wltp-jrshift 2.0.3

Gearshift tool implement the Sub-Annex 1 and Sub-Annex 2 of theCOMMISSION REGULATION (EU) 2017/1151 of 1 June 2017 - Annex XXI

versions:

documentation:

https://gearshift-calculation-tool.readthedocs.io/en/latest/

sources:

https://code.europa.eu/jrc-ldv/jrshift

keywords:

automotive, car, cars, driving, engine, emissions, fuel-consumption, gears, gearshifts, rpm, simulation, simulator, standard, vehicle, vehicles, WLTP

short name:

JR-Shift

live-demo:

Copyright and License:

© Copyright (c) 2021 European Union.

Licensed under the EUPL, Version 1.2 or – as soon they will be approved by the European Commission – subsequent versions of the EUPL (the “Licence”); You may not use this work except in compliance with the Licence. You may obtain a copy of the Licence at:

Unless required by applicable law or agreed to in writing, software distributed under the Licence is distributed on an “AS IS” basis, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the Licence for the specific language governing permissions and limitations under the Licence.

A python-3.6+ package to generate the gear-shifts of Light-duty vehicles

Table of Contents

• Introduction

  • Overview

• Installation

  • Prerequisites

  • Download

  • Install

  • Project files and folders

• Quick-Start

• Usage

  • Setup

  • Load data

  • Dispatcher

Introduction

The aim of the JR-Shift is obtain the Required Engine Speeds, the Available Powers, the Required Vehicle Speeds and the Gears for the whole WLTC based on the vehicle characteristics. The model should allow accurate calculation of final trace and the operating conditions of the engine.

Overview

The calculator accepts as input an excel file that contains the vehicle’s technical data, along with parameters for modifying the execution WLTC cycle, and it then spits-out the gear-shifts of the vehicle and the others parameters used during the obtaining of these. It does not calculate any CO₂ emissions.

Installation

Prerequisites

Python-3.6+ is required and Python-3.7 recommended. It requires numpy/scipy and pandas libraries with native backends.

Tip

On Windows, it is preferable to use the Anaconda distribution. To avoid possible incompatibilities with other projects

Download

Download the sources,

• either with git, by giving this command to the terminal:

  git clone https://github.com/JRCSTU/gearshift_calculation_tool --depth=1

Install

From within the project directory, run one of these commands to install it:

• for standard python, installing with pip is enough (but might):

  pip install -e .[path_to_gearshift_calculation_tool_folder]

Project files and folders

The files and folders of the project are listed below:

+--gearshift/                                       # main folder that contains the whole gearshift project
|   +--cli/                                         # folder that contains all cli scripts
|   +--core/                                        # folder that contains core packages
|       +--load/                                    # (package) python-code of the load
|           +--speed_phases/                        # folder that contains speed phases in ftr format
|           +--excel.py                             # (script) load from the excel file parameters
|       +--model/                                   # (package) python-code of the model
|           +--calculateShiftpointsNdvFullPC/       # (package) python-code of the calculate shift points, Ndv and  FullPC
|           +--scaleTrace/                          # (package) python-code of the calculate scale trace
|       +--write/                                   # (package) python-code of the write
|           +--excel.py                             # (script) write to the excel file output parameters
|   +--demos/                                       # folder that contains demo files
|   +--docs/                                        # folder that contains documentation
+-- AUTHORS.rst
+--setup.py                                         # (script) The entry point for `setuptools`, installing, testing, etc
+--README.rst
+--LICENSE.txt

Quick-Start

Cmd-line usage

The command-line usage below requires the Python environment to be installed, and provides for executing an experiment directly from the OS’s shell (i.e. cmd in windows or bash in POSIX), and in a single command. To have precise control over the inputs and outputs

$ gearshift --help                                                  ## to get generic help for cmd-line syntax
$ gearshift demo                                                    ## to get demo input file
$ gearshift run "path_input_file" -O "path_to_save_output_file"     ## to run gearshift tool

Usage

In this example we will use gearshift model in order to predict the gears.

Setup

Import dispatcher(dsp) from gearshift tool that contains functions and simulation model to process vehicle data and Import also schedula for selecting and executing functions. for more information on how to use schedula

from gearshift.core import dsp
import schedula as sh

Load data

• Load vehicle data for a specific vehicle from excel template

  vehData = 'gs_input_demo.xlsx'

• Define the input dictionary for the dispacher.

  input = dict(input_file_name=vehData)

Dispatcher

• Dispatcher will select and execute the proper functions for the given inputs and the requested outputs

  core = dsp(input, outputs=['sol'], shrink=True)

• Plot workflow of the core model from the dispatcher

  core.plot()

  This will automatically open an internet browser and show the work flow of the core model as below. You can click all the rectangular boxes to see in detail sub models like load, model, write and plot.



  The load module



• Load outputs of dispatcher Select the chosen dictionary key (sol) from the given dictionary.

  solution = sh.selector(['sol'], sh.selector(['sol'], core))

• Select each output case

  # Select first case
  solution['sol'][0]

  # Select second case case
  solution['sol'][1]

  # Select gears output for different cases
  gears = {}
  for sol in solution['sol']:
      gears[f'gears_{sol["Case"]}'] = sol['GearsOutput']
