wristpy

wristpy logo

A Python package for wrist-worn accelerometer data processing.

Build codecov Ruff stability-experimental LGPL--2.1 License pages

Welcome to wristpy, a Python library designed for processing and analyzing wrist-worn accelerometer data. This library provides a set of tools for loading sensor information, calibrating raw accelerometer data, calculating various physical activity metrics, finding non-wear periods, and detecting sleep periods (onset and wakeup times). Additionally, we provide access to other sensor data that may be recorded by the watch, including; temperature, luminosity, capacitive sensing, battery voltage, and all metadata.

Supported formats & devices

The package currently supports the following formats:

Format Manufacturer Device Implementation status
GT3X Actigraph wGT3X-BT ✅
BIN GENEActiv GENEActiv ✅
CSV Actigraph wGT3X-BT ✅ (HBN format only)

Special Note The idle_sleep_mode for Actigraph watches will lead to uneven sampling rates during periods of no motion (read about this here). Consequently, this causes issues when implementing wristpy's non-wear and sleep detection. As of this moment, we fill in the missing acceleration data with the assumption that the watch is perfectly idle in the face-up position (Acceleration vector = [0, 0, -1]). The data is filled in at the same sampling rate as the raw acceleration data. In the special circumstance when acceleration samples are not evenly spaced, the data is resampled to the highest effective sampling rate to ensure linearly sampled data.

Processing pipeline implementation

The main processing pipeline of the wristpy module can be described as follows:

  • Data loading: sensor data is loaded using actfast, and a WatchData object is created to store all sensor data.
  • Data calibration: A post-manufacturer calibration step can be applied, to ensure that the acceleration sensor is measuring 1g force during periods of no motion. There are three possible options: None, gradient, ggir.
  • Data imputation In the special case when dealing with the Actigraph idle_sleep_mode == enabled, the gaps in acceleration are filled in after calibration, to avoid biasing the calibration phase.
  • Metrics Calculation: Calculates various activity metrics on the calibrated data, namely ENMO (Euclidean norm, minus one), MAD (mean amplitude deviation) 1, Actigraph activity counts2, MIMS (monitor-independent movement summary) unit 3, and angle-Z (angle of acceleration relative to the x-y axis).
  • Non-wear detection: We find periods of non-wear based on the acceleration data. Specifically, the standard deviation of the acceleration values in a given time window, along each axis, is used as a threshold to decide wear or not wear. Additionally, we can use the temperature sensor, when available, to augment the acceleration data. This is used in the CTA (combined temperature and acceleration) algorithm 4, and in the DETACH algorithm 5. Furthermore, ensemble classification of non-wear periods is possible by providing a list (of any length) of non-wear algorithm options.
  • Sleep Detection: Using the HDCZ6 and HSPT7 algorithms to analyze changes in arm angle we are able to find periods of sleep. We find the sleep onset-wakeup times for all sleep windows detected. By default, adaptive non-wear handling absorbs non-wear immediately preceding detected sleep into the sleep period and removes those samples from non-wear; this can be disabled with --no-adaptive-nonwear in the CLI or adaptive_nonwear=False in Python. Any remaining sleep periods shorter than 15 minutes (default value) are removed. Additionally, the SIB (sustained inactivity bouts) and the SPT (sleep period time) windows are provided as part of the output to aid in sleep metric post-processing.
  • Physical activity levels: Using the chosen physical activity metric (aggregated into time bins, 5 second default) we compute activity levels into the following categories: [inactive, light, moderate, vigorous]. The threshold values can be defined by the user, while the default values are chosen based on the specific activity metric and the values found in the literature 8-10.
  • Data output: The output results can be saved in .csv or .parquet data formats, with the run-time configuration parameters saved in a .json dictionary.

Installation

Install the wristpy package from PyPI via:

pip install wristpy

Quick start

wristpy provides three flexible interfaces: a command-line tool for direct execution, an importable Python library, and a Docker image for containerized deployment.

Using Wristpy through the command-line:

Run single files:

wristpy /input/file/path.gt3x -o /save/path/file_name.csv -c gradient

Run entire directories:

wristpy /path/to/files/input_dir -o /path/to/files/output_dir -c gradient -O .csv

For a full list of command line arguments:

wristpy --help

Using Wristpy through a python script or notebook:

Running single files:

from wristpy.core import orchestrator

# Define input file path and output location
# Support for saving as .csv and .parquet
input_path = "/path/to/your/file.gt3x"
output_path = "/path/to/save/file_name.csv"

# Run the orchestrator
results = orchestrator.run(
    input=input_path,
    output=output_path,
    calibrator="gradient",  # Choose between 'ggir', 'gradient', or 'none'
)

# Data available in results object
physical_activity_metric = results.physical_activity_metric
anglez = results.anglez
physical_activity_levels = results.physical_activity_levels
nonwear_array = results.nonwear_status
sleep_windows = results.sleep_status
sib_periods = results.sib_periods
spt_periods = results.spt_periods

Running entire directories:

from wristpy.core import orchestrator

# Define input file path and output location

input_path = "/path/to/files/input_dir"
output_path = "/path/to/files/output_dir"

# Run the orchestrator
# Specify the output file type, support for saving as .csv and .parquet
results_dict = orchestrator.run(
    input=input_path,
    output=output_path,
    calibrator="gradient",  # Choose between 'ggir', 'gradient', or 'none'
    output_filetype=".csv",
)


# Data available in dictionary of results.
subject1 = results_dict["subject1"]

physical_activity_metric = subject1.physical_activity_metric
anglez = subject1.anglez
physical_activity_levels = subject1.physical_activity_levels
nonwear_array = subject1.nonwear_status
sleep_windows = subject1.sleep_status
sib_periods = subject1.sib_periods
spt_periods = subject1.spt_periods

Using Wristpy Through Docker

  1. Install Docker: Ensure you have Docker installed on your system. Get Docker

  2. Pull the Docker image:

    docker pull cmidair/wristpy:main

  3. Run the Docker image with your data:

    docker run -it --rm \
      -v "/local/path/to/data:/data" \
      -v "/local/path/to/output:/output" \
      cmidair/wristpy:main


    Replace /local/path/to/data with the path to your input data directory and /local/path/to/output with where you want results saved.

    To run a single file, we simply need to modify the mounting structure for the docker call slightly:

    docker run -it --rm \
     -v "/local/path/to/data/file.bin:/data/file.bin" \
     -v "/local/path/to/output:/output" \
     cmidair/wristpy:main


Customizing the Pipeline:

The Docker image supports multiple input variables to customize processing. You can set these by simply chaining these inputs as you would for the CLI input:

docker run -it --rm \
  -v "/local/path/to/data/file.bin:/data/file.bin" \
  -v "/local/path/to/output:/output" \
  cmidair/wristpy:main /data --output /output --epoch-length 5 --nonwear-algorithm ggir --nonwear-algorithm detach --thresholds 0.1 0.2 0.4

For more details on available options, see the orchestrator documentation.

References

  1. Vähä-Ypyä H, Vasankari T, Husu P, Suni J, Sievänen H. A universal, accurate intensity-based classification of different physical activities using raw data of accelerometer. Clin Physiol Funct Imaging. 2015 Jan;35(1):64-70. doi: 10.1111/cpf.12127. Epub 2014 Jan 7. PMID: 24393233.
  2. A. Neishabouri et al., “Quantification of acceleration as activity counts in ActiGraph wearable,” Sci Rep, vol. 12, no. 1, Art. no. 1, Jul. 2022, doi: 10.1038/s41598-022-16003-x.
  3. John, D., Tang, Q., Albinali, F. and Intille, S., 2019. An Open-Source Monitor-Independent Movement Summary for Accelerometer Data Processing. Journal for the Measurement of Physical Behaviour, 2(4), pp.268-281.
  4. Zhou S, Hill RA, Morgan K, et al, Classification of accelerometer wear and non-wear events in seconds for monitoring free-living physical activityBMJ Open 2015; 5:e007447. doi: 10.1136/bmjopen-2014-007447.
  5. A. Vert et al., “Detecting accelerometer non-wear periods using change in acceleration combined with rate-of-change in temperature,” BMC Medical Research Methodology, vol. 22, no. 1, p. 147, May 2022, doi: 10.1186/s12874-022-01633-6.
  6. van Hees, V.T., Sabia, S., Jones, S.E. et al. Estimating sleep parameters using an accelerometer without sleep diary. Sci Rep 8, 12975 (2018). https://doi.org/10.1038/s41598-018-31266-z.
  7. van Hees, V. T., et al. A Novel, Open Access Method to Assess Sleep Duration Using a Wrist-Worn Accelerometer. PLoS One 10, e0142533 (2015). https://doi.org/10.1371/journal.pone.0142533.
  8. Hildebrand, M., et al. Age group comparability of raw accelerometer output from wrist- and hip-worn monitors. Medicine and Science in Sports and Exercise, 46(9), 1816-1824 (2014). https://doi.org/10.1249/mss.0000000000000289.
  9. Treuth MS, Schmitz K, Catellier DJ, McMurray RG, Murray DM, Almeida MJ, Going S, Norman JE, Pate R. Defining accelerometer thresholds for activity intensities in adolescent girls. Med Sci Sports Exerc. 2004 Jul;36(7):1259-66. PMID: 15235335; PMCID: PMC2423321.
  10. Aittasalo, M., Vähä-Ypyä, H., Vasankari, T. et al. Mean amplitude deviation calculated from raw acceleration data: a novel method for classifying the intensity of adolescents' physical activity irrespective of accelerometer brand. BMC Sports Sci Med Rehabil 7, 18 (2015). https://doi.org/10.1186/s13102-015-0010-0.
