,<0.8.0, never on the guard extra.

Local development path

For offline development, a local authority registry is still supported:

from waveframe_guard import Guard

guard = Guard.local(
    workspace=".guard-local",
    authority="finance-policy@1.0.0",
    actor_identity={"id": "agent-1", "type": "agent", "role": "analyst"},
)

@guard.tool(action="wire_transfer", target="account_id")
def wire_transfer(account_id, amount):
    return perform_transfer(account_id, amount)

Guard.local(authority=...) loads either a legacy Ledger authority_bundle.v1 or a provenance-complete Ledger authority_bundle.v2. A v2 registry entry must also name the matching publication receipt and its canonical hash; a standalone or directly injected v2 contract is rejected. Direct contract=..., authorities={...}, and authority_loader=... inputs remain available for v1 advanced integrations and compatibility.

What Guard owns

Guard owns the developer-side enforcement boundary:

• local SDK integration
• compiled authority resolution
• normalized execution request enforcement
• local allow/block/escalate outcomes
• continuation windows and deferred release checks
• local receipts, replay artifacts, and runtime diagnostics
• evidence spooling for later Cloud submission

Guard does not author governance, publish authority, host organization workflows, operate the long-term evidence system, or ship the proprietary Guard Inspector UI.

Guard, Cloud, and Ledger

The complete Ledger v2 product flow is:

Ledger translates policy with a trusted domain pack and publishes authority
        -> Guard resolves and verifies the complete publication
        -> Guard derives typed facts and enforces before execution
        -> Guard emits bound decision evidence and execution attestation

Guard supports the additive atomic protocol needed to distribute this complete v2 chain. Existing Cloud-facing v1 and finance behavior remains compatible. Current released Cloud has not implemented the endpoint and is not claimed to distribute or consume the full v2 chain until Cloud PR #133 ships. This release provides the client/protocol boundary only; it does not claim hosted availability.

Cloud can publish lifecycle metadata such as active, superseded, or revoked, but Cloud does not decide runtime admissibility. Guard evaluates locally against compiled authority.

The selected domain pack owns the vocabulary and runtime fact schema. Guard supplies those facts from the intercepted proposal and never interprets policy language.

See the single authoritative release compatibility matrix for minimum, recommended, and release-tested pairings.

Local authority registry

For applications that resolve published contracts from a local registry, use the runtime layer:

from waveframe_guard import GovernedRuntime

runtime = GovernedRuntime(
    registry_path="contracts/index.json",
    reject_revoked_authority=True,
    warn_on_superseded=True,
)

runtime.install_actor({"id": "user-1", "type": "human", "role": "manager"})
runtime.bind_contract("finance-policy@1.0.0")

result = runtime.execute(
    fn=transfer,
    args=(1250000,),
    raise_on_block=False,
)

Runtime authority refs are explicit and versioned. Use finance-policy@1.0.0; unversioned IDs such as finance-policy are rejected because replay, audit, and cache integrity depend on deterministic authority identity.

Cloud-connected runtime

For application code that needs Cloud authority metadata and evidence delivery, use the Cloud-connected runtime:

from waveframe_guard import GuardRuntime

runtime = GuardRuntime.from_cloud(
    authority="finance-policy@1.0.0",
    api_key="...",
)

result = runtime.execute(
    actor={"id": "user-1", "type": "human", "role": "manager"},
    fn=transfer,
    args=(1250000,),
    raise_on_block=False,
)

runtime.flush_evidence()

execute(...) still enforces locally. Cloud availability is only required when you explicitly call flush_evidence().

Guard writes evidence to a durable local spool first:

.waveframe_guard/evidence/
  pending/
  sent/
  failed/

If a flush fails, evidence is retained and can be submitted again later.

Continuation and deferred release

Guard separates admissibility from release. An action can be admissible at T1, queued or delayed, and then blocked at T2 if its continuation lease no longer validates.

Guard emits:

• guard_continuation_lease.v1
• guard_release_validation.v1
• release blocked when execution was admissible earlier but a runtime dependency expired before release

Continuity signals are not Cloud decisions. Guard evaluates continuity locally; Cloud may display and preserve the evidence.

Guard Inspector

Guard Inspector is the private operational visualization layer for SDK-emitted evaluations, receipts, replay artifacts, continuity signals, and release posture.

It consumes Guard outcomes and artifacts. It is not part of the public Guard SDK package, does not author policy, and does not own enforcement semantics.

Repository surface

The public Guard surface includes:

• SDK facade
• local runtime
• deterministic evaluation model
• continuation governance
• replay artifacts
• deferred release model
• examples
• docs
• tests
• sample compiled contracts

Non-production or split-bound work is quarantined under temp/. In particular, temp/labs/cloud_runtime/ is a lab preview for future Cloud product work, not production Guard Cloud and not required for local enforcement.

Release discipline

Every substantive Guard change must update the release surface together:

code
+ README / docs
+ CHANGELOG
+ pyproject metadata
+ version-dependent files
+ tests
+ package build
+ tag
