wconv 2.0.0

Windows Format Converter

wconv

---

wconv is a simple command line utility that can be used to parse and convert Windows related formats into human readable form. Additionally, it supports simple modifications on Windows related formats.

Table of Contents

---

• Installation
• Supported Operations
  • ACE Module
    • From Integer
    • From String
    • Toggle Permission
    • Display ACE Flags
    • Display ACE Types
    • Display ACE Permissions
    • Trustees
  • SDDL Module
    • Parse SDDL
    • Add Everyone
    • Add Anonymous
  • SID Module
    • From base64
    • To base64
    • From Raw
    • Well Known
  • UAC Module
    • Parse UAC
    • Toggle Flag
    • Display Mappings
  • DESC Module
    • Parse SecurityDescriptor
• Library Information
• Resources

Installation

---

wconv can be build and installed as a pip package. The recommended way of installing wconv is using pipx

$ pipx install wconv

You can also build wconv from source and install it directly by using the following commands:

$ git clone https://github.com/qtc-de/wconv
$ cd wconv
$ pipx install .

If you want to use wconv as a programming library, simply declare it as a dependency of your project. To use the library for simple scripts, install via pipx as mentioned above and use the venv specific interpreter for script execution. The interpreter can be found using:

$ pipx environment --value PIPX_HOME
/home/user/.local/pipx
$ /home/user/.local/pipx/venvs/wconv/bin/python3
Python 3.11.2 (main, Nov 30 2024, 21:22:50) [GCC 12.2.0] on linux
Type "help", "copyright", "credits" or "license" for more information.
>>> import wconv

Additionally, wconv ships a bash-completion script. The completion script relies on the completion-helpers package. with completion-helpers already installed, the following command enables autocompletion for wconv:

$ cp wconv/resources/bash_completion.d/wconv ~/.bash_completion.d

Supported Operations

---

wconv is written as a Python library, but also contains a small reference implementation that uses the library functions to perform some useful operations. In the following some supported operations are demonstrated.

$ wconv --help
usage: wconv [-h] [--sid-mappings path] [--type-mappings path] {ace,sddl,sid,uac,desc} ...

wconv v2.0.0 - a command line utility to convert Windows specific formats into human readable form. Currently, wconv supports convertion of ACE, SDDL, SID, UAC and SecurityDescriptor
values.

positional arguments:
  {ace,sddl,sid,uac,desc}
    ace                 convert integer ace
    sddl                convert sddl string into readable permissions
    sid                 convert Windows SecurityIdentifier formats
    uac                 convert integer UserAccountControl
    desc                convert security descriptor

options:
  -h, --help            show this help message and exit
  --sid-mappings path   file containing SID mappings
  --type-mappings path  file containing object type mappings

Aside from the module specific options and flags, wconv supports two global options that can be used to specify additional information that is accessible from all modules. Using the --sid-mappings option, you can specify the path to a textfile that contains SID mappings in the following format:

<SID>: <NAME>
<SID>: <NAME>
...

The same can be used for Object Types using the --type-mappings option. Whenever wconv attempts to print a SID or Object Type, it checks whether a mapping to a human readable name exists and appends this data if present.

ACE Module

---

The ACE module supports operations to work with Windows ACE values. Its main purpose is to convert ACE values from binary or SDDL format into human readable form.

$ wconv ace --help
usage: wconv ace [-h] [--ace-flags] [--ace-types] [--ace-permissions] [--from-string] [--type type] [--toggle perm] [--trustees] [int]

positional arguments:
  int                integer ace value

options:
  -h, --help         show this help message and exit
  --ace-flags        show available ACE flags
  --ace-types        show available ACE types
  --ace-permissions  show permission definitions for requested type
  --from-string      interpret ace value als ace-string (sddl format)
  --type type        permission type (default: file)
  --toggle perm      toogles specified permission on the ace value
  --trustees         display available trustees

From Integer

Parses the given integer as an ACE. This is the default action and does not require an additional flag. The --type parameter can again be used to change the displayed permission types.

$ wconv ace 0x00050010
[+] Numeric:	0x00050010
[+] Permissions:
[+] 		+ DELETE
[+] 		+ WRITE_DAC
[+] 		+ WRITE_EXTENDED_ATTRIBUTES

From String

Parse ACE from string in SDDL format. The --type parameter can again be used to change the displayed permission types.

$ wconv ace --from-string '(A;OICINPFA;RPSDWD;;;BU)'
[+] ACE Type:	ACCESS_ALLOWED
[+] Trustee:	Users
[+] Numeric:	0x00050010
[+] Permissions:
[+] 		+ WRITE_EXTENDED_ATTRIBUTES
[+] 		+ DELETE
[+] 		+ WRITE_DAC

Toggle Permission

Toggle the specified permission on the ACE value:

$ wconv ace 0x00050010 --toggle WP --toggle GA
[+] Numeric:	0x10050030
[+] Permissions:
[+] 		+ GENERIC_ALL
[+] 		+ DELETE
[+] 		+ WRITE_DAC
[+] 		+ WRITE_EXTENDED_ATTRIBUTES
[+] 		+ EXECUTE

Display ACE Flags

Displays a list of all available ACE flags:

$ wconv ace --ace-flags
[+] CI - CONTAINER_INHERIT
[+] OI - OBJECT_INHERIT
[+] NP - NO_PROPAGATE_INHERIT
[+] IO - INHERIT_ONLY
[+] ID - INHERITED
[+] SA - SUCCESSFUL_ACCESS
[+] FA - FAILED_ACCESS

Display ACE Types

Displays a list of all available ACE types:

$ wconv ace --ace-types
[+] A - ACCESS_ALLOWED
[+] D - ACCESS_DENIED
[+] OA - ACCESS_ALLOWED_OBJECT
[+] OD - ACCESS_DENIED_OBJECT
[+] AU - SYSTEM_AUDIT
[+] AL - SYSTEM_ALARM
[+] OU - SYSTEM_AUDIT_OBJECT
[+] OL - SYSTEM_ALARM_OBJECT

Display ACE Permissions

Displays a list of all available ACE permissions:

$ wconv ace --ace-permissions
[+] 10000000 - GA - GENERIC_ALL
[+] 20000000 - GX - GENERIC_EXECUTE
[+] 40000000 - GW - GENERIC_WRITE
[+] 80000000 - GR - GENERIC_READ
[+] 00010000 - SD - DELETE
[+] 00020000 - RC - READ_CONTROL
[+] 00040000 - WD - WRITE_DAC
[+] 00080000 - WO - WRITE_OWNER
[+] 00000001 - CC - READ
[+] 00000002 - DC - WRITE
[+] 00000004 - LC - APPEND
[+] 00000008 - SW - READ_EXTENDED_ATTRIBUTES
[+] 00000010 - RP - WRITE_EXTENDED_ATTRIBUTES
[+] 00000020 - WP - EXECUTE
[+] 00000040 - DT - MEANINGLESS
[+] 00000080 - LO - READ_ATTRIBUTES
[+] 00000100 - CR - WRITE_ATTRIBUTES

The default permission type is set to file, but can be changed using the --type parameter:

$ wconv ace --ace-permissions --type service
[+] 10000000 - GA - GENERIC_ALL
[+] 20000000 - GX - GENERIC_EXECUTE
[+] 40000000 - GW - GENERIC_WRITE
[+] 80000000 - GR - GENERIC_READ
[+] 00010000 - SD - DELETE
[+] 00020000 - RC - READ_CONTROL
[+] 00040000 - WD - WRITE_DAC
[+] 00080000 - WO - WRITE_OWNER
[+] 00000001 - CC - QUERY_CONFIG
[+] 00000002 - DC - CHANGE_CONFIG
[+] 00000004 - LC - QUERY_STATISTIC
[+] 00000008 - SW - ENUM_DEPENDENCIES
[+] 00000010 - RP - START
[+] 00000020 - WP - STOP
[+] 00000040 - DT - PAUSE
[+] 00000080 - LO - INTERROGATE
[+] 00000100 - CR - USER_DEFINIED

Trustees

Display all available trustees:

$ wconv ace --trustees
[+] AN - Anonymous
[+] AO - Account Operators
[+] AU - Authenticated Users
[+] BA - Administrators
[+] BG - Guests
[+] BO - Backup Operators
[+] BU - Users
[+] CA - Certificate Publishers
[+] CD - Certificate Services DCOM Access
[+] CG - Creator Group
[+] CO - Creator Owner
[+] DA - Domain Admins
[+] DC - Domain Computers
[+] DD - Domain Controllers
[+] DG - Domain Guests
[+] DU - Domain Users
[+] EA - Enterprise Admins
[+] ED - Enterprise Domain Controllers
[+] RO - Enterprise Read-Only Domain Controllers
[+] PA - Group Policy Admins
[+] IU - Interactive Users
[+] LA - Local Administrator
[+] LG - Local Guest
[+] LS - Local Service
[+] SY - Local System
[+] NU - Network
[+] LW - Low Integrity
[+] ME - Medium Integrity
[+] HI - High Integrity
[+] SI - System Integrity
[+] NO - Network Configuration Operators
[+] NS - Network Service
[+] PO - Printer Operators
[+] PS - Self
[+] PU - Power Users
[+] RS - RAS Servers
[+] RD - Remote Desktop Users
[+] RE - Replicator
[+] RC - Restricted Code
[+] RU - Pre-Win2k Compatibility Access
[+] SA - Schema Administrators
[+] SO - Server Operators
[+] SU - Service
[+] WD - Everyone
[+] WR - Write restricted Code

SDDL Module

---

The SDDL module supports operations to convert SDDL strings into human readable form.

$ wconv sddl --help
usage: wconv sddl [-h] [--add-everyone] [--add-anonymous] [--type type] [str]

positional arguments:
  str              sddl string

options:
  -h, --help       show this help message and exit
  --add-everyone   add full permissions for everyone
  --add-anonymous  add full permissions for anonymous
  --type type      permission type (default: file)

Parse SDDL

Parses the given SDDL string. This is the default action and does not require additional arguments.

$ wconv sddl 'O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)'
[+] ACL Type:	DACL
[+] Owner:	Administrators
[+] Group:	Local System
[+] ACE List:
[+] ==================================
[+]     ACE Type:	ACCESS_DENIED
[+]     Trustee:	Administrators
[+]     Numeric:	0x000f01ff
[+]     Permissions:
[+]     		+ READ_CONTROL
[+]     		+ DELETE
[+]     		+ WRITE_DAC
[+]     		+ WRITE_OWNER
[+]     		+ SYNCHRONIZE
[+]     		+ READ
[+]     		+ WRITE
[+]     		+ APPEND
[+]     		+ READ_EXTENDED_ATTRIBUTES
[+]     		+ WRITE_EXTENDED_ATTRIBUTES
[+]     		+ EXECUTE
[+]     		+ MEANINGLESS
[+]     		+ READ_ATTRIBUTES
[+]     		+ WRITE_ATTRIBUTES
[+] ==================================
[+]     ACE Type:	ACCESS_ALLOWED
[+]     Trustee:	Creator Owner
[+]     Numeric:	0x00050050
[+]     Permissions:
[+]     		+ WRITE_EXTENDED_ATTRIBUTES
[+]     		+ MEANINGLESS
[+]     		+ DELETE
[+]     		+ WRITE_DAC
[+] ==================================

The default permission type is file and can be changed with the --type parameter:

$ wconv sddl 'O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)' --type service
[+] ACL Type:	DACL
[+] Owner:	Administrators
[+] Group:	Local System
[+] ACE List:
[+] ==================================
[+]     ACE Type:	ACCESS_DENIED
[+]     Trustee:	Administrators
[+]     Numeric:	0x000f01ff
[+]     Permissions:
[+]     		+ READ_CONTROL
[+]     		+ DELETE
[+]     		+ WRITE_DAC
[+]     		+ WRITE_OWNER
[+]     		+ SYNCHRONIZE
[+]     		+ READ
[+]     		+ WRITE
[+]     		+ APPEND
[+]     		+ READ_EXTENDED_ATTRIBUTES
[+]     		+ WRITE_EXTENDED_ATTRIBUTES
[+]     		+ EXECUTE
[+]     		+ MEANINGLESS
[+]     		+ READ_ATTRIBUTES
[+]     		+ WRITE_ATTRIBUTES
[+] ==================================
[+]     ACE Type:	ACCESS_ALLOWED
[+]     Trustee:	Creator Owner
[+]     Numeric:	0x00050050
[+]     Permissions:
[+]     		+ START
[+]     		+ PAUSE
[+]     		+ DELETE
[+]     		+ WRITE_DAC
[+] ==================================

Add Everyone

Add full access for everyone to the specified SDDL:

$ wconv sddl --add-everyone 'O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)'
[+] O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)(A;;GAGRGWGXRCSDWDWOSSCCDCLCSWRPWPDTLOCR;;;WD)

Add Anonymous

Add full access for anonymous to the specified SDDL:

$ wconv sddl --add-anonymous 'O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)'
[+] O:BAG:SYD:PAI(D;OICI;FA;;;BA)(A;OICIIO;RPDTSDWD;;;CO)(A;;GAGRGWGXRCSDWDWOSSCCDCLCSWRPWPDTLOCR;;;AN)

SID Module

---

The SID module can be used to convert between different representations of Windows SecurityIdentifiers. One use case is querying Active Directory via LDAP, where the objectSID attributes are stored as base64 encoded binary blobs.

$ wconv sid --help
usage: wconv sid [-h] [--to-b64] [--raw] [--well-known] [b64]

positional arguments:
  b64           sid value (default format: base64)

options:
  -h, --help    show this help message and exit
  --to-b64      converts formatted sid (S-1-*) to base64
  --raw         specify sid as raw hex string (010500...)
  --well-known  display list of well known sids

From Base64

Converts a SID from base64 format to its human readable form. This is the default action and does not require any flags:

$ wconv sid AQUAAAAAAAUVAAAAsexT/iL5hu1Kf3avAAIAAA==
[+] SID: S-1-5-21-4266912945-3985045794-2943778634-512 (DOMAIN_ADMINS)

To Base64

Converts a SID from its human readable form to base64:

$ wconv sid --to-b64 S-1-5-21-4266912945-3985045794-2943778634-512
[+] AQUAAAAAAAUVAAAAsexT/iL5hu1Kf3avAAIAAA==

From Raw

Converts a SID from raw hex representation to its human readable format:

$ echo -n "AQUAAAAAAAUVAAAAsexT/iL5hu1Kf3avAAIAAA==" | base64 -d | xxd -p
010500000000000515000000b1ec53fe22f986ed4a7f76af00020000
$ wconv sid --raw 010500000000000515000000b1ec53fe22f986ed4a7f76af00020000
[+] SID: S-1-5-21-4266912945-3985045794-2943778634-512 (DOMAIN_ADMINS)

Well Known

Display list of well known SIDs:

$ wconv sid --well-known
[+] S-1-0-0                   - NULL
[+] S-1-1-0                   - EVERYONE
[+] S-1-2-0                   - LOCAL
[+] S-1-2-1                   - CONSOLE_LOGON
[+] S-1-3-0                   - CREATOR_OWNER
[+] S-1-3-1                   - CREATOR_GROUP
[+] S-1-3-2                   - OWNER_SERVER
[+] S-1-3-3                   - GROUP_SERVER
[+] S-1-3-4                   - OWNER_RIGHTS
[+] S-1-5                     - NT_AUTHORITY
[...]

UAC Module

---

The UAC module can parse integer UserAccountControl values from ActiveDirectory into a human readable format. You can also toggle specific UAC Flags and output the corresponding integer representation again.

$ wconv uac --help
usage: wconv uac [-h] [--mapping] [--toggle flag] [int]

positional arguments:
  int            binary user account control value

options:
  -h, --help     show this help message and exit
  --mapping      display UserAccountControl mappings (flags)
  --toggle flag  toogles specified flag on the UserAccountControl value

Parse UAC

Parses a UserAccountControl value in its different components. This is the default action and does not require additional arguments:

$ wconv uac 1114624
[+] UserAccountControl:	1114624 (0x00110200)
[+]	+ NORMAL_ACCOUNT
[+]	+ DONT_EXPIRE_PASSWORD
[+]	+ NOT_DELEGATED

Toggle Flag

Adds the specified flag(s) to the UAC value:

$ wconv uac 1114624 --toggle DONT_REQ_PREAUTH --toggle TRUSTED_FOR_DELEGATION
[+] UserAccountControl:	5833216 (0x00590200)
[+]	+ NORMAL_ACCOUNT
[+]	+ DONT_EXPIRE_PASSWORD
[+]	+ TRUSTED_FOR_DELEGATION
[+]	+ NOT_DELEGATED
[+]	+ DONT_REQ_PREAUTH

Display Mappings

Display the integer to flag mappings:

$ wconv uac --mapping
[+] 0x00000001 - SCRIPT
[+] 0x00000002 - ACCOUNTDISABLE
[+] 0x00000008 - HOMEDIR_REQUIRED
[+] 0x00000010 - LOCKOUT
[+] 0x00000020 - PASSWD_NOTREQD
[+] 0x00000040 - PASSWD_CANT_CHANGE
[+] 0x00000080 - ENCRYPTED_TEXT_PWD_ALLOWED
[+] 0x00000100 - TEMP_DUPLICATE_ACCOUNT
[+] 0x00000200 - NORMAL_ACCOUNT
[+] 0x00000800 - INTERDOMAIN_TRUST_ACCOUNT
[+] 0x00001000 - WORKSTATION_TRUST_ACCOUNT
[+] 0x00002000 - SERVER_TRUST_ACCOUNT
[+] 0x00010000 - DONT_EXPIRE_PASSWORD
[+] 0x00020000 - MNS_LOGON_ACCOUNT
[+] 0x00040000 - SMARTCARD_REQUIRED
[+] 0x00080000 - TRUSTED_FOR_DELEGATION
[+] 0x00100000 - NOT_DELEGATED
[+] 0x00200000 - USE_DES_KEY_ONLY
[+] 0x00400000 - DONT_REQ_PREAUTH
[+] 0x00800000 - PASSWORD_EXPIRED
[+] 0x01000000 - TRUSTED_TO_AUTH_FOR_DELEGATION
[+] 0x04000000 - PARTIAL_SECRETS_ACCOUNT

DESC Module

---

The DESC module supports operations to convert SecurityDescriptors into human readable form.

$ wconv desc -h
usage: wconv desc [-h] [--hex] [--type type] [--sid sid] [--adminsd] b64

positional arguments:
  b64          security descriptor in base64

options:
  -h, --help   show this help message and exit
  --hex        specify the descriptor in hex format instead
  --type type  permission type (default: ad)
  --sid sid    filter for a specific sid
  --adminsd    filter out inherited ACEs

Parse SecurityDescriptor

Parses the given base64 formatted SecurityDescriptor. This is the default action and does not require additional flags. When specifying the --hex flag, the SecurityDescriptor is expected in hex format instead.

$ wconv desc AQAEjKQgAADAIAAAAAAAA...
[+] Owner:	S-1-5-21-1004336348-1177238915-682003330-512 (DOMAIN_ADMINS)
[+] Group:	S-1-5-21-1004336348-1177238915-682003330-513 (DOMAIN_USERS)
[+] Ace Count:	154
[+] ACE list:
[+]
[+] Trustee:	S-1-5-21-1004336348-1177238915-682003330-519 (ENTERPRISE_ADMINS)
[+] Numeric:	0x000f01ff
[+] ACE Flags:
[+] 		+ CONTAINER_INHERIT
[+] 		+ INHERITED
[+] Permissions:
[+] 		+ DELETE
[+] 		+ READ_CONTROL
[+] 		+ WRITE_DACL
[+] 		+ WRITE_OWNER
[+] 		+ DS_CREATE_CHILD
[+] 		+ DS_DELETE_CHILD
[+] 		+ ACTRL_DS_LIST
[+] 		+ DS_SELF
[+] 		+ DS_READ_PROP
[+] 		+ DS_WRITE_PROP
[+] 		+ DS_DELETE_TREE
[+] 		+ DS_LIST_OBJECT
[+] 		+ DS_CONTROL_ACCESS
[+]
[+] Trustee:	S-1-5-32-554 (ALIAS_PREW2KCOMPACC)
[+] Numeric:	0x00000004
[+] ACE Flags:
[+] 		+ CONTAINER_INHERIT
[+] 		+ INHERITED
[+] Permissions:
[+] 		+ ACTRL_DS_LIST
[+]
[+] Trustee:	S-1-5-32-544 (BUILTIN_ADMINISTRATORS)
[+] Numeric:	0x000f01bd
[+] ACE Flags:
[+] 		+ CONTAINER_INHERIT
[+] 		+ INHERITED
[+] Permissions:
[+] 		+ DELETE
[+] 		+ READ_CONTROL
[+] 		+ WRITE_DACL
[+] 		+ WRITE_OWNER
[+] 		+ DS_CREATE_CHILD
[+] 		+ ACTRL_DS_LIST
[+] 		+ DS_SELF
[+] 		+ DS_READ_PROP
[+] 		+ DS_WRITE_PROP
[+] 		+ DS_LIST_OBJECT
[+] 		+ DS_CONTROL_ACCESS
...

AdminSDHolder Filtering

ACE inheritance is deactivated for Active Directory objects protected by AdminSDHolder. To filter inherited permissions, you can use the --adminsd flag.

$ wconv desc AQAEjKQgAADAIAAAAAAAA... --adminsd
[+] ACE Type:	ACCESS_ALLOWED_OBJECT
[+] Trustee:	S-1-5-32-560 (WINDOWS_AUTHORIZATION_ACCESS_GROUP)
[+] Numeric:	0x00000010
[+] Obj Type:	46a9b11d-60ae-405a-b7e8-ff8a58d456d2 (Token-Groups-Global-And-Universal)
[+] Permissions:
[+] 		+ DS_READ_PROP
[+]
[+] ACE Type:	ACCESS_ALLOWED_OBJECT
[+] Trustee:	S-1-5-32-561 (TERMINAL_SERVER_LICENSE_SERVERS)
[+] Numeric:	0x00000030
[+] Obj Type:	6db69a1c-9422-11d1-aebd-0000f80367c1 (Terminal-Server)
[+] Permissions:
[+] 		+ DS_READ_PROP
[+] 		+ DS_WRITE_PROP
[+]
[+] ACE Type:	ACCESS_ALLOWED_OBJECT
[+] Trustee:	S-1-5-32-561 (TERMINAL_SERVER_LICENSE_SERVERS)
[+] Numeric:	0x00000030
[+] Obj Type:	5805bc62-bdc9-4428-a5e2-856a0f4c185e (Terminal-Server-License-Server)
[+] Permissions:
[+] 		+ DS_READ_PROP
[+] 		+ DS_WRITE_PROP

Library Information

---

Please notice that the wconv library is not really well thought out. A good term to describe it is quick and dirty, as I required the functionality of wconv and decided to write the functions in a reusable way. However, everything was written on the fly and many sections could be written better and may contain bugs. Pull requests to improve the library are always welcome :)

Resources

---

Here is a list of some resources that contain the required information about the different supported Windows structures.

• The Security Descriptor Definition Language of Love (Part 1)
• The Security Descriptor Definition Language of Love (Part 2)
• Understanding Windows File And Registry Permissions
• How do I convert a SID between binary and string forms
• How to use the UserAccountControl flags
• Parsing-the-NtSecurityDescriptor
• ldaptools
• sddl.py
