WorldMaker

## Project description

Create models of rotating and non-rotating planets by solving the differential equations for hydrostatic equilibrium, and create initial conditions for e.g. smoothed particle hydrodynamics (SPH) simulations by placing particles that precisely match the planet's profiles.

See the `tutorial.ipynb`

notebook for an introductory tutorial and examples
(https://github.com/srbonilla/WoMa), with additional documentation in this
file, below. Please see the class and function docstrings for full details.

Presented in Ruiz-Bonilla et al. (2020, MNRAS 500:3).

Includes SEAGen (https://github.com/jkeger/seagen; Kegerreis et al. 2019, MNRAS 487:4) with modifications for spinning planets.

Sergio Ruiz-Bonilla: sergio.ruiz-bonilla@durham.ac.uk

Jacob Kegerreis: jacob.kegerreis@durham.ac.uk

Tom Sandnes: thomas.d.sandnes@durham.ac.uk

If you find any bugs, potential improvements, or features worth adding, then please let us know!

## Files

`tutorial.ipynb`

Jupyter notebook tutorial and examples.`woma/`

Code directory.`main.py`

The main program classes and functions.`data/`

Data for equation of state (EoS) tables.`eos/`

EoS and temperature-density relations.`spherical_funcs/`

Functions for spherical profiles.`spin_funcs/`

Functions for spinning profiles.`misc/`

Miscellaneous functions and constants.

`README.md`

This file. General info and documentation.`LICENSE.txt`

GNU general public license v3+.`setup.py`

,`setup.cfg`

,`MANIFEST.in`

PyPI package files.

## Installation and requirements

- Install the package with
`pip install woma`

, or downloaded directly from https://pypi.org/project/woma/ - Python 3 (tested with 3.6.9) + seagen>=1.4.1, numpy, numba>=0.50.1, h5py

# Documentation

See the `tutorial.ipynb`

notebook for a tutorial and examples.
This documentation summarises the different primary options available.

Full documentation is provided in the class and function docstrings, particularly for the various utilities (e.g. equations of state functions) that are not the focus of the primary initial-conditions topics in the tutorial and here.

Most functions take an optional `verbosity`

argument
that controls the amount of printed information.
Set `0`

for no printing, `1`

for standard output, or `2`

for extra details.

### Contents

- Spherical profiles
- Spinning profiles
- Particle placement
- (Bonus) Impact initial conditions

## Notation etc.

- Formatted with black.
- Arrays are explicitly labelled with a prefix
`A1_`

, or`An_`

for an`n`

-dimensional array. `numba`

provides great speed increases, but places some odd requirements and limitations that lead us to some awkward or ugly but functional approaches...

## 1. Spherical profiles

All profiles require the temperature and either the pressure or density at the
surface: `T_s`

and `P_s`

or `rho_s`

,
plus the material and temperature-density relation for each layer (see below):
`A1_mat_layer`

and `A1_T_rho_type`

.
For a fixed-entropy relation, only the surface density is needed.

The optional parameter `num_prof`

sets the number of profile integration steps.
Default 1000.

### Equations of state (EoS)

It is important to check that the EoS you use are appropriate for your application.

So far, we have implemented several Tillotson, ANEOS, SESAME, and Hubbard & MacFarlane (1980) materials, with more on the way. Custom materials in SESAME-style tables can also be provided.

Materials are set for each layer with `A1_mat_layer`

using the following material names,
which are converted internally into material IDs,
set by a base type ID (multiplied by 100) plus a minor type:

- Tillotson (Melosh 1989; Benz & Asphaug 1999):
`1`

- Iron:
`Til_iron`

:`100`

- Granite:
`Til_granite`

:`101`

- Water:
`Til_water`

:`102`

- Basalt:
`Til_basalt`

:`103`

- Iron:
- Hubbard & MacFarlane (1980):
`2`

- Hydrogen-helium atmosphere:
`HM80_HHe`

:`200`

- Ice H20-CH4-NH3 mix:
`HM80_ice`

:`201`

- Rock SiO2-MgO-FeS-FeO mix:
`HM80_rock`

:`202`

- Hydrogen-helium atmosphere:
- SESAME (Lyon & Johnson 1992) and others in similar formats:
`3`

- Iron (2140):
`SESAME_iron`

:`300`

- Basalt (7530):
`SESAME_basalt`

:`301`

- Water (7154):
`SESAME_water`

:`302`

- Senft & Stewart (2008) water:
`SS08_water`

:`303`

- Haldemann, J. et al. (2020) AQUA:
`AQUA`

:`304`

- Chabrier, G. et al. (2019) Hydrogen:
`CMS19_H`

:`305`

- Chabrier, G. et al. (2019) Helium:
`CMS19_He`

:`306`

- Chabrier & Debras (2021) H/He mixture Y=0.245 (Jupiter):
`CD21_HHe`

:`307`

- Iron (2140):
- ANEOS (in SESAME-style tables):
`4`

- Forsterite (Stewart et al. 2019):
`ANEOS_forsterite`

:`400`

- Iron (Stewart, zenodo.org/record/3866507):
`ANEOS_iron`

:`401`

- Fe85Si15 (Stewart, zenodo.org/record/3866550):
`ANEOS_Fe85Si15`

:`402`

- Forsterite (Stewart et al. 2019):
- Custom (in SESAME-style tables):
`9`

- User-provided custom material(s):
`900`

,`901`

, ...,`904`

- User-provided custom material(s):

These are defined in `woma/misc/glob_vars.py`

,
including the file paths for custom tables.

### Temperature-density relations

These relations are set for each layer with `A1_T_rho_type`

:

`"adiabatic"`

: Adiabatic, only available for some EoS.`"power=a"`

where`a`

is a float: A power law T ~ rho^`a`

. So e.g.`"power=0"`

for isothermal.`"entropy=s"`

where`s`

is a float: A fixed specific entropy (J K^-1 kg^-1). Similar to adiabatic, but uses this entropy directly instead of deriving it from the temperature and density or pressure.

### Profile generation

There are several options for which additional parameters are set and which unknowns are found, depending on the number of layers in the planet.

Most of these functions are simple iterative bisection searches over the unknown parameter(s) to find a valid planet in hydrostatic equilibrium that satisfies the set attribute values.

The additional function arguments like `R_max`

set things like the upper bound
for an iteration so usually do not need to be precise.

Optional arguments for these functions (in addition to the `verbosity`

) set:

`tol`

: The tolerance for finding unknown parameters as a fractional difference between two consecutive iterations. Default usually 0.001, depending on the method.`num_attempt`

: The maximum number of iteration attempts if the tolerance has still not been reached. Default usually 40, depending on the method.

If the outer radii or masses of some but not all layers are required as inputs,
then the unknown elements in the input arrays can be left as `None`

, e.g.:
`A1_R_layer = [3.1415, None]`

or `A1_M_layer = [None, 1.23, 4.56]`

.

#### 1 layer

`gen_prof_L1_find_R_given_M()`

, requires:- Total mass:
`self.M`

- Maximum radius:
`R_max`

- Total mass:
`gen_prof_L1_find_M_given_R()`

, requires:- Total radius:
`self.R`

- Maximum mass:
`M_max`

- Total radius:

#### 2 layers

`gen_prof_L2_find_R1_given_M_R()`

, requires:- Total radius:
`self.R`

- Total mass:
`self.M`

- Total radius:
`gen_prof_L2_find_M_given_R_R1()`

, requires:- Total radius:
`self.R`

- Layer 1 outer radius:
`self.A1_R_layer[0]`

- Maximum mass:
`M_max`

- Total radius:
`gen_prof_L2_find_R_given_M_R1()`

, requires:- Total mass:
`self.M`

- Layer 1 outer radius:
`self.A1_R_layer[0]`

- Maximum radius:
`R_max`

- Total mass:
`gen_prof_L2_find_R_R1_given_M1_M2()`

, requires:- Layer 1 and 2 masses:
`self.A1_M_layer`

- Minimum and maximum radii:
`R_min`

,`R_max`

- Layer 1 and 2 masses:

#### 3 layers

`gen_prof_L3_find_M_given_R_R1_R2()`

, requires:- Layer 1, 2, and 3 outer radii:
`self.A1_R_layer`

- Layer 1, 2, and 3 outer radii:
`gen_prof_L3_find_R1_given_M_R_R2()`

, requires:- Total mass:
`self.M`

- Total radius:
`self.R`

- Layer 2 outer radius:
`self.A1_R_layer[1]`

- Total mass:
`gen_prof_L3_find_R2_given_M_R_R1()`

, requires:- Total mass:
`self.M`

- Total radius:
`self.R`

- Layer 1 outer radius:
`self.A1_R_layer[0]`

- Total mass:
`gen_prof_L3_find_R_given_M_R1_R2()`

, requires:- Total mass:
`self.M`

- Layer 1 and 2 outer radii:
`self.A1_R_layer[0]`

,`[1]`

- Total mass:
`gen_prof_L3_find_R1_R2_given_M_R_I()`

, requires:- Total mass:
`self.M`

- Total mass:

#### Adding layers

`gen_prof_given_inner_prof()`

: After generating an initial planet, a new layer can be added on top by integrating outwards. Requires:- Name of the material in the new layer:
`mat`

- Temperature-density relation in the new layer:
`T_rho_type`

- Minimum density at which the new layer will stop:
`rho_min`

- Minimum pressure at which the new layer will stop:
`P_min`

- Name of the material in the new layer:

#### Additional parameters

See the `main.py`

and other docstrings for full details.

The class's `num_prof`

parameter sets the number of radial profile steps,
while the profile generating functions take arguments like `tol`

and/or `num_attempt`

that control the convergence criterion and
maximum number of iterations to do to find the unknown parameters.

## 2. Spinning profiles

See `tutorial.ipynb`

for the main usage:

```
spherical_planet = woma.Planet( . . . )
spin_planet = woma.SpinPlanet(
planet = spherical_planet,
period = 24, # hours
)
```

The output attributes available from the `spin_planet`

object
are documented in the `SpinPlanet`

class docstring in `woma/main.py`

.

The primary outputs are the arrays of properties of the nested spheroids,
including their equatorial and polar radii (semi-major and semi-minor axes),
`A1_R`

and `A1_Z`

,
and for example their masses, densities, pressures, and temperatures,
`A1_m`

, `A1_rho`

, `A1_P`

, and `A1_T`

.

Additional parameters are similar to those in the spherical case mentioned above. See the docstrings for full details.

## 3. Particle placement

See `tutorial.ipynb`

for the main usage:

```
planet = woma.Planet( . . . )
# or
planet = woma.SpinPlanet( . . . )
N_particles = 1e7
N_ngb = 48 # Optional number of neighbours for approximate SPH smoothing lengths
particles = woma.ParticleSet(planet, N_particles, N_ngb=N_ngb)
```

The output attributes available from the `particles`

object
are documented in the `ParticlePlanet`

class docstring in `woma/main.py`

.

Particles can be saved to a SWIFT-style HDF5 file with the `save()`

method.
See its docstring and `save_particle_data()`

in `woma/misc/io.py`

for details.

The specific entropies of the particles can be added to the object using the
`set_material_entropies()`

or `calculate_entropies()`

methods.

## 4. Impact initial conditions

One of the motivations for WoMa's development was to create initial conditions for the modelling of planetary giant impacts. (Check out the open-source SWIFT code at www.swiftsim.com and see e.g. http://icc.dur.ac.uk/giant_impacts/ for more info about these applications.)

Therefore, we include here some simple utilities for setting up the initial conditions for an impact scenario between two planets, as described in Appendix A of Kegerreis et al. (2020), ApJ 897:161.

See the `tutorial.ipynb`

notebook for an example and the docstrings of
`impact_pos_vel_b_v_c_r()`

and `impact_pos_vel_b_v_c_t()`

in
`woma/misc/utils.py`

for the full documentation.
