xfetus 0.0.7

Python-based library for Synthesis of Ultrasound Fetal Imaging

xfetus - library for synthesis of ultrasound fetal imaging (:baby: :brain: :robot:) :warning: WIP :warning:

xfetus is a python-based library to syntheses fetal ultrasound images using GAN, transformers and diffusion models. It also includes methods to quantify the quality of synthesis (FID, PSNR, SSIM, and visual touring tests).

Installation

$ pip install xfetus

You can develop locally:

• Generate your SSH keys as suggested here (or here)
• Clone the repository by typing (or copying) the following line in a terminal at your selected path in your machine:

cd && mkdir -p $HOME/repositories/budai4medtech && cd  $HOME/repositories/budai4medtech
git clone [e-mail]:budai4medtech/xfetus.git

References

Presentation

Good practices in AI/ML for Ultrasound Fetal Brain Imaging Synthesis
Harvey Mannering, Sofia Miñano, and Miguel Xochicale

University College London
The deep learning and computer vision Journal Club
UCL Centre for Advance Research Computing
1st of June 2023, 15:00 GMT

Abstract Medical image datasets for AI and ML methods must be diverse to generalise well unseen data (i.e. diagnoses, diseases, pathologies, scanners, demographics, etc). However there are few public ultrasound fetal imaging datasets due to insufficient amounts of clinical data, patient privacy, rare occurrence of abnormalities, and limited experts for data collection and validation. To address such challenges in Ultrasound Medical Imaging, Miguel will discuss two proposed generative adversarial networks (GAN)-based models: diffusion-super-resolution-GAN and transformer-based-GAN, to synthesise images of fetal Ultrasound brain image planes from one public dataset. Similarly, Miguel will present and discuss AI and ML workflow aligned to good ML practices by FDA, and methods for quality image assessment (e.g., visual Turing test and FID scores). Finally, a simple prototype in GitHub, google-colabs and guidelines to train it using Myriad cluster will be presented as well as applications for Medical Image Synthesis e.g., classification, augmentation, segmentation, registration and other downstream tasks, etc. will be discussed. The resources to reproduce the work of this talk are available at https://github.com/budai4medtech/xfetus.

Citations

BibTeX to cite

@misc{iskandar2023realistic,
      author={
      	Michelle Iskandar and
      	Harvey Mannering and
      	Zhanxiang Sun and
      	Jacqueline Matthew and
      	Hamideh Kerdegari and
      	Laura Peralta and
      	Miguel Xochicale},
      title={Towards Realistic Ultrasound Fetal Brain Imaging Synthesis},
      year={2023},
      eprint={2304.03941},
      archivePrefix={arXiv},
      primaryClass={eess.IV}
}

Contributors

Thanks goes to all these people (emoji key):

ADD NAME SURNAME 🔬 🤔

Sofia Miñano 💻 🔬 🤔

Zhanxiang (Sean) Sun 💻 🔬 🤔

Harvey Mannering 💻 🔬 🤔

Michelle Iskandar 💻 🔬 🤔

Miguel Xochicale 💻 📖 🔧

This work follows the all-contributors specification.
Contributions of any kind welcome!
