xmris 0.7.0

A modern, N-dimensional, xarray-based toolbox for Magnetic Resonance Imaging and Spectroscopy.

MR data tends to arrive as a bare array plus a pile of numbers you have to keep in your head: which axis is time, how wide the sweep was, what zero means. xmris keeps all of that on the data itself. Your FID stays a plain xarray DataArray — axes named, time in seconds, metadata riding along — and the physics is one accessor away.

spectrum = fid.xmr.to_spectrum().xmr.autophase().xmr.to_ppm()

There is no custom class to learn. Every xarray habit you have keeps working, a whole grid of voxels goes through the same call as a single one, and the spectrum that comes out still knows its ppm axis.

Start with the documentation

→ andrewendlinger.github.io/xmris

That is where the package really lives. Every tutorial page is a live notebook: the plots and numbers you see come from the code right above them, re-run on every pull request. New here? Basics walks the FID → spectrum → ppm round trip from scratch; Concepts explains why xmris is fussy about names and metadata.

Quick start

The shortest path to something you can look at: simulate_fid hands you a signal that already carries the metadata the physics needs.

import xmris  # importing registers the .xmr accessor on every xarray object

fid = xmris.simulate_fid(
    amplitudes=[1.0, 0.4],
    chemical_shifts=[0.0, 5.2],  # ppm
    reference_frequency=120.66,  # MHz, the Larmor frequency of your nucleus
    n_points=1024,
)

spectrum = (
    fid
    .xmr.apodize_exp(lb=5.0)
    .xmr.zero_fill(target_points=2048)
    .xmr.to_spectrum()
    .xmr.autophase()
    .xmr.to_ppm()
)

print(spectrum.dims)                         # ('chemical_shift',)
print(round(spectrum.attrs["phase_p0"], 2))  # 2.17 — autophase wrote down what it applied

Got your own data? Then you build the DataArray yourself. Four steps, no magic:

import numpy as np
import xarray as xr
import xmris

# Step 1 — the time axis. Space it by your dwell time (here: a 4000 Hz sweep,
# so 1/4000 s per point). This axis alone sets the frequency axis later on —
# there is no separate sweep-width setting to keep in sync.
time = np.arange(1024) / 4000.0  # seconds

# Step 2 — your samples. Any complex array works; here, one fake peak
# 250 Hz off centre, decaying. Stack three copies to play three voxels.
signal = np.exp(2j * np.pi * 250.0 * time - time / 0.05)
data = np.stack([signal, 0.5 * signal, 0.25 * signal])  # (voxel, time)

# Step 3 — wrap it up. Name the dims, attach the time axis, and add the
# two facts only you can know:
fid = xr.DataArray(
    data,
    dims=["voxel", "time"],
    coords={"time": time},
    attrs={
        "reference_frequency": 120.66,  # MHz — your Larmor frequency
        "carrier_ppm": 0.0,             # which ppm sits at 0 Hz (1H water: 4.7)
    },
)

# Step 4 — done. The whole toolbox now works, all voxels at once:
spectrum = fid.xmr.to_spectrum()
print(spectrum.coords["frequency"].values[[0, -1]].tolist())  # [-2000.0, 1996.09375]

ppm = spectrum.xmr.to_ppm()
print(ppm.dims)  # ('voxel', 'chemical_shift')

The 4000 Hz you put into the time axis is the 4000 Hz you get back. Forget reference_frequency or carrier_ppm and to_ppm tells you, by name, before it does any maths — Hz and ppm takes it from here.

What is in the box

• Processing — zero filling, exponential and Lorentz-to-Gauss apodization, manual and automatic phasing, asymmetric-least-squares baseline correction, FID ↔ spectrum, Hz ↔ ppm.
• Vendor data — Bruker ParaVision arrays and their parameter dicts become a fully labelled FID, digital-filter group delay included: the one that puts a phase roll through everything if you forget it.
• Fitting — AMARES quantification via pyAMARES, returning a Dataset with your signal, the fit and the residual aligned.
• Plots and widgets — matplotlib helpers, plus sliders you can drag to phase, apodize, or scroll through a stack of spectra.

And what is not: xmris is a 0.x package, the MRS side is ahead of the imaging side, Bruker is the only vendor loader so far, and full MRSI grids — lazy, chunked, sitting on an anatomical image — are still to come. Core xmris will not do image reconstruction. The roadmap says what is shipped, what is moving, and what is still being argued about.

Install

pip install xmris             # or: uv add xmris
pip install "xmris[fitting]"  # adds AMARES quantification

Fitting is an extra because deep in its dependencies sits hlsvdpro, which ships no arm64 wheel; the pyamares-xmris repackage on PyPI adds the marker that skips it on Apple Silicon, so the install works there too. All else is in the bare install. Python 3.10 – 3.13.

Contributing

Issues and pull requests are welcome. uv sync --all-extras --dev then uv run test gets you a working checkout; the setup steps, the architecture contract and one page per kind of change are in the contributor guide.

Changelog

Upgrading? The changelog records what changed in each release. There is no CHANGELOG.md here — it is a rendered page, so every entry can link the issue, the pull request, and the docs behind it.

License

xmris is BSD 3-Clause — see LICENSE. Use it, build on it, ship it, paid work or not; just keep the notice.
